HEADLIGHTS – Hummer H2 2009 – SYSTEM WIRING DIAGRAMS

HEADLIGHTS

Headlights Wiring Diagram for Hummer H2 2009

List of elements for Headlights Wiring Diagram for Hummer H2 2009:

• Amb lt sens sig
• Ambient light/ sunload sensor assembly (top center of dash)
• Auto
• Aux hvac ign fuse 41 10a
• Body control module (bcm) (lower left of dash)
• Dimmer sw sig
• Drl fuse 26 10a
• Drl pcb relay
• Drl rly ctrl
• Flash to pass sig
• Flash to pass switch
• Fog lamp ind
• G100 (on left front frame body mount)
• G101 (right front corner of vehicle on frame rail near front tow hook)
• G200 (on left side of dash, behind left kick panel)
• Gmlan serial data
• Hdlp lo relay
• Head
• Headlamp & panel dimmer switch
• Headlamp dimmer switch
• Headlamps off sig
• Headlamps on sig
• Hi beam pcb relay
• Hi beam rly ctrl
• Hi hdlp lt fuse 27 10a
• Hi hdlp rt fuse 25 10a
• High beam ind
• Hot at all times
• Hot w/ run/crank relay energized
• Ign
• Instrument panel cluster (ipc)
• J100
• J101
• J217
• J219
• Jx205 (below left side of dash, to left of steering column)
• K2 x1
• Left daytime running lamp (drl)
• Left headlamp
• Left i/p junction block (lower left of dash)
• Lo beam rly ctrl
• Lo hdlp lt fuse 9 10a
• Lo hdlp rt fuse 14 10a
• Logic
• Off
• Park
• Park brake sw sig
• Park brake switch (parking brake assembly)
• Park lamps sig
• Pnk
• Right daytime running lamp (drl)
• Right headlamp
• Serial data
• Turn signal/ multi-function switch
• Underhood fuse block (left of engine compt)
• X1 k1
