ВНЕШНЕЕ ОСВЕЩЕНИЕ

Электросхема задних фар для Mitsubishi Diamante LS 2000

Электросхема задних фар для Mitsubishi Diamante LS 2000 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file

Электросхема задних фар для Mitsubishi Diamante LS 2000 - Список элементов:

  • B76
  • B89
  • G406 (on luggage compt lid, near latch)
  • Hot in run or start
  • Junction block (behind left side of dash)
  • Left rear lid light
  • Multi- purpose fuse 5 10a
  • Nca
  • Park/ neutral position switch (on left front of engine compt, on transaxle)
  • Right rear lid light

Электросхема внешнего освещения (1 из 2) для Mitsubishi Diamante LS 2000

Электросхема внешнего освещения (1 из 2) для Mitsubishi Diamante LS 2000 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

Электросхема внешнего освещения (1 из 2) для Mitsubishi Diamante LS 2000 - Список элементов:

  • B25
  • B71
  • B76
  • B77
  • B78
  • B80
  • B84
  • B89
  • C03
  • C04
  • C05
  • Column switch
  • Combination meter
  • Dedicated fuse 1 10a
  • Dedicated fuse 11 10a
  • Dedicated fuse 2 10a
  • Door locks system
  • Engine compartment relay box (on left front fender)
  • Flasher assembly (in front of shifter, under center console)
  • G100 (front of left front fender)
  • G101 (right front fender, behind headlight)
  • G203 (top of right kick panel)
  • G407 (center rear of luggage compt)
  • Hazard switch
  • Hot at all times
  • Hot in run or start
  • Interior lights system
  • J/c 5 (behind left side of dash)
  • J/c 5 (behind left side of dash)
  • Junction block
  • Junction block (behind left side of dash)
  • Left
  • Left front side marker light
  • Left front turn signal light
  • Left rear combination light
  • Left rear side marker light
  • Left turn ind
  • Multi- purpose fuse 4 10a
  • Nca
  • Right
  • Right front side marker light
  • Right front turn signal light
  • Right rear combination light
  • Right rear side marker light
  • Right turn ind
  • Standard high contrast
  • Taillight relay
  • Turn signal switch

Электросхема внешнего освещения (2 из 2) для Mitsubishi Diamante LS 2000

Электросхема внешнего освещения (2 из 2) для Mitsubishi Diamante LS 2000 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

Электросхема внешнего освещения (2 из 2) для Mitsubishi Diamante LS 2000 - Список элементов:

  • (2000) (2001)
  • Assist ecu (under right side of dash, near right kick panel)
  • B23
  • B53
  • B54
  • B76
  • Back-up lamps circuit
  • C10
  • Column switch
  • Computer data lines system
  • Data link connector (under left side of dash, near steering column)
  • G200 (left kick panel)
  • G300 (below left front seat)
  • G406 (on luggage compt lid, near latch)
  • Head
  • Hight mount stoplight
  • Hot at all times
  • Instrument panel ecu (behind left side of dash)
  • Junction block (behind left side of dash)
  • Left license plate light
  • Left rear lid light
  • Lighting switch
  • Multi- purpose fuse 3 15a
  • Nca
  • Off
  • Right license plate light
  • Right rear lid light
  • Stoplight switch
  • Tail
