Электросхемы Звуковой сигнал Гудок Chevrolet Pickup K2500 1997

Звуковой сигнал Гудок

Электросхема звукового сигнал Гудка для Chevrolet Pickup K2500 1997

Электросхема звукового сигнал Гудка для Chevrolet Pickup K2500 1997 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

Электросхема звукового сигнал Гудка для Chevrolet Pickup K2500 1997 - Список элементов:

  • (forward lamps harn, 26.5 cm from left headlamp breakout) s124
  • G101 (right inner fender, below underhood reel lamp)
  • Horn mini fuse 20a
  • Horn relay
  • Horn slip ring
  • Horn switch
  • Hot at all times
  • Left horn (front of vehicle)
  • Nca
  • Right horn (front of vehicle)
  • S128
  • Steering wheel
  • Underhood fuse-relay center
