Diagram sections — 28 (67 total)
AIR CONDITIONING ANTI-LOCK BRAKES ANTI-THEFT BODY CONTROL MODULES COMPUTER DATA LINES COOLING FAN CRUISE CONTROL DEFOGGERS ENGINE PERFORMANCE EXTERIOR LIGHTS GROUND DISTRIBUTION HEADLIGHTS HORN INSTRUMENT CLUSTER INTERIOR LIGHTS POWER ANTENNA POWER DISTRIBUTION POWER DOOR LOCKS POWER MIRRORS POWER SEATS POWER TOP/SUNROOF POWER WINDOWS RADIO STARTING/CHARGING SUPPLEMENTAL RESTRAINTS TRANSMISSION WARNING SYSTEMS WIPER/WASHER
AIR CONDITIONING
2.4L 2.4L, Manual A/C Wiring Diagram (1 of 2) for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Manual A/C Wiring Diagram (1 of 2) for Mitsubishi Eclipse GT 2002: 33 (lower right center of dash) g14 (on left end of dash) g15 (on rear of engine) g10 A-30 A-30-1 A/c switch Air thermo sensor Automatic compressor controller (behind right side of dash) Blower motor (behind right side of dash) Blower relay Blower switch C-108 C-111 Condenser fan motor Fan controller (attached to cooling fan shroud) Fuse 30a Fuse 7.5a Hot at all times Hot in on Illum Ind Inside Interior lights system Junction block (j/b) (on left end of dash) Nca Off Outside Outside/inside air selection damper control motor (behind right side of dash) Radiator fan motor Red Resistor (behind right side of dash, near blower motor) Right center of dash) g14 Thermistor sensor (behind center of dash, on heater unit) 2.4L, Manual A/C Wiring Diagram (2 of 2) for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Manual A/C Wiring Diagram (2 of 2) for Mitsubishi Eclipse GT 2002: 30 (on rear of engine) g10 A/c compressor A/c compressor relay A/c refrigerant temperature switch (on-off: 150 degrees centigrade) (off-on: 120 degrees centigrade) (on rear of a/c compressor) A/t A/t: powertrain control module m/t: engine control module (behind right side of dash) C-49 C-50 C-53 C-54 C-57 Def Defroster switch Dual pressure switch (behind right headlight, on receiver drier) Engine compartment relay box (left side of engine compartment) Engine controls system Fan control relay Foot Fuse 10a Fuse 20a Fusible link 2 50a Hot at all times M/t Mfi relay Nca Off On-off: 200 kpa (28 psi) off-on: 220 kpa (32 psi) On-off: 3140 kpa (455 psi) off-on: 2550 kpa (370 psi) Red Right center of dash) g14
3.0L 3.0L, Manual A/C Wiring Diagram (1 of 2) for Mitsubishi Eclipse GT 2002 List of elements for 3.0L, Manual A/C Wiring Diagram (1 of 2) for Mitsubishi Eclipse GT 2002: 35 (front of left front fender) g11 (lower right center of dash) g14 (on left end of dash) g15 A-30 A-30-1 A/c switch Air thermo sensor Automatic compressor controller (behind right side of dash) Blower motor (behind right side of dash) Blower relay Blower switch C-108 C-111 C12 C13 Condenser fan motor Fan controller (attached to cooling fan shroud) Fuse 30a Fuse 7.5a Hot at all times Hot in on Illum Ind Inside Interior lights system Junction block (j/b) (on left end of dash) Nca Off Outside Outside/inside air selection damper control motor (behind right side of dash) Pnk Radiator fan motor Red Resistor (behind right side of dash, near blower motor) Thermistor sensor (behind center of dash, on heater unit) 3.0L, Manual A/C Wiring Diagram (2 of 2) for Mitsubishi Eclipse GT 2002 List of elements for 3.0L, Manual A/C Wiring Diagram (2 of 2) for Mitsubishi Eclipse GT 2002: 38 (on left end of dash) g15 A/c compressor assembly A/c compressor relay A/t A/t: powertrain control module m/t: engine control module (behind right side of dash) C-42 C-51 C-52 C-55 C-58 C-59 C-62 Combination meter Def Defroster switch Distributor assembly Dual pressure switch (behind right headlight, on receiver drier) Engine compartment relay box (left side of engine compartment) Engine controls system Engine speed detection connector (in engine compartment relay box) Fan control relay Foot Fuse 10a Fuse 20a Fusible link 2 50a G4 (top rear of engine) Hot at all times Lock sensor M/t Magnetic clutch Mfi relay Of left front fender) g11 Off On-off: 200 kpa (28 psi) off-on: 220 kpa (32 psi) On-off: 3140 kpa (455 psi) off-on: 2550 kpa (370 psi) Pnk Red Right center of dash) g14
ANTI-LOCK BRAKES Anti-lock Brakes Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Anti-lock Brakes Wiring Diagram for Mitsubishi Eclipse GT 2002: 35 (inside of respective wheel) (right side of firewall) g2 Abs ecu (right rear corner of engine compartment, on hydraulic unit) Abs ind Abs solenoid valve C-41 C-42 C108 C112 Combination meter Connector lock switch Cruise control, exterior lights & transmissions systems Data link connector (dlc) (partial) (below left side of dash) Ded- icated fuse 5 15a Engine compartment relay box (on left side of engine compartment) Fusible link 3 60a Hot at all times Hot in on Hot in on or start Hydraulic unit J/c 1 (behind left end of dash) Junction block (j/b) (on left end of dash) Left front wheel speed sensor Left rear wheel speed sensor Motor Multi-purpose fuse 12 7.5a Multi-purpose fuse 2 7.5a Nca Off Right front wheel speed sensor Right rear wheel speed sensor Stoplight switch (behind dash, on brake pedal support) Tcl ind Tcl warn ind W/ tcl
ANTI-THEFT Forced Entry Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Forced Entry Wiring Diagram for Mitsubishi Eclipse GT 2002: 44 (base of left "b" pillar) (except convertible) g17 (below left rear seat) (convertible) g17 C101 C108 C112 C117 C118 C119 C42 Combination meter Dedicated fuse 18 10a Eclipse Eclipse spyder Engine compartment relay box (left side of engine compt) Etacs ecu Fusible link 4 40a G11 (behind left headlamp) G14 (lower center dash support) G15 (behind left end of dash) Headlights system Hood switch (in left rear of engine compartment) Horns system Hot at all times Hot in on or start Immobilizer circuit J/c 2 (behind left end of dash) Junction block (on left end of dash) Key reminder switch (closed when key is removed) Left door lock actuator Left door lock key cylinder switch Left door switch Lock Multi- purpose fuse 2 7.5a Nca Off Red Right door lock actuator Right door switch Security ind Theft alarm horn (at left side of engine compartment) Theft- alarm horn relay Trunk lid latch switch (eclipse spyder) liftgate latch switch (eclipse) Trunk lid lock key cylinder switch (eclipse spyder) liftgate lock key cylinder switch (eclipse) Unlock
2.4L 2.4L, Immobilizer Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Immobilizer Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002: 22 Anti-lock brake system Anti-theft alarm circuit C42 C54 C61 Combination meter Dedicated fuse 3 20a Dedicated fuse 5 15a Engine compartment relay box (left side of engine compt) Engine controls system G14 (lower center dash support) Hot at all times Ignition key Ignition key ring antenna Immobilizer ecm (behind center of dash) Key reminder switch Mfi relay (in engine compartment relay box) Nca Powertrain control module (behind right side of dash) Red Security indicator Stoplight switch (behind dash, on brake pedal support) 2.4L, Immobilizer Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Immobilizer Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002: 23 Anti-lock brake system Anti-theft alarm circuit C42 C49 C53 C56 Combination meter Dedicated fuse 3 20a Dedicated fuse 5 15a Engine compartment relay box (left side of engine compt) Engine control module (behind right side of dash) Engine controls system G14 (lower center dash support) Hot at all times Ignition key Ignition key ring antenna Immobilizer ecm (behind center of dash) Key reminder switch Mfi relay (in engine compartment relay box) Nca Red Security indicator Stoplight switch (behind dash, on brake pedal support)
