Электросхемы ЦЕНТРАЛЬНЫЙ ЗАМОК Jaguar X-Type 2003

ЦЕНТРАЛЬНЫЙ ЗАМОК

Электросхема центрального замка, С Дважды Захватывая для Jaguar X-Type 2003

https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO

Электросхема центрального замка, С Дважды Захватывая для Jaguar X-Type 2003 - Список элементов:

• (lower
• Acc
• Actuator switches
• Bl3
• Bl6
• Br3
• Br6
• Ca86
• Ca87
• Central junction fuse box (front left side of passenger bulkhead)
• Computer data lines system
• Door ajar
• Exterior lights system
• Fl3
• Fl9
• Fr3
• Fr9
• Fuse 15a
• Fuse 5a
• G1 (left rear of trunk)
• G15 (lower left "a" pillar)
• G37 (below center of dash, on left cross car beam)
• G4 (lower right "a" pillar)
• G5 (lower right "a" pillar)
• General electronic control module (behind right side of dash)
• Horns system
• Hot at all times
• Hot in run
• Ignition switch
• Inertia switch (vehicle impact: emergency unlock)
• Instrument cluster
• Ip1
• Ip10
• Ip11
• Ip5
• Ip6
• Jb172
• Key-in switch
• Left "a" pillar) g15
• Left front door latch assembly
• Left rear door latch assembly
• Lock
• Power distribution fuse box (left side of engine compt)
• Red
• Remote lock/unlock
• Reset
• Right "a" pillar) g4
• Right front door latch assembly
• Right rear door latch assembly
• Run
• Set
• Start
• Trunk lock motor
• Trunk release switch
• Unlock
