Infiniti G35 2003 - 2003 ELECTRICAL Fuses & Circuit Breakers - G35

Infiniti G35 2003 - IDENTIFICATION

WARNING:

Vehicle is equipped with air bag supplemental restraint system. Before attempting ANY repairs involving steering column, instrument panel or related components, see AIR BAG SAFETY PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in AIR BAG RESTRAINT SYSTEMS article in RESTRAINTS.

WARNING:

Always disconnect battery ground cable before servicing high-current fuses. It is recommended that high-current fuses be replaced by a qualified technician.

CAUTION:

When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery.

Infiniti G35 2003 - ENGINE COMPARTMENT JUNCTION & RELAY BLOCKS

NOTE:

For engine compartment fuse, fusible link and relay box locations, see Fig. 1.

Component Locations

Fuse and fusible link block is located at passenger's side of engine compartment. For component identification, see Fig. 6 and Fig. 7 . For circuit wiring diagram, see POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS article.
Relay box No. 1 is located at passenger's side of engine compartment. For component locations, see Fig. 2.
Relay box No. 2 is located at driver's side of engine compartment. For component locations, see Fig. 3.
Fusible link holder is located at passenger's side of engine compartment near battery connectors. For component locations, see Fig. 4. For component identification, see Fig. 6 and Fig. 15 . For circuit wiring diagram, see POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS article.
Intelligent Power Distribution Module (IPDM) is located at passenger's side of engine compartment. For relay locations, see Fig. 5. For component identification, see Fig. 8-Fig. 10 and Fig. 14-Fig. 16 . For circuit wiring diagram, see POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS article.

Fig. 1: Infiniti G35 2003 - Component Locations - Locating Engine Compartment Fuse & Fusible Link Box & Relay Box

Fig. 2: Infiniti G35 2003 - Component Locations - Locating Relay Box No. 1 Relays

Fig. 3: Infiniti G35 2003 - Component Locations - Locating Relay Box No. 2 Relays

Fig. 4: Infiniti G35 2003 - Component Locations - Locating Fusible Link Holder Components

Fig. 5: Infiniti G35 2003 - Component Locations - Locating Intelligent Power Distribution Module Relays

Fig. 6: Infiniti G35 2003 - Component Locations - Identifying Circuit Protection Components (1 Of 11)

Fig. 7: Infiniti G35 2003 - Component Locations - Identifying Circuit Protection Components (2 Of 11)

Fig. 8: Infiniti G35 2003 - Component Locations - Identifying Circuit Protection Components (3 Of 11)

Fig. 9: Infiniti G35 2003 - Component Locations - Identifying Circuit Protection Components (4 Of 11)

Fig. 10: Infiniti G35 2003 - Component Locations - Identifying Circuit Protection Components (5 Of 11)

Fig. 11: Infiniti G35 2003 - Component Locations - Identifying Circuit Protection Components (6 Of 11)

Fig. 12: Infiniti G35 2003 - Component Locations - Identifying Circuit Protection Components (7 Of 11)

Fig. 13: Infiniti G35 2003 - Component Locations - Identifying Circuit Protection Components (8 Of 11)

Fig. 14: Infiniti G35 2003 - Component Locations - Identifying Circuit Protection Components (9 Of 11)

Fig. 15: Infiniti G35 2003 - Component Locations - Identifying Circuit Protection Components (10 Of 11)

Fig. 16: Infiniti G35 2003 - Component Locations - Identifying Circuit Protection Components (11 Of 11)

Infiniti G35 2003 - INSTRUMENT PANEL JUNCTION & RELAY BLOCKS

NOTE:

For instrument panel and passenger area fuse block, relay, control module and unit locations, see Fig. 17 and Fig. 18 .

Component Locations

Circuit breaker is located behind driver's side kick panel. For component identification, see Fig. 6.
Fuse block is located behind driver's side kick panel. For component identification, see Fig. 7, Fig. 11-Fig. 14 and Fig. 16 . For circuit wiring diagram, see POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS article.
