VW TRANSPORTER 2017 – Airbag systems . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW TRANSPORTER
  4. >VW TRANSPORTER 2017
  5. >VW TRANSPORTER 2017 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW TRANSPORTER 2017 - Side airbag crash sensor on driver side - Side airbag crash sensor on front passenger side - Airbag control unit - Front passenger side airbag deactivated warning lamp - Fuse 29 on fuse holder C - Diagnostic connection



Wiring Diagram VW TRANSPORTER 2017 - Side airbag crash sensor on driver side - Side airbag crash sensor on front passenger side - Airbag control unit - Front passenger side airbag deactivated warning lamp - Fuse 29 on fuse holder C - Diagnostic connection https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
G179 Side airbag crash sensor on driver side
G180 Side airbag crash sensor on front passenger side
J234 Airbag control unit
K145 Front passenger side airbag deactivated warning lamp
SC29 Fuse 29 on fuse holder C
T2ac 2-pin connector, yellow, lower part of B-pillar, driver side
T2z 2-pin connector, yellow, lower part of B-pillar, front passenger side
T6r 6-pin connector, green
T16 16-pin connector, black
T50 50-pin connector, yellow
U31 Diagnostic connection
  605 Earth point, on top end of steering column
  638 Earth point, on right A-pillar
  639 Earth point, left A-pillar
  B283 Positive connection 7 (15a) in main wiring harness
*Only left-hand drive models
*2Only models with key operated switch to deactivate airbag
*3Only models with front head-thorax airbag
*4Only right-hand drive models

Wiring Diagram VW TRANSPORTER 2017 - Coil connector - Rear side airbag crash sensor on driver side - Rear side airbag crash sensor on front passenger side - Airbag control unit - Driver side airbag igniter - Front passenger side airbag igniter 1 - Driver seat belt tensioner igniter 1 - Front passenger seat belt tensioner igniter 1



Wiring Diagram VW TRANSPORTER 2017 - Coil connector - Rear side airbag crash sensor on driver side - Rear side airbag crash sensor on front passenger side - Airbag control unit - Driver side airbag igniter - Front passenger side airbag igniter 1 - Driver seat belt tensioner igniter 1 - Front passenger seat belt tensioner igniter 1 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Získejte přístup ke všem schématům zapojení automobiluDownload PDF file
F350 Coil connector
G256 Rear side airbag crash sensor on driver side
G257 Rear side airbag crash sensor on front passenger side
J234 Airbag control unit
N95 Driver side airbag igniter
N131 Front passenger side airbag igniter 1
N153 Driver seat belt tensioner igniter 1
N154 Front passenger seat belt tensioner igniter 1
T3l 3-pin connector, yellow, under driver seat
T3m 3-pin connector, yellow, lower part of B-pillar, front passenger side
T3p 3-pin connector, yellow, under front passenger seat
T3q 3-pin connector, yellow, lower part of B-pillar, driver side
T3z 3-pin connector, yellow
T12ae 12-pin connector, yellow, in steering wheel
T41 41-pin connector, grey
T50 50-pin connector, yellow
*Only models with front passenger airbag
*2Only models with rear curtain/head airbag
*3Only models with driver side belt tensioner
*4Only models with passenger side belt tensioner
*5Only models with no curtain/head airbag
*6Only models with curtain/head airbag

Wiring Diagram VW TRANSPORTER 2017 - Airbag control unit - Side airbag igniter on driver side - Side airbag igniter on front passenger side - Driver side curtain airbag rear igniter - Front passenger side curtain airbag rear igniter - Front left head-thorax airbag igniter - Front right head-thorax airbag igniter - 3-pin connector



Wiring Diagram VW TRANSPORTER 2017 - Airbag control unit - Side airbag igniter on driver side - Side airbag igniter on front passenger side - Driver side curtain airbag rear igniter - Front passenger side curtain airbag rear igniter - Front left head-thorax airbag igniter - Front right head-thorax airbag igniter - 3-pin connector https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Získejte přístup ke všem schématům zapojení automobiluDownload PDF file
J234 Airbag control unit
N199 Side airbag igniter on driver side
N200 Side airbag igniter on front passenger side
N343 Driver side curtain airbag rear igniter
N344 Front passenger side curtain airbag rear igniter
N507 Front left head-thorax airbag igniter
N508 Front right head-thorax airbag igniter
T3o 3-pin connector, yellow, under front passenger seat
T3r 3-pin connector, yellow, under front passenger seat
T3v 3-pin connector, yellow, under driver seat
T3y 3-pin connector, yellow, under driver seat
T50 50-pin connector, yellow
  376 Earth connection 11, in main wiring harness
*Only models with side airbag on driver side
*2Only models with front head-thorax airbag
*3Only left-hand drive models
*4Only models with rear curtain/head airbag
*5Only models with side airbag on front passenger side
*6Only right-hand drive models
*7Only models with curtain/head airbag

Wiring Diagram VW TRANSPORTER 2017 - Driver side belt switch - Key operated switch to deactivate front passenger side airbag - Airbag control unit



Wiring Diagram VW TRANSPORTER 2017 - Driver side belt switch - Key operated switch to deactivate front passenger side airbag - Airbag control unit https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Získejte přístup ke všem schématům zapojení automobiluDownload PDF file
E24 Driver side belt switch
E224 Key operated switch to deactivate front passenger side airbag
J234 Airbag control unit
T2aa 2-pin connector, black, under driver seat
T2ab 2-pin connector, green, under driver seat
T6br 6-pin connector, yellow
T10r 10-pin connector, black, under driver seat
T50 50-pin connector, yellow
  386 Earth connection 21, in main wiring harness
*Only models with key operated switch to deactivate airbag
*2Only models with belt switch
*3Only models with no memory function
*4Driver seat with memory function

Wiring Diagram VW TRANSPORTER 2017 - Airbag control unit - Control unit in dash panel insert - Onboard supply control unit - Dash panel insert - Airbag warning lamp



Wiring Diagram VW TRANSPORTER 2017 - Airbag control unit - Control unit in dash panel insert - Onboard supply control unit - Dash panel insert - Airbag warning lamp https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Získejte přístup ke všem schématům zapojení automobiluDownload PDF file
J234 Airbag control unit
J285 Control unit in dash panel insert
J519 Onboard supply control unit
K Dash panel insert
K75 Airbag warning lamp
T32 32-pin connector, blue
T50 50-pin connector, yellow
T73b 73-pin connector, white
  B383 Connection 1 (powertrain CAN bus, high), in main wiring harness
  B390 Connection 1 (powertrain CAN bus, low), in main wiring harness
  B708 Connection 1 (dash panel insert CAN bus high) in main wiring harness
  B709 Connection 1 (dash panel insert CAN bus low) in main wiring harness
*According to equipment
*2see applicable current flow diagram for CAN bus network
