2005-06 JAGUAR X-Type

Jaguar X-Type 2005 - BUZZERS, RELAYS & TIMERS

Jaguar X-Type 2005 BUZZERS, RELAYS & TIMERS LOCATION

Component	Location
Accessory Relay	In passenger junction fuse box. See Fig. 2 .
A/C Compressor Clutch Relay	In power distribution fuse box. See Fig. 1 .
Battery Saver Relay	In passenger junction fuse box. See Fig. 2 .
Blower Motor Relay	In passenger junction fuse box. See Fig. 2 .
Dip Beam Relay	In power distribution fuse box. See Fig. 1 .
EMS Control Relay	In power distribution fuse box. See Fig. 1 .
Heated Rear Window Relay	In passenger junction fuse box. See Fig. 2 .
Horn Relay	In power distribution fuse box. See Fig. 1 .
Main Beam/Front Fog Relay	In power distribution fuse box. See Fig. 1 .
Passenger Junction Fuse Box Ignition Relay	In passenger junction fuse box. See Fig. 2 .
Power Distribution Fuse Box Ignition Relay	In power distribution fuse box. See Fig. 1 .
Powerwash Pump Relay	In power distribution fuse box. See Fig. 1 .
Rear Wiper Motor Relay (Wagon)	In passenger junction fuse box. See Fig. 2 .
Reverse Lamps Relay	In passenger junction fuse box. See Fig. 2 .
Slave Ignition Relay	In power distribution fuse box. See Fig. 1 .
Starter Relay	In power distribution fuse box. See Fig. 1 .
Throttle Motor Relay	In passenger junction fuse box. See Fig. 2 .
Transit Isolation Relay	In engine compartment, near battery.
Windshield Heater Relay	In power distribution fuse box. See Fig. 1 .
Windshield Wiper Motor Relay	In power distribution fuse box. See Fig. 1 .

Jaguar X-Type 2005 - CIRCUIT PROTECTION DEVICES

Jaguar X-Type 2005 CIRCUIT PROTECTION DEVICES LOCATION

Component	Location
Passenger Junction Fuse Box	Behind left side of dash.
Power Distribution Fuse Box	On left side of engine compartment.

