HORN – Toyota Pickup 1992 – SYSTEM WIRING DIAGRAMS

HORN

Horn Wiring Diagram for Toyota Pickup 1992

List of elements for Horn Wiring Diagram for Toyota Pickup 1992:

• G200 (left kick panel)
• Haz-horn fuse 15a
• Horn (right front side of engine compartment)
• Horn relay (left kick panel)
• Horn switch (part of combination switch)
• Hot at all times
• R/b 2 (right side of engine compartment)
