Электросхема Генератора для Isuzu Rodeo S 2004
Электросхема Генератора для Isuzu Rodeo S 2004 - Список элементов:
15
- Battery
- Charging system warning light
- Dash fuse box (behind left side of dash, behind panel)
- Fuse cb-11 meter 15a
- Fuse eb-16 main 100a
- Fuse eb-3 acg-s 10a
- Fuse/ relay box (on right side of engine compt)
- Generator
- Hot in on or start
- I-1
- J/c b
- Meter assembly
- P-10 (at lower right front of engine)
- P-6/c-36 (at right side of engine compt, behind battery)
- Starting circuit
Электросхема стартера для Isuzu Rodeo S 2004
Электросхема стартера для Isuzu Rodeo S 2004 - Список элементов:
36
- 3.2l
- 3.5l
- A/t
- Acc
- Automatic transmission mode switch (3.2l: right side of transmission) (3.5l: on right side of transmission)
- Battery
- C-74
- Clutch start switch (behind left side of dash, on clutch pedal support)
- Dash fuse box (behind left side of dash, behind panel)
- E-21
- E-22
- Engine control module (ecm) (3.2l: left rear of engine compt) (3.5l di: left side of engine compt)
- Fuse cb-12 engine ig 15a
- Fuse cb-3 starter 10a
- Fuse eb-16 main 100a
- Fuse eb-19 ign-b2 50a
- Fuse/ relay box (on right side of engine compt)
- Fuse/relay box (on right side of engine compt)
- Hoid- in coil
- Hot in on or start
- J/c a
- Lock
- M/t
- Off
- P10 (at lower right front of engine)
- P6/c36 (at right side of engine compt, behind battery)
- Pnk
- Pull-in coil
- Rly ctrl
- Start
- Starter
- Starter motor
- Starter relay
- Starter solenoid
- Starter switch
- Str feed