3.0L 3.0L, Immobilizer Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002 List of elements for 3.0L, Immobilizer Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002: 22 (lower center dash support) g14 Anti-lock brake system Anti-theft alarm circuit C42 C55 C63 Combination meter Dedicated fuse 3 20a Dedicated fuse 5 15a Engine compartment relay box (left side of engine compt) Engine controls system Hot at all times Ignition key Ignition key ring antenna Immobilizer ecm (behind center of dash) Key reminder switch Mfi relay (in engine compartment relay box) Nca Powertrain control module (behind right side of dash) Red Security indicator Stoplight switch (behind dash, on brake pedal support) 3.0L, Immobilizer Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002 List of elements for 3.0L, Immobilizer Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002: 22 (lower center dash support) g14 Anti-lock brake system Anti-theft alarm circuit C42 C58 C62 Combination meter Dedicated fuse 3 20a Dedicated fuse 5 15a Engine compartment relay box (left side of engine compt) Engine control module (behind right side of dash) Engine controls system Hot at all times Ignition key Ignition key ring antenna Immobilizer ecm (behind center of dash) Key reminder switch Mfi relay (in engine compartment relay box) Nca Red Security indicator Stoplight switch (behind dash, on brake pedal support)
BODY CONTROL MODULES Body Control Modules Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Body Control Modules Wiring Diagram for Mitsubishi Eclipse GT 2002: 55 (behind left end of dash) joint connector 2 (convertible) (coupe) A10x A11x All times Anti-theft system C101 C102 C108 C112 C117 C118 C119 Column switch Computer data lines Dedicated fuse 11 10a Dedicated fuse 12 10a Dedicated fuse 13 10a Dedicated fuse 14 10a Dedicated fuse 15 7.5a Dedicated fuse 16 7.5a Dedicated fuse 17 10a Dedicated fuse 18 10a Dedicated fuse 8 10a Door locks system Engine compartment relay box (on left side of engine compartment) Engine compartment relay box (on left side of engine compartment) Etacs ecu Exterior lights system Front ecu G11 (behind left headlamp) G15 (behind left end of dash) G16 (behind left end of dash) Headlights system Headlights system, wiper washer system, exterior lights system Horns system Hot Hot at Hot in on In acc Interior lights system Interior lights system, power windows system Joint connector 2 (behind left end of dash) Junction block (on left end of dash) Multi- purpose fuse 14 15a Multi- purpose fuse 15 15a Multi- purpose fuse 2 7.5a Or start Pnk Power window relay Red Warning system Warning systems Wiper washer system
COMPUTER DATA LINES Computer Data Lines Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Computer Data Lines Wiring Diagram for Mitsubishi Eclipse GT 2002: 29 (2.4l) (3.0l) (a/t) (behind center of dash) auto cruise control ecu (behind lower center of dash) srs ecu (m/t) A/t A02 Abs ecu (right rear corner of engine compt) C108 C118 C20 C56 C57 C59 C60 C62 C72 Data link connector (below left side of dash) Engine control module (behind right side of dash) Etacs ecu G14 (lower center dash support) G15 (behind left end of dash) Hot at all times Joint connector 1 (behind left end of dash) Junction block (on left end of dash) M/t Multi- purpose fuse 15 15a Powertrain control module (behind right side of dash)
COOLING FAN Cooling Fan Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Cooling Fan Wiring Diagram for Mitsubishi Eclipse GT 2002: 30 2.4l 3.0l A-30 A-30-1 A/t A/t: C-49 C-50 C-51 C-52 C-53 C-54 C-55 C-58 Condenser fan motor Dedicated fuse 3 20a Engine compartment relay box (left side of engine compt) Engine controls system Fan control relay Fan controller (attached to cooling fan shroud) Fusible link 2 50a G11 (behind left headlamp) Hot at all times M/t M/t: Mfi relay Nca Powertrain control module engine control module (behind right side of dash) Radiator fan motor Red
CRUISE CONTROL Cruise Control Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002 List of elements for Cruise Control Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002: 42 (behind left end of dash) j/c 1 (behind right side of dash) 2.4l a Acc Auto-cruise control ecu (behind center of dash) Auto-cruise control switch Auto-cruise control vacuum pump (on right side of engine compartment) B 3.0l C107 C108 C41 C43 C54 C55 C57 C59 Cancel Clock spring Combination meter Cruise indicator Data link connector Engine control module Engine controls, starting/charging and anti-theft systems G14 (center of dash) Hot at all times Hot in on or start Ignition switch Junction block (on left end of dash) Main Multi- purpose 7.5a Multi- purpose fuse 2 10a Multi- purpose fuse 3 15a Nca Off Red Resume Run Set Start Stoplight switch (on brake pedal support) Throttle position sensor (on throttle body assembly) Vehicle speed sensor (on top right front of transaxle) Cruise Control Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002 List of elements for Cruise Control Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002: 37 (behind left end of dash) j/c 1 (behind left end of dash) j/c 2 (behind right side of dash) 2.4l a Auto-cruise control ecu (behind center of dash) Auto-cruise control switch Auto-cruise control vacuum pump (on right side of engine compartment) B 3.0l C108 C41 C43 C58 C60 C62 Cancel Clock spring Clutch pedal position switch (on clutch pedal support) Combination meter Cruise indicator Data link connector Engine control module) G14 (center of dash) G16 (behind left end of dash) Hot at all times Hot in on or start Junction block (on left end of dash) Main Multi- purpose fuse 15 15a Multi- purpose fuse 2 7.5a Multi- purpose fuse 4 7.5a Nca Red Resume Set Stoplight switch (on brake pedal support) Throttle position sensor (on throttle body assembly) Vehicle speed sensor (on top right front of transaxle)
DEFOGGERS Defoggers Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Defoggers Wiring Diagram for Mitsubishi Eclipse GT 2002: 38 (w/ a/c) (w/o a/c) 30a 7.5a Air conditioning system Automatic compressor controller C101 C108 C45 C46 C46 c45 Capacitor (on rear center of engine) Choke coil Convertible Defogger Defogger relay Except convertible F01 F02 F03 F04 F05 F08 f02 G14 (lower center dash support) G17 (convertible) (below left rear seat) Hot at all times Hot in run Illumination Ind Interior lights system Junction block (behind left side of dash) Multi- purpose fuse 20 Multi- purpose fuse 5 Nca Off Outside/ inside air selection switch (w/o a/c) a/c switch (w/ a/c) Vehicles with glass antenna Vehicles with whip antenna & convertible
ENGINE PERFORMANCE
2.4L 2.4L, Engine Performance Wiring Diagram, with M/T (1 of 2) for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Engine Performance Wiring Diagram, with M/T (1 of 2) for Mitsubishi Eclipse GT 2002: 31 (below intake manifold) (in engine compt relay box) mfi relay (on rear of cylinder head) camshaft position sensor A/c system A/c system, cooling fans system C49 C53 Capacitor (on rear center of engine) Dedicated fuse 3 20a Egr solenoid valve Engine compartment relay box (left side of engine compt) Engine control module (behind right side of dash) Evaporative emission purge solenoid Fuel injectors Fuel pump module G13 (rear of right front fender) G4 (upper rear of engine) G5 (behind right side of dash) G6 (convertible) (below right rear seat) G6 (ex convert) (base of right "b" pillar) Generator Hot at all times Idle air control motor (below throttle body) Ignition coil 1 Ignition coil 2 Instrument cluster system Knock sensor (on side of engine block) Nca Power steering pressure switch (on power steering pump) Red Spark plugs 2.4L, Engine Performance Wiring Diagram, with M/T (2 of 2) for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Engine Performance Wiring Diagram, with M/T (2 of 2) for Mitsubishi Eclipse GT 2002: 44 (below left side of dash) data link connector (dlc) (in exhaust system, after catalytic converter) heated oxygen sensor (rear) (in exhaust system, before catalytic converter) heated oxygen sensor (front) Auto cruise control ecu (behind center of dash) C101 C108 C112 C29 C30 C41 C56 C60 Combination meter Crankshaft position sensor (on lower front of engine, near crankshaft) Dedicated fuse 10 15a Dedicated fuse 18 10a Engine compartment relay box (left side of engine compt) Engine control module (behind right side of dash) Engine coolant temperature sensor (on rear of engine, near coolant outlet) Engine speed detection connector (in engine compt relay box) Evaporative emission ventilation solenoid (under rear of vehicle, near fuel tank) Fuel pump relay Fuel tank differential pressure sensor (top of fuel tank) G13 (rear of right front fender) G15 (behind left end of dash) G5 (behind right side of dash) Hot at all times Hot in on or start Immobilzer ecu Instrument cluster system J/c 1 (behind left side of dash) J/c 2 (behind