1998 CHRYSLER Sebring Convertible

Chrysler Sebring JX 1998 - BUZZERS, RELAYS & TIMERS

Chrysler Sebring JX 1998 BUZZERS, RELAYS & TIMERS

Component	Component Location
A/C Compressor Clutch Relay	In power distribution center.
Automatic Shut Down Relay	In power distribution center.
Combination Flasher	Part of multi-function switch.
Deck Lid Release Relay	In power distribution center.
Engine Starter Motor Relay	In power distribution center.
Fuel Pump Relay	In power distribution center.
Headlamp Delay Relay	On junction block.
High Speed Radiator Fan Relay	In power distribution center.
Horn Relay	On junction block.
Illuminated Entry Relay	Behind dash, right of steering column.
Intermittent Wiper Relay	In power distribution center.
Low Speed Radiator Fan Relay	In power distribution center.
Power Top Up/Down Relays	Front center of trunk area.
Rear Window Defogger Relay	On junction block.
Transmission Control Relay	In power distribution center.
Window Motor Relay (Right/Left)	In left door.
Wiper High/Low Relay	In power distribution center.

Chrysler Sebring JX 1998 - CIRCUIT PROTECTION DEVICES

Chrysler Sebring JX 1998 CIRCUIT PROTECTION DEVICES

Component	Component Location
ABS Relay Box	On ABS hydraulic modulator. See Fig. 1 .
Dedicated Fuses	In power distribution center.
Junction Block	Under left side of dash.
Multi-Purpose Fuses	On junction block, under left side of dash.
Power Distribution Center	On left front inner fender. See Fig. 2 .

Chrysler Sebring JX 1998 - CONTROL UNITS

Chrysler Sebring JX 1998 CONTROL UNITS

Component	Component Location
Air Bag Control Module	Under floor console, near transmission selector.
Body Control Module	On junction block, under left side of dash.
Combined Rear Lighting Module	At left rear quarter panel.
Controller Anti-Lock Brake	On right front inner fender.
Daytime Running Lamp Module	On junction block, under left side of dash.
Fuel Pump Module	In fuel tank.
Powertrain Control Module	Between air cleaner housing & power distribution center. See Fig. 2 .
Seat Belt Control Module	Rear of console.
Speed Proportional Steering Module	On left side of steering gear. See Fig. 2 .
Transmission Control Module	On left front inner fender. See Fig. 2 .
Window Timer Module	In left door.

Chrysler Sebring JX 1998 - MOTORS

Chrysler Sebring JX 1998 MOTORS

Component	Component Location
ABS Hydraulic Modulator	On right side of cowl panel. See Fig. 1 .
Idle Air Control Motor (2.4L)	On throttle body. See Fig. 3 .
Idle Air Control Motor (2.5L)	On throttle body. See Fig. 4 .
Mode Door Actuator	On left side of A/C-heater housing.
Power Top Pump Motor	In front of trunk.
Radiator Fan Motor	On rear of radiator.
Vapor Canister Leak Detection Pump	Under right front headlight, behind front fascia.
Windshield Washer Pump Motor	At bottom of washer fluid reservoir. See Fig. 1 .
Windshield Wiper Motor	Left side of cowl panel. See Fig. 2 .

Chrysler Sebring JX 1998 - SENDING UNITS & SENSORS

Chrysler Sebring JX 1998 SENDING UNITS & SENSORS

Component	Component Location
A/C Evaporator Temperature Sensor	On right side of HVAC housing.
Battery Temperature Sensor	On rear side of front bumper beam. See Fig. 2 .
Camshaft Position Sensor (2.4L)	At rear of cylinder head. See Fig. 3 .
Camshaft Position Sensor (2.5L)	In distributor.
Crankshaft Position (CKP) Sensor (2.4L)	On engine block, above oil filter.
Crankshaft Position (CKP) Sensor (2.5L)	On rear of transmission housing, above differential housing.
Engine Coolant Temperature Sensor (2.4L)	On top left front of engine. See Fig. 3 .
Engine Coolant Temperature Sensor (2.5L)	Near thermostat housing. See Fig. 4 .
Heated Oxygen Sensor (HO2S) (Downstream)	On rear of catalytic converter.
Heated Oxygen Sensor (HO2S) (Upstream)	On exhaust manifold.
Intake Air Temperature Sensor (2.4L)	On intake manifold plenum. See Fig. 3 .
Intake Air Temperature Sensor (2.5L)	On intake manifold plenum. See Fig. 5 .
Manifold Absolute Pressure (MAP) Sensor (2.4L)	On intake manifold plenum. See Fig. 3 .
Manifold Absolute Pressure (MAP) Sensor (2.5L)	On intake manifold plenum. See Fig. 5 .
Output Shaft Speed Sensor	On left side of transmission case. See Fig. 6 .
Throttle Position Sensor (2.4L)	On throttle body. See Fig. 3 .
Throttle Position Sensor (2.5L)	On throttle body. See Fig. 4 .
Turbine Speed Sensor	On left side of torque converter housing. See Fig. 6 .
Wheel Speed Sensor (Left Front)	On left front steering knuckle boss.
Wheel Speed Sensor (Right Front)	On right front steering knuckle boss. See Fig. 1 .
Wheel Speed Sensor (Rear) (2)	On respective rear brake support plate.

