Diagram sections — 28 (73 total)
AIR CONDITIONING ANTI-LOCK BRAKES ANTI-THEFT BODY CONTROL MODULES COMPUTER DATA LINES COOLING FAN CRUISE CONTROL DEFOGGERS ENGINE PERFORMANCE EXTERIOR LIGHTS GROUND DISTRIBUTION HEADLIGHTS HORN INSTRUMENT CLUSTER INTERIOR LIGHTS POWER DISTRIBUTION POWER DOOR LOCKS POWER MIRRORS POWER SEATS POWER TOP/SUNROOF POWER WINDOWS RADIO SHIFT INTERLOCK STARTING/CHARGING SUPPLEMENTAL RESTRAINTS TRANSMISSION WARNING SYSTEMS WIPER/WASHER
AIR CONDITIONING Manual A/C Wiring Diagram, with VBC for Nissan Frontier SE 2009 List of elements for Manual A/C Wiring Diagram, with VBC for Nissan Frontier SE 2009: 92 (behind right side of dash) m61 2.5l 4.0l A/c compressor (xterra: left front of engine) (frontier: front of engine compt) A/c relay A/c request Air mix door motor (behind center of dash) Aircon sw Avcc Batt Blend dr ccw Blend dr cw Blend feed back Blower fan Body control module (bcm) (frontier: left front of center console) (xterra: under left side of dash) Can-h Can-l Computer Computer data lines system Cooling fan hi relay Cooling fan lo relay Cooling fan motor (front of engine compt) Cpu Cursen (or tw) Data lines Defogger system E119 E120 E122 E124 E15 (right front of engine compt) E16 E24 E24 (crew cab) e15 (king cab) (right front of engine compt) E24 (frontier: right front of engine compt) Engine control module (ecm) (right rear of engine compt) Engine coolant temperature sensor (2.5l frontier & xterra: at rear of engine) (4.0l frontier: on top front of engine, in water outlet) F52 F54 Fan on Fr blower monitor Front air control (xterra: behind center of dash) Front blower motor (behind glove box, on intake unit) Front blower motor relay (in fuse & relay box) Front variable blower control (frontier: behind right side of dash) Frontier Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse 15a Fuse 20a Fuse block (j/b) (frontier: under right side of dash) (xterra: right side of dash) Fusible link i 40a Gnd Gnd (power) Gnd (sig) Gnd-a Hot at all times Hot in on Hot in on or start Ign Ignition relay Ill+ Ill- Intake door motor (frontier: behind glove box, on intake unit (xterra: behind right side of dash, on intake unit) Intake sensor Intake sensor (frontier: lower right side of dash) (xterra: behind right side of dash) Interior lights Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) M18 M61 (behind right side of dash) Mode (gnd) Mode ccw Mode cw Mode door motor (frontier: behind left side of dash) (xterra: behind center of dash) Mode feed back Mot+ Mot- Pnk Power sply Recirc door ccw Recirc door cw Red Refrigerant pressure sensor (front of engine compt) Rr def status Rr defrost request Sens rtn Setpoint Sig System Tps 2 (or pd press) V ref actr (5v) Xterra Manual A/C Wiring Diagram, without VBC for Nissan Frontier SE 2009 List of elements for Manual A/C Wiring Diagram, without VBC for Nissan Frontier SE 2009: 73 (behind glove box, on intake unit) (left front of center console) body control module (bcm) 2.5l 4.0l A/c compressor (front of engine compt) A/c relay A/c request Aircon sw Avcc Bat Blend dr ccw Blend dr cw Blend feed back Blower fan Can-h Can-l Computer data lines system Cpu E119 E122 E124 E15 (right front of engine compt) E16 Engine control module (ecm) (right rear of engine compt) Engine coolant temperature sensor (2.5l: at rear of engine) (4.0l: on top front of engine, in water outlet) F52 F54 Fr blower Front air control Front air mix door motor (behind center of dash) Front blower motor (behind glove box, on intake unit) Front blower motor relay (in fuse & relay box) Front blower motor resistor (behind right side of dash) Front blower switch Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse 15a Fuse 20a Fuse block (j/b) (under right side of dash) Gnd Gnd (power) Gnd (sig) Gnd-a Hot at all times Hot in on Hot in on or start Ign Ignition relay Ill+ Ill- Intake door motor Intake sensor Intake sensor (lower right side of dash) Interior lights system Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) M18 M61 (behind right side of dash) Mode (gnd) Mode ccw Mode cw Mode door motor (behind left side of dash) Mode feed back Off Pdpres Pnk Pow Recirc door ccw Recirc door cw Red Refrigerant pressure sensor (front of engine compt) Sens return Sig V ref actr (5v)
ANTI-LOCK BRAKES Anti-lock Brakes Wiring Diagram, with Traction Control & Stability Assist with Hill Assist (1 of 2) for Nissan Frontier SE 2009 List of elements for Anti-lock Brakes Wiring Diagram, with Traction Control & Stability Assist with Hill Assist (1 of 2) for Nissan Frontier SE 2009: 61 (left rear corner of engine compt) abs actuator & electric unit (control unit) Abs/tcs/vdc control unit Can-h Can-l Can2-h Can2-l Clus sup Clus_gnd Computer data lines system Data link connector (under left side of dash) Diag_k E119 E126 (left side of engine compt) E160 Exterior lights system Fl in sol Fl out sol Flu lv sw Fr in sol Fr lh pwr Fr lh sig Fr out sol Fr rh pwr Fr rh sig Fuse 10a Fuse block (j/b) (under right side of dash) Hdc_sw Hot at all times Hot in on or start Hsv1 Hsv2 Ign Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) Lamp sw Lamp sw on Left front wheel sensor (on left front wheel knuckle assembly) Left rear wheel sensor (at left wheelwell) Mot (+) Mot (-) Mtr gnd Mtr sply Pnk Red Right front wheel sensor (on right front wheel knuckle assembly) Right rear wheel sensor (at right rear wheelwell Rl in sol Rl out sol Rr in sol Rr lh pwr Rr lh sig Rr out sol Rr rh pwr Rr rh sig Solenoid valve Stop lamp relay (in fuse & relay box) Stop light switch (on bracket, above brake pedal) Usv1 Usv2 Vdc off sw Vlv ecu gnd Vlv ecu sply Anti-lock Brakes Wiring Diagram, with Traction Control & Stability Assist with Hill Assist (2 of 2) for Nissan Frontier SE 2009 List of elements for Anti-lock Brakes Wiring Diagram, with Traction Control & Stability Assist with Hill Assist (2 of 2) for Nissan Frontier SE 2009: 34 (w/ information display) unified meter control unit Abs ind Batt Brake fluid level switch (in brake fluid reservoir) Brake ind Can-h Can-l Clu p Clu_gnd Combination meter Computer data lines system E9 (left side of engine compt) Fuse & fusible link box (right rear of engine compt) Fuse 14 10a Fuse 21 10a Fuse block (j/b) (under right side of dash) Fusible link l 30a Fusible link n 40a Gnd Hill descent control ind Hill descent switch Hot at all times Hot in on or start Interior lights system M57 (behind left side of dash) M61 (behind right side of dash) Pnk Pwr Red Slip ind Steering angle sensor (behind