Defogger Wiring Diagram for Mazda MPV LX 1996

List of elements for Defogger Wiring Diagram for Mazda MPV LX 1996:

• Air conditioner fuse 15a
• Central processing unit
• Defog fuse 30a
• G201 (right side of i/p)
• G206 (center of i/p)
• G905 (right rear pillar)
• Hot at all times
• Hot in run or start
• Instrument cluster
• Joint box (below left side of i/p)
• Rear defroster indicator
• Rear window defroster
• Rear window defroster relay (left rear engine compartment in relay box)
• Rear window defroster switch