Jaguar X-Type 2005 - CONTROL UNITS

Jaguar X-Type 2005 CONTROL UNITS LOCATION

Component	Location
ABS, ABS/TC Or DSC Module (Sedan)	On right side of engine compartment. See Fig. 5 .
ABS, ABS/TC Or DSC Module (Wagon)	On right side of engine compartment. See Fig. 4 .
Cellular Phone Module (Sedan)	At left rear of trunk. See Fig. 5 .
Cellular Phone Module (Wagon)	At left rear of trunk. See Fig. 4 .
Climate Control Module (Combined With Control Panel) (Sedan)	Behind center of dash. See Fig. 5 .
Climate Control Module (Combined With Control Panel) (Wagon)	Behind center of dash. See Fig. 4 .
Climate Control Module (Remote) (Sedan)	Behind center of dash. See Fig. 5 .
Climate Control Module (Remote) (Wagon)	Behind center of dash. See Fig. 4 .
Cooling Fan Module (Sedan)	Near left side of radiator. See Fig. 5 .
Cooling Fan Module (Wagon)	Near left side of radiator. See Fig. 4 .
Driver Seat Module (Sedan)	Under driver's seat. See Fig. 5 .
Driver Seat Module (Wagon)	Under driver's seat. See Fig. 4 .
Dynamic Stability Control Module	On right side of engine compartment.
Engine Control Module (Sedan)	On right front side of engine compartment. See Fig. 5 .
Engine Control Module (Wagon)	On right front side of engine compartment. See Fig. 4 .
Fold-Back Mirror Module	In passenger junction fuse box. See Fig. 2 .
Fuel Pump Module (Sedan)	Under rear left seat. See Fig. 5 .
Fuel Pump Module (Wagon)	Under rear left seat. See Fig. 4 .
General Electronic Control Module (Sedan)	Behind right side of dash. See Fig. 5 .
General Electronic Control Module (Wagon)	Behind right side of dash. See Fig. 4 .
Headlamp Leveling Module (Sedan)	Behind left side of dash. See Fig. 5 .
Headlamp Leveling Module (Wagon)	Behind left side of dash. See Fig. 4 .
Ignition Module & Coil No. 1	On cylinder head bank 1.
Ignition Module & Coil No. 2	On cylinder head bank 2.
Ignition Module & Coil No. 3	On cylinder head bank 1.
Ignition Module & Coil No. 4	On cylinder head bank 2.
Ignition Module & Coil No. 5	On cylinder head bank 1.
Ignition Module & Coil No. 6	On cylinder head bank 2.
J Gate Module (Sedan)	Under center console. See Fig. 5 .
J Gate Module (Wagon)	Under center console. See Fig. 4 .
Navigation Control Module (Sedan)	At left rear of trunk. See Fig. 5 .
Navigation Control Module (Wagon)	At left rear of trunk. See Fig. 4 .
Parking Aid Module	In trunk, near spare wheelwell.
Passenger Seat Weight Sensing Module	Under passenger's seat.
Rain Sensing Module (Sedan)	Behind left side of dash. See Fig. 5 .
Rain Sensing Module (Wagon)	Behind left side of dash. See Fig. 4 .
Restraints Control Module (Sedan)	Under center console. See Fig. 5 .
Restraints Control Module (Wagon)	Under center console. See Fig. 4 .
RF Module	In roof console.
Speed Control Module (Sedan)	Left rear side of engine compartment. See Fig. 5 .
Speed Control Module (Wagon)	Left rear side of engine compartment. See Fig. 4 .
Trailer Towing Module	In trunk, near spare wheelwell. See Fig. 4 .
Transmission Control Module (Sedan)	On lower left "A" Pillar. See Fig. 5 .
Transmission Control Module (Wagon)	On lower left "A" Pillar. See Fig. 4 .
Vacuum Module (Sedan)	On left front side of engine compartment. See Fig. 5 .
Vacuum Module (Wagon)	On left front side of engine compartment. See Fig. 4 .
Vehicle Information Control Module (Sedan)	At left rear of trunk. See Fig. 5 .
Vehicle Information Control Module (Wagon)	At left rear of trunk. See Fig. 4 .
Voice Activation Control Module (Sedan)	At left rear of trunk. See Fig. 5 .
Voice Activation Control Module (Wagon)	At left rear of trunk. See Fig. 4 .

Jaguar X-Type 2005 - MOTORS

Jaguar X-Type 2005 MOTORS LOCATION

Component	Location
Blower (Automatic)	Behind right side of dash.
Cooling Fan (Left)	At left side of cooling pack.
Cooling Fan (Right)	At right side of cooling pack.
Defrost Door Actuator	On right side of air distribution unit.
Door Latch (Driver)	At rear of driver's door.
Door Latch (Left Rear)	At rear of left rear door.
Door Latch (Passenger)	At rear of right front door.
Door Latch (Right Rear)	At rear of right rear door.
Fresh/Recirculation Flap Actuator	On right side of air distribution unit.
Fuel Pump	In fuel tank.
Panel/Floor Actuator	On right side of air distribution unit.
Powerwash Pump	Behind right front wheelwell.
Seat Lumbar Pump (Left)	Under left front seat.
Seat Lumbar Pump (Right)	Under right front seat.
Seat Movement Motors (Left Front)	Under left front seat.
Seat Movement Motors (Right Front)	Under right front seat.
Starter Motor	At left rear of engine.
Tailgate Latch	At center rear of tailgate.
Tail Glass Latch	At tailgate.
Throttle Motor	On engine intake manifold.
Trunk Lock Motor	At rear center of trunk lid.
Vacuum Pump	At left rear of engine compartment.
Window Motor (Driver)	In driver's door.
Window Motor (Left Rear)	In left rear door.
Window Motor (Passenger)	In passenger's door.
Window Motor (Right Rear)	In right rear door.
Windshield Washer Pump	At right front side of engine compartment.
Wiper Motor (Front)	At base of windshield, on left side.
Wiper Motor (Rear)	In tailgate.

