AIR CONDITIONING – Toyota RAV4 EV 2000 – SYSTEM WIRING DIAGRAMS

AIR CONDITIONING

Heater Wiring Diagram for Toyota RAV4 EV 2000

List of elements for Heater Wiring Diagram for Toyota RAV4 EV 2000:

• (left kick panel) g200
• A13
• B13
• Blower motor (behind right side of dash)
• Blower resistor (behind right side of dash)
• Blower switch
• E12
• Fusible link block (on right side of engine compartment, near batttery)
• Heater relay
• Hot at all times
• Hot in on or start
• Htr fuse 50a
• Instrument panel j/b (on lower left side of dash)
• J/b 3 (behind center of dash)
• Off
• Passenger side r/b (at right kick panel)
• Turn & gauge fuse 10a

Manual A/C Wiring Diagram for Toyota RAV4 EV 2000

List of elements for Manual A/C Wiring Diagram for Toyota RAV4 EV 2000:

• (engine room main wire harness, left front corner of engine compartment)
• (engine room main wire harness, left front corner of engine compartment) e1
• (left kick panel) g200
• (left side of radiator) g108
• (right kick panel) g203
• A/c
• A/c amplifier (behind right side of dash)
• A/c condenser fan motor (on right front of engine compartment)
• A/c control switch
• A/c fuse 10a
• A/c magnetic clutch & lock sensor
• A/c thermistor (behind right side of dash)
• A/c triple pressure switch (a/c dual & single pressure switch) (on left front corner of engine compartment)
• A/c water temperature switch (on center front of engine compartment, behind front bumper)
• A13
• Ac1
• Act
• Alt fuse 100a
• B13
• Blower motor (behind right side of dash)
• Blower resistor (behind right side of dash)
• Blower switch
• C10
• C13
• C21
• Cds fan fuse 30a
• Defroster mode switch
• Dual
• E/g main relay
• E12
• Ecu-ig fuse 10a
• Engine control module (under center of dash)
• Engine room r/b (on left front of strut tower)
• Engine room r/b 2 (in front of left front strut tower)
• Fan 1 relay
• Fan 2 relay
• Fan 3 relay
• Fusible link block (on right side of engine compartment, near battery)
• Heater relay
• Hot at all times
• Hot in on or start
• Htr fuse 50a
• Ig+
• Ig-
• Instrument panel j/b (on lower left side of dash)
• J/b 3 (behind center of dash)
• J/c 3 (behind combination meter)
• J/c 5 (under center top of dash)
• J/c 6 (under front of center console)
• Led+
• Mg/c relay
• Mgc
• Off
• Passenger side r/b (at right kick panel)
• Radiator fan motor (on left front of engine compartment)
• Rdi fan fuse 30a
• Red
• Single
• Ssr+
• Ssr-
• Tach
• Turn & gauge fuse 10a
