2010 DODGE Caliber

Dodge Caliber Express 2010 - BUZZERS, RELAYS & TIMERS

Dodge Caliber Express 2010 BUZZERS, RELAYS & TIMERS LOCATION

Component	Location
MAIN Relay	Fuse/relay block. See Fig. 2.
RADIATOR FAN LOW/HIGH Relay	Fuse/relay block. See Fig. 2.
RADIATOR FAN MEDIUM/HIGH Relay	Fuse/relay block. See Fig. 2.
RADIATOR FAN SERIES/PARALLEL Relay	Fuse/relay block. See Fig. 2.
Trailer Tow Brake Lamp Relay	Under left side of rear bumper. See Fig. 18.
Trailer Tow Park Lamp Relay	Under right side of rear bumper. See Fig. 18.
Trailer Tow Relay (Left)	Under left side of rear bumper. See Fig. 18.
Trailer Tow Relay (Right)	Under right side of rear bumper. See Fig. 18.
Turbo Coolant Pump Relay	Fuse/relay block. See Fig. 2.

Dodge Caliber Express 2010 - CIRCUIT PROTECTION DEVICES

Dodge Caliber Express 2010 CIRCUIT PROTECTION DEVICES LOCATION

Component	Location
Fuse/Relay-Block	Left front corner of engine compartment. See Fig. 24.

Dodge Caliber Express 2010 - CONTROL UNITS

Dodge Caliber Express 2010 CONTROL UNITS LOCATION

Component	Location
All Wheel Drive (AWD) Control Module	Behind left kick panel. See Fig. 13.
Anti-Lock Brakes Module (Left)	Left rear of engine compartment. See Fig. 9.
Anti-Lock Brakes Module (Right)	Right rear of engine compartment. See Fig. 8.
Fuel Pump Module	Top left side of fuel tank. See Fig. 1.
Hands Free Module	Under left end of dash. See Fig. 21.
Inverter Module	Behind lower center of dash. See Fig. 21.
Occupant Restraint Controller Module	Under front of center console. See Fig. 12.
Powertrain Control Module	Left rear of engine compartment. See Fig. 9.
Radiator Cooling Fan Module	Left/right cooling fan motor. See Fig. 4.
Remote Entry/WCM Sentry Key Module	Under steering column. See Fig. 5.
Steering Control Module	Steering column. See Fig. 5.
Totally Integrated Power Module	Left side of engine compartment. See Fig. 9.
Transmission Control Module	Behind left side of dash. See Fig. 13.

Dodge Caliber Express 2010 - MOTORS

Dodge Caliber Express 2010 MOTORS LOCATION

Component	Location
Blower Motor	Under right side of dash. See Fig. 21.
Recirculation Door Actuator	Right side of HVAC unit. See Fig. 21.
Starter	Lower left rear of engine. See Fig. 11.
Throttle Body	Left side of engine. See Fig. 11.
Windshield Washer Pump	Washer fluid reservoir. See Fig. 3.
Wiper Motor (Front)	Left rear of engine compartment. See Fig. 9.
Wiper Motor (Rear)	Center of liftgate. See Fig. 7.