left side of dash) Junction block (on left end of dash) Malfunction indicator lamp (mil) Manifold differential pressure sensor (on right front of engine) Multi- purpose fuse 1 10a Multi- purpose fuse 2 7.5a Multi- purpose fuse 8 7.5a Nca Red Starting/ charging system Throttle position sensor (on throttle body) Vehicle speed sensor (left side of engine compt, on transaxle) Volume airflow sensor (left side of engine compt, on air cleaner) 2.4L, Engine Performance Wiring Diagram, with Sportronic (1 of 4) for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Engine Performance Wiring Diagram, with Sportronic (1 of 4) for Mitsubishi Eclipse GT 2002: 30 (below intake manifold) (on engine compt relay box) mfi relay (on rear of cylinder head) camshaft position sensor A/c system C50 C54 Capacitor (on rear center of engine) Dedicated 10a Dedicated fuse 3 20a Egr solenoid valve Engine compartment relay box (left side of engine compt) Engine speed detection connector (in engine compt relay box) Evaporative emission purge solenoid Fuel injectors G13 (rear of left front frnder) G4 (upper rear of engine) G5 (behind right side of dash) Generator Hot at all times Idle air control motor (below throttle body) Ignition coil 1 Ignition coil 2 Instrument cluster system J/c 2 (behind left side of dash) Nca Power steering pressure switch (on power steering pump) Powertrain control module (behind right side of dash) Red Spark plugs Starting/ charging system 2.4L, Engine Performance Wiring Diagram, with Sportronic (2 of 4) for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Engine Performance Wiring Diagram, with Sportronic (2 of 4) for Mitsubishi Eclipse GT 2002: 30 (in exhaust system, after catalytic converter) heated oxygen sensor (rear) (in exhaust system, before catalytic converter) heated oxygen sensor (front) Auto cruise control ecu (behind center of dash) C101 C108 C112 C41 Combination meter Crankshaft position sensor (on lower front of engine, near crankshaft) Dedicated fuse 10 15a Engine compartment relay box (left side of engine compt) Engine coolant temperature sensor (on rear of engine) Evaporative emission ventilation solenoid (under rear of vehicle, near fuel tank) Fuel pump relay Fuel tank differential pressure sensor (on top of fuel tank) G15 (behind left end of dash) G5 (behind right side of dash) Hot at all times Hot in on or start Immobilizer ecu (behind center of dash) Junction block (on left end of dash) Malfunction indicator lamp (mil) Manifold differential pressure sensor (on right side of engine) Multi- purpose fuse 1 10a Multi- purpose fuse 2 7.5a Multi- purpose fuse 8 7.5a Nca Red Throttle position sensor (on throttle body) Volume airflow sensor (left side of engine compt, on air cleaner) 2.4L, Engine Performance Wiring Diagram, with Sportronic (3 of 4) for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Engine Performance Wiring Diagram, with Sportronic (3 of 4) for Mitsubishi Eclipse GT 2002: 19 (below left side of dash) data link connector (dlc) Auto mode C29 C30 C41 C43 Combination meter Down Fuel pump module G15 (behind left side of dash) G6 (convertible) (below right rear seat) G6 (ex convert) (base of right "b" pillar) Interior lights system J/c 1 (behind left side of dash) J/c 2 (behind left side of dash) Select switch Shift switch Shift switch assembly Sport mode 2.4L, Engine Performance Wiring Diagram, with Sportronic (4 of 4) for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Engine Performance Wiring Diagram, with Sportronic (4 of 4) for Mitsubishi Eclipse GT 2002: 33 A/c system A/t control relay (on engine compt relay box) A/t control solenoid valve assembly (on top of transaxle) A/t fluid temp C112 C57 C61 Dedicated fuse 5 15a Dedicated fuse 9 20a Engine compartment relay box (left side of engine compt) Exterior lights system G13 (rear of left front fender) G201 (behind right side of dash) G4 (upper rear of engine) G5 (behind right side of dash) Hot at all times Hot in run or start Input shaft speed sensor (on transaxle) Instrument cluster system Junction block (on left end of dash) Knock sensor (on side of engine block) Low/ reverse Multi- purpose fuse 3 7.5a Output shaft speed sensor (on transaxle) Over drive Park/neutral position switch (on transaxle) Powertrain control module (behind right side of dash) Red Second Starting/ charging system Stoplight switch (on brake pedal support) Torque converter control Under drive 2.4L, Engine Performance Wiring Diagram, without Sportronic (1 of 3) for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Engine Performance Wiring Diagram, without Sportronic (1 of 3) for Mitsubishi Eclipse GT 2002: 30 (below intake manifold) (on engine compt relay box) mfi relay (on rear of cylinder head) camshaft position sensor A/c system C50 C54 Capacitor (on rear center of engine) Dedicated 10a Dedicated fuse 3 20a Egr solenoid valve Engine compartment relay box (left side of engine compt) Engine speed detection connector (in engine compt relay box) Evaporative emission purge solenoid Fuel injectors G13 (rear of left front fender) G4 (upper rear of engine) G5 (behind right side of dash) Generator Hot at all times Idle air control motor (below throttle body) Ignition coil 1 Ignition coil 2 Instrument cluster system J/c 2 (behind left side of dash) Nca Power steering pressure switch (on power steering pump) Powertrain control module (behind right side of dash) Red Spark plugs Starting/ charging system 2.4L, Engine Performance Wiring Diagram, without Sportronic (2 of 3) for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Engine Performance Wiring Diagram, without Sportronic (2 of 3) for Mitsubishi Eclipse GT 2002: 33 (in exhaust system, after catalytic converter) heated oxygen sensor (rear) (in exhaust system, before catalytic converter) heated oxygen sensor (front) Auto cruise control ecu (behind center of dash) C101 C108 C112 C41 Combination meter Crankshaft position sensor (on lower front of engine, near crankshaft) Dedicated fuse 10 15a Engine compartment relay box (left side of engine compt) Engine coolant temperature sensor (on rear of engine) Evaporative emission ventilation solenoid (under rear of vehicle, near fuel tank) Fuel pump module Fuel pump relay Fuel tank differential pressure sensor (on top of fuel tank) G15 (behind left end of dash) G5 (behind right side of dash) G6 (convertible) (below right rear seat) G6 (ex convert) (base of right "b" pillar) Hot at all times Hot in on or start Immobilizer ecu (behind center of dash) Junction block (on left end of dash) Malfunction indicator lamp (mil) Manifold differential pressure sensor (on right side of engine) Multi- purpose fuse 1 10a Multi- purpose fuse 2 7.5a Multi- purpose fuse 8 7.5a Nca Red Throttle position sensor (on throttle body) Volume airflow sensor (left side of engine compt, on air cleaner) 2.4L, Engine Performance Wiring Diagram, without Sportronic (3 of 3) for Mitsubishi Eclipse GT 2002 List of elements for 2.4L, Engine Performance Wiring Diagram, without Sportronic (3 of 3) for Mitsubishi Eclipse GT 2002: 37 (below left side of dash) data link connector (dlc) A/c system A/t control relay (on engine compt relay box) A/t control solenoid valve assembly (on top of transaxle) A/t fluid temp C112 C29 C30 C57 C61 Dedicated fuse 5 15a Dedicated fuse 9 20a Engine compartment relay box (left side of engine compt) Exterior lights system G13 (rear of left front fender) G201 (behind right side of dash) G4 (upper rear of engine) G5 (behind right side of dash) Hot at all times Hot in run or start Input shaft speed sensor (on transaxle) Instrument cluster system J/c 1 (behind left side of dash) Junction block (on left end of dash) Knock sensor (on side of engine block) Low/ reverse Multi- purpose fuse 3 7.5a Output shaft speed sensor (on transaxle) Over drive Park/neutral position switch (on transaxle) Powertrain control module (behind right side of dash) Red Second Starting/ charging system Stoplight switch (on brake pedal support) Torque converter control Under drive
