TRUNK, TAILGATE, FUEL DOOR

Trunk Release Wiring Diagram for Pontiac Sunfire GT 2000

Trunk Release Wiring Diagram for Pontiac Sunfire GT 2000 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

List of elements for Trunk Release Wiring Diagram for Pontiac Sunfire GT 2000:

  • (activated by remote key fob)
  • B10
  • Battery
  • Body control module (behind left side of dash)
  • Hot at all times
  • I/p fuse block (behind lower left side of dash)
  • Luggage compartment lid release solenoid (on rear deck lid)
  • Rear compt release control
  • Rfa batt fuse 10a