left side of dash, near steering column) Vdc off ind Vdc off switch Yaw rate/side/decel g sensor (crew cab: under center console) (king cab: beneath center console) Anti-lock Brakes Wiring Diagram, with Traction Control for Nissan Frontier SE 2009 List of elements for Anti-lock Brakes Wiring Diagram, with Traction Control for Nissan Frontier SE 2009: 73 (left rear corner of engine compt) abs actuator & electric unit (control unit) (w/ information display) unified meter control unit Abs ind Abs/abls control unit Brake fluid level switch (in brake fluid reservoir) Brake ind Can-h Can-l Cmc1 Cmc2 hsv1 cmc1 usv2 Cmc2 usv1 Combination meter Computer data lines system Data link connector (under left side of dash) Diag-k Driv1 gnd Driv1 sensep Driv1 sig E119 E126 (left side of engine compt) E160 E9 (left side of engine compt) Exterior lights system Fl in sol Fl lv sw Fl out sol Fr in sol Fr lh pwr Fr lh sig Fr out sol Fr rh pwr Fr rh sig Front pressure sensor (left rear of engine compt) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse 14 10a Fuse block (j/b) (under right side of dash) Fusible link l 30a Fusible link n 40a Gnd Hot at all times Hot in on or start Hsv2 Ign Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) Left front wheel sensor (on left front wheel knuckle assembly) Left rear wheel sensor (at left wheelwell) M57 (behind left side of dash) M61 (behind right side of dash) Mot (+) Mot (-) Mtr gnd Mtr sply Pnk Pwr Red Right front wheel sensor (on right front wheel knuckle assembly) Right rear wheel sensor (at right rear wheelwell) Rl in sol Rl out sol Rr in sol Rr lh pwr Rr lh sig Rr out sol Rr rh pwr Rr rh sig Sig Slip ind Solenoid valve Stop lamp sw Stop light switch (on bracket, above brake pedal) Vlv ecu gnd Vlv ecu sply Anti-lock Brakes Wiring Diagram, without Traction Control for Nissan Frontier SE 2009 List of elements for Anti-lock Brakes Wiring Diagram, without Traction Control for Nissan Frontier SE 2009: 55 (w/ information display) unified meter control unit Abs actuator & electric unit (control unit) (left rear corner of engine compt) Abs control unit Abs ind Can-h Can-l Combination meter Computer data lines system Data link connector (under left side of dash) Diag-k E119 E126 (left side of engine compt) E160 Exterior lights system Fl in sol Fl out sol Fr in sol Fr lh pwr Fr lh sig Fr out sol Fr rh pwr Fr rh sig Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse 14 10a Fuse block (j/b) (under right side of dash) Fusible link l 30a Fusible link n 40a Hot at all times Hot in on or start Ign Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) Left front wheel sensor (on left front wheel knuckle assembly) Left rear wheel sensor (at left wheelwell) M57 (behind left side of dash) M61 (behind right side of dash) Mot (+) Mot (-) Mtr gnd Mtr sply Pnk R in sol R out sol Red Right front wheel sensor (on right front wheel knuckle assembly) Right rear wheel sensor (at right rear wheelwell) Rr lh pwr Rr lh sig Rr rh pwr Rr rh sig Solenoid valve Stop lamp sw Stop light switch (on bracket, above brake pedal) Vlv ecu gnd Vlv ecu sply
ANTI-THEFT Forced Entry Wiring Diagram (1 of 2) for Nissan Frontier SE 2009 List of elements for Forced Entry Wiring Diagram (1 of 2) for Nissan Frontier SE 2009: 42 4n m3 Acc sw B19 (on left "c" pillar) Bat Bat (f/l) Bcm (left front of center console) Can-h Can-l Cdl lock sw Cdl unlock sw Combination meter Computer data lines system Crew cab Door sw (as) Door sw (dr) Door sw (rl) Door sw (rr) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd (power) Hot at all times Hot in acc or on Hot in on or start Key cylinder lock sw Key cylinder unlock sw King cab Left front door switch (in left "b" pillar) Left rear door switch (crew cab) (in left "c" pillar) Left rear lower door switch Left rear upper door switch M18 M19 M20 M4 4p M57 (behind left side of dash) Pnk Right rear door switch (crew cab) (in right "c" pillar) Security ind Security ind output Unified meter control unit (w/ information display) Forced Entry Wiring Diagram (2 of 2) for Nissan Frontier SE 2009 List of elements for Forced Entry Wiring Diagram (2 of 2) for Nissan Frontier SE 2009: 51 +ig Anti theft horn B132 (right "c" pillar) Between full stroke & n Can h Can l Computer data lines system Cpu Crew cab E122 E123 E124 E24 (right front of engine compt) E9 (left side of engine compt) Full stroke Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse 15a Fuse 20a Gnd Gnd (pwr) Gnd (sig) H/lp hi H/lp lo Headlamp left high relay Headlamp low relay Headlamp right high relay Headlights system Hi lp lo rh Horn (left front of engine compt) Horn relay (right rear of engine compt) Horns system Hot at all times Hot in on or start Ignition relay Ipdm e/r (right rear of engine compt) King cab Left front door lock assembly Lock Lock switch M57 (behind left side of dash) M79 (behind right side of dash) Main power window & door lock/ unlock switch Pnk Red Right front door switch Right power window & door lock/ unlock switch Right rear lower door switch Right rear upper door switch Unlock Unlock switch Immobilizer Wiring Diagram for Nissan Frontier SE 2009 List of elements for Immobilizer Wiring Diagram for Nissan Frontier SE 2009: 58 (2.5l) e15 e24 (right front of engine compt) (4.0l) +ig 15p Anti theft horn Bat (f/l) Bat (fuse) Bcm (left front of center console) Can h Can l Can-h Can-l Clock Combination meter Computer data lines system Cpu E121 E122 E124 E16 E9 (left side of engine compt) Engine control module (ecm) (right rear of engine compt) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse 15a Fuse 20a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd Gnd (power) Gnd (pwr) Gnd (sig) H/lp hi H/lp lo Headlights system Horn (left front of engine compt) Horn relay (right rear of engine compt) Horns system Hot at all times Hot in on or start Ign sw Ignition relay Immob ant sig (clock) Immob ant sig (rx, tx) Ipdm e/r (right rear of engine compt) M18 M20 M3 4n M4 5p M4 8p M57 (behind left side of dash) Nats antenna amplifier (right of steering column) Pnk Rx,tx Security ind Security ind output Unified meter control unit (w/ information display) Vb (12v)
