Dodge Dakota Sport 1993 - FUSES & CIRCUIT BREAKERS Fuses & Circuit Breakers 1992-95 Chrysler Motors
Dodge Dakota Sport 1993 - IDENTIFICATION FUSE PANEL IDENTIFICATION (1992-95 MODELS)
The fuse block is to the left of the steering column, under the instrument panel.
Fig. 1: Dodge Dakota Sport 1993 - Component Locations - Fuse Block Identification (1992-95 Models)
Dodge Dakota Sport 1993 - FUSE & CIRCUIT BREAKER I.D. (UNDER INSTRUMENT PANEL) 1 - 30 Amp (Green)
A/C Or Heater Blower Motor.
Dodge Dakota Sport 1993 - 2 - 30 Amp (Circuit Breaker)
Power Windows.
Dodge Dakota Sport 1993 - 3 - 10 Amp (Red) (1992-93); 15 Amp (Lt Blue) (1994-95)
Back-Up Lights, A/C Electronic Cycling Switch (1992-93); Back-Up Lights, Airbag Module, Overhead Console (1994-95).
Dodge Dakota Sport 1993 - 4 - Not Used (1992); 5 Amp (Tan) (1993-95)
ABS Brake System.
Dodge Dakota Sport 1993 - 5 - 20 Amp (Yellow)
Power Door Locks.
Dodge Dakota Sport 1993 - 6 - 15 Amp (Lt. Blue)
Horn, Tachometer.
Dodge Dakota Sport 1993 - 7 - 10 Amp (Red)
Anti-Lock Brake Module, Stoplights, Buzzers.
Dodge Dakota Sport 1993 - 8 - 20 Amp (Yellow)
Taillights, Park, Side Marker Lights, Clock & Radio Display Intensity, License & Panel Lights.
Dodge Dakota Sport 1993 - 9 - 15 Amp (Lt. Blue)
Cigarette Lighter.
Dodge Dakota Sport 1993 - 10 - 20 Amp (Yellow)
Windshield Washers & Wipers.
Dodge Dakota Sport 1993 - 11 - 20 Amp (Yellow)
Turn Signals, Rear Wheel Anti-Lock Module.
Dodge Dakota Sport 1993 - 12 - 10 Amp (Red)
Radio.
Dodge Dakota Sport 1993 - 13 - 4 Amp (Pink)
Cluster Lights, A/C & Heater Controls, Cigarette Lighter Light & Ash Receiver Light, Radio Lights & Overdrive Switch Light.
Dodge Dakota Sport 1993 - 14 - Not Used (1992-93); 15 Amp (Lt. Blue) (1994-95)
Airbag Module, Speedometer, Gauges, Telltales.
Dodge Dakota Sport 1993 - 15 - 2 Amp (Gray)
Speed Control.
Dodge Dakota Sport 1993 - 16 - 5 Amp (Tan)
Gauges & Indicator Lights: Low Oil Light, Low Washer Light, Service Reminder Light, Transmission Oil Light, Brake Warning Light, Anti-Lock Brake Warning Light, Fuel Pacer Light, 4WD Indicator Light, Malfunction Indicator Light, Warning Buzzer, Overdrive Switch (1992-93); Transmission Oil Temperature Lamp, 4WD Lamp, Overdrive Module Seat Belt Warning Buzzer (1994-95).
Dodge Dakota Sport 1993 - 17 - (Blank)
Not Used.
Dodge Dakota Sport 1993 - 18 - (Blank)
Not Used.
Dodge Dakota Sport 1993 - 19 - (Blank)
Not Used.
Dodge Dakota Sport 1993 - 20 - Not Used (1992-93); 25 Amp (Natural) (1994-95)
Fog Lamps and Off Road Lamps.
Dodge Dakota Sport 1993 - 21 - Turn Signal Flasher
No additional definition.
Dodge Dakota Sport 1993 - 22 - Time-Delay Relay
No additional definition.
Dodge Dakota Sport 1993 - 23 - Horn Relay
No additional definition.
Dodge Dakota Sport 1993 - 24 - Hazard Flasher
No additional definition.
Dodge Dakota Sport 1993 - 25 - Warning Buzzer
No additional definition.
Dodge Dakota Sport 1993 - 26 - Not Used (1992); ABS Light Relay (1993-95)
No additional definition.
Dodge Dakota Sport 1993 - UNDERHOOD POWER DISTRIBUTION CENTER IDENTIFICATION (1992-95)
WARNING: Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
Dodge Dakota Sport 1993 - FUSE & CIRCUIT BREAKER I.D. (ENGINE COMPARTMENT) A - Not Used (1992-93); 40 Amp (Green) (1994-95)
ABS System.
Dodge Dakota Sport 1993 - B - 30 Amp (Pink)
Starter, A/C Clutch, Radiator Fan Relay.
Dodge Dakota Sport 1993 - C - 40 Amp (Green)
Ignition Switch.
Dodge Dakota Sport 1993 - D - 20 Amp (Blue) (1992-93); 30 Amp (Blue) (1994-95)
ASD Relay (1992-95).
Dodge Dakota Sport 1993 - E - 50 Amp (Red)
Ignition System.
Dodge Dakota Sport 1993 - F - 20 Amp (Blue)
Under Hood Lamp, Time Delay Relay.
Dodge Dakota Sport 1993 - G - 40 Amp (Green) (1992-93); 50 Amp (Green) (1994-95)
Headlamp Switch.
Dodge Dakota Sport 1993 - F1 - 20 Amp (Yellow)
Hazard Flashers.
Dodge Dakota Sport 1993 - F2 - 5 Amp (Tan)
Interior Lamps, Power Mirrors, Clock, Radio Memory, Underhood Lamp, Time Delay Relay.
Relay Identification
- 1 - Starter Relay
- 2 - A/C Clutch Relay
- 3 - Auto Shutdown Relay
- 4 - Radiator Fan Relay
- 5 - Fuel Pump Relay
- 6 - Not Used (1992-93); ABS Power Relay (1994-95)
Dodge Dakota Sport 1993 - CAUTIONS & WARNINGS BATTERY
WARNING: When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See the COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section.
Dodge Dakota Sport 1993 - SUPPLEMENTAL RESTRAINT (AIR BAG SYSTEM) (IF EQUIPPED)
WARNING: The Diagnostic Energy Reserve Module (DERM) can maintain enough voltage to cause a deployment of the Inflator Module for up to 10 minutes after the Ignition Switch is turned off and the battery is disconnected. Many of the service procedures require disconnection of the Inflator Module to avoid an accidental deployment.