3.0L 3.0L, Engine Performance Wiring Diagram, with A/T (1 of 4) for Mitsubishi Eclipse GT 2002 List of elements for 3.0L, Engine Performance Wiring Diagram, with A/T (1 of 4) for Mitsubishi Eclipse GT 2002: 30 (in engine compt relay box) mfi relay A/c system A/c system, cooling fans system C52 C55 Dedicated fuse 18 10a Dedicated fuse 3 20a Detection conn (in engine compt relay box) Distributor Distributor assembly Engine compartment relay box (left side of engine compt) Engine speed Fuel injectors G13 (rear of right front fender) G4 (upper rear of engine) G5 (behind right side of dash) Generator Hot at all times Idle air control motor (below throttle body) Ignition coil Instrument cluster system J/c 2 (behind left side of dash) Nca Power steering pressure switch (on power steering pump) Power trans- istor Powertrain control module (behind right side of dash) Red Starting/ charging system To spark plugs Top dead center sensor 3.0L, Engine Performance Wiring Diagram, with A/T (2 of 4) for Mitsubishi Eclipse GT 2002 List of elements for 3.0L, Engine Performance Wiring Diagram, with A/T (2 of 4) for Mitsubishi Eclipse GT 2002: 37 (in left exhaust manifold) left bank heated oxygen sensor (front) (in left side of exhaust system, after catalytic converter) left bank heated oxygen sensor (rear) (in right exhaust manifold) right bank heated oxygen sensor (front) (in right side of exhaust system, after catalytic converter) Auto cruise control ecu (behind center of dash) C101 C108 C112 C41 Combination meter Crankshaft position sensor (on lower front of engine, near crankshaft) Dedicated fuse 10 15a Engine compartment relay box (left side of engine compt) Engine coolant temperature sensor (on rear center of engine) Evaporative emission ventilation solenoid (under rear of vehicle, near fuel tank) Fuel pump module Fuel pump relay Fuel tank differential pressure sensor (on top of fuel tank) G15 (behind left end of dash) G5 (behind right side of dash) G6 (convertible) (below right rear seat) G6 (ex convert) (base of right "b" pillar) Hot at all times Hot in on or start Immobilizer ecu Junction block (on left end of dash) Malfunction indicator lamp (mil) Manifold differential pressure sensor (on right side of intake manifold) Multi- purpose fuse 1 10a Multi- purpose fuse 2 7.5a Multi- purpose fuse 8 7.5a Nca Pnk Red Right bank heated oxygen sensor (rear) Throttle position sensor (on throttle body) Volume airflow sensor (left side of engine compt, on air cleaner) 3.0L, Engine Performance Wiring Diagram, with A/T (3 of 4) for Mitsubishi Eclipse GT 2002 List of elements for 3.0L, Engine Performance Wiring Diagram, with A/T (3 of 4) for Mitsubishi Eclipse GT 2002: 21 (below left side of dash) data link connector (dlc) (in right rear corner of engine compt) egr solenoid valve (in right rear corner of engine compt) evaporative emission purge solenoid Auto mode C101 C104 C29 C30 C41 C43 Combination meter Down G15 (behind left side of dash) Interior lights system J/c 1 (behind left side of dash) Junction block (on left end of dash) Red Select switch Shift switch Shift switch assembly Sport mode 3.0L, Engine Performance Wiring Diagram, with A/T (4 of 4) for Mitsubishi Eclipse GT 2002 List of elements for 3.0L, Engine Performance Wiring Diagram, with A/T (4 of 4) for Mitsubishi Eclipse GT 2002: 32 A/c system A/t control relay (in engine compt relay box) A/t control solenoid valve assembly (on top of transaxle) A/t oil temp C112 C59 C61 Dedicated fuse 5 15a Engine compartment relay box (left side of engine compt) Exterior lights system, wiper/ washer system G13 (rear of left front fender) G4 (upper rear of engine) G5 (behind right side of dash) Hot at all times Hot in run or start Immobilizer ecu Input shaft speed sensor (on transaxle) Instrument cluster system Junction block (on left end of dash) Knock sensor (under center of intake manifold) Low/ reverse Multi- purpose 7.5a Output shaft speed sensor (on transaxle) Over drive Park/neutral position switch (on transaxle) Powertrain control module (behind right side of dash) Red Second Starting/ charging system Stoplight switch (behind dash, on brake pedal support) Torque converter control Under drive 3.0L, Engine Performance Wiring Diagram, with M/T (1 of 3) for Mitsubishi Eclipse GT 2002 List of elements for 3.0L, Engine Performance Wiring Diagram, with M/T (1 of 3) for Mitsubishi Eclipse GT 2002: 29 (in engine compt relay box) mfi relay A/c system A/c system, cooling fans system C51 C58 Dedicated fuse 18 10a Dedicated fuse 3 20a Detection connector (in engine compt relay box) Distributor Distributor assembly Engine compartment relay box (left side of engine compt) Engine control module (behind right side of dash) Engine speed Fuel injectors G13 (rear of left front fender) G4 (upper rear of engine) G5 (behind right side of dash) Generator Hot at all times Idle air control motor (below throttle body) Ignition coil Instrument cluster system J/c 2 (behind left side of dash) Nca Power trans- istor Red Starting/ charging system To spark plugs Top dead center sensor 3.0L, Engine Performance Wiring Diagram, with M/T (2 of 3) for Mitsubishi Eclipse GT 2002 List of elements for 3.0L, Engine Performance Wiring Diagram, with M/T (2 of 3) for Mitsubishi Eclipse GT 2002: 38 (in left exhaust manifold) left bank heated oxygen sensor (front) (in left side of exhaust system, after catalytic converter) left bank heated oxygen sensor (rear) (in right exhaust manifold) right bank heated oxygen sensor (front) (in right side of exhaust system, after catalytic converter) right bank C101 C108 C112 C41 Combination meter Dedicated fuse 10 15a Engine compartment relay box (left side of engine compt) Engine coolant temperature sensor (on rear center of engine) Evaporative emission ventilation solenoid (under rear of vehicle, near fuel tank) Fuel pump module Fuel pump relay Fuel tank differential pressure sensor (on top of fuel tank) G13 (rear of right front fender) G15 (behind left end of dash) G5 (behind right side of dash) G6 (convertible) (below right rear seat) G6 (ex convert) (base of right "b" pillar) Heated oxygen sensor (rear) Hot at all times Hot in on or start Immobilizer ecu J/c 2 (behind left side of dash) Junction block (on left end of dash) Malfunction indicator lamp (mil) Manifold differential pressure sensor (on right side of intake manifold) Multi- purpose fuse 1 10a Multi- purpose fuse 2 7.5a Multi- purpose fuse 8 7.5a Nca Pnk Red Throttle position sensor (on throttle body) Vehicle speed sensor (left side of engine compt, on transaxle) Volume airflow sensor (left side of engine compt, on air cleaner) 3.0L, Engine Performance Wiring Diagram, with M/T (3 of 3) for Mitsubishi Eclipse GT 2002 List of elements for 3.0L, Engine Performance Wiring Diagram, with M/T (3 of 3) for Mitsubishi Eclipse GT 2002: 17 (below left side of dash) data link connector (dlc) (in right rear corner of engine compt) egr solenoid valve (in right rear corner of engine compt) evaporative emission purge solenoid A/c system Anti-theft system (immobilizer ecu) Auto cruise control ecu (behind center of dash) C29 C30 C62 Crankshaft position sensor (on lower front of engine, near crankshaft) Engine control module (behind right side of dash) G5 (behind right side of dash) Instrument cluster system J/c 1 (behind left side of dash) Knock sensor (under center of intake manifold) Power steering pressure switch (on power steering pump) Red
