Электросхемы Подогрев стекол и зеркал Volkswagen New Beetle GLS 2002

Подогрев стекол и зеркал

Электросхема подогрева зеркал заднего вида для Volkswagen New Beetle GLS 2002

https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO

Get access to all wiring diagrams of the car

Электросхема подогрева зеркал заднего вида для Volkswagen New Beetle GLS 2002 - Список элементов:

• (behind left side of dash) g202
• (beside steering column) g42
• Driver's side power mirror
• Fuse 10a
• Fuse 7.5a
• Fuse panel (behind left side of dash)
• Heated mirror relay
• Heating element
• Hot in on
• Hot in on or start
• Note: this circuit is for vehicles with manual windows. for vehicles with power windows, see power mirrors system.
• Passenger's side power mirror
• Power mirror switch
• Thirteen position auxiliary relay panel (integral to relay panel)

Электросхема заднего стекла для Volkswagen New Beetle GLS 2002

https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO

Get access to all wiring diagrams of the car

Электросхема заднего стекла для Volkswagen New Beetle GLS 2002 - Список элементов:

• (not used)
• 26a
• Fuse 20a
• Fuse panel (behind left side of dash)
• G42 (beside steering column)
• G52 (on left side of rear lid)
• Heated rear window
• Hot in on
• Interior lights system
• Rear window defogger indicator
• Rear window defogger switch
• Switch illumination
