Honda CR-V EX 2007 - 2007 ELECTRICAL Fuses & Circuit Breakers - CR-V
Honda CR-V EX 2007 - IDENTIFICATION
CAUTION: When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See appropriate COMPUTER RELEARN PROCEDURES articles in GENERAL INFORMATION before disconnecting battery.
Honda CR-V EX 2007 - DRIVER'S UNDER-DASH FUSE/RELAY BOX
NOTE: Driver's under-dash fuse/relay box is located under driver's side of instrument panel. See Fig. 1.
Fig. 1: Honda CR-V EX 2007 - Component Locations - Locating Driver's Under-Dash Fuse/Relay Box
Honda CR-V EX 2007 Under-Dash Fuse/Relay Box Fuses
Fuse Number Fuse Name Amps Component or Circuit Protected 1 IG 1 P/W 7.5A MICU, Moonroof Control Unit/Motor (EX, EX-L) 2 FUEL PUMP 15A Immobilizer-Keyless Control Unit, MICU, PCM, PGM-FI Main Relay 2 3 ALTERNATOR 10A Alternator, Brake Pedal Position Switch, CMP Sensor A, ELD Unit, EVAP Canister Purge Valve, MAF/IAT Sensor, Secondary HO2S 4 VSA 7.5A MICU, VSA Modulator-Control Unit, Yaw Rate-Lateral Acceleration Sensor 5 H/SEAT 15A Driver's Seat Heater Relay (Low) (EX-L), Driver's Seat Heater Relay (High) (EX-L) 6 FR FOG 20A Not Used 7 - - Not Used 8 IG1 RR WIPER 10A Rear Window Wiper Motor 9 IG1 ODS 7.5A ODS Unit, Hazard Warning Switch/Passenger's Airbag Cut-off Indicator, MICU, SRS Unit 10 METER 7.5A Gauge Control Module, MICU, Shift Lock Solenoid, TPMS Control Unit 11 SRS 10A MICU, SRS Unit 12 H/L R HIGH 10A Right Headlight (High Beam) 13 H/L L HIGH 10A Left Headlight (High Beam) 14 SMALL (INTR) 7.5A Ambient Light (LX), Audio Remote Switch (EX, EX-L), Audio Unit (LX, EX; EX-L except Navigation), Climate Control Unit (EX-L), Cruise Control Set/Resume/Cancel Switch, D3 Switch/Park-Pin Switch, Driver's Seat Heater Switch, Front Passenger's Seat Heater Switch (EX-L), Glove Box Light, Hazard Warning Switch/Passenger's Airbag Cut-Off Indicator, HVAC Control Unit (LX, EX, EX-L), VTEC Oil Pressure Switch (EX, EX-L), Navigation Unit (EX-L: Navigation), Power Mirror Switch, Voice Control Switch (EX-L: Navigation), VSA OFF Switch 15 SMALL (EXTR) 7.5A Left Front Parking Light, License Plate Light, Taillights, Trailer Lighting Connector (Option Connector), Right Front Parking Light 16 H/L R LOW 10A Right Headlight (Low Beam) 17 H/L L LOW 10A Left Headlight (Low Beam) 18 H/L HIGH MAIN 20A MICU 19 SMALL MAIN 15A MICU 20 +B TRMS 7.5A MICU, TPMS Control Unit 21 H/L LOW MAIN 20A MICU 22 - - Not Used 23 - - Not Used 24 MOONROOF 20A Moonroof Control Unit/Motor (EX, EX-L) 25 DOOR LOCK 20A MICU 26 DR P/W 20A Power Window Master Switch/Driver's Door Lock Switch 27 +B HAC OP 20A Not Used 28 RR ACC SOCKET 15A Cargo Area Accessory Power Socket Relay 29 +B ACC 15A Front Accessory Power Socket Relay 30 AS P/W 20A Front Passenger's Power Window Switch, Power Window Master Switch/Driver's Door Lock Switch 31 +B CTR TABLE ACC 15A Console Accessory