DEFOGGERS Defogger Wiring Diagram for Nissan 240SX SE 1991 List of elements for Defogger Wiring Diagram for Nissan 240SX SE 1991: 19 (right "c" pillar) (right side of hatch door) Condenser Coupe Fastback Fuse b 10a Fuse block (left side of i/p) Fuse s 20a Fuse t 20a G203 (right side kick panel) Hot at all times Hot in run or start Illum. Interior lights system Nca On ind. Rear window defogger Rear window defogger relay (left side of i/p) Rear window defogger switch Time control unit (left kick panel)
HORN Horn Wiring Diagram for Nissan 240SX SE 1991 List of elements for Horn Wiring Diagram for Nissan 240SX SE 1991: 12 Cruise control steering switch Fuse & fusible link box Fuse 2 10a High pitch horn Horn relay (in engine compartment relay block) Horn switch Hot at all times Low pitch horn Nca Slip ring W/ cruise control W/o cruise control
POWER ANTENNA Power Antenna Wiring Diagram for Nissan 240SX SE 1991 List of elements for Power Antenna Wiring Diagram for Nissan 240SX SE 1991: 11 Auto antenna timer (left rear of luggage compartment) Fuse b 10a Fuse block Fuse d 10a Fuse r 10a G407 (center rear of trunk) Hot at all times Hot in acc or on Hot in on or start Power antenna motor Radio
POWER DOOR LOCKS Power Door Lock Wiring Diagram for Nissan 240SX SE 1991 List of elements for Power Door Lock Wiring Diagram for Nissan 240SX SE 1991: 13 Circuit breaker (left kick panel) Door lock timer (right kick panel) Driver's side door lock actuator Driver's side lock knob switch G203 (right kick panel) Hot at all times Limit switch Lock Locked Passenger's side door lock actuator Passenger's side lock knob switch Unlock Unlocked
POWER MIRRORS Power Mirror Wiring Diagram for Nissan 240SX SE 1991 List of elements for Power Mirror Wiring Diagram for Nissan 240SX SE 1991: 11 Fuse block Fuse e 10a G300 (below left front seat) Hot in acc or on Left side door mirror Left/right Mirror position switch Mirror select switch Power mirror switch Right side door mirror Up/down
POWER WINDOWS Power Window Wiring Diagram for Nissan 240SX SE 1991 List of elements for Power Window Wiring Diagram for Nissan 240SX SE 1991: 13 Auto Circuit breaker (left side of dash, in fuse/ relay block) G304 (below left rear seat) Hot at all times Ignition relay (left side of dash, in fuse/relay block) Left front power window motor Lock switch Off Power tops system Power window amplifier (left front door) Power window main switch Right front power window motor Right front power window switch
RADIO Radio Wiring Diagrams, Integrated with Active Speaker for Nissan 240SX SE 1991 List of elements for Radio Wiring Diagrams, Integrated with Active Speaker for Nissan 240SX SE 1991: 20 Amplification unit Antenna Cassette player (w/ radio) Fuse block Fuse d 10a Fuse r 10a G201 (right side of i/p) Hot at all times Hot in acc or run Interior lights system Left front speaker Left rear speaker Nca Pnk Power antenna system Rear speaker amplifier (behind rear seat) Red Right front speaker Right rear speaker Window antenna Radio Wiring Diagrams, Integrated without Active Speaker for Nissan 240SX SE 1991 List of elements for Radio Wiring Diagrams, Integrated without Active Speaker for Nissan 240SX SE 1991: 17 Antenna Cassette player (w/ radio) Fuse block Fuse d 10a Fuse r 10a Hot at all times Hot in acc or run Interior lights system Left front speaker Left rear speaker Nca Pnk Power antenna system Red Right front speaker Right rear speaker Window antenna Radio Wiring Diagrams, Remote with Active Speakers for Nissan 240SX SE 1991 List of elements for Radio Wiring Diagrams, Remote with Active Speakers for Nissan 240SX SE 1991: 21 Amplification unit Antenna Cassette deck Fuse block Fuse d 10a Fuse r 10a G201 (right side of i/p) Hot at all times Hot in acc or run Left front speaker Left rear speaker Nca Pnk Power antenna system Radio Rear speaker amplifier (behind rear seat) Red Right front speaker Right rear speaker W/ cassette Window antenna Radio Wiring Diagrams, Remote without Active Speakers for Nissan 240SX SE 1991 List of elements for Radio Wiring Diagrams, Remote without Active Speakers for Nissan 240SX SE 1991: 19 Antenna Cassette deck Fuse block Fuse d 10a Fuse r 10a Hot at all times Hot in acc or run Interior lights system Left front speaker Left rear speaker Nca Pnk Power antenna system Radio Red Right front speaker Right rear speaker W/ cassette Window antenna
STARTING/CHARGING Charging Wiring Diagram for Nissan 240SX SE 1991 List of elements for Charging Wiring Diagram for Nissan 240SX SE 1991: 20 (w/ heads up display) (w/o heads up display) Alternator Battery Bulb check relay (in fuse/relay block, left side of i/p) Charge indicator Fuse 4 10a Fuse 8 10a Fuse block Fuse/ fusible link box (in relay box, right front fender) G103 (right front shock tower) G12 G201 (right side of i/p) Hot in on or start Instrument cluster Instument cluster system Nca Pnk Smj (left side of i/p) Starter motor Starting Wiring Diagram for Nissan 240SX SE 1991 List of elements for Starting Wiring Diagram for Nissan 240SX SE 1991: 15 A/t Acc Battery Clutch interlock switch (left kick panel) Fuse/ fusible link box (in relay box, right front fender) G100 (front of left front fender) Ignition switch Inhibitor switch (on transmission) Interlock relay (front right fender) M/t canada M/t usa Nca Off Start Starter motor
WIPER/WASHER Front Wiper/Washer Wiring Diagram for Nissan 240SX SE 1991 List of elements for Front Wiper/Washer Wiring Diagram for Nissan 240SX SE 1991: 23 A10 A11 B10 B11 B12 D12 Fuse block Fuse d 10a Fuse f 20a G101 (right front fender) G203 (right kick panel) Hot in acc or on Int Inter- mittent Off Pnk Smj (left side of dash) Time control unit (left kick panel) Wash Washer motor (right front fender) Wiper & washer switch Wiper amplifier (left side of safety wall) (w/o abs) (right side of safety wall) (w/ abs) Wiper motor Rear Wiper/Washer Wiring Diagram for Nissan 240SX SE 1991 List of elements for Rear Wiper/Washer Wiring Diagram for Nissan 240SX SE 1991: 14 A12 C12 Fuse block Fuse e 20a G203 (right kick panel) G407 (center rear of trunk) Hot in acc or on Interior lights system Nca Rear washer motor (right front fender) Rear wiper & washer switch Rear wiper amplifier (center rear of trunk) Rear wiper motor Smj (left side of dash)