EXTERIOR LIGHTS Back-up Lamps Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002 List of elements for Back-up Lamps Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002: 12 C112 Except sport mode G17 (base of left "b" pillar) Hot in run or start Junction block (on left end of dash) Left back-up light Multi- purpose fuse 3 7.5a Park/ neutral position switch (on transaxle) Right back-up light Sport mode Transmissions system Wiper/ washer system Back-up Lamps Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002 List of elements for Back-up Lamps Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002: 9 Back-up light switch C112 G17 (base of left "b" pillar) Hot in run or start Junction block (on left end of dash) Left back-up light Multi- purpose fuse 3 7.5a Right back-up light Wiper/washer system Exterior Lamps Wiring Diagram (1 of 2) for Mitsubishi Eclipse GT 2002 List of elements for Exterior Lamps Wiring Diagram (1 of 2) for Mitsubishi Eclipse GT 2002: 40 (behind left end of dash) A10x A11x C101 C112 Capacitor (on left "c" pillar) Convertible Dedicated fuse 15 7.5a Dedicated fuse 16 7.5a Dedicated fuse 18 10a Dedicated fuse 5 15a Dedicated fuse 8 10a Engine compartment relay box (at left side of engine compartment) Except convertible Front ecu G1 (behind right headlamp) G11 (behind left headlamp) G16 G16 (behind left end of dash) G17 (below left rear seat) G9 (left side of hatch door) Gnd Hight mounted stop light (rear shelf) Hight mounted stop light (trunk lid) Hot at all times J/c 1 (behind left end of dash) J/c 2 (behind left end of dash) Junction block (on left end of dash) Left front combination light Left rear combination light Left rear side marker light License plate light Nca Off Power source Right front combination light Right rear combination light Right rear side marker light Stoplight switch (on brake pedal support) Taillight relay Exterior Lamps Wiring Diagram (2 of 2) for Mitsubishi Eclipse GT 2002 List of elements for Exterior Lamps Wiring Diagram (2 of 2) for Mitsubishi Eclipse GT 2002: 36 (lower center dash support) C101 C108 C112 C118 C119 C41 C43 Column switch Combination meter Data link connector (dlc) (under left side of dash) Etacs ecu G14 G15 (behind left end of dash) Gnd Hazard warning light switch Head Hot in on Hot in on or start Interior lights system J/c 1 (behind left end of dash) J/c 2 (behind left end of dash) Junction block (on left end of dash) Left Left turn ind Left turn signal light relay Lighting switch Multi- purpose fuse 2 7.5a Multi- purpose fuse 5 7.5a Off Power source Right Right turn ind Right turn signal light relay Tail Turn signal switch
GROUND DISTRIBUTION Ground Distribution Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Ground Distribution Wiring Diagram for Mitsubishi Eclipse GT 2002: 36 (below right rear seat) (convertible) A/t control relay, engine control module, powertrain control module, vehicle speed sensor Abs ecu Accessory socket, brake fluid level switch, engine control module, knock sensor shield, heated oxygen sensor shields, powertrain control module, Amplifier, connector lock switch, switch, hazard warning light key reminder switch, data link connector, foglight air selection switch, defroster switch, combination meter, right door lock actuator, right door lock key cylinder switch, power window sub-switch, outside/inside switch, a/c switch, cigarette lighter, auto cruise control ecu, immobilizer ecu Battery Combination meter shield, data link connector, combination meter, etacs ecu, column switch, power window main switch, left door lock actuator, left door lock key cylinder switch, blower motor, remote controlled mirror switch, multi-center display unit, rheostat, fuel pump relay, glove box light switch, automatic compressor controller Connector lock switch, right headlight, right front combination light, right foglight, windshield washer motor, windshield wiper motor Dome light assembly, sunroof switch, sunroof motor assembly, vanity mirror lights Ecm/pcm-combination meter shield (3.0l), ignition coil 1 (2.4l), ignition coil 2 (2.4l), ignition failure sensor, powertrain control module, distributor assembly (3.0l), knock sensor shield (2.4l) Fan controller (2.4l), fan control relay (2.4l) Fan controller (3.0l), fan control relay (3.0l), front ecu, left front combination light, left foglight, hood switch Fuel pump module G1 (behind right headlamp) G10 (left side of engine) G11 (behind left headlamp) G12 (near battery) G13 (rear of left front fender) G14 (lower center dash support) G15 (behind left end of dash) G16 (behind left end of dash) G17 (convertible) (below left rear seat) G17 (except convertible) (base of left "b" pillar) G2 (right side of firewall) G3 (right kick panel) G4 (upper rear of engine) G5 (behind right side of dash) G6 (except convertible) (base of right "b" pillar) G7 (center front of roof) G9 (left side of hatch door) Hight mount stoplight (except convertible) Liftgate latch switch, back-up lights, liftgate lock key cylinder switch, motor antenna ecu, convertible top module, high mount stop light (covertible), defogger (convertible), trunk lid latch switch Rear washer motor Starter relay interlock switch, left headlight, left rear combination light, right rear combination light, seat belt switch, clutch pedal position switch, power seat assembly, front ecu, license plate light, left rear side marker light, right rear side marker light, Vehicle speed sensor
HEADLIGHTS Headlights Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Headlights Wiring Diagram for Mitsubishi Eclipse GT 2002: 60 (behind left end of dash) (behind left end of dash) g16 (left side of engine compt) engine compartment relay box A10 A11 Beam C101 C108 C112 C118 C119 C42 C43 Column switch Column- ecu Combination meter Ded- icated fuse 10a Ded- icated fuse 15a Dedicated fuse 11 10a Dedicated fuse 12 10a Dedicated fuse 13 10a Dedicated fuse 14 10a Dimmer/ passing switch Engine compartment relay box (left side of engine compt) Etacs ecu Fog Fog- light relay Fog- light switch Front ecu Front ecu (in engine compt relay box) G1 (behind right headlamp) G11 (behind left headlamp) G14 (lower center dash support) G15 G15 (behind left end of dash) G16 (behind left end of dash) Head Headlight relay high Headlight relay low Hot at all times Hot in on Hot in on or start Ill Interior lights system Joint conn- ector 2 (behind left end of dash) Joint connector 2 (behind left end of dash) Junction block (on left end of dash) Left fog- light Left front door switch Left headlight Lighting switch Multi- purpose fuse 15 15a Multi- purpose fuse 2 7.5a Multi- purpose fuse 5 7.5a Off Red Right fog- light Right headlight Sound systems Tail
HORN Horn Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Horn Wiring Diagram for Mitsubishi Eclipse GT 2002: 9 Clock spring Door locks system Horn (behind left side of front bumper) Horn relay (on engine compt relay box) Horn switch Hot at all times Junction block (behind left side of dash) Multi-purpose fuse 2 15a Nca
INSTRUMENT CLUSTER Instrument Cluster Wiring Diagram (1 of 2) for Mitsubishi Eclipse GT 2002 List of elements for Instrument Cluster Wiring Diagram (1 of 2) for Mitsubishi Eclipse GT 2002: 74 (2.4l a/t) (2.4l m/t) (2.4l) (3.0l a/t) (3.0l m/t) (3.0l) (a/t) (behind left end of dash) (lower center dash support) Abs ind Anti-lock brakes system Anti-theft system Brake fluid level switch (on side of master cylinder) Brake ind C108 C41 C42 C53 C55 c62 c54 C57 c59 C59 c62 c57 C60 Charge ind Combination meter Cruise control system Cruise ind Dedicated fuse 18 10a Door ind Engine compartment relay box (on left side of engine compt) Engine control module (m/t) powertrain control module (a/t) (behind right side of dash) Engine controls system Exterior lights system Foglight ind Fuel gauge Fuel ind Fuel pump & gauge unit (in top of fuel tank) G13 (behind right side of dash) G14 G15 G5 (behind right side of dash) G6 (cov: below right rear seat, except conv: base of right "b" pillar) Headlights system Hi beam ind Hot at all times Hot in on or start Illumination Interior lights system Joint connector 1 (behind left end of dash) Junction block (behind left end of dash) Junction connector 2 (behind left end of dash) Lcd odometer/trip Left turn ind Malfunction ind Multi- Nca Oil ind Oil pressure switch (2.4l: lower right side of engine, 3.0l: lower left side of engine) Parking brake switch Powertrain control module (behind right side of dash) Purpose fuse 2 7.5a Right turn ind Seat belt ind Security ind Speedometer Srs ind Starting/charging system Tachometer Tcl ind Tcl warning ind Temperature gauge To d ind (diagram 2 of 2) To p ind (diagram 2 of 2) Vehicle speed sensor (left side of eng compt, on transaxle) Warning systems Instrument Cluster Wiring Diagram (2 of 2) for Mitsubishi Eclipse GT 2002 List of elements for Instrument Cluster Wiring Diagram (2 of 2) for Mitsubishi Eclipse GT 2002: 39 (behind left end of dash) 1 ind 2 ind 3 ind 4 ind Ambient temperature sensor C108 C118 C37 C38 C43 Combination meter Compass ecu Compass sensor D ind Dedicated fuse 15 7.5a Engine compartment relay box (on left side of engine compt) Engine controls system Engine coolant temperature gauge unit (near coolant outlet) Etacs ecu (behind left side of dash, on junction block) Exterior lights system From cluster illumination (diagram 1 of 2) From foglight ind (diagram 1 of 2) G15 Headlights system Hot in acc or on Hot w/taillight relay energized (front ecu) Interior lights system Joint connector 2 (behind left end of dash) Junction block (behind left end of dash) Junction connector 2 (behind left end of dash) Multi center display unit Multi- N ind P ind Purpose fuse 9 15a R ind Red Sound system
