| E1 | Lighting switch |
| E223 | Tilting mechanism button |
| K150 | Tipping mechanism warning lamp |
| L16 | Fresh air control light bulb |
| L76 | Button illumination |
| T4 | 4-pin connector, near fuel tank |
| T8i | 8-pin connector, under dash panel, left |
| T10 | 10-pin connector |
| T22 | 22-pin connector, under dash panel, left |
| T22a | 22-pin connector, on lighting switch |
| 28 | Earth point, on bulkhead, left |
| A4 | Positive (+) connection (58b), in dash panel wiring harness |
| A11 | Positive (+) connection (58b), in wiring harness for instruments |
| W8 | Connection(15a), in rear wiring harness |
| X55 | Positive (+) connection (15a), in optional equipment wiring harness |
| A | Battery |
| F239 | Tilting/tipping mechanism limitation switch |
| F240 | Tilting/tipping mechanism pressure switch |
| J404 | Terminal 15 relief relay, under driver's seat |
| J432 | Tipping mechanism relay |
| N248 | Tipping mechanism valve |
| S186 | Tilting/tipping mechanism fuse, under driver's seat |
| T4 | 4-pin connector, near fuel tank |
| V160 | Tilting/tipping mechanism hydraulic pump |
| 54 | Earth point, on rear cross panel |
| D17 | Positive (+) connection -1- (15), in engine wiring harness |
| W8 | Connection(15a), in rear wiring harness |
