Dodge Pickup D250 1993 - ELECTRICAL COMPONENT LOCATOR 1993 ELECTRICAL COMPONENT LOCATOR Chrysler Corp. - Electrical Component Locations
Dodge Pickup D250 1993 - BUZZERS, RELAYS & TIMERS
Dodge Pickup D250 1993 BUZZERS, RELAYS & TIMERS LOCATION
Component Location A/C Cut-Out Relay On left inner fender panel. See Fig. 1 . Air Intake Heater Relays (Diesel) On left inner fender panel, on top of left wheelwell. Auto Shutdown Relay On left inner fender panel. See Fig. 1 . Electronic Modulated Converter Clutch (EMCC) Relay On left fender panel. See Fig. 1 . Fuel Pump Relay On left inner fender panel. See Fig. 1 . Hazard Flasher Relay On fuse/relay block. See Fig. 2 . Headlight/Key/Seat Belt Buzzer To right of steering column, on bracket. Horn Relay On fuse/relay block. See Fig. 2 . Ignition Light Time Delay Relay Left of steering column, taped to main harness. Rear Defogger Timer/Relay Integral part of rear defogger switch. Starter Relay On left inner fender panel. See Fig. 1 . Turn Signal Flasher On fuse/relay block. See Fig. 2 .
Dodge Pickup D250 1993 - CIRCUIT PROTECTION DEVICES
Dodge Pickup D250 1993 CIRCUIT PROTECTION DEVICES LOCATION
Component Location Circuit Breakers Headlight In headlight switch. Power Door Locks In fuse block cavity No. 6. See Fig. 2 . Power Windows In fuse block cavity No. 2. See Fig. 2 . Fuse/Relay Block Under dash, to left of steering column. See Fig. 2 . Fusible Links In engine compartment, on left inner fender. See Fig. 1 .
Dodge Pickup D250 1993 - CONTROL UNITS
Dodge Pickup D250 1993 CONTROL UNITS LOCATION
Component Location Cruise Control Module Integral part of PCM. Daytime Running Lights Module In engine compartment, forward of right wheelwell. Intermittent Wiper Module Under dash, to right of steering column. Powertrain Control Module (PCM) In engine compartment, on left inner fender. See Fig. 1 . Rear Anti-Lock Brake System (RABS) Module Under right side of dash, behind glove box. Trans. Overdrive Module Behind dash, to right of glove box.
Dodge Pickup D250 1993 - SENDING UNITS & SENSORS
Dodge Pickup D250 1993 SENDING UNITS & SENSORS LOCATION
Component Location Camshaft Position Sensor In distributor. Charge Air Temp. Sens. (Gas) On right front corner of intake manifold. See Fig. 4 . Coolant Temperature Sensor Diesel On left side of cylinder head, at rear end. See Fig. 5 . Gasoline Near alternator. See Fig. 4 . Coolant Temp. Sender/Sw. (Gas.) Near alternator. See Fig. 4 . Crank. Pos. (Eng. Speed) Sensor Diesel Above crankshaft pulley. Gasoline On right side of transmission bellhousing. See Fig. 6 . Fuel Gauge Sending Unit In fuel tank. Intake Air Temp. Sensor (Diesel) On top of intake plenum, to rear of air intake tube attachment. See Fig. 5 . Low Fuel Sensor In fuel gauge sending unit. Manifold Absolute Pressure (MAP) Sensor On front of throttle body. See Fig. 3 . Oil Pressure Sender/Switch Diesel On left side of cylinder block, near power steering pump. See Fig. 5 . Gasoline Near distributor. See Fig. 3 . Power Brake Vacuum Sensor (Diesel) On left fender panel, below hood hinge. RABS Sensor On differential housing. Throttle Position (TP) Sensor Diesel On injection pump. Gasoline On left side of throttle body. See Fig. 3 . Vehicle Speed (Distance) Sensor 2WD On left side of transmission tailshaft housing. 4WD On left side of transfer case. Water-In-Fuel Sensor (Diesel) At bottom of fuel filter, in drain valve. See Fig. 7 .
