AIR CONDITIONING – Toyota Tacoma 2004 – SYSTEM WIRING DIAGRAMS

  1. Home
  2. >TOYOTA
  3. >Toyota 2004
  4. >Toyota Tacoma 2004
  5. >Toyota Tacoma 2004 - ALL WIRING DIAGRAMS

Download PDF file

AIR CONDITIONING

Heater Wiring Diagram for Toyota Tacoma 2004

Heater Wiring Diagram for Toyota Tacoma 2004 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

List of elements for Heater Wiring Diagram for Toyota Tacoma 2004:

  • (at right end of dash) ie
  • (in dash harness, at right kick panel)
  • (in dash harness, at right side of dash) i16
  • A j10
  • Blower motor (below right side of dash, in blower housing)
  • Blower resistor (below right side of dash, in blower housing)
  • C j9
  • Ea (at left front fender)
  • Gauge fuse 10a
  • Heater blower switch
  • Heater fuse 50a
  • Heater relay
  • Hot at all times
  • Hot in on or start
  • I19
  • J/b 1 (behind dash, left of steering column)
  • J10 d
  • J9 e
  • Junction connector 9 & 10 (on left side of engine compartment, at r/b 2)
  • Junction connector 9 & 10 (on left side of engine compt, at r/b 2)
  • Off
  • R/b 2 (on left side of engine compartment)
  • Red

Manual A/C Wiring Diagram for Toyota Tacoma 2004

Manual AC Wiring Diagram for Toyota Tacoma 2004 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

List of elements for Manual A/C Wiring Diagram for Toyota Tacoma 2004:

  • (behind dash, above steering column) j/b 3 (left)
  • (in dash harness, at right kick panel) i19
  • (in dash harness, at top left side of dash) i7
  • (in engine compartment harness, near battery) e3
  • 2.4l, 2.7l
  • 3.4l
  • A j10
  • A/c control assembly
  • A/c dual pressure switch (behind right side of dash)
  • A/c fuse 10a
  • A/c magnetic clutch (right front of engine)
  • A/c thermistor (behind right side of dash)
  • Ac1
  • Act
  • Air inlet control servo motor (right end of dash)
  • Air mix control servo motor (center of dash)
  • Air vent mode control servo motor (center left of dash)
  • B/l
  • Blower motor (below right side of dash, in blower housing)
  • Blower resistor (below right side of dash, in blower housing)
  • C j9
  • D14
  • D19
  • Def
  • Ea (at left front fender)
  • Ecu-b fuse 7.5a
  • Engine control module (behind right side of dash)
  • Engine coolant temperature sensor (2.4l, 2.7l: on rear of engine) (3.4l: on front of engine)
  • F/d
  • F15
  • F16
  • F17
  • Face
  • Foot
  • Frsh
  • Gauge fuse 10a
  • Gnd
  • Heater blower switch
  • Heater fuse 50a
  • Heater relay
  • Hot at all times
  • Hot in on or start
  • I10 (in dash harness, at center of dash)
  • I13 (in dash harness, at right side of dash)
  • I16 (in dash harness, at right side of dash)
  • I9 (in dash harness, at center of dash)
  • Ie (at right end of dash)
  • Ig (at left end of dash)
  • Ig+
  • Interior lights system
  • J/b 1 (behind dash, left of steering column)
  • J/b 3 (center) (behind center of dash)
  • J/b 3 (left) (behind dash, above steering column)
  • J10
  • Junction connector 9 & 10 (on left side of engine compartment, at r/b 2)
  • Off
  • R/b 2 (on left side of engine compartment)
  • Recirc
  • Red
  • Thw
