1995-96 JAGUAR XJR, XJ6 & XJ12

Jaguar XJ12 1995 - BUZZERS, RELAYS & TIMERS

Jaguar XJ12 1995 BUZZERS, RELAYS & TIMERS

Component	Component Location
Accessory Relay	On right rear side of luggage compartment. See Fig. 2 .
A/C Clutch Relay	Behind right headlamp. See Fig. 2 .
A/C Isolate Relay	On right rear side of luggage compartment. See Fig. 2 .
Auxiliary Positive Relay	On trunk fuse box. See Fig. 2 .
Blower Relay (Left)	On right side of heelboard. See Fig. 2 .
Blower Relay (Right)	On right side of heelboard. See Fig. 2 .
Cigar Lighter Relay	On right side of heelboard. See Fig. 2 .
Dip Relay (Left) (1996)	Behind left headlamp. See Fig. 2 .
Dip Relay (Right) (1996)	Behind right headlamp. See Fig. 2 .
Deadlock Relay (Left Front & Right Rear)	On left side of heelboard. See Fig. 2 .
Deadlock Relay (Right Front & Left Rear)	On left side of heelboard. See Fig. 2 .
Door Lock Relay	On left side of heelboard. See Fig. 2 .
Door Mirror Heaters Relay	On right side of heelboard. See Fig. 2 .
Door Unlock Relay	On left side of heelboard. See Fig. 2 .
Driver Door Unlock Relay	On left side of heelboard. See Fig. 2 .
ECM Controlled Relay (XJR & XJ6)	Behind right headlamp. See Fig. 2 .
Front Fog Lamp Relay (1996)	Behind left headlamp. See Fig. 2 .
Fuel Filler Flap Relay	On left side of heelboard. See Fig. 2 .
Fuel Injector Relay (XJ12)	Behind right headlamp. See Fig. 2 .
Fuel Pump Relay 1	On right rear side of luggage compartment. See Fig. 2 .
Fuel Pump Relay 2 (XJR & XJ12)	In luggage compartment behind battery. See Fig. 2 .
Gearshift Interlock Relay	In center console, in front right corner of shift lever assembly. See Fig. 2 .
Headlamp Power Wash Pump Relay	In front of right engine bay fuse box. See Fig. 2 .
Heated Backlamp Relay	On right rear side of luggage compartment. See Fig. 2 .
Heater Pump Relay	Behind left headlamp. See Fig. 2 .
High Mounted Stop Lamp Relay	On right rear side of luggage compartment. See Fig. 2 .
High Speed Relay (Left)	On right side of heelboard. See Fig. 2 .
High Speed Relay (Right)	On right side of heelboard. See Fig. 2 .
Horn Relay	On left engine bay fuse box. See Fig. 2 .
Ignition Coil Relay (XJ12)	In front of right engine bay fuse block. See Fig. 2 .
Ignition Positive Relay	On right engine bay fuse box. See Fig. 2 .
Ignition Positive Relay	On left heelboard fuse box. See Fig. 2 .
Ignition Positive Relay	On right heelboard fuse box. See Fig. 2 .
Keylock Relay	In center console, in front right corner of shift lever assembly. See Fig. 2 .
Lumbar Deflate Relay (Left Rear Seat)	On right side of heelboard. See Fig. 2 .
Main Beam Relay (1996)	Behind right headlamp. See Fig. 2 .
Puddle Lamp Relay	On left side of heelboard. See Fig. 2 .
Seat Heater Timer (Left Rear) (1996)	On left side of heelboard. See Fig. 2 .
Seat Heater Timer (Right Rear) (1996)	On right side of heelboard. See Fig. 2 .
Seat Heater Relay (Driver) (1996)	Under driver's seat. See Fig. 2 .
Seat Heater Relay (Passenger) (1996)	Under front passenger's seat. See Fig. 2 .
Seat Lower Relay (Driver)	Under driver's seat. See Fig. 2 .
Seat Lower Relay (Passenger)	Under front passenger's seat. See Fig. 2 .
Seat Raise Relay (Driver)	Under driver's seat. See Fig. 2 .
Seat Raise Relay (Passenger)	Under front passenger' seat. See Fig. 2 .
Secondary Air Injection Relay	Behind right headlamp. See Fig. 2 .
Starter Relay	Behind left headlamp. See Fig. 2 .
Trunk Release Relay	On right rear side of luggage compartment. See Fig. 2 .
Wiper FAST/SLOW Relay	Behind left headlamp. See Fig. 2 .
Wiper ON/OFF Relay	Behind left headlamp. See Fig. 2 .
Windshield Heater Relay (Left)	Beside left "A" post. See Fig. 2 .
Windshield Heater Relay (Right)	Beside left "A" post. See Fig. 2 .
Windshield Wash Pump Relay	In front of right engine bay fuse box. See Fig. 2 .