BODY CONTROL MODULES Body Control Modules Wiring Diagram for Nissan Frontier SE 2009 List of elements for Body Control Modules Wiring Diagram for Nissan Frontier SE 2009: 81 15p A/c request Acc sw Air conditioning system Anti-theft system Auto light sensor input Bat Bat (f/l) Bat saver output Bcm (left front of center console) Can-h Can-l Cargo lamp output Cargo lamp sw Cdl lock sw Cdl unlock sw Comb sw input 1 Comb sw input 2 Comb sw input 3 Comb sw input 4 Comb sw input 5 Comb sw output 1 Comb sw output 2 Comb sw output 3 Comb sw output 4 Comb sw output 5 Computer data lines system Defogger system Door lock output (all) Door locks & anti-theft systems Door locks & headlights systems Door locks system Door sw (as) Door sw (dr) Door sw (rl) Door sw (rr) Door unlock output (dr) Door unlock output (other) Exterior lights system Fan on Flasher output (left) Flasher output (right) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd (pwr) Hazard sw Headlights system Hot at all times Hot in on or acc Hot in on or start Ign sw Immob antenna sig (clock) Immob antenna sig (rx,tx) Interior lights system Key cyl lock sw Key cyl unlock sw Key ring out Key sw Key switch M18 M19 M20 M57 (behind left side of dash) Pnk Power tops system Power windows & power tops systems Pwr window (bat) Pwr window (rap) Red Room lamp output Rr def sw Security ind output Sig gnd Sig pwr Signal Tpms mode sw Trailer left flasher Trailer right flasher Warning systems
COMPUTER DATA LINES Computer Data Lines Wiring Diagram for Nissan Frontier SE 2009 List of elements for Computer Data Lines Wiring Diagram for Nissan Frontier SE 2009: 46 (right rear of engine compt) engine control module (ecm) (xterra: below left side of dash, near steering column) (frontier: behind left side of dash, near steering column) steering angle sensor A/t assembly (if equipped) Abs actuator & electric unit (control unit) (left rear corner of engine compt) Abs/tcs/vdc control unit Acc Air bag diagnosis sensor unit (frontier: under center console) (xterra: under console box) Ant sig Audio unit Body control module (bcm) (frontier: left front of center console) (xterra: under left side of dash) Can-h Can-l Combination meter Data link connector (under left side of dash) Diag-k Differential lock control unit (w/ electronic locking rear differential) (xterra: under center of dash) E122 E16 E57 Earth F502 Fuse 12 10a Fuse 19 10a Fuse 4 10a Fuse block (j/b) (frontier: under right side of dash) (xterra: right side of dash) Hot at all times Hot in on or acc Hot in on or start Ipdm e/r (right rear of engine compt) K-line M152 M18 M35 M41 M42 Nats antenna amplifier (frontier: right of steering column) (xterra: behind center of dash) Pnk Rx, tx Rxd Satellite radio tuner (pre-wiring) (xterra: behind left side of dash) Shield Tcm Transfer control unit (w/ part time 4wd) (behind left side of dash) Txd W/ vdc W/o vdc & frontier
COOLING FAN Cooling Fan Wiring Diagram for Nissan Frontier SE 2009 List of elements for Cooling Fan Wiring Diagram for Nissan Frontier SE 2009: 30 (2.5l) (4.0l) (5.0l) (pathfinder: at left side of engine) Can-h Can-l Computer data lines system Cooling fan high relay Cooling fan low relay Cooling fan motor (front of engine compt) Cpu E120 E122 E124 E15 (right front of engine compt) E16 E24 (frontier: right front of engine compt) Engine control module (ecm) (right rear of engine compt) Engine coolant temperature sensor (4.0l frontier: on top front of engine, in water outlet) (2.5l frontier & xterra: rear of engine) F52 F54 F79 Fuse & fusible link box (right rear of engine compt) Fusible link i 40a Gnd Gnd-a Hot at all times Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) Motor fan Pnk
CRUISE CONTROL Cruise Control Wiring Diagram for Nissan Frontier SE 2009 List of elements for Cruise Control Wiring Diagram for Nissan Frontier SE 2009: 62 1q e160 2.5l 4.0l A/t Accel/ resume switch Accelerator pedal position (app) sensor (under left side of dash) Aps1 Aps2 Ascd brake switch (on bracket above brake pedal) Ascd clutch switch (on bracket, above clutch pedal) Ascd steering switch Ascd sw Avcc Avcc 2 Avcc2 Bncsw Brake Can-h Can-l Cancel switch Close Coast/ set switch Combination meter Combination switch (spiral cable) Computer data lines system Cruise ind (4.0l) E15 (right front of engine compt) E16 E24 (4.0l) e15 (2.5l) (right front of engine compt) Electric throttle control actuator (on throttle body) Engine control module (ecm) (right rear of engine compt) F52 F54 Fuse 12 10a Fuse 14 10a Fuse 19 10a Fuse 20 10a Fuse block (j/b) (under right side of dash) Gnd Gnd-a Gnd-a2 Hot at all times Hot in on or start M/t M102 M30 M61 (behind right side of dash) Motor 1 Motor 2 Nca On/off main switch Open Pnk Red Sensor 1 Sensor 2 Set ind (4.0l) Stop light switch (on bracket, above brake pedal) Throttle control motor Throttle position sensor Tps 1 Unified meter control unit (w/ information display)
DEFOGGERS Defoggers Wiring Diagram for Nissan Frontier SE 2009 List of elements for Defoggers Wiring Diagram for Nissan Frontier SE 2009: 58 +ig 15p A/c & av switch assembly Automatic a/c B165 B210 B211 (frontier) (left rear of passenger compt) Bat (f/l) Bcm (frontier: left front of center console) (xterra & pathfinder: under left side of dash) Can-h Can-l Computer data lines system Cpu D603 (xterra & pathfinder) (xterra: right side of tailgate) (pathfinder: top right of back door) D604 D651 Door mirror defogger E120 E122 E124 E24 (frontier & pathfinder: right front of engine compt) Front air control (xterra: behind center of dash) Frontier Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse 15a Fuse block (j/b) (frontier: under right side of dash) (xterra: right side of dash) (pathfinder: behind right end of dash) Fusible link g 50a Gnd Gnd pwr Heated mirror relay (if equipped) Hot at all times Hot in on Hot in on or start Ign Ign sw Ignition relay Ipdm e/r (right rear of engine compt) Left door mirror (xterra & pathfinder: at driver's door mirror) M18 M20 M57 (frontier & pathfinder: behind left side of dash) (xterra: left a-pillar) M61 (behind right side of dash) M61 (pathfinder) (behind right side of dash) M79 (xterra & frontier) (behind right side of dash) Manual a/c Pnk Rear window defogger Rear window defogger relay Red Right door mirror (xterra & pathfinder: at front passenger's door mirror) Rr def Rr def req Rr def sw Rr defog Xterra & pathfinder Xterra w/ vbc & frontier Xterra w/o vbc & pathfinder
ENGINE PERFORMANCE