INTERIOR LIGHTS Courtesy Lamps Wiring Diagram, Convertible for Mitsubishi Eclipse GT 2002 List of elements for Courtesy Lamps Wiring Diagram, Convertible for Mitsubishi Eclipse GT 2002: 52 (behind left end of dash) j/c 1 (behind left end of dash) j/c 2 10a A/t C101 C102 C108 C112 C117 C118 C119 C43 C77 C78 Combination meter Dedicated fuse 17 Dedicated fuse 18 Dome light Door Engine compartment relay box (on left side of engine compartment) Etacs ecu G14 (lower center dash support) G15 (behind left end of dash) G17 (base of left "b" pillar) G7 (center front of roof) Hot at all times Hot in acc & on Hot in on & start Junction block (on left end of dash) Key reminder switch Left door lock actuator Left door switch Left vanity mirror light Lock M/t Multi- purpose fuse 14 15a Multi- purpose fuse 2 7.5a Nca Off Off on Pnk Powertrain control module (behind right side of dash) Red Right door switch Right vanity mirror light Trunk lid latch switch Trunk light Trunk light switch Unlock Vehicle speed sensor (on transaxle) W/ anti- theft W/o anti- theft Courtesy Lamps Wiring Diagram, Coupe for Mitsubishi Eclipse GT 2002 List of elements for Courtesy Lamps Wiring Diagram, Coupe for Mitsubishi Eclipse GT 2002: 54 (behind left end of dash) j/c 1 (behind left end of dash) j/c 2 10a A/t C101 C102 C108 C112 C117 C118 C119 C43 C77 C78 Combination meter Dedicated fuse 17 Dedicated fuse 18 Dome light Door Engine compartment relay box (on left side of engine compartment) Etacs ecu G14 (lower center dash support) G15 (behind left end of dash) G17 (base of left "b" pillar) G7 (center front of roof) Hot at all times Hot in acc & on Hot in on & start Junction block (on left end of dash) Key reminder switch Left door lock actuator Left door switch Left vanity mirror light Liftgate latch switch Liftgate light switch Lock Luggage comp- artment light M/t Multi- purpose fuse 14 15a Multi- purpose fuse 2 7.5a Nca Off Off on Pnk Powertrain control module (behind right side of dash) Red Right door switch Right vanity mirror light Unlock Vehicle speed sensor (on transaxle) W/ anti- theft W/ sunroof W/o anti- theft W/o sunroof Instrument Illumination Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Instrument Illumination Wiring Diagram for Mitsubishi Eclipse GT 2002: 35 A-10x A-11x A/t selector lever position illumination light (w/o sport mode trans) Air conditioning switch Ashtray illumination light C108 C22 C41 C43 C86 Column switch Combination meter Dedicated fuse 15 7.5a Engine compartment relay box (on left side of engine compt) Engine controls system (w/sport mode transmission) Foglight switch Front ecu G15 (behind left end of dash) Glove box lamp Glove box light switch Hazard warning light switch Heater control panel illumination light Hot at all times Hot in start & on Illum Illumination J/c 2 (behind left end of dash) Joint connector 1 (behind left end of dash) Junction block (on left end of dash) Multi- center display unit Multi- purpose fuse 2 7.5a Nca Radio/ tape player/ cd changer Rheostat Tail- light relay
POWER ANTENNA Power Antenna Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Power Antenna Wiring Diagram for Mitsubishi Eclipse GT 2002: 20 Antenna feeder cable C112 C22 Dedicated fuse 17 10a Dedicated fuse 18 10a Engine compartment relay box (left side of engine compt) G17 (convertible) (below left rear seat) G17 (except convertible) (base of left "b" pillar) Hot at all times Hot in acc & run Hot in run or start Joint connector 2 (behind left side of dash) Junction block (on left end of dash) Motor antenna Motor antenna assembly (on left side of luggage compt) Motor antenna ecu Multi- purpose fuse 2 7.5a Nca Pnk Radio, tape player & cd changer
POWER DISTRIBUTION Power Distribution Wiring Diagram (1 of 2) for Mitsubishi Eclipse GT 2002 List of elements for Power Distribution Wiring Diagram (1 of 2) for Mitsubishi Eclipse GT 2002: 59 (connected to battery positive terminal) (in front of engine compt relay box) Air conditioning system Air conditioning, anti-theft, cooling fans, transmissions, engine controls systems Air conditioning, cooling fans systems Air conditioning, sound, interior lights, defogger, headlights, transmissions, instrument cluster, exterior lights systems Anti-lock brakes system Anti-lock brakes, cruise control, anti-theft, transmissions, exterior lights systems Anti-theft system Battery Dedicated fuse 1 15a Dedicated fuse 10 15a Dedicated fuse 11 10a Dedicated fuse 12 10a Dedicated fuse 13 10a Dedicated fuse 14 10a Dedicated fuse 15 7.5a Dedicated fuse 16 7.5a Dedicated fuse 18 10a Dedicated fuse 2 15a Dedicated fuse 3 20a Dedicated fuse 4 10a Dedicated fuse 5 15a Dedicated fuse 7 7.5a Dedicated fuse 8 10a Dedicated fuse 9 20a Door locks, ant-theft, horns systems Door locks, exterior lights systems Engine compartment relay box (on left side of engine compartment) Engine controls system Exterior lights system Front ecu Fusible link 1 60a Fusible link 2 50a Fusible link 3 60a Fusible link 4 40a Fusible link 5 30a Fusible link 6 30a Fusible link 7 120a G10 (left side of engine) G12 (near battery) Headlight relay high Headlight relay low Headlights system Headlights system & foglights Headlights, anti-theft systems Nca Off Power tops system Red Sound, door locks, interior lights, headlights, transmissions, warning, instrument cluster, engine controls, power windows, wiper/washer, power tops, exterior lights, anti-theft systems Starting/ charging system Starting/charging system Taillight relay To dedicated fuse 20 (diagram 2 of 2) To dedicated fuse 22 (diagram 2 of 2) To ignition switch (diagram 2 of 2) To multi- purpose fuse 15 (diagram 2 of 2) Transmissions system Power Distribution Wiring Diagram (2 of 2) for Mitsubishi Eclipse GT 2002 List of elements for Power Distribution Wiring Diagram (2 of 2) for Mitsubishi Eclipse GT 2002: 61 (on left end of dash) junction block Acc Accessory socket Air conditioning system Air conditioning, defogger, headlights, power windows, exterior lights systems Anti-lock brakes & power tops Audio systems (amplifier) C108 C111 C113 C66 C67 C70 C71 C78 Cigarette lighter Cruise control system Dedicated fuse 17 10a Dedicated fuse 20 20a Dedicated fuse 22 20a Dedicated fuses (attached to junction block, behind left side of dash) Defogger relay Engine compartment relay box (on left side of engine compartment) Engine controls system Engine controls, starting/ charging systems From fusible link 1 (diagram 1 of 2) From fusible link 4 (diagram 1 of 2) From fusible link 5 (diagram 1 of 2) From multi- purp0se fuse 5 (diagram 2 of 2) G13 (rear of left front fender) G14 (lower center of dash) G5 (behind right side of dash) Ignition switch Joint connector Junction block (on left end of dash) Lock Mirrors systems Multi- purpose fuse 1 10a Multi- purpose fuse 11 7.5a Multi- purpose fuse 12 7.5a Multi- purpose fuse 14 15a Multi- purpose fuse 15 15a Multi- purpose fuse 19 30a Multi- purpose fuse 2 7.5a Multi- purpose fuse 20 30a Multi- purpose fuse 3 7.5a Multi- purpose fuse 4 7.5a Multi- purpose fuse 5 7.5a Multi- purpose fuse 7 20a Multi- purpose fuse 8 7.5a Multi- purpose fuse 9 15a Power tops system Power windows, seats systems Red Sound, door locks, interior lights, wiper/washer systems Start Starting/charging system Systems To defogger relay (diagram 2 of 2) Wiper/washer systems Wiper/washer, door locks, interior lights systems