Chrysler Sebring JX 1998 - SOLENOIDS & SOLENOID VALVES

Chrysler Sebring JX 1998 SOLENOIDS & SOLENOID VALVES

Component	Component Location
Deck Lid Solenoid	On deck lid latch.
Duty Cycle EVAP/Purge Solenoid	On left strut tower. See Fig. 2 .
Electronic EGR Transducer Solenoid (2.4L)	At right rear of cylinder head. See Fig. 3 .
Electronic EGR Transducer Solenoid (2.5L)	On left exhaust manifold, near rear of engine. See Fig. 4 .
Transmission Solenoids & Pressure Switch Assembly	On top left front of transmission. See Fig. 6 .
Vehicle Speed Control Servo	On left strut tower. See Fig. 2 .

Chrysler Sebring JX 1998 - SWITCHES

Chrysler Sebring JX 1998 SWITCHES

Component	Component Location
A/C Pressure Transducer (2.4L)	Near compressor, attached to valve on discharge line.
A/C Pressure Transducer (2.5L)	Near compressor, attached to valve on discharge line. See Fig. 4 .
Back-Up Lamp Switch	Rear of transmission.
Brake Warning Pressure Switch	On master cylinder.
Clutch Pedal Position Switch	On clutch pedal mounting bracket.
Oil Pressure Switch (2.4L)	Right side of engine block, below exhaust manifold.
Oil Pressure Switch (2.5L)	On side of engine block, near oil filter.
Power Steering Pressure Switch	Mounted to power steering gear. See Fig. 2 .
Seat Belt Switch	In seat belt buckle.
Stop Lamp Switch	Top of brake pedal.
Transmission Range Switch (A/T)	Front of transmission.
Washer Fluid Level Switch	In washer fluid reservoir.

Chrysler Sebring JX 1998 - MISCELLANEOUS

Chrysler Sebring JX 1998 MISCELLANEOUS

Component	Component Location
Blower Motor Resistor Block	On lower right side of heater housing.
Data Link Connector (DLC)	Left of steering column, bottom of dash.
Distributor (2.5L)	On right rear of engine, near air intake. See Fig. 4 .
Ignition Coil Pack (2.4L)	On top of valve cover. See Fig. 3 .
Ignition Coil Pack (2.5L)	In distributor.
Power Amplifier	Under right front seat.

Chrysler Sebring JX 1998 - CONNECTORS

Chrysler Sebring JX 1998 CONNECTORS LOCATION

Component	Location
C104 (Light Gray, 10 Pin)	Under power distribution center. See Fig. 2 .
C105 (Black, 10 Pin)	Under power distribution center. See Fig. 2 .
C111 (Black, 10 Pin)	At rear of powertrain control module.
C113 (Light Gray, 10 Pin)	At rear of powertrain control module.
C121 (Black, 16 Pin)	Behind left kick panel.
C126 (Black, 16 Pin)	Behind left side of dash, near junction block.
C165 (Black, 4 Pin) (2.5L)	On left side of intake manifold.
C224 (Gray, 16 Pin)	At left side of steering column.
C300 (Black, 6 Pin)	Near trunk light.
C301 (Black, 6 Pin)	Behind right quarter panel.
C305 (Red, 3 Pin)	Near trunk latch.
C309 (Gray, 2 Pin)	Under driver seat.
C310 (Brown, 16 Pin)	At left "A" pillar.
C311 (Blue, 12 Pin)	At left "A" pillar.
C315 (Brown, 16 Pin)	At right "A" pillar.
C316 (Blue, 12 Pin)	At right "A" pillar.
C332 (Black, 6 Pin)	Behind left kick panel.
C340 (Black, 4 Pin)	Under driver seat.
C341 (Green/Black, 2 Pin)	Under passenger seat.
C342 (Black, 10 Pin)	At front of floor console.