Jaguar XJ12 1995 - CIRCUIT PROTECTION DEVICES

Jaguar XJ12 1995 CIRCUIT PROTECTION DEVICES

Component	Component Location
Engine Bay Fuse Box (Left)	In engine compartment, on left front inner wheelwell. See Fig. 2 .
Engine Bay Fuse Box (Right)	In engine compartment, on right front inner wheelwell. See Fig. 2 .
Heelboard Fuse Box (Left)	On left side of heelboard. See Fig. 2 .
Heelboard Fuse Box (Right)	On right side of heelboard. See Fig. 2 .
Power Fuse (250A)	Under front right side of right rear seat. See Fig. 2 .
Power Fuse (500A)	On rear of battery. See Fig. 2 .
Trunk Fuse Box	On right rear side of luggage compartment. See Fig. 2 .

Jaguar XJ12 1995 - CONTROL UNITS

Jaguar XJ12 1995 CONTROL UNITS

Component	Component Location
ABS/Traction Control Module	On right rear side of engine compartment. See Fig. 1 .
A/C Control Module	On right side of A/C unit, behind right side of dash. See Fig. 1 .
Air Bag Diagnostic Monitor	Behind right side of dash. See Fig. 1 .
Body Processor Module	Behind glove box. See Fig. 1 .
Column/Mirror Movement Control Module	Behind left side of dash. See Fig. 1 .
Decoder Module	In center console, beside shift lever assembly. See Fig. 1 .
Dimmer Module	Behind steering column cover.
Engine Control Module	Behind right side footwell trim panel. See Fig. 1 .
Fan Control Relay Module	Below left headlamp. See Fig. 1 .
Ignition Modules (2) (XJ12)	In engine compartment, on right inner fender.
Lamp Control Module (1996)	On right rear side of luggage compartment. See Fig. 1 .
Lighting Control Module (Left Front) (1995)	Behind left headlamp. See Fig. 1 .
Lighting Control Module (Rear) (1995)	On right rear side of luggage compartment. See Fig. 1 .
Lighting Control Module (Right Front) (1995)	Behind right headlamp. See Fig. 1 .
Seat Control Module (Driver)	Under driver's seat. See Fig. 1 .
Seat Control Module (Passenger)	Under passenger's seat. See Fig. 1 .
Seat Control Module (Rear) (1996)	Behind center of rear seats. See Fig. 1 .
Security & Locking Control Module	On left front of luggage compartment. See Fig. 1 .
Sliding Roof Control Module	Behind roof console. See Fig. 1 .
Speed Control, Control Module	Behind left side of dash. See Fig. 1 .
Suppression Module	On left front of engine compartment.
Transmission Control Module	Behind right side of dash. See Fig. 1 .
Variable Steering Control Module	Behind left kick panel. See Fig. 1 .

Jaguar XJ12 1995 - MOTORS

Jaguar XJ12 1995 MOTORS

Component	Component Location
Aspirator Motor	Under left side of dash.
Blower Motors	Behind right & left side of dash.
Fuel Filler Flap Actuator	On left front side of luggage compartment.
Heater Pump	On right rear side of engine compartment.
Power Wash Pump	On right side of engine compartment, on inner fender.
Seat Lumbar Pumps	Inside seats.
Secondary Air Injection Pump	On left front of engine.
Sliding Roof Motor	Inside roof console.
Supercharger Intercooler Coolant Pump (XJR)	On left front of engine compartment.
Traction Control Actuator	On left rear side of engine compartment.
Trunk Release Actuator	In luggage compartment, near latch assembly.
Variable Force Motor	Inside transmission.
Vacuum Pump & Control Valve	On left front side of engine compartment.
Windshield Wash Motor	In washer fluid reservoir.
Wiper Motor	On left side of firewall.

