POWER DOOR LOCKS

Power Door Locks Wiring Diagram for Hummer H2 2009

Power Door Locks Wiring Diagram for Hummer H2 2009 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

List of elements for Power Door Locks Wiring Diagram for Hummer H2 2009:

  • (lower left of i/p) instrument panel fuse block
  • (on passenger side rear of body, near "d" pillar behind trim panel) g410
  • 3b2
  • 3b4
  • 4a7
  • Ajar ind sig
  • Ajar sw sig
  • Aux hvac ign fuse 41 10a
  • B+ volt
  • Body control module (bcm) (lower left of dash)
  • Closed sw sig
  • Coax
  • Computer data lines system
  • Data bus+
  • Data bus-
  • Ddm fuse 15a
  • Driver door latch
  • Driver door lock/window switch
  • Exterior lights system
  • Fuel doors system
  • G103 (on front of right cylinder head)
  • G200 (on left side of dash, behind left kick panel)
  • G203 (lower right side of dash, behind right kick panel)
  • G302 (in left "b" pillar, behind trim panel)
  • G306 (in right "b" pillar, behind trim panel)
  • Gmlan serial data
  • Gnd
  • Ground
  • Headlights system
  • Hood ajar switch (hood latch assembly)
  • Horn rly ctrl
  • Horns system
  • Hot at all times
  • Hot w/ run/crank relay energized
  • Ign
  • Info fuse 5a
  • Instrument panel cluster (ipc)
  • Instrument panel fuse block (lower left of i/p)
  • J217
  • J901
  • J902 (lower right side of liftgate, 6.5 cm from right liftgate ajar switch junction to liftgate harness)
  • Key sw sig
  • Keyless entry antenna
  • Lck 1 fuse 15a
  • Lck 2 fuse 15a
  • Left i/p junction block (lower left of dash)
  • Left liftgate ajar switch (left side of liftgate)
  • Left rear door latch
  • Liftgate door lock actuator (center of liftgate)
  • Lock ctrl
  • Lock sw sig
  • Logic
  • Low beam rly ctrl
  • Lr dr ajar sw sig
  • Lt dr circuit breaker 25a
  • Nca
  • Park lp rly ctrl
  • Passenger door latch
  • Passenger door lock/window switch
  • Pdm fuse 15a
  • Pnk
  • Power distribution system
  • Rear door lock/unlock pcb relay
  • Remote control door lock receiver (rcdlr) (center of dash)
  • Right i/p junction block (right of dash)
  • Right liftgate ajar switch (lower right side of liftgate)
  • Right rear door latch
  • Rr dr ajar sw sig
  • Rt doors circuit breaker cb2 25a
  • Security ind
  • Serial data
  • Sut
  • Suv
  • Tan
  • Trunk, tailgate,
  • Underhood fuse block (left of engine compt)
  • Unlck 1 fuse 15a
  • Unlck 2 fuse 15a
  • Unlock control
  • Unlock ctrl
