Honda CR-V LX 2005 - 2005 ELECTRICAL Fuses & Circuit Breakers - CR-V
Honda CR-V LX 2005 - IDENTIFICATION
CAUTION: When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See appropriate COMPUTER RELEARN PROCEDURES articles in GENERAL INFORMATION before disconnecting battery.
Honda CR-V LX 2005 - DRIVER'S UNDER-DASH FUSE/RELAY BOX
NOTE: Driver's under-dash fuse/relay box is located under driver's side of instrument panel. See Fig. 1.
Fig. 1: Honda CR-V LX 2005 - Component Locations - Locating Driver's Under-Dash Fuse/Relay Box
Honda CR-V LX 2005 Under-Dash Fuse/Relay Box Fuses
Fuse Number Fuse Name Amps Component or Circuit Protected 1 - - Not used 2 RR ACC SOCKET 10A Rear Accessory Power Socket 3
(Canada)- - DRL Control Unit, Multiplex Control Unit 4 ACG 10A Alternator, CMP Sensor A, Cruise Control Main Switch/VSA OFF Switch, ELD Unit, EVAP Canister Purge Valve, EVAP Canister Vent Shut Valve, IMT Valve, Secondary HO2S, VSS (M/T), VSA Modulator-Control Unit 5 - - Not used 6 P/W RELAY 7.5A A/F Sensor Relay, Moonroof Close and Open Relays (USA:, EX, SE; Canada: EX-L), Power Window Master Switch, Power Window Relay 7 SUNROOF 20A Moonroof Close and Open Relays (USA:, EX, SE; Canada: EX-L) 8 ACC RADIO 7.5A Gauge Assembly, Multiplex Control Unit, Shift Lock Solenoid (A/T) 9 RR WIPER 7.5A Front Passenger's Weight Sensor Unit, OPDS Unit, Rear Wiper Control Unit, Wiper/Washer Switch 10 METER 7.5A A/T Reverse Relay (A/T), Back-up Light Switch (M/T), Gauge Assembly, Keyless Receiver Unit, Multiplex Control Unit, Security Control Unit Connector (Honda Accessory) 11 - - Not used 12 DAY LIGHT 7.5A DRL Control Unit (Canada), Multiplex Control Unit 13 SRS 10A SRS Unit 14 HAC MIRROR 10A A/C Compressor Clutch Relay, A/C Condenser Fan Relay, Blower Motor Relay (USA: SE; Canada: EX, EX-L), Power Mirror Switch, Radiator Fan Relay, Rear Window Defogger Relay, Recirculation Control Motor, Seat Heater Relay (USA: SE; Canada: EX-L) 15 FR ACC SOCKET 15A Front Accessory Power Socket Relay 16 HEATED SEAT 20A Seat Heater Relay (USA: SES; Canada: EX-L) 17 FUEL PUMP 15A ECM/PCM, Front Passenger's Airbag Cut-off Indicator, Immobilizer Control Unit, PGM-FI Main Relay 2, SRS Unit 18 ACC CIGAR 15A Audio Unit, Front Accessory Power Socket, Rear Accessory Power Socket Relay 19 TURN LIGHT 7.5A Hazard Warning Switch 20 FR WIPER 20A Multiplex Control Unit, Windshield Wiper Motor, Wiper/Washer Switch 21 - - Not used 22 AS P/W 20A Front Passenger's Power Window Switch, Power Window Master Switch 23 DR P/W 20A Power Window Master Switch 24 RR L P/W 20A Left Rear Power Window Switch, Power Window Master Switch 25 RR R P/W 20A Right Rear Power Window Switch, Power Window Master Switch
Honda CR-V LX 2005 - UNDER-HOOD FUSE/RELAY BOX
NOTE: Under-hood fuse/relay box is located in right side of engine compartment. See Fig. 3.
Fig. 3: Honda CR-V LX 2005 - Component Locations - Locating Under-Hood Fuse/Relay Box
Fig. 4: Honda CR-V LX 2005 - Component Locations - Identifying Under-Hood Fuse/Relay Box Components
Honda CR-V LX 2005 Under-Hood Fuse/Relay Box Fuses
Fuse Number Fuse Name Amps Component or Circuit Protected 1 CONDENSER FAN 20A A/C Compressor Clutch Relay, A/C Condenser Fan Relay 2 ENG 30A A/F Sensor Relay, DRL Relay (Canada), Ignition Coil Relay, No. 31, 32, 33 and 34 Fuses (in the Auxiliary Under-Dash Fuse/Relay Box), PGM-FI Main Relay 1 3 INTERIOR LIGHT 15A Front Ceiling Light, Ignition Key Switch/Key Light, Rear Ceiling Light, Rear Wiper Control Unit, Spotlights, XM Receiver Connector A (USA: EX, SE) (Honda Accessory) 4 COOLING FAN 20A Radiator Fan Relay 5 HAZARD 15A Hazard Warning Switch, Trailer Lighting Connector (Honda Accessory) 6 SMALL LIGHT 15A Taillight Relay 7 HORN, STOP 15A Brake Pedal Position Switch, Horn Relay 8 DBW 15A Throttle Actuator Control Module Relay 9 BACK UP 10A Audio Unit, DLC, Gauge Assembly, Immobilizer Control Unit 10 ABS MOTOR 30A VSA Modulator-Control Unit 11 REAR DEFROSTER 20A Rear Window Defogger Relay 12 HEATER MOTOR 40A Blower Motor Relay 13 POWER WINDOW 40A No. 7 and 23 Fuses (in the Under-Dash Fuse/Relay Box), Power Window Relay 14 OPTION 40A No. 2, 3, 5, 15 and 16 Fuses (in the Under-Dash Fuse/Relay Box) 15 L HEAD LIGHT 20A DRL Control Unit (Canada), Gauge Assembly, Left Headlight 16 DOOR LOCK 20A Multiplex Control Unit 17 R HEAD LIGHT 20A DRL Control Unit (Canada), Right Headlight 18 ABS F/S 30A VSA Modulator-Control Unit 19 BATTERY 100A Battery, Power Distribution 20 IG1 50A Ignition Switch (BAT)
Honda CR-V LX 2005 - AUXILIARY UNDER-HOOD FUSE/RELAY BOX
NOTE: Auxiliary under-hood fuse/relay box is located in right side of engine compartment. See Fig. 3.
Honda CR-V LX 2005 Auxiliary Under-Hood Fuse/Relay Box Fuses
Fuse Number Fuse Name Amps Component or Circuit Protected 31 IG COIL 15A Ignition Coil Relay 32 FI ECU 15A PGM-FI Main Relay 1 33
(Canada)DAY LIGHT 7.5A DRL Relay 34 LAF HEATER 20A A/F Sensor Relay
