Электросхемы ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG Nissan Armada SL 2014

ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG

Электросхема подушек безопасности SRS AirBag (1 из 3) для Nissan Armada SL 2014

https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO

Электросхема подушек безопасности SRS AirBag (1 из 3) для Nissan Armada SL 2014 - Список элементов:

• (behind center of dash) m61
• Air bag diagnosis sensor unit (under center console)
• Air bag ind
• As1 (+)
• As1 (-)
• As2 (+)
• As2 (-)
• B113
• Can h
• Can l
• Combination meter
• Computer data lines system
• Cutoff tell tale
• Czs-shld
• Data link connector (behind lower left side of dash)
• Dr1 (+)
• Dr1/dr2
• Dr2 (+)
• Eczs (+)
• Eczs (-)
• Fuse 10a
• Fuse block (j/b) (behind right end of dash)
• Gnd
• Hot in acc or on
• Hot in on or start
• Ign
• K-line
• Left side air bag (satellite) sensor (near base of left "b" pillar)
• Left side front curtain air bag module (in left "a" pillar)
• Left side rear curtain air bag module (in left "c" pillar)
• Lh buckle sw
• Lh curtain 2 (+)
• Lh curtain 2 (-)
• Lh curtain1 (+)
• Lh curtain1 (-)
• Lh-sat sens (+)
• Lh-sat sens (-)
• M23
• M24
• M35
• M40
• M60
• M61 (behind center of dash)
• Ods in
• P-lh1 (+)
• P-lh1 (-)
• P-lh2 (+)
• P-lh2 (-)
• P-rh1 (+)
• P-rh1 (-)
• P-rh2 (+)
• P-rh2 (-)
• Pnk
• Rh buckle sw
• Rh curtain 2 (+)
• Rh curtain 2 (-)
• Rh curtain inf (+)
• Rh curtain inf (-)
• Rh-sat sens (+)
• Rh-sat sens (-)
• Right front seat belt pre-tensioner (at right "b" pillar)
• Right front side air bag module (in passenger's seat)
• Right side air bag (satellite) sensor (near base of right "b" pillar)
• Right side front curtain air bag module (in right "a" pillar)
• Right side rear curtain air bag module (in right "c" pillar)
• S-lh1 (+)
• S-lh1 (-)
• S-rh1 (+)
• S-rh1 (-)
• Seat belt ind
• Seat belt minder
• Shield
• Shield gnd
• Unified meter control unit (w/ information display)
• Warn lamp

Электросхема подушек безопасности SRS AirBag (2 из 3) для Nissan Armada SL 2014

https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO

Get access to all wiring diagrams of the car

Электросхема подушек безопасности SRS AirBag (2 из 3) для Nissan Armada SL 2014 - Список элементов:

• (behind right side of dash) (w/ service replacement) front passenger air bag module
• (behind right side of dash) front passenger air bag module
• (left front of engine compt) e14
• B132 (at right "d" pillar)
• B19 (at left "d" pillar)
• Crash zone sensor (at center front of engine compt)
• Driver air bag module
• E29
• Left front seat belt pre-tensioner (at left "b" pillar)
• Left front side air bag module (in driver's seat)
• Left seat belt buckle pre-tensioner assembly
• M10
• M101
• M103
• M105
• M106
• Red
• Right seat belt buckle pre-tensioner assembly (under passenger's seat)
• Shield
• Spiral cable (combination switch) (behind left side of dash)

Электросхема подушек безопасности SRS AirBag (3 из 3) для Nissan Armada SL 2014

https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO

Get access to all wiring diagrams of the car

Электросхема подушек безопасности SRS AirBag (3 из 3) для Nissan Armada SL 2014 - Список элементов:

• (+)
• (-)
• 12a
• B132 (at right "d" pillar)
• B136
• B149
• B350
• Belt tension sensor (near base of right "b" pillar)
• Bts (+)
• Bts (-)
• Bts sig
• Front passenger air bag off indicator
• Gnd
• Ign
• M36
• M79 (behind right side of dash)
• Occupant classification system control unit (under front passenger's seat)
• Occupant classification system sensor (under front passenger's seat)
• Ods led
• Passenger air bag off ind
• Red
• Sig
