COMPUTER DATA LINES – Suzuki Grand Vitara JLS+ 2000 – SYSTEM WIRING DIAGRAMS

COMPUTER DATA LINES

Computer Data Lines for Suzuki Grand Vitara JLS+ 2000

List of elements for Computer Data Lines for Suzuki Grand Vitara JLS+ 2000:

• (below left side of dash) diagnosis connector (air bag)
• (right of steering column)
• Abs control module (left rear of engine compt)
• Air bag control module (lower center of dash)
• Data link connector
• Diagnosis connector (abs) (right of steering column)
• Dome fuse 15a
• E61
• Ecm/pcm (behind glove box)
• G115 (rear of engine)
• G200 (left kick panel)
• G302 (below front of center console)
• Hot at all times
• J/c (e40) (behind right side of dash)
• Pnk
• Underdash fuse/relay box