Jaguar XJ12 1995 - SENDING UNITS & SENSORS

Jaguar XJ12 1995 SENDING UNITS & SENSORS

Component	Component Location
Ambient Temperature Sensor	On left front wheelwell arch liner.
Camshaft Position Sensor (XJR & XJ6)	Right side of engine.
Camshaft Position Sensor (XJ12)	On "A" bank camshaft cover.
Compressor Lock Sensor (XJ12)	On A/C compressor.
Coolant Sensor (Display)	On thermostat housing.
Crankshaft Position Sensor	On engine timing cover.
EGR Temperature Sensor (XJR & XJ6)	Below throttle body assembly.
Evaporator Temp. Sensor	Under left side of dash, on left side of A/C unit.
Engine Coolant Temperature Sensor (XJR & XJ6)	On thermostat housing.
Engine Coolant Temperature Sensor (XJ12)	On "B" bank thermostat housing.
Engine Speed Sensor (XJ12)	On rear side of engine.
Fluid Temperature Sensor	In transmission.
Fuel Tank Pressure Sensor	On fuel tank evaporative flange.
Heated Oxygen Sensors (4)	In exhaust system, before & after catalytic converter.
Heater Matrix Temp. Sensor	Under left side of dash, on left side of A/C unit.
Impact Sensors (2)	In engine compartment, behind left & right headlamps.
In-Car Temp. Sensor	On left side of dash.
Input Speed Sensor (XJR & XJ12)	On left side of transmission.
Intake Air Temperature Sensor (XJR & XJ6)	On engine air intake elbow.
Intake Air Temperature Sensor (XJ12)	On "A" bank of engine air intake.
Knock Sensors (2) (XJR & XJ6)	On left front & left rear of engine block.
Manifold Absolute Pressure Sensors (2) (XJ12)	On rear of "A" & "B" bank intake manifolds.
Mass Air Flow Sensor (XJR & XJ6)	On fresh air inlet, behind air filter.
Output Shaft Sensor	On transmission.
Safing Sensor	Behind right kick panel.
Security System Inclination Sensor	On left front of luggage compartment.
Intrusion Sensors	Under headliner, near each door post.
Solar Sensor	In top (center) panel of dash.
Throttle Position Sensor (XJR & XJ6)	On throttle body assembly.
Throttle Position Sensor (XJ12)	On throttle body turntable.
Wheel Speed Sensors	On each wheel hub.

Jaguar XJ12 1995 - SOLENOID & SOLENOID VALVES

Jaguar XJ12 1995 SOLENOID & SOLENOID VALVES

Component	Component Location
Canister Close Valve (XJ6, 1996)	In right rear of engine compartment, under floor panel.
Dump Valve	In engine compartment, behind left headlamp.
EGR Valve	On intake manifold.
Evaporative Emission Control Valve (XJR & XJ6)	Behind left headlamp, below relays.
Evaporative Emission Control Valves (2) (XJ12)	Behind left & right headlamps, below relays.
Gear Shift Interlock Solenoid	In center console, at base of shift lever assembly.
Heater Valve	On right rear side of engine compartment.
Idle Air Control Valve (XJR & XJ6)	On throttle body.
Idle Air Control Valve (2) (XJ12)	On "A" & "B" bank throttle bodies.
Keylock Solenoid	On steering column.
Secondary Air Injection Switching Valve (XJ12)	On rear of "A" bank intake manifold.

Jaguar XJ12 1995 - SWITCHES

Jaguar XJ12 1995 SWITCHES

Component	Component Location
Ambient Temp. Switch	On left front wheelwell arch liner.
Brake Fluid Level Switch	In brake fluid reservoir.
Brake Switch	On brake pedal bracket.
Coolant Level Switch	In coolant reservoir.
Kickdown Switch (A/T)	Under accelerator pedal.
Inertia Switch	Behind right kick panel.
Not In-Park Microswitch	In center console, at base of shift lever.
Oil Pressure Switch	On left side of engine block.
Parking Brake Switch	On base of parking brake lever.
Power Steering Pressure Switch (XJ12)	On power steering pump.
Pressure Switch Manifold (XJR & XJ12)	In transmission.
Radiator Thermostatic Switch	On lower left side of radiator.
Refrigerant Pressure Switches	On right rear side of engine compartment.
Reverse Switch (M/T)	Below center console, in transmission tunnel
Seat Belt Switch	At base of driver's seat belt buckle.
Speed Control Brake Switch	On brake pedal bracket.
Washer Fluid Level Switch	In washer fluid reservoir.