Chrysler Sebring JX 1998 - GROUNDS

Chrysler Sebring JX 1998 GROUNDS LOCATION

Component	Location
G100	At left strut tower. See Fig. 2 .
G101	At rear of transaxle. See Fig. 6 .
G102	At left strut tower. See Fig. 2 .
G103	At right strut tower.
G200	Behind center of dash.
G201	At base of gearshift.
G300	At left side of trunk opening.
G301	Behind left kick panel.
G302	At center of deck lid.
G303	Behind right rear quarter panel.
G304	At base of gearshift.

Chrysler Sebring JX 1998 - SPLICES

Chrysler Sebring JX 1998 SPLICES LOCATION

Component	Location
S100	At breakout for transmission control module. See Fig. 2 .
S101	At left strut tower. See Fig. 2 .
S102	Inside power distribution center. See Fig. 2 .
S103	Inside power distribution center. See Fig. 2 .
S104	Inside power distribution center. See Fig. 2 .
S105	Inside power distribution center. See Fig. 2 .
S106	Inside power distribution center. See Fig. 2 .
S107	Inside power distribution center. See Fig. 2 .
S108	Near breakout for powertrain control module. See Fig. 2 .
S109	At left strut tower. See Fig. 2 .
S110	Inside power distribution center. See Fig. 2 .
S111	At right strut tower. See Fig. 1 .
S112	Behind right side of dash. See Fig. 1 .
S113 (2.4L)	Near breakout for MAP/IAT sensor.
S113 (2.5L)	At breakout for generator. See Fig. 4 .
S114 (2.4L)	At injector breakout. See Fig. 3 .
S114 (2.5L)	Between injector No. 2 & No. 4.
S115 (2.4L)	Near breakout for MAP/IAT sensor. See Fig. 3 .
S115 (2.5L)	Near breakout for EGR solenoid. See Fig. 4 .
S116 (2.4L)	Near breakout for MAP/IAT sensor.
S116 (2.5L)	Near breakout for injector No. 6. See Fig. 4 .
S117 (2.4L)	Near breakout for camshaft position sensor. See Fig. 3 .
S117 (2.5L)	Near breakout for IAC motor. See Fig. 4 .
S118 (2.4L)	Near breakout for engine starter motor. See Fig. 3 .
S118 (2.5L)	Near breakout for ECT sensor. See Fig. 4 .
S120 (2.4L)	Near breakout for powertrain control module.
S120 (2.5L)	Near breakout for powertrain control module. See Fig. 4 .
S121 (2.5L)	At breakout for powertrain control module.
S122	At breakout for powertrain control module.
S123 (2.4L)	In fuel rail harness.
S123 (2.5L)	In fuel rail harness. See Fig. 4 .
S124 (2.4L)	Near breakout for noise suppressor.
S124 (2.5L)	Near breakout for distributor. See Fig. 4 .
S125	Near breakout for turbine speed sensor. See Fig. 6 .
S126	Near breakout for EGR solenoid.
S127	Near breakout for power distribution center. See Fig. 2 .
S129	Near breakout for stoplight switch.
S130	Near breakout for powertrain control module.
S131 (2.4L)	At breakout for powertrain control module.
S132 (2.4L)	At breakout for powertrain control module.
S133 (2.4L)	At breakout for ignition coil. See Fig. 3 .
S200	At breakout for cigar lighter.
S201	Behind center of dash.
S202	Behind center of dash.
S203	Near breakout for mode door actuator.
S301	Near breakout for combined rear lighting module.
S302	Near breakout for map/reading light.
S303	Near breakout for left visor light.
S304	Near breakout for rear window defogger.
S305	At breakout for body control module.
S306	At breakout for body control module.
S307	At breakout for body control module.
S308	Near breakout for courtesy light relay.
S310	Near breakout for courtesy light relay.
S311	Near breakout for courtesy light relay.
S312	At left kick panel.
S400	Near breakout for left door speaker.
S401	Near breakout for right door speaker.
S402	Near left door connector.
S403	Near right door connector.
S404	Near breakout for backup light.
S405	Near grommet.
S406	At left taillight.
S407	At right taillight.
S408	At left taillight.
S409	At right taillight.
