AIR CONDITIONING – Ford Econoline E350 1995 – SYSTEM WIRING DIAGRAMS

AIR CONDITIONING

4.9L

4.9L, A/C Wiring Diagram, California for Ford Econoline E350 1995

List of elements for 4.9L, A/C Wiring Diagram, California for Ford Econoline E350 1995:

• (behind right side of i/p)
• (left front of engine compartment)
• (left rear corner of vehicle)
• (left rear of engine compartment
• (right front of engine compartment)
• (right side of safety wall)
• 15a
• A/c pressure cut out switch
• A/c clutch cycling pressure switch
• A/c clutch diode
• A/c compressor clutch
• A/c control assembly
• Aux- iliary high blower motor relay
• Auxiliary blower motor
• Auxiliary blower motor relay (left rear corner of vehicle)
• Auxiliary blower motor resistor (left rear corner of vehicle)
• Auxiliary blower switch
• Blend door actuator (behind center of i/p)
• Blower motor
• Blower motor relay (left side of engine compartment)
• Blower motor resistor
• C 1995 vftc
• Def
• Engine compartment fuse panel
• Floor
• Front blower switch
• Fuse 9
• Fuse a 60a
• Fuse f 60a
• G108 (left side of engine compartment near battery)
• G108 (left side of engine compartment, near battery)
• G202
• G206 (behind instrument cluster)
• G404 (left rear corner of vehicle, near left tail light)
• Hot at all times
• Hot in run
• Interior fuse panel
• Lo/ rear
• Max
• Mix
• Near brake master cylinder)
• Norm
• Off
• Pcm power relay
• Power- train control module
• Rear auxiliary blower switch
• Red
• Temper- ature control switch
• Vent
• W/ rear control
• W/o rear con- trol
• Wide open throttle relay (lower left side of engine compartment)

4.9L, A/C Wiring Diagram, Federal for Ford Econoline E350 1995

List of elements for 4.9L, A/C Wiring Diagram, Federal for Ford Econoline E350 1995:

• (behind right side of i/p)
• (diesel)
• (gasoline)
• (left front of engine compartment)
• (left rear corner of vehicle)
• (left rear of engine compartment near brake master cylinder)
• (right front of engine compartment)
• (right side of safety wall)
• 15a
• A/c pressure cut out switch
• A/c clutch cycling pressure switch
• A/c clutch diode
• A/c compressor clutch
• A/c control assembly
• Aux- iliary high blower motor relay
• Auxiliary blower motor
• Auxiliary blower motor relay (left rear corner of vehicle)
• Auxiliary blower motor resistor (left rear corner of vehicle)
• Auxiliary blower switch
• Blend door actuator (behind center of i/p)
• Blower motor
• Blower motor relay (left side of engine compartment)
• Blower motor resistor
• C 1995 vftc
• Def
• Diesel
• Engine compartment fuse panel
• Floor
• Front blower switch
• Fuse 9
• Fuse a 60a
• Fuse f 60a
• G108 (left side of engine compartment near battery)
• G108 (left side of engine compartment, near battery)
• G202
• G206 (behind instrument cluster)
• G404 (left rear corner of vehicle, near left tail light)
• Gasoline
• Hot at all times
• Hot in run
• Interior fuse panel
• Max
• Mix
• Norm
• Off
• Power- train control module
• Rear auxiliary blower switch
• Temper- ature control switch
• Used for 4.9 l engines only
• Vent
• W/ rear control
• W/o rear con- trol

4.9L, Heater Wiring Diagram for Ford Econoline E350 1995

List of elements for 4.9L, Heater Wiring Diagram for Ford Econoline E350 1995:

• (behind right side of i/p)
• (left rear corner of vehicle)
• (not used)
• (right side of safety wall)
• 15a
• Aux- iliary high blower motor relay
• Auxiliary blower motor
• Auxiliary blower motor relay (left rear corner of vehicle)
• Auxiliary blower motor resistor (left rear corner of vehicle)
• Auxiliary blower switch
• Blend door actuator (behind center of i/p)
• Blower motor
• Blower motor relay (left side of engine compartment)
• Blower motor resistor
• C 1995 vftc
• Def
• Engine compartment fuse panel
• Floor
• Front blower switch
• Function selector switch
• Fuse 9
• Fuse a 60a
• Fuse f 60a
• G108 (left side of engine compartment near battery)
• G202
• G206 (behind instrument cluster)
• G404 (left rear corner of vehicle, near left tail light)
• Hot at all times
• Hot in run
• Interior fuse panel
• Mix
• Off
• Power- train control module
• Rear auxiliary blower switch
• Temper- ature control switch
• Used for 4.9 l engines only
• Vent
• W/ rear control
• W/o rear con- trol

5.0L

5.0L, A/C Wiring Diagram for Ford Econoline E350 1995

List of elements for 5.0L, A/C Wiring Diagram for Ford Econoline E350 1995:

• (behind right side of i/p)
• (diesel)
• (gasoline)
• (left front of engine compartment)
• (left rear corner of vehicle)
• (left rear of engine compartment near brake master cylinder)
• (right front of engine compartment)
• (right side of safety wall)
• 15a
• A/c pressure cut out switch
• A/c clutch cycling pressure switch
• A/c clutch diode
• A/c compressor clutch
• A/c control assembly
• Aux- iliary high blower motor relay
• Auxiliary blower motor
• Auxiliary blower motor relay (left rear corner of vehicle)
• Auxiliary blower motor resistor (left rear corner of vehicle)
• Auxiliary blower switch
• Blend door actuator (behind center of i/p)
• Blower motor
• Blower motor relay (left side of engine compartment)
• Blower motor resistor
• C 1995 vftc
• Def
• Diesel
• Engine compartment fuse panel
• Floor
• Front blower switch
• Fuse 9
• Fuse a 60a
• Fuse f 60a
• G108 (left side of engine compartment near battery)
• G108 (left side of engine compartment, near battery)
• G202
• G206 (behind instrument cluster)
• G404 (left rear corner of vehicle, near left tail light)
• Gasoline
• Hot at all times
• Hot in run
• Interior fuse panel
• Lo/ rear
• Max
• Mix
• Norm
• Off
• Power- train control module
• Rear auxiliary blower switch
• Temper- ature control switch
• Used for 4.9 l engines only
• Vent
• W/ rear control
• W/o rear con- trol

5.0L, Heater Wiring Diagram for Ford Econoline E350 1995

List of elements for 5.0L, Heater Wiring Diagram for Ford Econoline E350 1995:

• (behind right side of i/p)
• (left rear corner of vehicle)
• (not used)
• (right side of safety wall)
• 15a
• Aux- iliary high blower motor relay
• Auxiliary blower motor
• Auxiliary blower motor relay (left rear corner of vehicle)
• Auxiliary blower motor resistor (left rear corner of vehicle)
• Auxiliary blower switch
• Blend door actuator (behind center of i/p)
• Blower motor
• Blower motor relay (left side of engine compartment)
• Blower motor resistor
• C 1995 vftc
• Def
• Engine compartment fuse panel
• Floor
• Front blower switch
• Function selector switch
• Fuse 9
• Fuse a 60a
• Fuse f 60a
• G108 (left side of engine compartment near battery)
• G202
• G206 (behind instrument cluster)
• G404 (left rear corner of vehicle, near left tail light)
• Hot at all times
• Hot in run
• Interior fuse panel
• Mix
• Off
• Power- train control module
• Rear auxiliary blower switch
• Temper- ature control switch
• Used for 4.9 l engines only
• Vent
• W/ rear control
• W/o rear con- trol

5.8L

5.8L, A/C Wiring Diagram for Ford Econoline E350 1995

List of elements for 5.8L, A/C Wiring Diagram for Ford Econoline E350 1995:

• (behind right side of i/p)
• (diesel)
• (gasoline)
• (left front of engine compartment)
• (left rear corner of vehicle)
• (left rear of engine compartment near brake master cylinder)
• (right front of engine compartment)
• (right side of safety wall)
• 15a
• A/c pressure cut out switch
• A/c clutch cycling pressure switch
• A/c clutch diode
• A/c compressor clutch
• A/c control assembly
• Aux- iliary high blower motor relay
• Auxiliary blower motor
• Auxiliary blower motor relay (left rear corner of vehicle)
• Auxiliary blower motor resistor (left rear corner of vehicle)
• Auxiliary blower switch
• Blend door actuator (behind center of i/p)
• Blower motor
• Blower motor relay (left side of engine compartment)
• Blower motor resistor
• C 1995 vftc
• Def
• Diesel
• Engine compartment fuse panel
• Floor
• Front blower switch
• Fuse 9
• Fuse a 60a
• Fuse f 60a
• G108 (left side of engine compartment near battery)
• G108 (left side of engine compartment, near battery)
• G202
• G206 (behind instrument cluster)
• G404 (left rear corner of vehicle, near left tail light)
• Gasoline
• Hot at all times
• Hot in run
• Interior fuse panel
• Lo/ rear
• Max
• Mix
• Norm
• Off
• Power- train control module
• Rear auxiliary blower switch
• Temper- ature control switch
• Used for 4.9 l engines only
• Vent
• W/ rear control
• W/o rear con- trol

5.8L, Heater Wiring Diagram for Ford Econoline E350 1995

List of elements for 5.8L, Heater Wiring Diagram for Ford Econoline E350 1995:

• (behind right side of i/p)
• (left rear corner of vehicle)
• (not used)
• (right side of safety wall)
• 15a
• Aux- iliary high blower motor relay
• Auxiliary blower motor
• Auxiliary blower motor relay (left rear corner of vehicle)
• Auxiliary blower motor resistor (left rear corner of vehicle)
• Auxiliary blower switch
• Blend door actuator (behind center of i/p)
• Blower motor
• Blower motor relay (left side of engine compartment)
• Blower motor resistor
• C 1995 vftc
• Def
• Engine compartment fuse panel
• Floor
• Front blower switch
• Function selector switch
• Fuse 9
• Fuse a 60a
• Fuse f 60a
• G108 (left side of engine compartment near battery)
• G202
• G206 (behind instrument cluster)
• G404 (left rear corner of vehicle, near left tail light)
• Hot at all times
• Hot in run
• Interior fuse panel
• Mix
• Off
• Power- train control module
• Rear auxiliary blower switch
• Temper- ature control switch
• Used for 4.9 l engines only
• Vent
• W/ rear control
• W/o rear con- trol

7.3L

7.3L Diesel, A/C Wiring Diagram for Ford Econoline E350 1995

List of elements for 7.3L Diesel, A/C Wiring Diagram for Ford Econoline E350 1995:

• (behind right side of i/p)
• (diesel)
• (gasoline)
• (left front of engine compartment)
• (left rear corner of vehicle)
• (left rear of engine compartment near brake master cylinder)
• (right front of engine compartment)
• (right side of safety wall)
• 15a
• A/c pressure cut out switch
• A/c clutch cycling pressure switch
• A/c clutch diode
• A/c compressor clutch
• A/c control assembly
• Aux- iliary high blower motor relay
• Auxiliary blower motor
• Auxiliary blower motor relay (left rear corner of vehicle)
• Auxiliary blower motor resistor (left rear corner of vehicle)
• Auxiliary blower switch
• Blend door actuator (behind center of i/p)
• Blower motor
• Blower motor relay (left side of engine compartment)
• Blower motor resistor
• C 1995 vftc
• Def
• Diesel
• Engine compartment fuse panel
• Floor
• Front blower switch
• Fuse 9
• Fuse a 60a
• Fuse f 60a
• G108 (left side of engine compartment near battery)
• G108 (left side of engine compartment, near battery)
• G202
• G206 (behind instrument cluster)
• G404 (left rear corner of vehicle, near left tail light)
• Gasoline
• Hot at all times
• Hot in run
• Interior fuse panel
• Lo/ rear
• Max
• Mix
• Norm
• Off
• Power- train control module
• Rear auxiliary blower switch
• Temper- ature control switch
• Used for 4.9 l engines only
• Vent
• W/ rear control
• W/o rear con- trol