Jaguar XJ12 1995 - MISCELLANEOUS

Jaguar XJ12 1995 MISCELLANEOUS

Component	Component Location
Data Link Connector	Beside right kick panel.
Power Amplifier	On center front of luggage compartment. See Fig. 1 .
Security Antenna	On backlamp.
Security Sounder	On right front side of engine compartment.
Telephone Transceiver	On center front of luggage compartment. See Fig. 1 .
Transit Isolation Device	On positive battery terminal.
Variable Steering Converter	On steering rack.

Jaguar XJ12 1995 - CONNECTORS

Jaguar XJ12 1995 CONNECTORS

Component	Component Location
AB7 (Black, 3 Pin)	Behind column switch-gear.
AB11 (Natural, 4 Pin)	At right "A" pillar.
AB12 (Natural, 4 Pin)	At left "A" pillar.
BL1 (Black, 13 Pin)	At left front wheelwell.
BR1 (Black, 13 Pin)	At right front wheelwell.
BS3 (Yellow, 8 Pin)	Under left rear seat.
BS4 (White, 20 Pin)	Under rear seat console.
BS5 (Yellow, 8 Pin)	Under right rear seat.
BS10 (Yellow, 3 Pin)	Under left rear seat.
BS11 (Yellow, 3 Pin)	Under right rear seat.
BT4 (Black, 48 Pin)	Above fuel tank.
BT50 (White, 18 Pin)	Near trunk fuse box.
CA8 (Green, 20 Pin)	At left "A" pillar.
CA9 (Black, 20 Pin)	At left "A" pillar.
CA10 (White, 8 Pin)	At left "A" pillar.
CA11 (White, 20 Pin)	Passenger's underscuttle.
CA12 (White, 14 Pin)	Passenger's underscuttle.
CA13 (White, 6 Pin)	At left "B" pillar.
CA14 (White, 4 Pin)	At left "B" pillar.
CA15 (White, 6 Pin)	At right "B" pillar.
CA16 (White, 4 Pin)	At right "B" pillar.
CA18 (Yellow, 20 Pin)	Under center console glove box.
CA23 (Black, 20 Pin)	Under driver's seat.
CA23-D (Black, 20 Pin)	Under driver's seat.
CA24 (White, 6 Pin)	Under center console glove box.
CA24-D (White, 6 Pin)	Under driver's seat.
CA25 (Yellow, 3 Pin)	At right "A" pillar.
CA27 (White, 6 Pin)	Under front passenger's seat.
CA28 (Black, 20 Pin)	Under driver's seat.
CA77 (Yellow, 2 Pin)	At left "A" pillar.
CA78 (White, 4 Pin)	At right "A" pillar.
CA79 (White, 4 Pin)	At left "B" pillar.
CA80 (White, 4 Pin)	At right "B" pillar.
CA83 (Black, 8 Pin)	At roof console.
CA109 (White, 12 Pin)	Under right rear seat.
CC3 (Gray, 20 Pin)	Under center console glove box.
CC4 (White, 14 Pin)	Under center console glove box.
CC5 (White, 20 Pin)	Under center console glove box.
CC18 (Yellow, 20 Pin)	Under center console glove box.
CC38 (Yellow, 2 Pin)	Passenger's underscuttle.
CC53 (Black, 2 Pin)	Passenger's underscuttle.
CV1 (White, 6 Pin)	At left rear wheelwell.
CV3 (Black, 4 Pin)	Above fuel tank.
DD16 (Black, 6 Pin)	At driver's door sill.
FC4 (Blue, 20 Pin)	Driver's underscuttle.
FC5 (Black, 48 Pin)	At left end of dash.
FC6 (Black, 48 Pin)	At right end of dash.
FC7 (Black, 48 Pin)	Passenger's underscuttle.
FC8 (Black, 12 Pin)	Driver's underscuttle.
FC16 (Black, 20 Pin)	Passenger's underscuttle.
FC57 (Black, 12 Pin)	Passenger's underscuttle.
FU1 (White, 6 Pin)	At fuel tank trim/battery cover.
GB10 (Black, 12 Pin)	At left side of center console "J" gate.
GB15 (White, 8 Pin)	At left side of center console "J" gate.
IC2 (White, 8 Pin)	Above fuel tank.
IC7 (White, 8 Pin)	Passenger's underscuttle.
IC22 (White, 18 Pin)	Under right rear seat.
IC23 (Black, 4 Pin)	At left rear seat heelboard.
LL2 (Black, 3 Pin)	At left front wheelwell.
LS3 (Black, 48 Pin)	At left "A" pillar.
LS11 (Black, 4 Pin)	At left side spoiler.
ML1-D (White, 10 Pin)	Under driver's seat.
ML1-P (White, 10 Pin)	Under passenger's seat.
PI1 (White, 13 Pin)	Behind right headlight.
PI59 (Black, 13 Pin)	At left side of engine compartment, forward of fuse box.
PI61 (Black, 13 Pin)	Behind right headlight.
PI63 (Black, 20 Pin)	At right "A" pillar.
PI66 (Black, 2 Pin)	At left side of engine compartment, forward of fuse box.
PI73 (Yellow, 2 Pin)	At right "A" pillar.
PI74 (Yellow, 8 Pin)	At right "A" pillar.
PI142 (Black, 2 Pin)	At center of firewall.
PI161 (White, 6 Pin)	At right "A" pillar.
RF4 (Black, 12 Pin)	At roof console.
RS3 (Brown, 48 Pin)	At right "A" pillar.
RT61 (Black, 12 Pin)	Under rear parcel shelf.
SH1 (Gray, 2 Pin)	At left "A" pillar.
SH8 (White, 4 Pin)	At left "A" pillar.
TL5 (Green, 2 Pin)	Near right taillight assembly.
TL6 (Green, 2 Pin)	Near left taillight assembly.