Dodge Caliber Express 2010 - SENDING UNITS & SENSORS

Dodge Caliber Express 2010 SENDING UNITS & SENSORS LOCATION

Component	Location
ABS Wheel Speed Sensor (Left Front)	Left front wheel hub assembly. See Fig. 9.
ABS Wheel Speed Sensor (Left Rear)	Left rear wheel hub assembly. See Fig. 16.
ABS Wheel Speed Sensor (Right Front)	Right front wheel hub assembly. See Fig. 8.
ABS Wheel Speed Sensor (Right Rear)	Right rear wheel hub assembly. See Fig. 17.
Accelerator Pedal Position Sensor	Top of accelerator pedal bracket. See Fig. 13.
A/C Pressure Transducer	Right front corner of engine compartment. See Fig. 3.
Ambient Air Temperature Sensor	Left front of engine compartment. See Fig. 24.
Brake Fluid Level Sensor	Brake fluid reservoir. See Fig. 9.
Camshaft Position Sensor 1/1	Left rear of engine. See Fig. 11.
Camshaft Position Sensor 1/2	Right rear of engine. See Fig. 25.
Crankshaft Position Sensor	Right rear of engine. See Fig. 25.
Dynamics (ESP) Sensor	Under front of center console. See Fig. 14.
Engine Coolant Temperature Sensor 1	Rear of cylinder head. See Fig. 25.
Engine Coolant Temperature Sensor 2	Left side of engine. See Fig. 11.
Evaporator Temperature Sensor	Behind left center of dash. See Fig. 21.
Impact Sensor (Left Front)	Left front corner of engine compartment. See Fig. 4.
Impact Sensor (Right Front)	Right front corner of engine compartment. See Fig. 3.
Input Speed Sensor	Left side of transmission. See Fig. 22.
Intake Air Temperature Sensor	Rear of engine.
Knock Sensor	Left side of engine. See Fig. 11.
MAP Sensor	Left front of engine. See Fig. 11.
Oil Temperature Sensor	Front of engine. See Fig. 11.
Output Speed Sensor	Right side of transmission. See Fig. 22.
Oxygen Sensor 1/1	Right rear of engine, in exhaust. See Fig. 25.
Oxygen Sensor 1/2	Exhaust system. See Fig. 9.
Side Impact Sensor (Left 1)	Near base of left "B" pillar. See Fig. 15.
Side Impact Sensor (Left 2)	Near base of left "C" pillar. See Fig. 16.
Side Impact Sensor (Right 1)	Near base of right "B" pillar. See Fig. 6.
Side Impact Sensor (Right 2)	Near base of right "C" pillar. See Fig. 17.
Steering Angle Sensor	Steering column. See Fig. 5.
Tire Pressure Transponder (Left Front)	Left front wheelwell. See Fig. 10.
Tire Pressure Transponder (Left Rear)	Left rear wheelwell. See Fig. 1.
Tire Pressure Transponder (Right Front)	Right front wheelwell.
Tire Pressure Transponder (Right Rear)	Right rear wheelwell. See Fig. 29.
Vehicle Speed Sensor	Right rear of engine. See Fig. 25.

Dodge Caliber Express 2010 - SOLENOIDS & SOLENOID VALVES

Dodge Caliber Express 2010 SOLENOIDS & SOLENOID VALVES LOCATION

Component	Location
A/C Compressor Solenoid	Left front of engine. See Fig. 11.
Camshaft Position Solenoid 1/1	Left front of engine. See Fig. 11.
Camshaft Position Solenoid 1/2	Right front of engine. See Fig. 11.
EVAP Purge Solenoid	Lower left rear of engine compartment. See Fig. 9.
Fuel Injectors 1 - 4	Top left side of engine. See Fig. 25.
Manifold Flow Valve	Left rear of engine. See Fig. 11.

Dodge Caliber Express 2010 - SWITCHES

Dodge Caliber Express 2010 SWITCHES LOCATION

Component	Location
Clutch Interlock Switch	Top of clutch pedal assembly. See Fig. 13.
Driver Seat Belt Switch	Integral to driver seat belt buckle assembly. See Fig. 15.
Engine Oil Pressure Switch	Left side of engine. See Fig. 11.
EVAP System Monitor Switch	Near EVAP canister. See Fig. 1.
Hood Ajar Switch	Left rear of engine compartment. See Fig. 9.
Parking Brake Switch	Base of parking brake lever assembly. See Fig. 23.
Stop Lamp Switch	Top of brake pedal assembly. See Fig. 13.
Transmission Solenoid/Pressure Switch Assembly	Lower left rear of transmission. See Fig. 22.