POWER DOOR LOCKS Power Door Locks Wiring Diagram, with Keyless Entry for Mitsubishi Eclipse GT 2002 List of elements for Power Door Locks Wiring Diagram, with Keyless Entry for Mitsubishi Eclipse GT 2002: 57 (2.4l) (3.0l) (base of left "b" pillar) (except convertible) g17 (behind left end of dash) g15 (below left rear seat) (convertible) g17 A/t C101 C102 C108 C112 C117 C118 C119 C57 C59 Dedicated fuse 17 10a Dedicated fuse 18 10a Door lock switch Eclipse Eclipse spyder Engine compartment relay box (left side of engine compt) Engine controls system Etacs ecu Exterior lights system G14 (lower center dash support) G15 (behind left end of dash) Horns system Hot at all times Hot in on or acc Hot in start or run Instrument cluster system Interior lights system J/c 1 (behind left end of dash) Junction block (on left end of dash) Key reminder switch Left door key cylinder switch Left front door lock actuator Left front door switch Lock M/t Multi- purpose fuse 14 15a Multi- purpose fuse 15 15a Multi- purpose fuse 2 7.5a Nca Pnk Power window main switch Power window sub switch Powertrain control module (behind right side of dash) Red Right front door lock actuator Right front door switch Trunk lid latch switch (eclipse spyder) liftgate latch switch (eclipse) Trunk light switch (eclipse spyder) liftgate light switch (eclipse) Unlock Vehicle speed sensor (on transaxle) W/ anti- theft W/o anti- theft Power Door Locks Wiring Diagram, without Keyless Entry for Mitsubishi Eclipse GT 2002 List of elements for Power Door Locks Wiring Diagram, without Keyless Entry for Mitsubishi Eclipse GT 2002: 51 (2.4l) (3.0l) (base of left "b" pillar) (except convertible) g17 (behind left end of dash) g15 (below left rear seat) (convertible) g17 A/t C101 C108 C112 C117 C118 C119 C57 C59 Dedicated fuse 18 10a Door lock switch Eclipse Eclipse spyder Engine compartment relay box (left side of engine compt) Engine controls system Etacs ecu G14 (lower center dash support) G15 (behind left end of dash) Horns system Hot at all times Hot in start or run Instrument cluster system J/c 1 (behind left end of dash) Junction block (on left end of dash) Key reminder switch Left door key cylinder switch Left front door lock actuator Left front door switch Lock M/t Multi- purpose fuse 15 15a Multi- purpose fuse 2 7.5a Nca Power window main switch Power window sub switch Powertrain control module (behind right side of dash) Red Right door key cylinder switch Right front door lock actuator Right front door switch Trunk lid latch switch (eclipse spyder) liftgate latch switch (eclipse) Trunk light switch (eclipse spyder) liftgate light switch (eclipse) Unlock Vehicle speed sensor (on transaxle) W/ anti- theft W/o anti- theft
POWER MIRRORS Power Mirrors Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Power Mirrors Wiring Diagram for Mitsubishi Eclipse GT 2002: 14 C108 Down G15 (behind left end of dash) Hot in acc or run Joint conn- ector 2 Junction block (on left end of dash) Left Left remote controlled mirror Multi- purpose fuse 11 7.5a Nca Off Remote controlled mirror switch Right Right remote controlled mirror
POWER SEATS Power Seats Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Power Seats Wiring Diagram for Mitsubishi Eclipse GT 2002: 19 Capacitor Down Engine compartment relay box (on left side of engine compt) Front height Front height motor Fusible link 5 30a Fwd G16 (behind left end of dash) Hot at all times Nca Power seat assembly Power seat switch Rear height Rear height motor Recline Reclining motor Rwd Slide Slide motor
POWER TOP/SUNROOF Convertible Top Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Convertible Top Wiring Diagram for Mitsubishi Eclipse GT 2002: 32 2.4l 3.0l A/t C108 C111 C112 C57 C59 Convertible top by-pass switch Convertible top control module (behind left rear seat) Convertible top switch Fuse 30a Fuse 7.5a Fusible link (under front of engine compartment relay box) G13 (rear of left front fender) G17 (below left rear seat) Hot at all times Hot in on Hot in on or start Joint connector 1 Joint connector 2 Junction block (j/b) (under left end of dash) Left quarter power window motor Left topstack drive motor (at left front corner of trunk) M/t Nca Power window relay Power windows system Powertrain control module (behind right side of dash) Right quarter power window motor Right topstack drive motor (at right front corner of trunk) Vehicle speed sensor (vss) (left side of engine compt, on transaxle) Sunroof Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Sunroof Wiring Diagram for Mitsubishi Eclipse GT 2002: 25 C102 C108 C109 C114 C118 C119 Close/ down Dedicated fuse 10a Dedicated fuse 20a Dedicated fuses (attached to junction block, behind left side of dash) Door locks & interior lights systems Etacs ecu G15 (behind left end of dash) G7 (center front of roof) Hot at all times Hot in on Hot in on & start J/c 2 (on left end of dash) Junction block (on left end of dash) Multi- purpose fuse 12 7.5a Multi- purpose fuse 2 7.5a Off Open Sun roof assembly (at front of sun roof opening) Sun roof switch
POWER WINDOWS Power Windows Wiring Diagram, Convertible for Mitsubishi Eclipse GT 2002 List of elements for Power Windows Wiring Diagram, Convertible for Mitsubishi Eclipse GT 2002: 39 Auto down C101 C108 C110 C111 C112 C118 C119 Convertible top control module (behind left rear seat) Dedicated fuse 18 10a Down Engine compartment relay box (left side of engine compartment) Etacs ecu Fuse 2 7.5a Fusible link 5 30a G15 (behind left end of dash) Hot at all times Hot in run or start Joint conn 2 Junction block (on left end of dash) Left door switch Left front Left front power window motor Left quarter Left quarter power window motor Lock Lock switch Nca Off Power tops system Power window main switch Power window relay Power window sub switch Right door switch Right front Right front power window motor Right quarter Right quarter power window motor Unlock Power Windows Wiring Diagram, Coupe for Mitsubishi Eclipse GT 2002 List of elements for Power Windows Wiring Diagram, Coupe for Mitsubishi Eclipse GT 2002: 31 C101 C108 C110 C111 C112 C118 C119 Dedicated fuse 18 10a Down Engine compartment relay box (left side of engine compartment) Etacs ecu Fuse 2 7.5a Fusible link 5 30a G15 (behind left end of dash) Hot at all times Hot in run or start Joint conn 2 Junction block (on left end of dash) Left Left door switch Left front power window motor Lock switch Nca One touch down control circuit Power tops system Power window main switch Power window relay Power window sub switch Right Right door switch Right front power window motor
RADIO Radio Wiring Diagram, with Amplifier for Mitsubishi Eclipse GT 2002 List of elements for Radio Wiring Diagram, with Amplifier for Mitsubishi Eclipse GT 2002: 36 (base of right "b" pillar) Antenna feeder cable Audio amplifier C21 C22 Cd auto changer Center speaker Dedicated fuse 17 10a Dedicated fuse 2 10a Dedicated fuse 20 20a Dedicated fuses (attached to junction block, behind left side of dash) Din cable Engine compartment relay box (left side of engine compt) G14 G17 (base of left "b" pillar) Glass antenna Hot at all times Hot in acc & run Hot in run or start Interior lights system Junction block (on left end of dash) Junction connector 2 (behind left side of dash) Left door speaker Left rear speaker Left tweeter Motor antenna Motor antenna assembly (left side of trunk area) Multi center display unit Nca Pnk Radio, tape player & cd changer Red Right door speaker Right rear speaker Right tweeter Solid state Radio Wiring Diagram, without Amplifier for Mitsubishi Eclipse GT 2002 List of elements for Radio Wiring Diagram, without Amplifier for Mitsubishi Eclipse GT 2002: 23 Antenna feeder cable C21 C22 Cd auto changer Dedicated fuse 17 10a Dedicated fuse 18 10a Din cable Engine compartment relay box (left side of eng compt) Glass antenna (if equipped) Hot in accy or on Interior lights system Junction connector 2 (behind left side of dash) Left door speaker Left rear speaker Left tweeter Multi center display unit Nca Radio & cd player Red Right door speaker Right rear speaker Right tweeter Whip antenna (if equipped)
