FUSES & CIRCUIT BREAKERS Fuses & Circuit Breakers 1993-95 Jeep
Jeep Cherokee Country 1995 - IDENTIFICATION FUSES & CIRCUIT BREAKERS
The fuse block is to the left of the steering column, under the instrument panel.
Fig. 1: Jeep Cherokee Country 1995 - Component Locations - Fuse Panel Identification (1993-95)
Jeep Cherokee Country 1995 - FUSE & CIRCUIT BREAKER I.D. (PASSENGER COMPARTMENT) 1 - 25 Amp (Natural)
Rear Window Wiper, Washer.
Jeep Cherokee Country 1995 - 2 - 15 Amp (Lt. Blue)
Radio, Cigar Lighter, Dome Lamp (1993).
Jeep Cherokee Country 1995 - 3 - Not Used
Not Used.
Jeep Cherokee Country 1995 - 4 - 15 Amp (Lt. Blue)
Flash to Pass.
Jeep Cherokee Country 1995 - 5 - 25 Amp (Natural) (1992)
Blower Motor.
Jeep Cherokee Country 1995 - 6 - 30 Amp (Circuit Breaker)
Power Windows.
Jeep Cherokee Country 1995 - 7 - 2 Amp (Pink)
Antilock Brakes (ABS).
Jeep Cherokee Country 1995 - 8 - 20 Amp (Yellow)
Turn Signal Flasher.
Jeep Cherokee Country 1995 - 9 - 10 Amp (Red)
Radio/Clock & Memory, Courtesy Lights, Glove Box, Cargo, Dome Lamps, Telltales.
Jeep Cherokee Country 1995 - 10 - Not Used
Not Used.
Jeep Cherokee Country 1995 - 11 - 25 Amp (Natural)
Headlamp Delay Module, Horns.
Jeep Cherokee Country 1995 - 12 - Not Used
Not Used.
Jeep Cherokee Country 1995 - 13 - 20 Amp (Yellow)
Power Door Locks.
Jeep Cherokee Country 1995 - 14 - Not Used
Not Used.
Jeep Cherokee Country 1995 - 15 - 15 Amp (Lt. Blue)
Instrument Panel Lamps, Clock, Radio/Clock & Memory, Headlamp Switch, Parking Lamps.
Jeep Cherokee Country 1995 - 16 - 30 Amp (Circuit Breaker)
Power Seats, Trailer Tow.
Jeep Cherokee Country 1995 - 17 - 7.5 Amp (Violet)
Instrument Cluster Guages, Headlamp Delay Module, Chime Module, Overhead Console.
Jeep Cherokee Country 1995 - 18 - 25 Amp (Natural)
Heated Rear Window.
Jeep Cherokee Country 1995 - 19 - 5 Amp (Tan)
Instrument Panel Lamps, Radio Illumination.
Jeep Cherokee Country 1995 - 20 - 5.5 Amp (Circuit Breaker)
Windshield Wiper/Windshield Washer.
Jeep Cherokee Country 1995 - RELAY PANEL IDENTIFICATION (1993-95 MODELS)
The relay panel is to the right of the steering column, under the instrument panel.
Jeep Cherokee Country 1995 - RELAY IDENTIFICATION (PASSENGER COPMPARTMENT) 1 - Illuminated Entry Relay (1993-94); Not Used (1995)
No additional definition.
Jeep Cherokee Country 1995 - 2 - Horn Relay (1993-94); Dual Flasher Relay (1995)
No additional definition.
Jeep Cherokee Country 1995 - 3 - Rear Window Defogger Relay
No additional definition.
Jeep Cherokee Country 1995 - 4 - Not Used
No additional definition.
Jeep Cherokee Country 1995 - 5 - Not Used (1993-94); Horn Relay (1995)
No additional definition.
Jeep Cherokee Country 1995 - 6 - Not Used
No additional definition.
Jeep Cherokee Country 1995 - 7 - Not Used
No additional definition.
Jeep Cherokee Country 1995 - 8 - Radio Illumination Relay
No additional definition.
Jeep Cherokee Country 1995 - 9 - Power Door Lock (Unlock) Relay
No additional definition.
Jeep Cherokee Country 1995 - 10 - Power Door Lock (Lock) Relay
No additional definition.
Jeep Cherokee Country 1995 - POWER DISTRIBUTION CENTER IDENTIFICATION (1993-95)
WARNING: Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
Jeep Cherokee Country 1995 - FUSE & CIRCUIT BREAKER I.D. (POWER DISTRIBUTION) 1 - 60 Amp (Blue)
Generator Output.
Jeep Cherokee Country 1995 - 2 - 30 Amp (Green)
Engine Control (ECU) - Fuel Pump, Injectors, Ignition Coil, Oxygen Sensors, Generator Field, Engine Controller Automatic Transmission Controller (ATCU).
Jeep Cherokee Country 1995 - 3 - 40 Amp (Orange)
Fuse Block.
Jeep Cherokee Country 1995 - 4 - 20 Amp (Yellow)
Hazard Lamps.
Jeep Cherokee Country 1995 - 5 - 40 Amp (Orange)
Headlamp Switch.
Jeep Cherokee Country 1995 - 6 - 50 Amp (Red)
Ignition Switch - Engine Controller, Fuel Pump Relay, Automatic Shutdown Relay Coil.
Jeep Cherokee Country 1995 - 7 - 40 Amp (Orange)
Heated Rear Window, Starter Solenoid.
Jeep Cherokee Country 1995 - 8 - 40 Amp (Orange)
ABS Pump Motor.
Jeep Cherokee Country 1995 - 9 - 60 Amp (Blue)
Generator Output.
Jeep Cherokee Country 1995 - 10 - 30 Amp (Green)
ABS System.
Jeep Cherokee Country 1995 - 11 - 15 Amp (Blue)
Ignition Switch - Back-up Lamps, A/C Relay Coil, Shift Selector, Speed Control, Aux. Cooling Fan Relay Coil.
Jeep Cherokee Country 1995 - 12 - 10 Amp (Red)
Automatic Transmission.
Jeep Cherokee Country 1995 - 13 - 15 Amp (Blue)
Auxilliary Lamps - Fog Lamps, Underhood Lamps.
Jeep Cherokee Country 1995 - 14 - 20 Amp (Yellow)
Engine Controller.
Jeep Cherokee Country 1995 - 15 - 20 Amp (Yellow)
Aux. Cooling Fan.
Jeep Cherokee Country 1995 - 16 - 10 Amp (Red)
Ignition Off Draw (1993), Radio/Clock Memory, Ignition Off Draw, Dome Courtesy (1994-95).
Jeep Cherokee Country 1995 - RELAY IDENTIFICATION (POWER DISTRIBUTION)
- A - Aux. Cooling Fan Relay
- B - Fuel Pump Relay
- C - ABS Pump Relay
- D - Air Conditioning Relay
- E - Auto Shutdown Relay
- F - Starter Relay
- G - ABS System Relay
Jeep Cherokee Country 1995 - CAUTIONS & WARNINGS BATTERY
WARNING: When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See the COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section.
Jeep Cherokee Country 1995 - SUPPLEMENTAL RESTRAINT (AIR BAG SYSTEM) (IF EQUIPPED)
WARNING: The Diagnostic Energy Reserve Module (DERM) can maintain enough voltage to cause a deployment of the Inflator Module for up to 10 minutes after the Ignition Switch is turned off and the battery is disconnected. Many of the service procedures require disconnection of the Inflator Module to avoid an accidental deployment.
