Jaguar S-Type R 2003 - 2003 ELECTRICAL Fuses & Circuit Breakers - S-Type
Jaguar S-Type R 2003 - IDENTIFICATION
CAUTION: When a fuse box lid is removed, take care to protect the fuse box from moisture and reinstall lid as soon as possible.
Jaguar S-Type R 2003 - FRONT POWER DISTRIBUTION BOX LOCATION
The front power distribution fuse box is located in the right front of the engine compartment. See Fig. 1 . For front power distribution fuse box fuse and relay identification, see Fig. 2 and/or Fig. 3 .
Fig. 1: Jaguar S-Type R 2003 - Component Locations - Identifying Power Distribution Fuse Boxes
Jaguar S-Type R 2003 - PRIMARY JUNCTION BOX LOCATION
Primary junction box is locations on the right side of the instrument panel. See Fig. 1 . For primary junction fuse box fuse and relay identification, see Fig. 4 and/or Fig. 5 .
Jaguar S-Type R 2003 - REAR POWER DISTRIBUTION BOX
Rear power distribution box is located to the right of the spare tire. See Fig. 1 . For rear power distribution fuse box fuse and relay identification, see Fig. 6 -Fig. 8 .