Jaguar XJ12 1995 - GROUNDS

Jaguar XJ12 1995 GROUNDS

Component	Component Location
BTG17	At right side of trunk. See Fig. 1 .
BTG18	At right rear corner of trunk. See Fig. 1 .
BTG48	At right rear corner of trunk. See Fig. 1 .
BTG49	At right rear corner of trunk. See Fig. 1 .
CAG30	At left "A" pillar. See Fig. 1 .
CAG31	Under left side of parcel shelf. See Fig. 1 .
CAG33	Under front of right rear seat. See Fig. 1 .
CAG91	Under left side of parcel shelf. See Fig. 1 .
CAG92	Under front of right rear seat. See Fig. 1 .
CAG93	Under front of left rear seat. See Fig. 1 .
CAG96	Under front of left rear seat. See Fig. 1 .
CAG100	At right "A" pillar. See Fig. 1 .
CAG103	Under driver's seat. See Fig. 1 .
CAG104	Under front passenger's seat. See Fig. 1 .
CAG110	Under front passenger's seat. See Fig. 1 .
CAG116	Under front passenger's seat. See Fig. 1 .
CCG8	Under center console. See Fig. 1 .
CCG43	At right side of dash. See Fig. 1 .
CCG49	At right side of dash. See Fig. 1 .
CCG50	Under center console. See Fig. 1 .
CCG51	Under center console. See Fig. 1 .
CEG2	Under front of center console. See Fig. 1 .
CLG2	At left side of dash. See Fig. 1 .
FCG15	At left side of dash. See Fig. 1 .
FCG26	At left side of dash. See Fig. 1 .
FUG8	At right front of trunk. See Fig. 1 .
ICG16	At right front of trunk. See Fig. 1 .
ICG24	Under front of center console. See Fig. 1 .
LSG19	At front of left front fender. See Fig. 1 .
LSG51	At front of left front fender. See Fig. 1 .
MLG2	Under driver's seat. See Fig. 1 .
MLG2	Under passenger's seat. See Fig. 1 .
PIG75	At right "A" pillar. See Fig. 1 .
PIG76	At right side of firewall. See Fig. 1 .
PIG77	At front of right front fender. See Fig. 1 .
PIG153	At right side of firewall. See Fig. 1 .
PIG159	At front of right front fender. See Fig. 1 .
PLG3	Under front passenger's seat. See Fig. 1 .
RSG41	Behind right headlight. See Fig. 1 .
RSG42	At right side of firewall. See Fig. 1 .
RSG8	Behind right headlight. See Fig. 1 .
SHG6	At front of left front fender. See Fig. 1 .
