Chevrolet Monte Carlo SS 2006 - 2006 ELECTRICAL Fuses & Circuit Breakers - Impala & Monte Carlo

Chevrolet Monte Carlo SS 2006 - IDENTIFICATION

CAUTION:

When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See PROGRAMMING AND SETUP article in GENERAL INFORMATION before disconnecting battery.

Chevrolet Monte Carlo SS 2006 - FUSIBLE LINK

Fusible links are usually located between battery and starter or electrical center. For description and repair procedures, see Fig. 1.

Fig. 1: Chevrolet Monte Carlo SS 2006 - Component Locations - Repairing Fusible Links

Chevrolet Monte Carlo SS 2006 - INSTRUMENT PANEL FUSE BLOCK

NOTE:

Instrument panel fuse block is located on right side end of instrument panel, behind access panel.

Fig. 2: Chevrolet Monte Carlo SS 2006 - Component Locations - Identifying Instrument Panel Fuse Block

Chevrolet Monte Carlo SS 2006 Fuse Block - I/P

Fuse	Rating	Description
AIRBAG Fuse	10A	Inflatable Restraint Sensing and Diagnostic Module (SDM), Inflatable Restraint Front Passenger Presence System (PPS) Module
AMP Fuse	25A	Audio Amplifier
AUX Fuse	20A	Auxiliary Power Outlet - Seat, Auxiliary Power Outlet - Front, Auxiliary Power Outlet - Front 2, Auxiliary Power Outlet - Rear
CNSTR Fuse	10A	Evaporative Emission (EVAP) Canister Vent Solenoid
DR/LCK Fuse	25A	DOOR UNLOCK PCB Relay - Driver, DOOR UNLOCK PCB Relay, and DOOR LOCK PCB Relay
HTD/SEAT Fuse	20A	Heated Seat Control Module (KA1), Emergency Vehicle Rear Compartment Lid Lamps Relay (T53)
ONSTAR Fuse	10A	Vehicle Communication Interface Module (VCIM) (UE1), Garage Door Opener (UG1), Digital Radio Receiver (U2K)
PWR/MIR Fuse	2A	Outside Rearview Mirror Switch
S/ROOF Fuse	20A	Sunroof Motor (CF5)
PWR/SEAT Circuit Breaker	25A	Seat Adjuster Switch - Driver, Seat Adjuster Switch - Passenger
PWR/WNDW Circuit Breaker	25A	Window Switch - Driver, Window Switch - Passenger (Coupe), Window Switch - Front Passenger (Sedan)

Chevrolet Monte Carlo SS 2006 - UNDERHOOD FUSE BLOCK

NOTE:

Underhood fuse box is located on right side of engine compartment mounted to the strut tower.

Fig. 3: Chevrolet Monte Carlo SS 2006 - Component Locations - Identifying Underhood Compartment Fuse Block