Power Socket Relay (EX, EX-L) 32 RR R P/W 20A Right Rear Power Window Switch, Power Window Master Switch/Driver's Door Lock Switch 33 +B P/W RR L 20A Left Rear Power Window Switch, Power Window Master Switch/Driver's Door Lock Switch 34 ACC RADIO 7.5A Audio Unit (LX, EX; EX-L except Navigation), Cargo Area Accessory Power Socket Relay, Console Accessory Power Socket Relay, Front Accessory Power Socket Relay, MICU, Navigation Unit (EX-L: Navigation), Stereo Amplifier (EX-L: Navigation) 35 ACC KEYLOCK 7.5A Ignition Key Switch Light, MICU 36 IG2 HAC 10A A/C Compressor Clutch Relay, Blower Motor Relay, Driver's Seat Heater Switch (EX-L), Fan Control Relay, Front Passenger's Seat Heater Switch (EX-L), HVAC Control Unit (LX, EX, EX-L), MICU, Power Mirror Switch, Radiator Fan Relay, Rear Window Defogger Relay, Recirculation Control Motor (LX, EX, EX-L) 37 DAY LIGHT 7.5A MICU 38 FR WIPER 30A MICU
Honda CR-V EX 2007 - UNDER-HOOD FUSE/RELAY BOX
NOTE: Under-hood fuse/relay box is located in right side of engine compartment. See Fig. 3.
Fig. 3: Honda CR-V EX 2007 - Component Locations - Locating Under-Hood Fuse/Relay Box
Fig. 4: Honda CR-V EX 2007 - Component Locations - Identifying Under-Hood Fuse/Relay Box Components
Honda CR-V EX 2007 Under-Hood Fuse/Relay Box Fuses
Fuse Number Fuse Name Amps Component or Circuit Protected 1 MAIN FUSE 100A Alternator, Multi-fuse 2, Fuses 4, 6, 7, 8, 9, 19, 20, 21, 22 and 23 in Under-hood Fuse/Relay Box EPS 70A Not Used 2 OP MAIN 80A Fuses 5, 6, 7, 28, 29, and 31 in Under-dash Fuse/Relay Box IG MAIN 50A Ignition Switch 3 VSA MTR 40A VSA Modulator-Control Unit VSA FSR 20A VSA Modulator-Control Unit 4 H/L MAIN 50A Fuses 18, 19, 20 and 21 in Under-dash Fuse/Relay Box P/W MAIN 40A Fuses 24, 25, and 26 in Under-dash Fuse/Relay Box, Power Window Relay 5 EPT-R - Not Used 6 SUB FAN MTR 20A A/C Condenser Fan Relay 7 MAIN FAN MTR 20A Radiator Fan Relay 8 RR DEF 30A Rear Window Defogger Relay 9 BLOWER 40A Blower Motor Relay 10 HAZARD 15A Hazard Warning Switch/Passenger's Airbag Cut-off Indicator, MICU, Trailer Lighting Connector (Option Connector) 11 LAF 15A PCM, A/F Sensor, EVAP Canister Vent Shut Valve, PGM-FI Sub-relay 12 STOP&HORN 15A Brake Pedal Position Switch, MICU 13 P/SEAT-REC 20A Not Used 14 P/SEAT-SLI 20A Not Used 15 OIL LVL 7.5A A/C Condenser Fan Diode, A/C Condenser Fan Relay 16 EPT-L - Not Used 17 HI-PWR SOUND 15A Navigation Unit (EX-L: Navigation) 18 IG COIL 15A Ignition Coil Relay 19 FI MAIN 15A PGM-FI Main Relay 1 20 MG CLUTCH 7.5A A/C Compressor Clutch Relay 21 DBW 15A ETCS Control Relay 22 INTR LT 7.5A Cargo Area Light, Ceiling Light, Front Individual May Lights, Ignition Key Switch/Key Light, MICU 23 BACK UP 10A Audio Unit (LX, EX; EX-L except Navigation), DLC, Gauge Control Module, Immobilizer Control Unit-Receiver, MICU, Navigation Unit (EX-L: Navigation)