2.5L 2.5L, Engine Performance Wiring Diagram (1 of 4) for Nissan Frontier SE 2009 List of elements for 2.5L, Engine Performance Wiring Diagram (1 of 4) for Nissan Frontier SE 2009: 53 (left side of engine compt) (on front of engine) f16 (on top of engine) (right front of engine compt) (right front of engine compt) e15 15p A/t Af-h1 (fr) Af-ip1(fr) Af-un1(fr) Af-vm1(fr) Avcc Avcc2 Battery current sensor (front of engine compt) Combination meter Computer data lines system Condenser 1 Crankshaft position sensor (pos) (rear of engine, on transmission housing) Cvtcr E15 Engine control module (right rear of engine compt) Evap Evap canister purge volume control solenoid valve (on left side of engine) F52 Ftrps Fuel injector Fuse 10a Fuse block (j/b) (under right side of dash) Gnd Hot in on or start Inj 1 Inj 2 Inj 3 Inj 4 Knk1 Knock sensor (on top of engine) M/t Mal- funct- tion indicator lamp Motor1 Motor2 O2hrr Park/ neutral position switch (m/t) (on trans- mission) Pdpres Phase Pnk Pos Ps pres Qa+ Red Refrigerant pressure sensor (front of engine compt) Tps1 Unified meter control unit (w/ information display) V mot 2.5L, Engine Performance Wiring Diagram (2 of 4) for Nissan Frontier SE 2009 List of elements for 2.5L, Engine Performance Wiring Diagram (2 of 4) for Nissan Frontier SE 2009: 29 (on top of engine) Accelerator pedal position sensor (under left side of dash) E119 E122 E15 (right front of engine compt) Ecm relay Electric throttle control actuator (on throttle body) F16 (on front of engine) Fuel pump relay Fuse 15a Fuse 20a Hot at all times Hot in on or start Ignition coil 1 (w/ power transistor) Ignition coil 2 (w/ power transistor) Ignition coil 3 (w/ power transistor) Ignition coil 4 (w/ power transistor) Ipdm e/r (right rear of engine compt) Nca Plug spark Pnk Red Sensor 1 Sensor 2 Spark plug Throttle control motor Throttle control motor relay Throttle position (tp) sensor 1 Throttle position (tp) sensor 2 2.5L, Engine Performance Wiring Diagram (3 of 4) for Nissan Frontier SE 2009 List of elements for 2.5L, Engine Performance Wiring Diagram (3 of 4) for Nissan Frontier SE 2009: 16 (or pnk) Air fuel (a/f) ratio sensor (left rear of engine compt) Camshaft position sensor (phase) (at rear of engine) Cruise control system E119 E15 (right (front of engine compt) Engine coolant temperature sensor (at rear of engine) Evap control system pressure sensor (under left rear of vehicle) Fuse 15a Heated oxygen sensor 2 (below vehicle, on front tube) Hot in on or start Intake valve timing control solenoid valve (on front of engine) Ipdm e/r (right rear of engine compt) Mass airflow (maf) sensor (front of engine compt) Pnk Red 2.5L, Engine Performance Wiring Diagram (4 of 4) for Nissan Frontier SE 2009 List of elements for 2.5L, Engine Performance Wiring Diagram (4 of 4) for Nissan Frontier SE 2009: 53 A/f-ia1(fr) Aps1 Aps2 Ascdsw Avcc Avcc2 Batt Bncsw Brake Can l Can-h Cdcv Cir sen Computer data lines system Cruise control system Cursen Data link connector (under left side of dash) E121 E15 (right front of engine compt) E16 E160 E9 (left side of engine compt) Engine control module (right rear of engine compt) Evap canister vent control valve (under rear of vehicle, on evap canister) F52 Fpr Fuel level sensor unit & fuel pump (on fuel tank) Fuse 10a Fuse 20a Fuse block (j/b) (under right side of dash) Gnd Gnd 02 Gnd a Gnd a2 Hot at all times Ign 1 Ign 2 Ign 3 Ign 4 Ign sw Ipdm e/r (right rear of engine compt) Kline Motrly Neut O2srr Pnk Power steering pressure sensor (at front of engine compt) Pspress Red Red red Ssoff Stoplight switch (on bracket, above brake pedal) Tps2
4.0L 4.0L, Engine Performance Wiring Diagram (1 of 4) for Nissan Frontier SE 2009 List of elements for 4.0L, Engine Performance Wiring Diagram (1 of 4) for Nissan Frontier SE 2009: 65 (left front of engine) f16 (left side of engine) (right front of engine compt) (right front of engine compt) e24 (right side of engine) 15p Af+1 Af+2 Af-1 Af-h1 Af-h2 Avcc Avcc2 Battery current sensor (front of engine compt) Combination meter Computer data lines system Condenser 1 (near fuel injector 3) Crankshaft position sensor (pos) (at rear of engine) Cvtc l Cvtc r E15 E24 Engine control module (right rear of engine compt) Evap Evap canister purge volume control solenoid valve (front left side of engine) F54 Ftrps Fuel injector Fuse 10a Fuse block (j/b) (under right side of dash) Gnd Hot in on or start Ignition coil 5 (w/ power transistor) (right side of engine) Inj 1 Inj 2 Inj 3 Inj 4 Inj 5 Inj 6 Knk1 Knk2 Knock sensor (bank 1) (on right side of engine) Knock sensor (bank 2) (on left side of engine) Malfunction indicator lamp Motor1 Motor2 Nca O2hrl O2hrr O2srl Park/ neutral position switch (on trans- mission) (m/t) Pdpres Phase lh Phase rh Pnk Pos Ps pres Qa+ Red Refrigerant pressure sensor (front of engine compt) Spark plug Tps1 Unified meter control unit (w/ information display) V mot Vias 4.0L, Engine Performance Wiring Diagram (2 of 4) for Nissan Frontier SE 2009 List of elements for 4.0L, Engine Performance Wiring Diagram (2 of 4) for Nissan Frontier SE 2009: 29 Accelerator pedal position sensor (app) (under left side of dash) E119 E122 E24 (right front of engine compt) Ecm relay Electric throttle control actuator (on throttle body) F16 (left front of engine) Fuel pump relay Fuse 15a Fuse 20a Hot at all times Hot in on or start Ignition coil 1 (w/ power transistor) (right side of engine) Ignition coil 2 (w/ power transistor) (left side of engine) Ignition coil 3 (w/ power transistor) (right side of engine) Ignition coil 4 (w/ power transistor) (left side of engine) Ignition coil 6 (w/ power transistor) (left side of engine) Ipdm e/r (right rear of engine compt) Nca Plug spark Pnk Red Sensor 1 Sensor 2 Spark plug Throttle control motor Throttle control motor relay Throttle position (tp) sensor 1 Throttle position (tp) sensor 2 4.0L, Engine Performance Wiring Diagram (3 of 4) for Nissan Frontier SE 2009 List of elements for 4.0L, Engine Performance Wiring Diagram (3 of 4) for Nissan Frontier SE 2009: 18 Air fuel (a/f) ratio sensor 1 (bank 1) (right side of engine compt) Air fuel (a/f) ratio sensor 1 (bank 2) (left side of engine compt) Camshaft position sensor (phase) (bank 2) (at left rear of engine) Cruise control system E119 E24 (right front of engine compt) Engine coolant temperature sensor (on top front of engine, in water outlet) Evap control system pressure sensor (under left rear of vehicle) Fuse 15a Heated oxygen sensor 2 (bank 1) (under center of vehicle) Heated oxygen sensor 2 (bank 2) (below vehicle on exhaust pipe) Hot in on or start Intake valve timing control solenoid valve (bank 1) (right front of engine) Intake valve timing control solenoid valve (bank 2) (left front of engine) Ipdm e/r (right rear of engine compt) Mass air flow (maf) sensor (left side of eng compt, near air intake box) Pnk Red 4.0L, Engine Performance Wiring Diagram (4 of 4) for Nissan Frontier SE 2009 List of elements for 4.0L, Engine Performance Wiring Diagram (4 of 4) for Nissan Frontier SE 2009: 57 A/f-2 A/t Aps1 Aps2 Ascdsw Avcc Avcc2 Batt Bncsw Brake Camshaft position sensor (phase) (bank 1) (right rear of engine) Can l Can-h Cdcv Computer data lines system Cruise control system Cursen Data link connector E121 E16 E160 E24 (right front of engine compt) E9 (left side of engine compt) Engine control module (right rear of engine compt) Evap canister vent control valve (under rear of vehicle, on evap canister) F54 Fpr Fuel level sensor unit & fuel pump (on fuel tank) Fuse 10a Fuse 20a Fuse block (j/b) (under right side of dash) Gnd Gnd 02 Gnd a Gnd a2 Hot at all times Ign 1 Ign 2 Ign 3 Ign 4 Ign 5 Ign 6 Ign sw Ipdm e/r (right rear of engine compt) Kline M/t Motrly Neut O2srr Pdpres Pnk Power steering pressure sensor (at front of engine compt) Red Ssoff Stoplight switch (on bracket, above brake pedal) Tps2 Vias control solenoid valve
