Электросхемы ЦЕНТРАЛЬНЫЙ ЗАМОК Ford Explorer XLT 2012

ЦЕНТРАЛЬНЫЙ ЗАМОК

Электросхема центрального замка, С Интеллектуальный Доступ (1 из 2) для Ford Explorer XLT 2012

Электросхема центрального замка, С Интеллектуальный Доступ (1 из 2) для Ford Explorer XLT 2012Download PDF file

Электросхема центрального замка, С Интеллектуальный Доступ (1 из 2) для Ford Explorer XLT 2012 - Список элементов:

  • (2 led's)
  • (5 led's)
  • (body main wiring assembly, near breakout to c312)
  • (body main wiring assembly, near breakout to g300) s304
  • (left kick panel) g300
  • (right rear quarter panel)
  • (right rear quarter panel) g302
  • (under right front of center console) g201
  • Accessory delay relay
  • Ajar
  • All lock
  • Backup transceiver (under center console)
  • Body control module (left end of dash)
  • C210
  • C211
  • C2153d
  • C2153e
  • C2280a
  • C2280b
  • C2280c
  • C2280d
  • C2280f
  • C237
  • C3138
  • C3139
  • C316
  • C327
  • Clock
  • Computer data lines system
  • Cpk19
  • Cpk23
  • Cpk28
  • Cpl11
  • Cpl25
  • Cpl26
  • Cpl31
  • Cpl36
  • Cpl39
  • Cpl51
  • Cpl52
  • Cpl84
  • Data
  • Door lock
  • Door unlock
  • Dr door unlock
  • Driver side door lock control switch
  • Fuse 10a
  • Fuse 15a
  • Fuse 20a
  • G103 (left front corner of engine compt)
  • G201 (under right front of center console)
  • G300 (left kick panel)
  • G302
  • Gd214
  • Gnd
  • Hood ajar
  • Hood switch (left front of engine compt)
  • Hot at all times
  • Internal antenna
  • K line
  • Keypad illm(fet)
  • Left front door latch
  • Left rear door latch
  • Lf door ajar
  • Lock
  • Lpk32
  • Lr door ajar
  • Memory set switch
  • Memory systems
  • Micro
  • Ms can +
  • Ms can -
  • Ms can+
  • Ms can-
  • Not used
  • Power windows system
  • Pwr gnd
  • Remote function actuator (rfa) module (under glove box)
  • Rf door ajar
  • Right front door latch
  • Right rear door latch
  • Rke receiver
  • Rpk32
  • Rpk39
  • Rr door ajar
  • S211
  • S301 (body main wiring assembly, near breakout to g300)
  • S312
  • S315 (body main wiring assembly, near breakout to joint connector 3 (ms-can))
  • S325
  • S500
  • S501
  • S602
  • S800
  • Set 1
  • Set 2
  • Set 3
  • Tire pressure monitor module (under center console)
  • Trunk, tailgate, fuel doors system
  • Unlock
  • Vbatt
  • Vdb06
  • Vdb07
  • Vpk32
  • Vpk33
  • Vpk39
  • Vpk40
  • Vpl56
  • W/ memory
  • W/o memory

Электросхема центрального замка, С Интеллектуальный Доступ (2 из 2) для Ford Explorer XLT 2012

Электросхема центрального замка, С Интеллектуальный Доступ (2 из 2) для Ford Explorer XLT 2012 - Список элементов:

  • (2 led's)
  • (base of left "d" pillar) rear passive start antenna
  • (center of rear bumper) liftgate intelligent access (ia) antenna
  • 1/2
  • 3/4
  • 5/6
  • 7/8
  • 9/0
  • Ant +
  • Ant -
  • Bpp
  • C210
  • C211
  • C2153a
  • C2153b
  • C2153c
  • C237
  • C3138
  • C3139
  • C406
  • C510
  • C610
  • Ccb08
  • Cdc35
  • Center passive start antenna (under center console)
  • Cpk29
  • Cpk30
  • Cpk31
  • Cpl45
  • Exterior lights system
  • Front passive start antenna (under center console)
  • G201 (under right front of center console)
  • G300 (left kick panel)
  • G302 (right rear quarter panel)
  • Gd214
  • Gnd
  • Keyless entry keypad
  • Keypad a
  • Keypad b
  • Keypad c
  • Left front exterior door handle
  • Liftgate sw
  • Lock
  • Logic gnd
  • Micro
  • Passenger side door lock control switch
  • Red
  • Remote function actuator (rfa) module (under glove box)
  • Right front exterior door handle
  • Rpk01
  • Rpk02
  • Rpk05
  • Rpk06
  • Rpk07
  • Rpk08
  • S201
  • S232 (main wiring harness, near breakout to joint connector 1 (i-can))
  • S501
  • S602
  • Sbp23
  • Sbp27
  • Start/ stop 1 (active high)
  • Start/stop 1
  • Start/stop switch
  • Trunk, tailgate, fuel doors system
  • Unlock
  • Vbatt
  • Vpk01
  • Vpk02
  • Vpk05
  • Vpk06
  • Vpk07
  • Vpk08

Электросхема центрального замка, без Интеллектуальный Доступ (1 из 2) для Ford Explorer XLT 2012

Электросхема центрального замка, без Интеллектуальный Доступ (1 из 2) для Ford Explorer XLT 2012 - Список элементов:

  • (2 led's)
  • (5 led's)
  • (body main wiring assembly, near breakout to c312) s325
  • (body main wiring assembly, near breakout to g300)
  • (body main wiring assembly, near breakout to g300) s304
  • (body main wiring assembly, near breakout to joint connector 3 (ms-can)) s315
  • Accessory delay relay
  • All lock/ unlock relay
  • Body control module (bcm) (left end of dash)
  • C2280c
  • C2280d
  • C3138
  • C3139
  • C316
  • C327
  • Cpk19
  • Cpk23
  • Cpl31
  • Cpl36
  • Cpl39
  • Door lock
  • Door unlock
  • Driver door unlock relay
  • Driver side door lock control switch
  • Fuse 15a
  • Fuse 20a
  • G300 (left kick panel)
  • G302 (right rear quarter panel)
  • Hot at all times
  • Left rear door latch
  • Lock
  • Lr door ajar
  • Memory set switch
  • Memory systems
  • Micro
  • Passenger side door lock control switch
  • Power windows system
  • Rf door ajar
  • Right front door latch
  • Right rear door latch
  • Rr door ajar
  • S301
  • S312
  • S500
  • S501
  • S602
  • S700
  • S800
  • Set 1
  • Set 2
  • Set 3
  • Unlock
  • W/ memory
  • W/o memory

Электросхема центрального замка, без Интеллектуальный Доступ (2 из 2) для Ford Explorer XLT 2012

Электросхема центрального замка, без Интеллектуальный Доступ (2 из 2) для Ford Explorer XLT 2012 - Список элементов:

  • (not used)
  • (under center console)
  • 1/2
  • 3/4
  • 5/6
  • 7/8
  • 9/0
  • Ajar
  • Body control module (bcm) (left end of dash)
  • C2280b
  • C2280c
  • C2280d
  • C2280f
  • C3138
  • C432
  • C934
  • Computer data lines system
  • Cpk29
  • Cpk30
  • Cpl45
  • Fuse 10a
  • Fuse 15a
  • G103 (left front corner of engine compt)
  • G300 (left kick panel)
  • G301 (left rear quarter panel)
  • Hood ajar
  • Hood switch (left front of engine compt)
  • Hot at all times
  • Internal antenna rke receiver
  • Keyless entry keypad
  • Keypad a
  • Keypad b
  • Keypad c
  • Keypad illum (fet)
  • Left front door latch
  • Lf door ajar
  • Liftgate ajar
  • Liftgate latch (manual liftgate)
  • Liftgate release relay
  • Liftgate release switch (manual liftgate)
  • Liftgate sw
  • Micro
  • Ms can+
  • Ms can-
  • Nca
  • Red
  • S410
  • S501
  • Tire pressure monitor module
  • Vdb06
  • Vdb07