STARTING/CHARGING Charging Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002 List of elements for Charging Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002: 33 (2.4l) (3.0l) 40a 7.5a Acc Anti-theft system B45 Battery C108 C111 C41 C42 C50 C52 C54 C55 Charge indicator Comb- ination meter Dedicated fuse 7 Engine comp- artment relay box (left side of engine compt) Fusible link 4 Fusible link 7 120a G10 (left side of engine) G12 (near battery) Generator Ignition switch Junction block (on left end of dash) Lock Multi- purpose fuse 2 7.5a Nca Powertrain control module (behind right side of dash) Start Starting circuit Charging Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002 List of elements for Charging Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002: 31 (2.4l) (3.0l) 40a 7.5a Acc Anti-theft system B45 Battery C108 C111 C41 C51 C53 C58 Charge indicator Comb- ination meter Dedicated fuse 7 Engine comp- artment relay box (left side of engine compt) Engine control module (behind right side of dash) Fusible link 4 Fusible link 7 120a G10 (left side of engine) G12 (near battery) Generator Ignition switch Junction block (behind left end of dash) Lock Multi- purpose fuse 2 7.5a Nca Start Starting circuit Starting Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002 List of elements for Starting Wiring Diagram, A/T for Mitsubishi Eclipse GT 2002: 18 Acc Anti-theft system Battery Charging circuit Engine compartment relay box (left side of engine compt) Engine controls system Except sport mode Fusible link 4 40a Fusible link 7 120a G10 (left side of engine) G12 (near battery) Ignition switch Lock Nca Park/ neutral position switch (on transaxle) Sport mode Start Starter Starting Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002 List of elements for Starting Wiring Diagram, M/T for Mitsubishi Eclipse GT 2002: 18 Acc Anti-theft system Battery Charging circuit Engine compartment relay box (left side of engine compt) Engine controls systems Fusible link 4 40a Fusible link 7 120a G10 (left side of engine) G12 (near battery) G16 (behind left end of dash) Ignition switch Interlock switch Lock Nca Start Starter Starter relay (in engine compt relay box)
SUPPLEMENTAL RESTRAINTS Supplemental Restraints Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Supplemental Restraints Wiring Diagram for Mitsubishi Eclipse GT 2002: 28 (behind lower center of dash) g14 C-108 C-41 C-42 C-72 C-74 C72 Clock spring Combination meter Connector lock switch Connector lock switch (connector coupled: on) (connector uncoupled: off) Data link connector (dlc) (partial) (below left side of dash) Driver's side air bag module (squib) Fuse 7.5a Hot in on or start J/c 1 (behind left end of dash) Junction block (on left end of dash) Left side air bag module (squib) (w/side air bag) Left side impact sensor (w/side air bags) (in base of left "b" pillar) Nca Note: connector c-74 is used on vehicle if equipped w/side air bags. Off Passenger's side air bag module (squib) Right side air bag module (squib) (w/side air bag) Right side impact sensor (w/side air bags) (in base of right "b" pillar) Solid state Srs ind. Srs-ecu (behind lower center of dash, near center reinforcement)
TRANSMISSION A/T Wiring Diagram, with Sportronic for Mitsubishi Eclipse GT 2002 List of elements for A/T Wiring Diagram, with Sportronic for Mitsubishi Eclipse GT 2002: 63 (2.4l) (3.0l) (below left side of dash) (rear of left front fender) g13 1 ind 2 ind 3 ind 4 ind A/t control relay (in engine compt relay box) A/t control solenoid valve (on top of transaxle) A/t oil temp Auto C-112 C41 C43 C50 C52 C54 C55 C57 C59 C61 C63 Combination meter Crankshaft position sensor (lower front of engine, near crankshaft) Cruise control system D ind Data link connector Engine compartment relay box (left side of engine compt) Engine controls system Engine coolant temp sensor (rear of engine, near coolant outlet) Exterior lights system Fuse 10a Fuse 15a Fuse 20a Fuse 7.5a G13 (rear of left front fender) G5 (behind right side of dash) Hot at all times Hot in run or start Input shaft speed sensor (on transaxle) J/c 1 (behind left side of dash) J/c 2 (behind left side of dash) Junction block (on left end of dash) Low/ reverse Mfi relay (in engine compt relay box) N ind Ouput shaft speed sensor (on transaxle) Over drive P ind Park/neutral position switch (on transaxle) Powertrain control module (behind right side of dash) R ind Red Second Shift switch Shift switch assembly Sport Starting/ charging system Stoplight switch (on brake pedal support) Throttle position sensor (on throttle body) Torque converter control Under drive A/T Wiring Diagram, without Sportronic for Mitsubishi Eclipse GT 2002 List of elements for A/T Wiring Diagram, without Sportronic for Mitsubishi Eclipse GT 2002: 42 (below left side of dash) (rear of left front fender) g13 A/t control relay (in engine compt relay box) A/t control solenoid valve (on top of transaxle) A/t oil temp C-112 C50 C54 C57 C61 Crankshaft position sensor (lower front of engine, near crankshaft) Cruise control system Data link connector Engine compartment relay box (left side of engine compt) Engine controls system Engine coolant temp sensor (rear of engine, near coolant outlet) Exterior lights system Fuse 10a Fuse 15a Fuse 20a Fuse 7.5a G13 (rear of left front fender) G5 (behind right side of dash) Hot at all times Hot in run or start Input shaft speed sensor (on transaxle) J/c 1 (behind left side of dash) J/c 2 (behind left side of dash) Junction block (on left end of dash) Low/ reverse Mfi relay (in engine compt relay box) Output shaft speed sensor (on transaxle) Over drive Park/neutral position switch (on transaxle) Powertrain control module (behind right side of dash) Red Second Starting/ charging system Stoplight switch (on brake pedal support) Throttle position sensor (on throttle body) Torque converter control Under drive
WARNING SYSTEMS Warning Systems Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Warning Systems Wiring Diagram for Mitsubishi Eclipse GT 2002: 33 (left side of dash) j/c 1 (left side of dash) j/c 2 (under left side of dash) C101 C108 C112 C117 C118 C119 C41 C42 Column switch Combination meter Data link connector (partial) Dedicated fuse 18 10a Engine compartment relay box (left side of engine compt) Etacs ecu G14 (lower center dash support) G15 (behind left end of dash) G16 (behind left end of dash) Head/tail lamp on Headlights system Hot at all times Hot in run J/c 2 (left side of dash) Junction block (on left end of dash) Key reminder switch Left front door switch Multi- purpose fuse 2 10a Nca Or start Seat belt ind Seat belt switch
WIPER/WASHER Front Wiper/Washer Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Front Wiper/Washer Wiring Diagram for Mitsubishi Eclipse GT 2002: 52 (2.4l) (3.0l) A/t A10x A11x Acc & on C108 C112 C118 C119 C57 C59 Circuit breaker Column ecu Column switch Dedicated fuse 17 10a Dedicated fuse 18 10a Engine compartment relay box (left side of engine compartment) Etacs-ecu Fast Front ecu (in engine compartment relay box) G1 (behind right headlamp) G11 (behind left headlamp) G15 (behind left end of dash) High Hot at all times Hot in Hot in acc & on Hot in on Instrument cluster system Int Int control J/c 1 (behind left end of dash) J/c 2 J/c 2 (behind left end of dash) Junction block (on left end of dash) Low M/t Mist Multi- purpose fuse 2 7.5a Multi- purpose fuse 5 7.5a Multi- purpose fuse 7 20a Off Park switch Pnk Powertrain control module (behind right side of dash) Slow Start or on Vehicle speed sensor (on transaxle) Wash Windshield washer motor (in washer fluid reservoir) Windshield wiper motor (in right rear of engine compt) Rear Wiper/Washer Wiring Diagram for Mitsubishi Eclipse GT 2002 List of elements for Rear Wiper/Washer Wiring Diagram for Mitsubishi Eclipse GT 2002: 50 (behind left end of dash) g15 A/t A10x A11x Acc or on Back-up light switch C101 C108 C112 C117 C118 C119 C59 Capacitor Column ecu Column switch Dedicated fuse 17 10a Dedicated fuse 18 10a Engine compartment relay box (left side of engine compartment) Etacs-ecu Exterior lights systyem Front ecu (in engine compt relay box) G11 (behind left headlamp) G15 (behind left end of dash) G3 (right kick panel) Hot Hot at all times Hot in Hot in acc or on In on Instrument cluster system Intermittent J/c 1 (behind left end of dash) J/c 2 (behind left end of dash) Junction block (on left end of dash) M/t Multi- purpose fuse 14 15a Multi- purpose fuse 2 7.5a Multi- purpose fuse 3 7.5a Multi- purpose fuse 5 7.5a Nca Off Park/neutral position switch (left side of eng compt, on transaxle) Powertrain control module (behind right side of dash) Rear washer motor (in washer fluid reservoir) Rear washer switch Rear wiper motor (in liftgate) Start or on Transmissions system Vehicle speed sensor (on transaxle)
