Fiat GRANDE PUNTO 1.3 Multijet – PARTICLE FILTER SYSTEM – – WIRING DIAGRAM, LOCATION COMPONENTS, OPERATIONAL DESCRIPTION – WIRING DIAGRAM, LOCATION COMPONENTS, OPERATIONAL DESCRIPTION

WIRING DIAGRAM - PARTICLE FILTER SYSTEM - Fiat GRANDE PUNTO 1.3 Multijet

PARTICLE FILTER SYSTEM - WIRING DIAGRAM Fiat GRANDE PUNTO 1.3 Multijet

Get access to all wiring diagrams of the car

COMPONENTS - PARTICLE FILTER SYSTEM - Fiat GRANDE PUNTO 1.3 Multijet

Component code	Description	Reference to the operation
B001	JUNCTION UNIT
B099	MAXI FUSE BOX ON BATTERY
C015	DASHBOARD EARTH, DRIVER'S SIDE	-
D029	ENGINE CABLES/ENGINE SERVICES CABLE COUPLING	-
E050	INSTRUMENT PANEL
K187	FAP DIFFERENTIAL PRESSURE SENSOR
K190	DOWNSTREAM PARTICULATE FILTER TEMPERATURE SENSOR (DPF)
M001	BODY COMPUTER
M010	ENGINE MANAGEMENT ECU

COMPONENT LOCATION - PARTICLE FILTER SYSTEM - Fiat GRANDE PUNTO 1.3 Multijet

PARTICLE FILTER SYSTEM - COMPONENT LOCATION Fiat GRANDE PUNTO 1.3 Multijet

Get access to all wiring diagrams of the car

Component code	Description	Reference to the operation
B001	JUNCTION UNIT
B099	MAXI FUSE BOX ON BATTERY
C015	DASHBOARD EARTH, DRIVER'S SIDE	-
D029	ENGINE CABLES/ENGINE SERVICES CABLE COUPLING	-
E050	INSTRUMENT PANEL
K187	FAP DIFFERENTIAL PRESSURE SENSOR
K190	DOWNSTREAM PARTICULATE FILTER TEMPERATURE SENSOR (DPF)
M001	BODY COMPUTER
M010	ENGINE MANAGEMENT ECU

DESCRIPTION - PARTICLE FILTER SYSTEM - Fiat GRANDE PUNTO 1.3 Multijet

An electronic control system supervises and governs all engine parameters to optimise performance and fuel consumption by means of a real-time response to different service conditions.To conform with the most recent pollution control regulations (EURO 4), the most recent version of electronic management which includes new components and a swirl solenoid valve and DPF particle filter has been adopted.The DPF particle filter (Diesel Particulate Filter) is a mechanical filter, inserted in the exhaust pipes which traps the carbon particles present in the exhaust gases on diesel engines. The filter makes it possible to almost totally eliminate the emission of carbon particles in line with current legislation.During the normal usage of the vehicle, the engine management control unit records a series of data related to usage (period of usage, type of journey, temperatures reached, etc.) and empirically calculates the quantity of particulates accumulated in the filter.The filter is an accumulation system and should be periodically regenerated (cleaned) by burning the carbon particles.This regeneration is managed by the engine management control unit on the basis of information provided by the sensors and if the following conditions are satisfied: vehicle speed above 40 Km/h for at least 15 minutes and particle mass below 200%.During the procedure the engine management control unit increases the engine speed to 3500 rpm and activates the fans for about 5 minutes; a message is sent at the end and is shown on the panel display.767There may be a limited increase in the engine speed during the regeneration, a limited increase in fumes and high temperatures at the exhaust. These situations should not be interpreted as problems and have no adverse affect on the behaviour of the vehicle or on the environment.The system has two warning lights in the instrument panel for signalling the accumulation status of the filter: the filter blocked warning light and the EOBD warning light.The filter blocked warning light is activated after a certain number of consecutively interrupted regenerations.The EOBD warning light is activated if the accumulation level of 250% is exceeded memorizing the errors in the control unit memory: when the EOBD warning light is activated it is vital to carry out a forced regeneration using the diagnostic equipment (Examiner).Two specific sensors inform the control unit about the operation of the particle filter:- The differential pressure sensor constantly measures the difference in pressure between the inlet and outlet of the particle filter: this measurement makes it possible to determine the filter blockage level.- The temperature sensor downstream of the catalyzer, located between the catalyzer and the particle filter, allows the engine management control unit to monitor the temperature of the exhaust gases downstream of the catalyzer and consequently an increase in temperature caused by catalytic combustion.For more detailsThe system is also controlled by dedicated relays in the engine compartment control unit. Lines supplying the control unit and various system components (sensors and actuators) are protected by dedicated fuses that are also located inside the engine compartment.

FUNCTIONAL DESCRIPTION - PARTICLE FILTER SYSTEM - Fiat GRANDE PUNTO 1.3 Multijet

Engine management control unit M10 controls and governs the entire electronic ignition and injection system.The ignition-operated power supply arrives via a line protected by fuse F20 of the engine compartment junction unit B1 at pin 23 of connector A of M10 .Main injection relay T7 of B1 controls the entire system: this is protected by a line protected by fuse F43 of engine compartment control unit B1 and is excited by a control signal (earth) from pin 80 of connector A of control unit M10 and thus sends a power supply:- to pin 5 of connector A of the control unit, via the line of fuse F29 of B1 ;- to pins 4 and 6 of connector A of the actual control unit, via the line protected by fuse F28 of B1;The engine management control unit M10 receives signals from the different sensors thereby keeping all the engine operating parameters in check, in particular there are three specific sensors for the management of the operation of the particle filter.The FAP differential pressure sensor K187 receives a power supply from the control unit M10 from pin 14 of connector A and a reference earth from pin 33 of connector A and sends a signal proportional to the pressure to pin 49 of connector A of M10.The downstream catalyzer temperature sensor K190 receives a reference earth from pin 11 of connector A of the control unit M10 and supplies a signal proportional to the temperature measured at pin 91 of connector A of control unit M10.The control unit is then connected via the CAN to the Body Computer M1 and to the instrument panel E50 thereby controlling the switching on of the filter blocked warning light and the displays in the panel.
