Электросхемы ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ Fiat 500 Pop 2012

ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ

схема предупреждения ремня безопасности для Fiat 500 Pop 2012

https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO

схема предупреждения ремня безопасности для Fiat 500 Pop 2012 - Список элементов:

• (body rear harness, under center console) s027
• (center rear of engine compt) g024a
• (engine harness, rear of engine compt) s005
• (left rear of engine compt) g010a
• (rear of engine) oil temperature sensor
• 1r sts belt sw driv (+)
• 1r sts belt sw driv(+)
• A101
• B20
• B25
• Batt bus bar
• Bcm/ccn ctrl batt fd
• Body control module
• Brake fluid level sensor (center rear of engine compt)
• Brk lvl sw sig
• C153
• C154
• C337
• Can b bus(+)
• Can b bus(-)
• Can c bus(+)
• Can c bus(-)
• Circuit board
• Cluster
• Computer data lines system
• D41
• D42
• D64
• D65
• Driv ft dr ajar sw in
• Driver seat belt buckle switch
• Eng ctrl com snsr rtn
• Eng oil temp snsr sig
• Engine control module (center rear of engine compt)
• F721
• Fuse 60a
• Fuse 7.5a
• G010a (left rear of engine compt)
• G021 (left kick panel)
• G041a (left rear quarterpanel)
• G24
• G74
• G75
• G78
• Gnd
• Hot at all times
• Hot in run or start
• Ign r pre
• K900
• Left front door latch
• Lgate ajar sig
• Liftgate door latch
• Occupant restraint controller module (center of dash)
• Oil press snse/sw sig
• Oil press sw sig
• Oil pressure switch (lower left front of engine)
• Parking brake switch (under center console)
• Pass ft dr ajar sw in
• Pdc bus bar 3
• Power distribution center (left rear of engine compt)
• Prk brk sw sig
• R57
• Right front door latch
• S011
• S012
• Z921
• Z924
• Z927

Электросхема системы контроля давления в шинах для Fiat 500 Pop 2012

https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO

Get access to all wiring diagrams of the car

Электросхема системы контроля давления в шинах для Fiat 500 Pop 2012 - Список элементов:

• A101
• A943
• Batt bus bar
• Batt feed
• Body control module
• C308
• Can b bus(+)
• Can b bus(-)
• Can c bus(+)
• Can c bus(-)
• Circuit board
• Cluster
• Computer data lines system
• Ctrl batt fd bcm/ccn
• D41
• D42
• D64
• D65
• Fuse 10a
• Fuse 60a
• G021 (left kick panel)
• G042b
• Gnd
• Hot at all times
• Pdc bus bar 3
• Power distribution center (left rear of engine compt)
• Tire pressure module
• Z921
• Z942