Chevrolet Monte Carlo SS 2006 Fuse Block - Underhood

Fuse	Rating	Description
A/C CMPRSR Fuse	10A	A/C Compressor Clutch
ABS MTR1 Fuse	60A	Electronic Brake Control Module (EBCM)
ABS MTR2 Fuse	60A	Electronic Brake Control Module (EBCM)
AIRBAG/DISPLAY Fuse	10A	Instrument Panel Cluster (IPC), HVAC Control Module, Inflatable Restraint Passenger Air Bag On/Off Indicator, and Inflatable Restraint Sensing and Diagnostic Module (SDM)
AUX PWR Fuse	25A	Auxiliary Power Outlet - Left and Auxiliary Power Outlet - Right
BATT 1 Fuse	60A	CNSTR, ONSTAR, AMP, and AUX Fuses
BATT 2 Fuse	60A	HTD/SEAT, AIR BAG, PWR/SEAT, PWR/MIR, S/ROOF, DR/LCK Fuses, and RAP Relay
BATT 3 Fuse	40A	Rear Window Defogger Grid
BATT 4 Fuse	30A	Blower Motor Control Processor
BCM Fuse	10A	Body Control Module (BCM), Ignition Switch, and Theft Deterrent Exciter Module
CHMSL/BACKUP Fuse	10A	Body Control Module (BCM)
DISPLAY Fuse	10A	Data Link Connector (DLC), Remote Control Door Lock Receiver (RCDLR), Instrument Panel Cluster (IPC), and HVAC Control Module
DRL 1 Fuse	15A	DRL 2 Fuse
DRL 2 Fuse	15A	LT LO BEAM Fuse, RT LO BEAM Fuse
ECM IGN Fuse	10A	Engine Control Module (ECM)
ECM/TCM Fuse	15A	Engine Control Module (ECM) and Transmission Control Module (TCM)
EMISSIONS 1 Fuse	15A	Heated Oxygen Sensor (HO2S) 1, Heated Oxygen Sensor (HO2S) 2, and Evaporative Emission (EVAP) Canister Purge Solenoid Valve
EMISSIONS 2 Fuse	15A	Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor, Intake Manifold Tuning (IMT) Valve Solenoid (LZ9), Valve Lifter Oil Manifold Assembly (LS4), A/C CMPRSR Relay, FAN 1 Relay, FAN 2 Relay, and FAN 3 Relay
ETC/ECM Fuse	15A	Engine Control Module (ECM)
FAN1 Fuse	30A	FAN 1 Relay
FAN2 Fuse	30A	FAN 3 Relay
FOG LAMPS Fuse	10A	Fog Lamp - LF and Fog Lamp - RF
FUEL/PUMP Fuse	15A	Fuel Pump and Sender Assembly
HDLP MDL Fuse	15A	C122 or Headlamp Flasher Module (6J7)
HORN Fuse	15A	Horn Assembly
HTD MIR Fuse	10A	Outside Rearview Mirror - Driver and Outside Rearview Mirror - Passenger
INJ 1 Fuse	20A	Fuel Injectors 1-6 (LZE, LZ4, LZ9), or Fuel Injectors 1-3-5-7, and Ignition Coils 1-3-5-7 (LS4)
INJ 2 Fuse	20A	Ignition Control Module (LZE, LZ4, LZ9), or Fuel Injectors 2-4-6-8, and Ignition coils 2-4-6-8 (LS4)
INT LIGHTS Fuse	10A	Body Control Module (BCM)
INT LTS/PNL DIM Fuse	15A	Body Control Module (BCM)
LT HI BEAM FUSE	10A	Headlamp - High Beam - Left or Headlamp Flasher Module (6J7)
LT LO BEAM Fuse	10A	Headlamp - Low Beam - Left
LT PARK Fuse	10A	Marker lamp - LF, Park/Turn Signal Lamp - LF, Tail Lamp - Left, Tail/Stop and Turn Signal - Left, and Marker Lamp - LR (Coupe)
LT SPOT Fuse (9C1, 9C3)	15A	Spot Lamp - Left (7x6, 7X7)
LT T/SIG Fuse	15A	Body Control Module (BCM)
PWR DROP/CRANK Fuse	10A	Blunt Cut Wire (9C1, 9C3)
RADIO Fuse	20A	Radio
RT HI BEAM Fuse	10A	Headlamp - High Beam - Right or Headlamp Flasher Module (6J7)
RT LO BEAM Fuse	10A	Headlamp - Low Beam - Right
RT PARK Fuse	10A	Marker Lamp - RF, Park/Turn Signal Lamp - RF, Tail lamp - Right, Tail/Stop and Turn Signal - Right, License lamp, and Marker Lamp - RR (Coupe)
RT SPOT Fuse (9C1, 9C3)	15A	Spot Lamp - Right (7X7)
RT T/SIG Fuse	15A	Body Control Module (BCM)
RVC SEN Fuse	10A	Body Control Module (BCM)
STRG WHL Fuse	2A	Steering Wheel Controls - Left and Steering Wheel Controls - Right
STRTR Fuse	40A	Starter
TRANS Fuse	10A	1-2 Shift Solenoid (1-2 SS) Valve, 2-3 Shift Solenoid (2-3 SS) Valve, Torque Converter Clutch (TCC) Solenoid Valve, and Transmission Control Module (TCM)
WPR Fuse	25A	WIPER PCB Relay
WSW Fuse	10A	Windshield Washer Fluid Pump
FAN 1 Relay	-	Cooling Fan - Left
FAN 2 Relay	-	Cooling Fan - Right
FAN 3 Relay	-	Cooling Fan - Right
FUEL/PUMP Relay	-	FUEL PUMP Fuse
PWR/TRN Relay	-	ETC/ECM, INJ 1, INJ 2, EMISSIONS 1, and EMISSIONS 2 Fuses
REAR DEFOG Relay	-	BATT 3 and HTD MIR Fuses
STRTR Relay	-	STRTR Fuse