EXTERIOR LIGHTS Backup Lamps Wiring Diagram for Nissan Frontier SE 2009 List of elements for Backup Lamps Wiring Diagram for Nissan Frontier SE 2009: 23 (right front of engine compt) A/t A/t assembly Backup lamp relay (in fuse & relay box) Backup light switch (4.0l: on transmission) (2.5l: on right side of transmission) C205 C206 E119 E121 E15 E9 (left side of engine compt) F502 Fuse 38 10a Fuse 51 10a Hot in on or start Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) Left rear combination lamp (backup) M/t Pnk Rev lamp relay Right rear combination lamp (backup) Trailer connector Transmission control module (tcm) Exterior Lamps Wiring Diagram (1 of 2) for Nissan Frontier SE 2009 List of elements for Exterior Lamps Wiring Diagram (1 of 2) for Nissan Frontier SE 2009: 82 (behind left side of dash) m57 (behind right side of dash) m79 15p m4 Backup lamps circuit Bat (f/l) Body control module (bcm) (left front of center console) C201 C202 C207 C208 Can-h Can-l Combi sw input 1 Combi sw input 2 Combi sw input 3 Combi sw input 4 Combi sw input 5 Combi sw output 1 Combi sw output 2 Combi sw output 3 Combi sw output 4 Combi sw output 5 Combination switch (lighting & turn signal switch) Computer data lines system Door sw (as) Door sw (dr) Door sw (rl) Door sw (rr) E108 E111 E121 E15 (right front of engine compt) E9 (left side of engine compt) Electric brake (pre-wiring) Flasher out (lh) Flasher out (rh) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse 15a Fuse block (j/b) (under right side of dash) Fusible link g 50a Fusible link h 30a Fusible link m 30a Gnd(pwr) Hazard sw Hazard switch Hot at all times Hot in on or start Ign sw Input 1 Input 2 Input 3 Input 4 Input 5 Interior lights system Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) Left rear combination lamp Left trailer turn relay (in fuse & relay box) M18 M19 M20 M61 (behind right side of dash) Out (lh) Output 1 Output 2 Output 3 Output 4 Output 5 Park Pnk Red Right front combination lamp Right rear combination lamp Right trailer turn relay (in fuse & relay box) Side marker Stop Tail Trailer connector Trailer flash Trailer flash out (rh) Trailer tow relay 2 (in fuse & relay box) Turn Exterior Lamps Wiring Diagram (2 of 2) for Nissan Frontier SE 2009 List of elements for Exterior Lamps Wiring Diagram (2 of 2) for Nissan Frontier SE 2009: 56 (in fuse & relay box) (w/ vdc) stop lamp relay (w/ information display) unified meter control unit +ig 8q e160 A/t Abs actuator & electric unit (control unit) (left rear corner of engine compt) Abs/tcs/vdc control unit B117 (under right front seat) Brake Can-h Can-l Combination meter Cpu E121 E122 E123 E124 E15 (2.5l) e24 (4.0l) (right front of engine compt) E15 (right front of engine compt) E16 E17 E27 E9 (left side of engine compt) Engine control module (ecm) (right rear of engine compt) Fuse 10a Fuse 20a Fuse 37 10a Fuse block (j/b) (under right side of dash) Gnd (pwr) Gnd (sig) High- mounted stop lamp assembly (stop lamp) Hot at all times Hot in on or start Ignition relay Interior lights system Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) Left front combination lamp Left license plate lamp Left turn ind M/t M4 8p M57 (behind left side of dash) Park Pnk Red Right license plate lamp Right turn ind Shift interlock system Side marker Stop lamp sw Stop lamp sw on Stop light switch (on bracket, above brake pedal) Tail lamp relay Tail/lp rly Trailer tow relay 1 (in fuse & relay box) Turn
GROUND DISTRIBUTION Ground Distribution Wiring Diagram (1 of 2) for Nissan Frontier SE 2009 List of elements for Ground Distribution Wiring Diagram (1 of 2) for Nissan Frontier SE 2009: 19 4.0l A/t assembly Abs actuator & electric unit (control unit) Bcm (body control module), main power window & door lock/unlock switch, left front door lock assembly, data link connector, combination switch, combination meter, sunroof switch, auto anti-dazzling inside mirror, front room/map lamp assembly, left door mirror & nats antenna amplifier Brake fluid level switch, front wiper motor, right front fog lamp, daytime light relay 1, daytime light relay 2, washer fluid level switch, left front combination lamp, right front combination lamp, trailer tow relay 1, trailer tow relay 2, horn, back-up lamp relay (m/t), fuel level sensor unit & fuel pump & trailer Combination meter, left front combination lamp, right front combination lamp, front blower motor relay (2.5l king cab), left front fog lamp, cooling fan motor (4.0l), left trailer turn relay, right trailer turn relay, ecm (2.5l), ipdm e/r (2.5l), knock sensor (2.5l), park/neutral position (pnp) (m/t), crankshaft position sensor (pos) (2.5l), camshaft position sensor (phase) (2.5l), electronic throttle control actuator (shield wire) (2.5l), left rear combination lamp, right rear combination lamp, left license plate lamp & right license plate lamp Data link connector, front passenger air bag off indicator, combination meter, air bag diagnosis sensor unit, steering angle sensor, front air control, hazard switch, front blower switch, cargo lamp switch, clutch interlock cancel switch, transfer control unit, vdc off switch, hdc switch, a/t device, door mirror remote control switch, left front heated seat switch, console power socket, right front heated seat switch & front variable blower control E126 (left side of engine compt) E15 (right front of engine compt) E24 (right front of engine compt) E9 (left side of engine compt) Ecm (4.0l), differential lock control unit, front blower motor relay (crew cab) (4.0l), clutch interlock