Jaguar X-Type 2005 - SENDING UNITS & SENSORS

Jaguar X-Type 2005 SENDING UNITS & SENSORS LOCATION

Component	Location
Air Conditioning Pressure Sensor	On left side of engine compartment.
Ambient Temperature Sensor	At left front of engine compartment.
APP Sensor	Above accelerator pedal.
Auto Headlights Sensor	Behind rear view mirror.
Brake Pressure Sensor	On dynamic stability control module, on right side of engine compartment.
CKP Sensor	Next to engine crankshaft pulley.
CMP Sensor 1	On front of bank 1 cylinder head.
CMP Sensor 2	On front of bank 2 cylinder head.
Discharge Temperature Sensor	On right side of air distribution unit.
ECT Sensor	On front engine vee.
EFT Sensor	On front fuel rail.
EOT Sensor	Next to engine oil filter.
Evaporator Temperature Sensor	On right side of air distribution unit.
Front Impact Sensor	At center front of engine compartment.
FTP Sensor	On top of fuel tank.
Fuel Level Sensor 1 & 2	At top of fuel tank.
HO2 Sensor Downstream 1/2	On bank 1 exhaust.
HO2 Sensor Downstream 2/2	On bank 2 exhaust.
HO2 Sensor Upstream 1/1	On bank 1 exhaust.
HO2 Sensor Upstream 2/1	On bank 2 exhaust.
In-Car Temperature Sensor	Behind center of dash.
Inclination Sensor	At left rear of trunk.
IP Sensor	On rear fuel rail.
Knock Sensor	On engine vee.
MAF Sensor	On engine air intake duct.
MAP Sensor	On rear intake manifold.
Parking Aid Sensor (Front Left Center)	At left center of front bumper.
Parking Aid Sensor (Front Right Center)	At right center of front bumper.
Parking Aid Sensor (Left Front)	At left side of front bumper.
Parking Aid Sensor (Left Rear)	At left side of rear bumper.
Parking Aid Sensor (Rear Left Center)	At left center of rear bumper.
Parking Aid Sensor (Rear Right Center)	At right center of rear bumper.
Parking Aid Sensor (Right Front)	At right side of front bumper.
Parking Aid Sensor (Right Rear)	At right side of rear bumper.
Passenger Seat Belt Tension Sensor	In passenger's seat belt buckle.
Passenger Seat Weight Pressure Sensor	Under passenger's seat cushion.
Side Impact Sensor (Driver)	At lower left "B/C" pillar.
Side Impact Sensor (Driver Rear)	Near left rear seat belt anchor.
Side Impact Sensor (Passenger)	At lower right "B/C" pillar.
Side Impact Sensor (Passenger Rear)	Near right rear seat belt anchor.
Steering Angle Sensor	On steering column.
TP Sensor	On engine intake manifold.
Transmission Range Sensor	On top of transmission.
Vehicle Information Sensor	At top left side of dash.
Wheel Speed Sensor (Front Left & Front Right)	On respective front wheel hub assemblies.
Wheel Speed Sensor (Rear Left & Rear Right)	On respective rear wheel hub assemblies.
Yaw Rate Sensor (Sedan)	Behind center console. See Fig. 5 .
Yaw Rate Sensor (Wagon)	Behind center console. See Fig. 4 .

Jaguar X-Type 2005 - SOLENOIDS & SOLENOID VALVES

Jaguar X-Type 2005 SOLENOIDS & SOLENOID VALVES LOCATION

Component	Location
Air Conditioning Compressor Clutch	At front of engine.
EVAP Canister Close Valve	At rear of vehicle, behind fuel tank.
EVAP Canister Purge Valve	On engine compartment bulkhead.
Fuel Injector No. 1	On engine fuel rail.
Fuel Injector No. 2	On engine fuel rail.
Fuel Injector No. 3	On engine fuel rail.
Fuel Injector No. 4	On engine fuel rail.
Fuel Injector No. 5	On engine fuel rail.
Fuel Injector No. 6	On engine fuel rail.
Idle Speed Control Valve	On throttle assembly.
IMT Solenoid Valve 1	On bottom intake manifold.
IMT Solenoid Valve 2	On top intake manifold.
VVT Solenoid Valve 1	On cylinder head bank 1.
VVT Solenoid Valve 2	On cylinder head bank 2.