Dodge Caliber Express 2010 - MISCELLANEOUS

Dodge Caliber Express 2010 MISCELLANEOUS LOCATION

Component	Location
A/C Pressure Transducer	Right front corner of engine compartment. See Fig. 3.
Blower Motor Resistor	On blower motor. See Fig. 21.
Data Link Connector	Under left end of dash. See Fig. 13.
Generator	Lower left front of engine. See Fig. 11.
Horn 1	Left front of engine compartment. See Fig. 24.
Ignition Capacitor	Right rear of engine. See Fig. 25.
Ignition Coils 1 - 4	Top right side of engine. See Fig. 25.
Shift Lever Assembly	Behind lower center of dash. See Fig. 23.

Dodge Caliber Express 2010 - CONNECTORS

Dodge Caliber Express 2010 CONNECTORS LOCATION

Component	Location
C100 (14 Pin)	Left side of engine compartment. See Fig. 9.
C103 (34 Pin)	Left front of engine compartment. See Fig. 26.
C104 (Black, 16 Pin)	Left front of engine compartment. See Fig. 26.
C105 (Dark Gray, 4 Pin)	Left side of engine compartment. See Fig. 9.
C106 (6 Pin)	Lower left rear of transmission. See Fig. 22.
C200 (43 Pin)	Under lower left side of dash. See Fig. 21.
C201 (43 Pin)	Under lower left side of dash. See Fig. 21.
C202 (20 Pin)	Base of left "A" pillar. See Fig. 21.
C203 (20 Pin)	Base of right "A" pillar. See Fig. 21.
C204 (Natural, 10 Pin)	Under center console. See Fig. 12.
C300	Behind left quarterpanel. See Fig. 16.
C301 (Green, 16 Pin)	Behind left kick panel. See Fig. 13.
C302 (Natural, 14 Pin)	Behind left kick panel. See Fig. 13.
C303 (Natural, 14 Pin)	Behind right end of dash. See Fig. 14.
C304 (Yellow, 14 Pin)	Under front passenger's seat. See Fig. 19.
C305 (Yellow, 14 Pin)	Under driver's seat. See Fig. 15.
C306 (Green, 16 Pin)	Behind right end of dash. See Fig. 14.
C308 (Light Gray, 14 Pin)	Left "B" pillar. See Fig. 15.
C309 (Light Gray, 14 Pin)	Right "B" pillar. See Fig. 6.
C310 (8 Pin)	Left "D" pillar. See Fig. 7.
C311 (6 Pin)	Left "D" pillar. See Fig. 7.
C323	Left rear of vehicle. See Fig. 18.
C325	Left rear of vehicle. See Fig. 18.
C326	Left rear of vehicle. See Fig. 18.
C327	Left rear of vehicle. See Fig. 18.
C328	Right rear of vehicle. See Fig. 18.
C348	Under front passenger's seat. See Fig. 20.
C349	Under driver's seat. See Fig. 20.
C352	Under front passenger's seat. See Fig. 20.
C353	Under driver's seat. See Fig. 20.

Dodge Caliber Express 2010 - GROUNDS

Dodge Caliber Express 2010 GROUNDS LOCATION

Component	Location
G100	Left side of engine. See Fig. 11.
G101	Left front of engine compartment. See Fig. 11.
G110	Right front of engine compartment. See Fig. 3.
G111	Upper left front of engine compartment. See Fig. 4.
G112	Left front of engine compartment. See Fig. 4.
G200	Near left "A" pillar. See Fig. 21.
G201	Near right "A" pillar. See Fig. 21.
G300	Under front of center floor console. See Fig. 14.
G301	Behind left kick panel. See Fig. 13.
G302	Behind left quarterpanel. See Fig. 16.
G303	Behind left quarterpanel. See Fig. 16.

