AIR CONDITIONING – Subaru Forester XT 2005 – SYSTEM WIRING DIAGRAMS

AIR CONDITIONING

Automatic A/C Wiring Diagram (1 of 2) for Subaru Forester XT 2005

List of elements for Automatic A/C Wiring Diagram (1 of 2) for Subaru Forester XT 2005:

• Air mix actuator (behind center of dash)
• Ambient sensor (behind center of front bumper)
• Auto a/c control module
• Blower fan relay (behind left side of dash)
• Blower motor (behind lower right side of dash)
• Combination meter
• Defogger system
• Evaporative thermo switch (behind right side of dash, on a/c heater module)
• F68
• Fresh/recirc actuator (behind right side of dash)
• Fuse 15a
• Gb-2 (at base of right "a" pillar)
• Gb-4 (under front of center console)
• Hot at all times
• I10
• I11
• I48
• I49
• In-vehicle temperature sensor (behind right side of dash)
• Interior lights system
• Main fuse box (m/b) (at left side of engine compt)
• Mode actuator (behind right side of dash)
• Red
• Sun load sensor (at top right side of dash)

Automatic A/C Wiring Diagram (2 of 2) for Subaru Forester XT 2005

List of elements for Automatic A/C Wiring Diagram (2 of 2) for Subaru Forester XT 2005:

• 2.5l
• 2.5l turbo
• A/c compressor (at right front of engine)
• A/c pressure switch (at left front corner of engine compartment)
• A/c relay holder (on left side of engine compt)
• Air conditioning relay
• B134
• B135
• B136
• B137
• B152
• B271
• Engine control module (under right side of dash)
• Engine controls system
• Engine coolant temperature sensor & thermometer (on top right front of engine)
• F41
• Fan mode relay
• Fan relay 1
• Fan relay 2
• Fuse & relay box (f/b) (behind left side of dash)
• Fuse 1 15a
• Fuse 17 15a
• Fuse 18 15a
• Fuse 2 15a
• Fuse 30a
• Gf-1 (behind right side of front bumper)
• Hot at all times
• Hot in on or start
• Main fan motor (at left front of engine compt)
• Nca
• Sub fan motor (at right front of engine compt)

Manual A/C Wiring Diagram for Subaru Forester XT 2005

List of elements for Manual A/C Wiring Diagram for Subaru Forester XT 2005:

• (at left front corner of engine compt) a/c pressure switch
• (at left front of of engine compartment)
• A/c compressor (at right front of engine)
• A/c relay holder (on left side of engine compt)
• Air conditioning relay
• Air conditioning switch
• B134
• B135
• B136
• B137
• B152
• B271
• Blower fan relay (behind left side of dash)
• Blower fan switch
• Blower motor (behind lower right side of dash)
• Blower motor resistor (behind right side of dash)
• Combination meter
• Defogger system
• Engine control module (under right side of dash)
• Engine controls system
• Engine coolant temperature sensor & thermometer (on top right front of engine)
• Evaporative thermo switch (behind right side of dash, on a/c-heater module)
• F41
• Fan mode relay
• Fan relay 1
• Fan relay 2
• Fresh/recirc actuator (behind right side of dash)
• Fuse & relay box (f/b) (behind left side of dash)
• Fuse 1 15a
• Fuse 17 15a
• Fuse 18 15a
• Fuse 2 15a
• Fuse 30a
• Gb-2 (at base of right "a" pillar)
• Gb-4 (under front of center console)
• Gf-1 (behind right side of front bumper)
• Hot at all times
• Hot in on or start
• I11
• Interior lights system
• Main fan motor
• Off
• Red
• Sub fan motor (at right front of engine compartment)
