Электросхемы Автомтическая коробка Передач (АКПП) Полная привод (4WD) Блокировка Дифференциала Buick Century Custom 2002

Автомтическая коробка Передач (АКПП) Полная привод (4WD) Блокировка Дифференциала

3.1L

3.1L ВИН Дж, Электросхема автоматической коробки передач АКПП для Buick Century Custom 2002

https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO

Get access to all wiring diagrams of the car

3.1L ВИН Дж, Электросхема автоматической коробки передач АКПП для Buick Century Custom 2002 - Список элементов:

• (in fuel injector harness)
• (on transaxle right axle case extension) vehicle speed sensor
• 1-2 shift sol
• 2-3 shift sol
• A/t sensor hi
• A/t sensor lo
• Automatic transaxle (4t65-e)
• Automatic transaxle fluid pressure manual valve position switch
• Automatic transaxle fluid temperature sensor
• Automatic transaxle input shaft speed sensor
• B12
• Battery in
• Bcm & instrument cluster
• Body control module & instrument cluster
• Brake switch in
• Cluster fuse 10a
• Data link connector (below dash, right side of steering column)
• Ecm fuse 22 10a
• Ect return
• Ect sensor in
• Eng emis fuse 30 10a
• Engine controls system
• Engine coolant temperature sensor (top left side of engine)
• G113 (lower left front of engine on transaxle stud)
• G113 (lower left front of engine, on transaxle stud)
• Gnd
• Hot at all times
• Hot in off, run or start
• Hot in run or start
• Hot in run, bulb test or start
• I/p fuse block (behind right side of dash)
• Ign 0 fuse 10a
• Ignition (0) in
• Ignition (1) in
• Instrument panel cluster (ipc)
• Map sensor
• Mil ctrl
• Park/neutral position (pnp) switch (top right rear of transaxle)
• Pc sol hi
• Pc sol lo
• Pcm ground
• Pcm-bcm ign relay fuse 10a
• Pnk
• Powertrain control module (left side of engine compt, in air cleaner assembly)
• Pressure control sol
• Red
• Rev
• S105
• S121
• S270
• Serial data
• Service engine soon
• Splice pack sp205 (near dlc)
• Stop lamp switch (on brake pedal support bracket)
• Tan
• Tcc pwm sol
• Tcc release
• Tcc release in
• Tcc/ brake switch
• Tft sensor gnd
• Tft sensor in
• Throttle position sensor (on throttle body)
• Tp 5v ref
• Tp sensor in
• Tps return
• Tr sw in-a
• Tr sw in-b
• Tr sw in-c
• Tr sw in-p
• Trans fuse 26 10a
• Trans range a
• Trans range b
• Trans range c
• Underhood fuse block (mounted to right front strut tower)
• Vss hi (signal)
• Vss lo (ground)