Jaguar X-Type 2005 - SWITCHES

Jaguar X-Type 2005 SWITCHES LOCATION

Component	Location
Brake Cancel Switch	Above brake pedal.
Brake Fluid Level Switch	On brake fluid master cylinder.
Brake On/Off Switch	Above brake pedal.
Clutch Cancel Switch	Above clutch pedal.
Clutch Pedal Safety Switch	At top of clutch pedal.
Hood Security Switch	At right front side of engine compartment.
Inertia Switch	On lower right "A" pillar.
Oil Pressure Switch	On engine block, near oil filter.
Parking Brake Switch	On parking brake assembly.
Seat Belt Switch (Driver)	In driver's seat belt buckle.
Seat Belt Switch (Passenger)	In passenger's seat belt buckle.
Washer Fluid Level Switch	At right front of engine compartment, on washer fluid reservoir.

Jaguar X-Type 2005 - MISCELLANEOUS

Jaguar X-Type 2005 MISCELLANEOUS LOCATION

Component	Location
AM/FM Antenna	At center of roof.
Battery	At left front of engine compartment.
Blower Series Resistor	Near blower motor.
CD Autochanger (Sedan)	At left rear of trunk. See Fig. 5 .
CD Autochanger (Wagon)	At left rear of trunk. See Fig. 4 .
Curtain Air Bag Igniter (Driver)	At left "E" pillar.
Curtain Air Bag Igniter (Passenger)	At right "E" pillar.
Data Link Connector	Under steering column.
Dual Air Bag Igniters (Driver)	In steering wheel.
Dual Air Bag Igniters (Passenger)	Behind right side of dash.
Generator	At right front of engine.
Ignition Capacitor	On engine, below air intake.
Knee Bolster Igniter (Driver)	Below steering column.
Navigation GPS Antenna (Sedan)	Under rear left side of parcel shelf.
Navigation GPS Antenna (Wagon)	Under left side of rear spoiler.
Parking Aid Sounder (Front)	Behind center of dash.
Parking Aid Sounder (Rear) (Sedan)	Under rear parcel shelf.
Parking Aid Sounder (Rear) (Wagon)	Behind left rear quarterpanel.
Passive Anti-Theft System Transceiver	On steering column, near ignition switch.
Power Amplifier (Sedan)	At left rear of trunk. See Fig. 5 .
Power Amplifier (Wagon)	At left rear of trunk. See Fig. 4 .
Rear Accessory Connector	At left rear of trunk.
Seat Back Heater (Driver)	In driver's seat.
Seat Back Heater (Passenger)	In passenger's seat.
Seat Belt Buckle Pretensioner Igniter (Driver)	In driver's seat belt buckle.
Seat Belt Buckle Pretensioner Igniter (Passenger)	In passenger's seat belt buckle.
Seat Cushion Heater (Driver)	In driver's seat.
Seat Cushion Heater (Passenger)	In passenger's seat.
Security Sounder (Active)	Behind left front wheelwell.
Security Sounder (Passive)	At left front of vehicle.
Side Air Bag Igniter (Driver)	In driver's seat back.
Side Air Bag Igniter (Passenger)	In passenger's seat back.
Telephone Antenna, Bumper (Sedan)	At rear bumper.
TV Antenna & Amplifier 1, 2, 3 & 4	Behind left rear roof trim, above fixed glass.
Vehicle Information Antenna & Amplifier (Sedan)	Behind right "E" pillar.
Vehicle Information Antenna & Amplifier (Wagon)	Behind left rear roof trim, above fixed glass.

