Wiring Diagram - REVERSING LIGHTS - Fiat DUCATO 2.8 JTD 8V fino a 02/05
Components - REVERSING LIGHTS - Fiat DUCATO 2.8 JTD 8V fino a 02/05
| Component code | Description | Reference to the assembly |
| B002 | JUNCTION UNIT UNDER DASHBOARD | - |
| C030 | LEFT REAR EARTH | - |
| C031 | RIGHT REAR EARTH | - |
| D001 | FRONT/DASHBOARD COUPLING | - |
| D025 | DASHBOARD/LEFT REAR COUPLING | - |
| D026 | DASHBOARD/RIGHT REAR COUPLING | - |
| D097 | SHORT CIRCUITING COUPLING | - |
| D187 | FRONT/REVERSING SWITCH BRIDGE COUPLING | - |
| F030 | LEFT REAR LIGHT CLUSTER | |
| F031 | RIGHT REAR LIGHT CLUSTER | |
| I020 | REVERSING LIGHTS SWITCH | - |
| I081 | MULTIFUNCTION SWITCH ON GEARBOX | - |
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - |
Location Components - REVERSING LIGHTS - Fiat DUCATO 2.8 JTD 8V fino a 02/05
| Component code | Description | Reference to the assembly |
| B002 | JUNCTION UNIT UNDER DASHBOARD | - |
| C030 | LEFT REAR EARTH | - |
| C031 | RIGHT REAR EARTH | - |
| D001 | FRONT/DASHBOARD COUPLING | - |
| D025 | DASHBOARD/LEFT REAR COUPLING | - |
| D026 | DASHBOARD/RIGHT REAR COUPLING | - |
| D097 | SHORT CIRCUITING COUPLING | - |
| D187 | FRONT/REVERSING SWITCH BRIDGE COUPLING | - |
| F030 | LEFT REAR LIGHT CLUSTER | |
| F031 | RIGHT REAR LIGHT CLUSTER | |
| I020 | REVERSING LIGHTS SWITCH | - |
| I081 | MULTIFUNCTION SWITCH ON GEARBOX | - |
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - |
Description - REVERSING LIGHTS - Fiat DUCATO 2.8 JTD 8V fino a 02/05
The vehicle is equipped with reversing lights located in the tail-light clusters.These are operated whenever reverse is engaged via a special multifunction switch.The circuit is supplied with the key on MAR and protected by a fuse located in the underfacia junction unit.
Operational Description - REVERSING LIGHTS - Fiat DUCATO 2.8 JTD 8V fino a 02/05
The reversing light activation signal leaves switch I081, ignition-operated (INT/A) via a connection between ignition switch H001 and pin 48 connector C of under-facia junction unit B002. Power is supplied to short-circuit junction D097D - pin 1- via fuse F31 housed in the junction unit. The short-circuit junction supplies, in turn, reversing light switch I081 from pin 5.When reverse is engaged, switch I081 closes - across pin G and pin H - and sends a signal to short-circuit junction D097D, pin 7, that governs activation of the respective bulbs housed in tail-lights F030 F031.A signal also comes from parking sensor control unit (see function E3090).
