AUDI A6 1999 – Anti-lock brake system (ABS) with electronic differential lock (EDL), traction control system (ASR/TCS) and electronic stability program (ESP), Model year 1999 . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >AUDI
  3. >AUDI A6
  4. >AUDI A6 1999
  5. >AUDI A6 1999 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram AUDI A6 1999 - ABS with EDL control unit - speed sensors



Wiring Diagram AUDI A6 1999 - ABS with EDL control unit - speed sensors https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
DIgnition/starter switch
E132Traction control system switch
G44Rear right speed sensor
G45Front right speed sensor
G46Rear left speed sensor
G47Front left speed sensor
J104ABS with EDL control unit
S7Fuse in fuse box
T10k10-pin connector, orange, connector point, A pillar, left
T10au10-pin connector, grey, connector point, A pillar, right
   22 Earth point, on hydraulic unit
   100 Earth connection -1-, in ABS wiring harness
   135 Earth connection -2-, in dash panel wiring harness
   199 Earth connection -3-, in dash panel wiring harness
   A2 Positive (+) connection (15), in dash panel wiring harness
   A19 Connection (58s), in dash panel wiring harness (switch illumination)
   J9 Connection -1- (15a), in ABS wiring harness
*Models with front-wheel drive
**Models with four-wheel drive
***Both possible

Wiring Diagram AUDI A6 1999 - ABS with EDL control unit - ABS hydraulic unit - brake light switch - handbrake warning switch



Wiring Diagram AUDI A6 1999 - ABS with EDL control unit - ABS hydraulic unit - brake light switch - handbrake warning switch https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Holen Sie sich Zugriff auf alle Schaltpläne AutoDownload PDF file
FBrake light switch
F9Handbrake warning switch
F47Cruise control system brake pedal switch (diesel direct injection system)
J104ABS with EDL control unit
N55ABS hydraulic unit
N101ABS inlet valve, front left
N102ABS outlet valve, front left
N133ABS inlet valve, rear right
N135ABS outlet valve, rear right
T10k10-pin connector, orange, connector point, A pillar, left
T10au10-pin connector, grey, connector point, A pillar, right
   135 Earth connection -2-, in dash panel wiring harness
   199 Earth connection -3-, in dash panel wiring harness
   A18 Connection (54), in dash panel wiring harness
   B131 Connection (54), in interior wiring harness
*Both possible

Wiring Diagram AUDI A6 1999 - ABS with EDL control unit - ABS hydraulic unit - return flow pump relay - relay for solenoid valves - electronic stability program hydraulic pump



Wiring Diagram AUDI A6 1999 - ABS with EDL control unit - ABS hydraulic unit - return flow pump relay - relay for solenoid valves - electronic stability program hydraulic pump https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Holen Sie sich Zugriff auf alle Schaltpläne AutoDownload PDF file
J104ABS with EDL control unit
J105ABS return flow pump relay
J106Relay for ABS solenoid valves
N55ABS hydraulic unit
N99ABS inlet valve, front right
N100ABS outlet valve, front right
N134ABS inlet valve, rear left
N136ABS outlet valve, rear left
N225Electronic stability program switch valve -1-
N226Electronic stability program switch valve -2-
N227Electronic stability program high pressure valve -1-
N228Electronic stability program high pressure valve -2-
S13Fuse in fuse box
S123ABS control unit fuse 1
S241Fuse in fuse box
S242Fuse in fuse box
T10k10-pin connector, orange, connector point, A pillar, left
V39ABS return flow pump
V156Electronic stability program hydraulic pump
   22 Earth point, on hydraulic unit
   A52 Positive (+) connection 2 (30), in dash panel wiring harness
*Up to 12.1998
**From 01. 1999

Wiring Diagram AUDI A6 1999 - ABS with EDL control unit - steering angle sender and yaw rate



Wiring Diagram AUDI A6 1999 - ABS with EDL control unit - steering angle sender and yaw rate https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Holen Sie sich Zugriff auf alle Schaltpläne AutoDownload PDF file
G85Steering angle sender
G200Lateral acceleration sender
G202Yaw rate sender
J104ABS with EDL control unit
J217Automatic gearbox control unit
J220Motronic control unit
S16Fuse in fuse box
T10k10-pin connector, orange, connector point, A pillar, left
T10au10-pin connector, grey, connector point, A pillar, right
T15r15-pin connector, brown, connector point, right A pillar
T15u15-pin connector, red, connector point, electronics box, plenum chamber
   135 Earth connection -2-, in dash panel wiring harness
   199 Earth connection -3-, in dash panel wiring harness
   A32 Positive (+) connection (30), in dash panel wiring harness
   A121 Connection (high bus), in dash panel wiring harness
   A122 Connection (low bus), in dash panel wiring harness
•CAN bus
*Models with 6-cylinder petrol engines
**Models with automatic gearbox 01V
***Both possible
#Up to 12. 1998
##From 01. 1999

Wiring Diagram AUDI A6 1999 - ABS with EDS control unit - senders lateral acceleration and brake pressure - dash panel insert



Wiring Diagram AUDI A6 1999 - ABS with EDS control unit - senders lateral acceleration and brake pressure - dash panel insert https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Holen Sie sich Zugriff auf alle Schaltpläne AutoDownload PDF file
G200Lateral acceleration sender
G201Brake pressure sender -1-
J104ABS with EDL control unit
J218Combi-processor in dash panel insert
J401Navigation system with CD drive control unit
KDiagnosis connection
K14Handbrake warning lamp
K47ABS warning lamp
K86Traction control system warning lamp
T10k10-pin connector, orange, connector point, A pillar, left
T10ab10-pin connector, purple, connector point, A pillar, right
T10au10-pin connector, grey, connector point, A pillar, right
T16a16-pin connector, diagnosis connection
T3232-pin connector, blue, on dash panel insert
T32a32-pin connector, green, on dash panel insert
   A76 Connection (diagnosis wire K), in dash panel wiring harness
   A127 Connection (rear left speed sensor), in dash panel wiring harness
   A128 Connection (rear right speed sensor), in dash panel wiring harness
*Up to 12. 1998
**From 01. 1999
***Models with navigation system