Jaguar X-Type 2005 - CONNECTORS

Jaguar X-Type 2005 CONNECTORS LOCATION

Component	Location
CA1 (Natural, 22 Pin)	At lower left "A" pillar.
CA5 (Black, 12 Pin)	At top of fuel tank.
CA10 (Grey, 22 Pin)	At left "A" pillar.
CA15 (Black, 20 Pin)	At left "A" pillar.
CA16 (Black, 20 Pin)	At left "A" pillar.
CA20 (Black, 20 Pin)	At right "A" pillar.
CA21 (Black, 20 Pin)	At right "A" pillar.
CA25 (Natural, 14 Pin)	At left "B" pillar.
CA30 (Natural, 14 Pin)	At right "B" pillar.
CA36 (Green, 16 Pin)	At lower left "A" pillar.
CA40 (Gray, 16 Pin)	At right "A" pillar.
CA45 (Gray, 6 Pin)	At left "E" pillar.
CA65 (Black, 18 Pin)	Under left front seat.
CA70 (Black, 18 Pin)	Under left front seat.
CA127 (Black, 2 Pin)	At left "E" pillar.
CA129 (Gray, 12 Pin)	At spare wheelwell.
CA170 (Green, 16 Pin)	At lower left "A" pillar.
CA189 (Black, 2 Pin)	At lower left "A" pillar.
CA210 (Black, 2 Pin)	At top of fuel tank.
CA230 (Blue, 16 Pin)	At lower left "A" pillar.
CA240 (Gray, 12 Pin)	At lower left "A" pillar.
CA406 (Gray, 3 Pin)	Below left rear seat cushion.
CA407 (Gray, 16 Pin)	Below left rear seat cushion.
CA413 (Black, 12 Pin)	Behind left side of dash.
CA414 (Blue, 16 Pin)	Below left rear seat cushion.
CA431 (Gray, 16 Pin)	Under left front seat.
DL2 (Black, 42 Pin)	At right side of engine compartment.
DM6 (Gray, 4 Pin)	Under driver's seat.
EN4 (Black, 12 Pin)	At top of engine.
IP34 (Natural, 10 Pin)	In steering wheel cassette.
JB1 (Black, 42 Pin)	At left side of engine compartment.
JB2 (Green, 16 Pin)	Behind left side of dash.
JB3 (Blue, 14 Pin)	Below left side of dash.
JB15 (Black, 2 Pin)	Behind right front wheelwell.
JB79 (Black, 6 Pin)	Behind left front wheelwell.
JB129 (Gray, 22 Pin)	Behind left side of dash.
JB130 (Green, 22 Pin)	Behind left side of dash.
JB133 (Black, 2 Pin)	Behind left front wheelwell.
JB145 (Black, 8 Pin)	At left side of engine compartment.
JB173 (Black, 10 Pin)	Behind left front wheelwell.
JB187 (Black, 2 Pin)	At left front of engine compartment.
JB188 (Black, 2 Pin)	At left front of engine compartment.
JB196 (Gray, 10 Pin)	Behind left side of dash.
JB237 (Black, 2 Pin)	At left side of engine compartment.
NA24 (Green, 16 Pin)	Below left side of dash.
NA25 (Gray, 8 Pin)	Below left side of dash.
NA26 (Black, 2 Pin)	At GPS antenna.
PH11 (Gray, 10 Pin)	At lower left "A" pillar.
TL10 (Gray, 6 Pin)	Below left side of parcel shelf.
WG1 (Black, 4 Pin)	At center rear of roof.
WG3 (Black, 3 Pin)	At center rear of roof.
WL1 (Black, 8 Pin)	At rear center of roof.
WL3 (Black, 3 Pin)	At center rear of roof.
WT1 (Black, 8 Pin)	At tailgate.
WT3 (Black, 3 Pin)	At tailgate.

Jaguar X-Type 2005 - GROUNDS

Jaguar X-Type 2005 GROUNDS LOCATION

Component	Location
G1	Trunk, LH rear. See Fig. 3 .
G2	Trunk, LH rear. See Fig. 3 .
G3	LH "E" post (heated rear window ground). See Fig. 3 .
G4	RH "A" post, upper. See Fig. 3 .
G5	Right "A" post, lower. See Fig. 3 .
G8	RH strut tower. See Fig. 3 .
G10	Under RH headlamp assembly. See Fig. 3 .
G11	Under LH headlamp assembly. See Fig. 3 .
G13	Engine block (battery engine ground). See Fig. 3 .
G14	Rearward of power distribution fuse box. See Fig. 3 .
G15	LH "A" post, lower. See Fig. 3 .
G16	Under battery tray (battery engine ground). See Fig. 3 .
G17	On generator bracket. See Fig. 3 .
G18	Under RH headlamp assembly. See Fig. 3 .
G32	Under LH headlamp assembly. See Fig. 3 .
G33	ABS/TC/DSC control module bracket. See Fig. 3 .
G35	LH "E" post, lower. See Fig. 3 .
G36	LH cross car beam. See Fig. 3 .
G37	RH cross car beam. See Fig. 3 .
G38	Roof, top of LH "E" post (high mount stop lamp ground-sedan only). See Fig. 3 .
G39	Trunk, LH rear. See Fig. 3 .
G40	Trunk, LH rear. See Fig. 3 .
G50	RH rear roof panel. See Fig. 3 .
G51	Under body LH dash panel. See Fig. 3 .