Dodge Pickup D250 1993 - MOTORS
Dodge Pickup D250 1993 MOTORS LOCATION
Component Location Blower Motor At right end of engine compartment firewall. Idle Air Control Motor On back of throttle body. See Fig. 3 . Windshield Washer Motor On bottom of windshield washer reservoir. Windshield Wiper Motor On center of firewall.
Dodge Pickup D250 1993 - SOLENOIDS & SOLENOID VALVES
Dodge Pickup D250 1993 SOLENOIDS & SOLENOID VALVES LOCATION
Component Location Canister Purge Solenoid Above rear end of left valve cover. See Fig. 3 . Electronic Modulated Converter Clutch (EMCC) Solenoid 3-Speed On left side of trans., where main case mates with tailshaft housing. 4-Speed (Overdrive) On left side of trans., mounted vertically (part of overdrive solenoid). EGR Solenoid (Calif.) Near EGR valve (part of EET transducer). See Fig. 4 . Fuel Shut-Off Solenoid (Diesel) On top of injector pump. See Fig. 5 . KSB Solenoid (Diesel) On left side of injector pump. See Fig. 5 . Overdrive Solenoid On left side of trans., mounted vertically (part of EMCC solenoid). RABS Dual Solenoid Valve On left frame rail, near rear axle.
Dodge Pickup D250 1993 - SWITCHES
Dodge Pickup D250 1993 SWITCHES LOCATION
Component Location A/C Clutch Cycling & Low-Pressure Switches At right end of engine compartment firewall, on or near "H" valve. Back-Up Light Switch A/T On left side of trans., near bottom (part of neutral safety switch). M/T On left side of transmission, near top. Brake/Stoplight Switch (Cruise) On brake pedal bracket. Brake Warning Light Switch Below master cylinder, on combination valve. Clutch Switch (Cruise) On clutch pedal bracket. Coolant Thermoswitch (Diesel - A/T) On left side of cylinder head, behind fuel filter. See Fig. 7 . Liftgate Ajar Switch In liftgate latch assembly. Neutral Safety Switch (A/T) On left side of trans., near bottom (part of back-up light switch). Oil Pressure Sender/Switch Diesel On left side of cylinder block, near power steering pump. See Fig. 5 . Gasoline Near distributor. See Fig. 3 . Seat Belt Switch In driver's seat belt buckle. Trans. Thermal Switch (Diesel) On left side of trans., near front left corner of valve body. Transfer Case Switch (4WD) On top of transfer case. 4WD Indicator Switch On front axle tube.
Dodge Pickup D250 1993 - MISCELLANEOUS
Dodge Pickup D250 1993 MISCELLANEOUS LOCATION
Component Location A/C Clutch Diode Near A/C compressor, in electrical connector. Air Intake Heaters (Diesel) On top of intake plenum, forward of air inlet tube. Blower Motor At right end of engine compartment firewall. Blower Motor Resistor Under right side of dash, on top of A/C-heater duct. Diagnostic Connectors Ignition Off Draw In left rear corner of engine compartment, on harness. See Fig. 1 . RABS Data Link Under right side of dash, taped to RABS module harness. PCM Data Link At left fender panel, near PCM. See Fig. 3 . Diode & Mold Assy. (Ramcharger) At left "C" pillar. Electr. EGR Transducer (Calif.) On top of EGR valve. See Fig. 4 . Fuel Heater (Diesel) At top of fuel filter, on adapter plate. See Fig. 7 .
Dodge Pickup D250 1993 - COMPONENT LOCATION GRAPHICS
NOTE:
Fig.res may show multiple component locations. - appropriate table for proper figure references.
Fig. 1: Dodge Pickup D250 1993 - Component Locations - Component Locations (1 Of 7)
Fig. 2: Dodge Pickup D250 1993 - Component Locations - Component Locations (2 Of 7)
Fig. 3: Dodge Pickup D250 1993 - Component Locations - Component Locations (3 Of 7)
Fig. 4: Dodge Pickup D250 1993 - Component Locations - Component Locations (4 Of 7)
Fig. 5: Dodge Pickup D250 1993 - Component Locations - Component Locations (5 Of 7)
Fig. 6: Dodge Pickup D250 1993 - Component Locations - Component Locations (6 Of 7)
Fig. 7: Dodge Pickup D250 1993 - Component Locations - Component Locations (7 Of 7)