7.3L Diesel, Heater Wiring Diagram for Ford Econoline E350 1995

List of elements for 7.3L Diesel, Heater Wiring Diagram for Ford Econoline E350 1995:

• (behind right side of i/p)
• (left rear corner of vehicle)
• (not used)
• (right side of safety wall)
• 15a
• Aux- iliary high blower motor relay
• Auxiliary blower motor
• Auxiliary blower motor relay (left rear corner of vehicle)
• Auxiliary blower motor resistor (left rear corner of vehicle)
• Auxiliary blower switch
• Blend door actuator (behind center of i/p)
• Blower motor
• Blower motor relay (left side of engine compartment)
• Blower motor resistor
• C 1995 vftc
• Def
• Engine compartment fuse panel
• Floor
• Front blower switch
• Function selector switch
• Fuse 9
• Fuse a 60a
• Fuse f 60a
• G108 (left side of engine compartment near battery)
• G202
• G206 (behind instrument cluster)
• G404 (left rear corner of vehicle, near left tail light)
• Hot at all times
• Hot in run
• Interior fuse panel
• Mix
• Off
• Power- train control module
• Rear auxiliary blower switch
• Temper- ature control switch
• Used for 4.9 l engines only
• Vent
• W/ rear control
• W/o rear con- trol

7.5L

7.5L, A/C Wiring Diagram for Ford Econoline E350 1995

List of elements for 7.5L, A/C Wiring Diagram for Ford Econoline E350 1995:

• (behind right side of i/p)
• (diesel)
• (gasoline)
• (left front of engine compartment)
• (left rear corner of vehicle)
• (left rear of engine compartment near brake master cylinder)
• (right front of engine compartment)
• (right side of safety wall)
• 15a
• A/c pressure cut out switch
• A/c clutch cycling pressure switch
• A/c clutch diode
• A/c compressor clutch
• A/c control assembly
• Aux- iliary high blower motor relay
• Auxiliary blower motor
• Auxiliary blower motor relay (left rear corner of vehicle)
• Auxiliary blower motor resistor (left rear corner of vehicle)
• Auxiliary blower switch
• Blend door actuator (behind center of i/p)
• Blower motor
• Blower motor relay (left side of engine compartment)
• Blower motor resistor
• C 1995 vftc
• Def
• Diesel
• Engine compartment fuse panel
• Floor
• Front blower switch
• Fuse 9
• Fuse a 60a
• Fuse f 60a
• G108 (left side of engine compartment near battery)
• G108 (left side of engine compartment, near battery)
• G202
• G206 (behind instrument cluster)
• G404 (left rear corner of vehicle, near left tail light)
• Gasoline
• Hot at all times
• Hot in run
• Interior fuse panel
• Lo/ rear
• Max
• Mix
• Norm
• Off
• Power- train control module
• Rear auxiliary blower switch
• Temper- ature control switch
• Used for 4.9 l engines only
• Vent
• W/ rear control
• W/o rear con- trol

7.5L, Heater Wiring Diagram for Ford Econoline E350 1995

List of elements for 7.5L, Heater Wiring Diagram for Ford Econoline E350 1995:

• (behind right side of i/p)
• (left rear corner of vehicle)
• (not used)
• (right side of safety wall)
• 15a
• Aux- iliary high blower motor relay
• Auxiliary blower motor
• Auxiliary blower motor relay (left rear corner of vehicle)
• Auxiliary blower motor resistor (left rear corner of vehicle)
• Auxiliary blower switch
• Blend door actuator (behind center of i/p)
• Blower motor
• Blower motor relay (left side of engine compartment)
• Blower motor resistor
• C 1995 vftc
• Def
• Engine compartment fuse panel
• Floor
• Front blower switch
• Function selector switch
• Fuse 9
• Fuse a 60a
• Fuse f 60a
• G108 (left side of engine compartment near battery)
• G202
• G206 (behind instrument cluster)
• G404 (left rear corner of vehicle, near left tail light)
• Hot at all times
• Hot in run
• Interior fuse panel
• Mix
• Off
• Power- train control module
• Rear auxiliary blower switch
• Temper- ature control switch
• Used for 4.9 l engines only
• Vent
• W/ rear control
• W/o rear con- trol