Dodge Caliber Express 2010 - SPLICES

Dodge Caliber Express 2010 SPLICES LOCATION

Component	Location
S003	Center front of engine compartment, above left radiator fan. See Fig. 4.
S005	Left side of engine compartment, rear of TIPM. See Fig. 9.
S007	Left side of engine compartment, in PCM C1 breakout. See Fig. 9.
S008	Left rear of engine compartment. See Fig. 9.
S024	Left side of engine compartment, under fuse/relay block. See Fig. 24.
S026	Left front of engine compartment, near impact sensor breakout. See Fig. 4.
S033	Left front of engine compartment, near impact sensor breakout. See Fig. 4.
S102	Breakout for powertrain control module C2. See Fig. 11.
S103	Right top of engine. See Fig. 11.
S104	Near breakout for ignition coil 4. See Fig. 11.
S105	Left front of engine. See Fig. 11.
S106	Left side of engine. See Fig. 11.
S107	Left side of engine. See Fig. 11.
S112	Left rear of engine compartment. See Fig. 9.
S150	Left front of engine. See Fig. 11.
S200	Below center console. See Fig. 21.
S203	Left of instrument panel. See Fig. 21.
S204	Behind right side of dash. See Fig. 21.
S205	Left of instrument panel. See Fig. 21.
S206	Left of instrument panel. See Fig. 21.
S207	Under center console. See Fig. 12.
S208	Left of instrument panel. See Fig. 21.
S209	Left of instrument panel. See Fig. 21.
S210	Left of instrument panel. See Fig. 21.
S214	Lower center of instrument panel. See Fig. 21.
S220	Left side of instrument panel. See Fig. 21.
S302	Body harness, below right side of instrument panel. See Fig. 14.
S303	Front of left front wheelwell. See Fig. 10.
S304	Rear of left front fender. See Fig. 10.
S305	Body harness, near left side instrument panel. See Fig. 13.
S306	Left side of body, below front door opening. See Fig. 15.
S307	Body harness, below left side instrument panel. See Fig. 13.
S308	Left side of body, below front door opening. See Fig. 15.
S309	Body harness, below center of instrument panel. See Fig. 14.
S310	Behind left kick panel. See Fig. 13.
S311	Body harness, below left side instrument panel. See Fig. 13.
S312	Body harness, below right side of instrument panel. See Fig. 14.
S313	Body harness, below left side instrument panel. See Fig. 13.
S314	Behind left kick panel. See Fig. 13.
S315	Behind left kick panel. See Fig. 13.
S317	Behind left kick panel. See Fig. 13.
S320	Left side of body, below "B" pillar. See Fig. 15.
S321	Body harness, at lower left instrument panel. See Fig. 13.
S323	Below center of instrument panel, in breakout for cabin heater. See Fig. 13.
S324	Behind left kick panel. See Fig. 13.
S325	Trailer tow harness. See Fig. 18.
S326	Left side of body, below "B" pillar. See Fig. 15.
S328	Above right rear wheelwell. See Fig. 17.
S329	Left side of body, below "B" pillar. See Fig. 15.
S333	Left rear of vehicle. See Fig. 18.
S334	Left side of transmission. See Fig. 22.
S335	Left side of engine compartment. See Fig. 26.
S336	Left side of engine compartment. See Fig. 26.
S337	Trailer tow harness. See Fig. 18.
S338	Under driver's seat. See Fig. 19.
S339	Trailer tow harness. See Fig. 18.
S341	Trailer tow harness. See Fig. 18.
S342	Trailer tow harness. See Fig. 18.
S343	Trailer tow harness. See Fig. 18.
S345	Above right rear wheelwell. See Fig. 17.
S348	Above right rear wheelwell. See Fig. 17.
S351	Center of right front door. See Fig. 27.
S352	Front of right front door. See Fig. 27.
S353	Center of right front door. See Fig. 27.
S354	Front of right front door. See Fig. 27.
S355	Near upper left corner of liftgate. See Fig. 7.
S360	Left front headliner. See Fig. 28.
S361	Left front headliner. See Fig. 28.
S362	Left front headliner. See Fig. 28.
S368	Above right rear wheelwell. See Fig. 17.
S373	Right body, below right rear door opening. See Fig. 17.
S374	Above right rear wheelwell. See Fig. 17.
S382	Above left front wheelwell. See Fig. 10.
