Fiat DOBLO 1.9 JTD 8V da 12/03 – PREPARATION FOR CELLULAR TELEPHONE – – MY 2005 – WIRING DIAGRAM, LOCATION COMPONENTS, OPERATIONAL DESCRIPTION – WIRING DIAGRAM, LOCATION COMPONENTS, OPERATIONAL DESCRIPTION

Fiat DOBLO 1.9 JTD 8V  da 12/03 – PREPARATION FOR CELLULAR TELEPHONE –  – MY 2005 – WIRING DIAGRAM, LOCATION COMPONENTS, OPERATIONAL DESCRIPTION – WIRING DIAGRAM, LOCATION COMPONENTS, OPERATIONAL DESCRIPTION



Components - PREPARATION FOR CELLULAR TELEPHONE - Fiat DOBLO 1.9 JTD 8V da 12/03



Component codeDescriptionReference to the assembly
B001JUNCTION UNIT
B2JUNCTION UNIT UNDER DASHBOARD
C15DASHBOARD EARTH, DRIVER''S SIDE
D75RADIO PHONE COUPLING
D099RADIO PHONE PREPARATION COUPLING
H001IGNITION SWITCH
M001BODY COMPUTER
P20RADIO
P37LEFT FRONT SPEAKER IN DASHBOARD
P38RIGHT FRONT SPEAKER IN DASHBOARD



Component codeDescriptionReference to the assembly
B001JUNCTION UNIT
B2JUNCTION UNIT UNDER DASHBOARD
C15DASHBOARD EARTH, DRIVER''S SIDE
D75RADIO PHONE COUPLING
D099RADIO PHONE PREPARATION COUPLING
H001IGNITION SWITCH
M001BODY COMPUTER
P20RADIO
P37LEFT FRONT SPEAKER IN DASHBOARD
P38RIGHT FRONT SPEAKER IN DASHBOARD
The vehicle is available, on request, with preparation for the installation of a mobile phone.This preparation is configured as follows:- dual function aerial (car radio and mobile phone);- hands-free speaker, located in the dashboard on the passenger side (it is the same speaker for the radio with two connections: one for the radio and one for the mobile phone hands-free function);- hands-free microphone located inside the front courtesy light.The connection for the mobile phone has two power supplies: one direct from the battery and one only with the ignition ON.The two lines are protected by fuses in the junction unit under the battery and in the engine compartment.
The radio phone connection D75 receives a direct power supply (pin 9) from the battery via the line for fuse F39 of the junction unit under the dashboard B02 and protected by fuse F1 of the engine compartment junction unit B01.It receives an ignition-controlled power supply (INT) at pin 7 via the line for fuse F49 of the junction unit under the dashboard B02.The power supply with the side lights on (POS) reaches pin 8 at the radio phone connection D79 via the line protected by fuse F51 of the junction unit under the dashboard B02.Pin 10 of connection D75 is earthed, whilst the cables leave pins 5 and 6 with signals for the right front speaker in the dashboard P38 at connector A (left front speaker P37 at connector A for right hand drive versions).The radio phone connection D75 exchanges information via pins 4, 3 and 1 with the radio P20 (pins 7, 8 and 9 connector C).A connection for the mobile phone aerial is located near connector D75.

JUNCTION UNIT



B001A



B001B



B001C



B001C



B001C



B001C



B001C



B001D



B001E



B001F



B001F



B001F



B001F



B001F



B1A



B1A



B1B



B1C



B1C



B1C



B1C



B1C



B1C



B1C



B1C



B1D



B1E



B1E



B1F



B1F



B1F



B1F



B1F



B1F



JUNCTION UNIT UNDER DASHBOARD



B002A



B002A



B002A



B002A



B002A



B002C



B002D



B002D



B002E



B002E



B002E



B002F



B002G



B002G



B2A



B2A



B2A



B2A



B2A



B2C



B2D



B2D



B2D



B2E



B2E



B2E



B2E



B2F



B2G



DASHBOARD EARTH, DRIVER''S SIDE



C015A



C015A



C015C



C15A



C15A



C15B



C15C



RADIO PHONE COUPLING



D075



D75



RADIO PHONE PREPARATION COUPLING



D099



D099



IGNITION SWITCH



H001A



H001B



H1A



H1B



BODY COMPUTER



M1A



M1A



M1A



M1A



M1C



M1D



M1E



M1F



M001A



M001A



M001A



M001A



M001A



M001C



M001C



M001C



M001D



M001D



M001E



M001E



M001F



M001F



RADIO



P020A



P020A



P020B



P020B



P020B



P020B



P020B



P020C



P020D



P20A



P20A



P20B



P20C



P20D



LEFT FRONT SPEAKER IN DASHBOARD



P037



P037A



P037B



P37



RIGHT FRONT SPEAKER IN DASHBOARD



P038



P038A



P038B



P38A



P38B