cancel relay 1, clutch interlock cancel relay 2, ipdm e/r (4.0l), transfer shut off relay 1, crankshaft position sensor (pos) (4.0l), camshaft position sensor (phase) (bank 2) (4.0l), electric throttle control actuator shield, atp switch (a/t), transfer control device (actuator position switch), wait detection switch, differential lock position switch, camshaft position sensor (phase) (bank 1), 4lo switch, knock sensor (bank 1) shield (4.0l) & knock sensor (bank 2) shield (4.0l) F10 (4.0l: left front of engine) (2.5l: on front of engine) F16 (2.5l: on front of engine) (4.0l: left front of engine) Glove box lamp, lower front power socket, fuse block j/b, right door mirror, electric brake (pre-wiring) & right power window & door lock/ unlock switch Ignition coil 2 (w/ power transistor), ignition coil 4 (w/ power transistor), ignition coil 6 (w/ power transistor) (4.0l), condenser 1, ignition coil 1 (w/ power transistor), ignition coil 3 (w/ power transistor) & ignition coil 5 (w/ power transistor) (4.0l) M57 (behind left side of dash) M61 (behind right side of dash) M79 (behind right side of dash) Ground Distribution Wiring Diagram (2 of 2) for Nissan Frontier SE 2009 List of elements for Ground Distribution Wiring Diagram (2 of 2) for Nissan Frontier SE 2009: 13 Air bag diagnosis sensor unit shield & crash zone sensor shield B117 (under right front seat) B132 (right "c" pillar) B19 (crew cab: on left "c" pillar) (king cab: left rear of passenger compt) B211 (left rear of passenger compt) B7 (under driver's seat) E14 (left side of engine compt) E203 (front of engine compt) Generator Left seat belt buckle switch & left power seat switch Left vanity lamp, right vanity lamp, sunroof motor assembly, left rear power window switch, left front seat heater, left front door switch (king cab), left rear upper door switch (king cab) & left rear lower door switch (king cab) Rear window defogger Right seat belt buckle switch (crew cab), right power seat switch, occupant classification system control unit (crew cab) & occupant classification system control unit (king cab, w/o power seats)
HEADLIGHTS Headlights Wiring Diagram, with DRL (1 of 2) for Nissan Frontier SE 2009 List of elements for Headlights Wiring Diagram, with DRL (1 of 2) for Nissan Frontier SE 2009: 58 (j/b) (under right side of dash) 15p Bat (f/l) Bcm (left front of center console) Can-h Can-l Comb sw in 1 Comb sw in 2 Comb sw in 3 Comb sw in 4 Comb sw in 5 Comb sw out 1 Comb sw out 2 Comb sw out 3 Comb sw out 4 Comb sw out 5 Combination switch (lighting & turn signal switch) Daytime light relay 2 (in fuse & relay box) Door sw (as) Door sw (dr) Door sw (rl) Door sw (rr) E9 (left side of engine compt) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block Fusible link g 50a Gnd Gnd (pwr) Hot at all times Hot in on or start Ign sw Input 1 Input 2 Input 3 Input 4 Input 5 Left front door switch (crew cab) (in left "b" pillar) Left rear door switch (crew cab) (in left "c" pillar) M18 M19 M20 M57 (behind left side of dash) Optical sensor (w/ auto light system) (top of dash) Output 1 Output 2 Output 3 Output 4 Output 5 Pnk Red Remote keyless entry receiver (top right side of dash) Right front door switch (crew cab) Right rear door switch (crew cab) (right "c" pillar) Sens in 2 Sensor gnd Sig Sig gnd Headlights Wiring Diagram, with DRL (2 of 2) for Nissan Frontier SE 2009 List of elements for Headlights Wiring Diagram, with DRL (2 of 2) for Nissan Frontier SE 2009: 48 (left side of engine compt) e9 +ig Brake indicator Can-h Can-l Charge indicator Combination meter Computer data lines system Cpu Daytime light relay 1 (in fuse & relay box) Dtrl rly cont E107 E119 E122 E123 E124 E15 (2.5l) e24 (4.0l) (right front of engine compt) E15 (right front of engine compt) E9 (left side of engine compt) Fr fog Front fog lamp relay Fuse 10a Fuse 15a Fuse 20a H/lp hi H/lp lo Headlamp low relay High High beam indicator Hot at all times Hot in on or start Ignition relay Ipdm e/r (right rear of engine compt) Left front combination lamp (headlamp) Left front fog lamp Left head- lamp high relay Low M57 (behind left side of of dash) Parking brake switch (on parking brake lever) Pnk Pwr gnd Red Right front combination lamp (headlamp) Right front fog lamp Right head- lamp high relay Sig gnd Starting/charging system Unified meter control unit (w/ information display) Headlights Wiring Diagram, without DRL (1 of 2) for Nissan Frontier SE 2009 List of elements for Headlights Wiring Diagram, without DRL (1 of 2) for Nissan Frontier SE 2009: 56 (j/b) (under right side of dash) 15p Bat (f/l) Bcm (left front of center console) Can-h Can-l Comb sw in 1 Comb sw in 2 Comb sw in 3 Comb sw in 4 Comb sw in 5 Comb sw out 1 Comb sw out 2 Comb sw out 3 Comb sw out 4 Comb sw out 5 Combination switch (lighting & turn signal switch) Door sw (as) Door sw (dr) Door sw (rl) Door sw (rr) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block Fusible link g 50a Gnd Gnd (pwr) Hot at all times Hot in on or start Ign sw Input 1 Input 2 Input 3 Input 4 Input 5 Left front door switch (crew cab) (in left "b" pillar) Left rear door switch (crew cab) (in left "c" pillar) M18 M19 M20 M57 (behind left side of dash) Optical sensor (w/ auto light system) (top of dash) Output 1 Output 2 Output 3 Output 4 Output 5 Pnk Red Remote keyless entry receiver (top right side of dash) Right front door switch (crew cab) Right rear door switch (crew cab) (right "c" pillar) Sens in 2 Sensor gnd Sig Sig gnd Headlights Wiring Diagram, without DRL (2 of 2) for Nissan Frontier SE 2009 List of elements for Headlights Wiring Diagram, without DRL (2 of 2) for Nissan Frontier SE 2009: 42 +ig Can-h Can-l Combination meter Computer data lines system Cpu E107 E11 E122 E123 E124 E15 (2.5l) e24 (4.0l) (right front of engine compt) E15 (right front of engine compt) E9 (left side of engine compt) Fr fog Front fog lamp relay Fuse 10a Fuse 15a Fuse 20a H/lp hi H/lp lo H/lp lo rh Headlamp low relay High High beam indicator Hot at all times Hot in on or start Ignition relay Ipdm e/r (right rear of engine compt) Left front combination lamp (headlamp) Left front fog lamp Left headlamp high relay Low M61 (behind right side of of dash) Pnk Pwr gnd Red Right front combination lamp (headlamp) Right front fog lamp Right headlamp high relay Sig gnd Unified meter control unit (w/ information display)
HORN Horn Wiring Diagram for Nissan Frontier SE 2009 List of elements for Horn Wiring Diagram for Nissan Frontier SE 2009: 17 Anti theft horn Combination switch (spiral cable) Cpu E122 E162 E9 (left side of engine compt) Fuse & fusible link box (right rear of engine compt) Fuse 30 15a Horn (left front of engine compt) Horn relay (right rear of engine compt) Horn switch Hot at all times Ipdm e/r (right rear of engine compt) M102 M30 W/ dual note horn W/ single note horn
INSTRUMENT CLUSTER Instrument Cluster Wiring Diagram (1 of 2) for Nissan Frontier SE 2009 List of elements for Instrument Cluster Wiring Diagram (1 of 2) for Nissan Frontier SE 2009: 65 (w/ 4wd) 4wd fail ind (w/ information display) unified meter control unit A/t oil temp ind (a/t) Abs actuator & electric unit (left rear corner of engine compt) Abs ind Air bag ind Ambient sensor 2 (front center of engine compt) Atp ind (a/t & 4wd) Auto anti-dazzling inside mirror Brake fluid level switch (in brake fluid reservoir) Brake ind Buzzer Charge ind Combination meter Computer data lines system Cruise ind (w/ ascd) Diff lock ind (w/ electronic locking rear differential) Door ind E9 (left side of engine compt) Engine controls system Exterior lights system Fuel gauge Fuse 10a Fuse block (j/b) (under right side of dash) Gnd High beam ind Hill descent control ind (w/ vdc) Hot at all times Hot in on or start Ign Interior lights system Left turn ind Low fuel ind M57 (behind left side of dash) M61 (behind right side of dash) Malfunction ind lamp Meter illum O/d off (a/t) Oil pressure gauge Oil pressure ind Parking brake switch (on parking brake lever) Pnk Power tops system Red Right turn ind Seat belt ind Security ind (w/ immobilizer) Set ind (w/ ascd) Slip ind (w/ vdc) Sound systems Speedometer Starting/charging system Tachometer Temp+ Temp- Tire pressure ind Transmissions system Vdc off (w/ vdc) Voltage gauge W/ vdc W/o vdc Warning systems Washer ind Water temp gauge Wiper/washer system Instrument Cluster Wiring Diagram (2 of 2) for Nissan Frontier SE 2009 List of elements for Instrument Cluster Wiring Diagram (2 of 2) for Nissan Frontier SE 2009: 33 B117 (under right front seat) B7 (under driver's seat) Bcm (left front of center console) Can h Can l Can-h Can-l Computer data lines system Cpu Crew cab Dr sw (as) Dr sw (dr) Dr sw (rl) Dr sw (rr) E122 Fuel level sensor unit & fuel pump (fuel level sensor) (on fuel tank) Ipdm e/r (right rear of engine compt) King cab Left front door switch Left front door switch (in left "b" pillar) Left rear door switch (crew cab) (in left "c" pillar) Left rear lower door switch Left rear upper door switch M18 M19 Oil pressure sw Oil pressure switch (2.5l: on right side of engine) (4.0l: right side of engine) Pnk Right front door switch Right rear door switch (crew cab) (right "c" pillar) Right rear lower door switch Right rear upper door switch Sec ind out
INTERIOR LIGHTS Courtesy Lamps Wiring Diagram, with Power Door Locks for Nissan Frontier SE 2009 List of elements for Courtesy Lamps Wiring Diagram, with Power Door Locks for Nissan Frontier SE 2009: 53 (behind left kick panel) cargo light relay 15p B117 (under right front seat) B132 (right "c" pillar) B19 (left rear of passenger compt) Bat (f/l) Bat (fuse) Bat saver Bcm (left front of center console) Can-h Can-l Cargo lamp output Cargo lamp sw Cargo lamp switch Computer data lines system Crew cab Door sw (as) Door sw (dr) Door sw (rl) Door sw (rr) Front room/map lamp assembly (w/ front map lamps) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd (pwr) High mounted stop lamp assembly (cargo lamp) Hot at all times Hot in on or start Ign sw Ignition keyhole illumination (if equipped) Instrument illumination circuit Key ring out Key switch King cab Left front door switch (in left "b" pillar) Left rear door switch (crew cab) (in left "c" pillar) Left rear lower door switch Left rear upper door switch Left vanity lamp (if equipped) M18 M19 M20 M57 (behind left side of dash) M61 (behind right side of dash) Pnk Right front door switch Right rear door switch (crew cab) (right "c" pillar) Right rear lower door switch Right rear upper door switch Right vanity lamp (if equipped) Room lamp Room lamp 2nd row Courtesy Lamps Wiring Diagram, without Power Door Locks for Nissan Frontier SE 2009 List of elements for Courtesy Lamps Wiring Diagram, without Power Door Locks for Nissan Frontier SE 2009: 46 (behind left kick panel) cargo light relay 15p B117 (under right front seat) B7 (under driver's seat) Bat (f/l) Bat (fuse) Bcm (left front of center console) Can-h Can-l Cargo lamp output Cargo lamp sw Cargo lamp switch Computer data lines system Crew cab Diode 6 Door sw (as) Door sw (dr) Door sw (rl) Door sw (rr) Front room/map lamp assembly (w/ front map lamps) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd (pwr) High mounted stop lamp assembly (cargo lamp) Hot at all times Hot in on or start Ign sw Instrument illumination circuit Key switch King cab Left front door switch (in left "b" pillar) Left rear door switch (crew cab) (in left "c" pillar) M18 M19 M20 M57 (behind left side of dash) M61 (behind right side of dash) Pnk Red Right front door switch Right rear door switch (crew cab) (right "c" pillar) Room lamp 2nd row W/ front map lamps W/o front map lamps Instrument Illumination Wiring Diagram for Nissan Frontier SE 2009 List of elements for Instrument Illumination Wiring Diagram for Nissan Frontier SE 2009: 83 (w/ premium audio system) steering wheel audio control switch +ig 15p 4wd shift switch (4 wheel drive) A/t device (a/t) (in center console) Ascd steering switch Audio unit (if equipped) Bat (f/l) Bcm (left front of center console) Can-h Can-l Cargo lamp switch Clutch interlock cancel switch (if equipped) Comb sw in 1 Comb sw in 2 Comb sw in 3 Comb sw in 4 Comb sw in 5 Comb sw out 1 Comb sw out 2 Comb sw out 3 Comb sw out 4 Comb sw out 5 Combination meter Combination switch (lighting & turn signal switch) Combination switch (spiral cable) Computer data lines system Cpu Data link connector (under left side of dash) Differential lock mode switch (w/ electronic locking rear differential) Door mirror remote control switch (w/ power outside mirrors) E122 E124 E24 (4.0l) e15 (2.5l) (right front of engine compt) Electric brake (pre- wiring) Front air control Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse 20a Fuse block (j/b) (under right side of dash) Fusible link g 50a Glove box lamp Gnd (pwr) Gnd (sig) Hazard switch Hill descent control switch (w/ vdc) Hot at all times Hot in on or start Ign sw Ignition Input 1 Input 2 Input 3 Input 4 Input 5 Ipdm e/r (right rear of engine compt) Left front heated seat switch (if equipped) M102 M18 M20 M30 M43 M57 (behind left side of dash) M64 M65 M79 (behind right side of dash) Meter illum Output 1 Output 2 Output 3 Output 4 Output 5 Pnk Red Relay Right front heated seat switch (crew cab) Tail lamp relay Tail/l rly Unified meter control unit (w/ information display) Vdc off switch (w/ vdc) W/ base audio system W/ premium audio system crew cab W/ premium audio system king cab
POWER DISTRIBUTION Power Distribution Wiring Diagram (1 of 2) for Nissan Frontier SE 2009 List of elements for Power Distribution Wiring Diagram (1 of 2) for Nissan Frontier SE 2009: 72 (behind right side of dash) (right rear of engine compt) fuse & fusible link box (right rear of engine compt) ipdm e/r 10a A/c relay Air conditioning system Anti-lock brakes system Anti-theft, starting/charging & horns systems Battery Computer data lines system Cpu Defogger & cooling fans systems Door locks, interior lights & warning systems E118 E119 E121 E122 E123 E124 E128 E129 E202 E204 E30 Ecm relay Engine controls & anti-theft systems Engine controls system Exterior lights system Front fog lamp relay Front power socket Front wiper hi relay Front wiper relay Fuse Fuse & relay box (right rear of engine compt) Fuse 10a Fuse 15a Fuse 20a Fuse 30a Fusible link a 140a Fusible link b 60a Fusible link box (battery) (right side of engine compt) Fusible link c 80a Fusible link d 80a Fusible link e 100a Fusible link f 80a Fusible link g 50a Fusible link i 40a Fusible link j 40a Fusible link l 30a Fusible link n 40a Headlights system Heated mirror relay Interior lights, exterior lights & headlights systems M79 Pnk Red Seats, exterior lights, interior lights, headlights, defogger, warning, door locks, anti-theft, power tops, wiper/washer & power windows systems Sound systems Starting/ charging system Tail lamp relay Throttle control motor relay To fuse 22 (diagram 2 of 2) To fuse 48 (diagram 2 of 2) To headlight hi relay (diagram 2 of 2) To ignition relay (diagram 2 of 2) To ignition switch (diagram 2 of 2) Transmissions system W/ 4-wheel drive W/ trailer tow 7 pin W/ trailer tow 7 pin fusible link h 30a W/ trailer tow 7 pin fusible link m 30a Wiper/ washer system Power Distribution Wiring Diagram (2 of 2) for Nissan Frontier SE 2009 List of elements for Power Distribution Wiring Diagram (2 of 2) for Nissan Frontier SE 2009: 74 (2.5l) (4.0l) (diagram 1 of 2) (right rear of engine compt) ipdm e/r (under right side of dash) fuse block (j/b) 10p m4 12p 13p m4 15p 16p m4 1n m3 4n m3 5n m3 5p m4 8p m4 9p m4 Acc Accessory relay Air conditioning & defogger systems Anti-lock brakes & trans- missions systems Anti-lock brakes system Anti-theft, power tops, wiper/ washer & door locks systems Console power socket Cpu Defogger system Defogger, warning, engine controls, power windows, headlights, interior lights, exterior lights, Door locks, anti-theft & interior lights systems E119 E121 E122 E123 E124 E158 E159 E160 E24 e15 (right front of engine compt) Engine controls system Engine controls, exterior lights, warning, transmissions, anti-lock brakes & instrument cluster systems From a/c relay (diagram 1 of 2) From fuse 43 (diagram 1 of 2) From fuse 52 (diagram 1 of 2) From fusible link b (diagram 1 of 2) From fusible link j b From ignition switch (diagram 2 of 2) Fuel pump relay Fuse 10a Fuse 15a Headlamp lh high relay Headlamp low relay Headlamp rh high relay Headlights & anti-theft systems Ig2 red Ignition relay Ignition switch M61 (behind right side of dash) M79 (behind right side of dash) Mirrors system Off Pnk Rear window defogger relay Red Seats system Sound systems Sound, door locks, anti-theft & power windows systems Start Starting/ charging system To ignition relay (diagram 2 of 2) Transmissions & exterior lights systems Transmissions & starting/charging systems Transmissions system Transmissions, air conditioning, anti-lock brakes, engine controls, headlights, interior lights, exterior lights, instrument cluster, warning, door locks & anti-theft systems Transmissions, sound, shift interlock & engine controls systems W/ crew cab Wiper/ washer system
POWER DOOR LOCKS Door Lock & Keyless Entry Wiring Diagram, Crew Cab (1 of 2) for Nissan Frontier SE 2009 List of elements for Door Lock & Keyless Entry Wiring Diagram, Crew Cab (1 of 2) for Nissan Frontier SE 2009: 56 Acc sw Bat (f/l) Bat (fuse) Bat saver output Body control module (bcm) (left front of center console) Can-h Can-l Cdl lock sw Cdl unlock sw Closed Door lock output (all) Door sw (as) Door sw (dr) Door sw (rl) Door sw (rr) Door unlock output (dr) Dr unlk output (other) Exterior lights system Flasher output (left) Flasher output (right) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd Gnd (power) Headlights system Hot at all times Hot in acc or on Hot in on or start Ign sw Inserted Interior lights system Key cylinder lock sw Key cylinder unlock sw Key sw Key switch Left front door switch (in left "b" pillar) Left rear door switch (in left "c" pillar) M18 M19 M20 M3 4n M4 15p M57 (behind left side of dash) Open Pnk Pwr Pwr sply out Remote keyless entry receiver (top right side of dash) Removed Right front door switch Right rear door switch (right "c" pillar) Room lamp output Sensor gnd Signal Door Lock & Keyless Entry Wiring Diagram, Crew Cab (2 of 2) for Nissan Frontier SE 2009 List of elements for Door Lock & Keyless Entry Wiring Diagram, Crew Cab (2 of 2) for Nissan Frontier SE 2009: 43 (rear of left rear door) left rear door lock actuator (rear of right front door) right front door lock actuator (rear of right rear door) right rear door lock actuator +ig Actuator Anti theft horn Between full stroke & n Can h Can l Computer data lines system Cpu Data link connector (under left side of dash) E122 E124 E24 (right front of engine compt) E9 (left side of engine compt) Fuse & fusible link box (right rear of engine compt) Fuse 15a Fuse 20a Gnd Gnd (pwr) Gnd (sig) H/lp hi H/lp lo Headlights system Horn (left front of engine compt) Horn relay (right rear of engine compt) Horns system Hot at all times Hot in on or start Ignition relay Ipdm e/r (right rear of engine compt) Key cylinder switch Left front door lock assembly Lock Lock switch full stroke M57 (behind left side of dash) M79 (behind right side of dash) Main power window & door lock/ unlock switch Pnk Right power window & door lock/ unlock switch Unlock Unlock switch full stroke Door Lock & Keyless Entry Wiring Diagram, King Cab (1 of 2) for Nissan Frontier SE 2009 List of elements for Door Lock & Keyless Entry Wiring Diagram, King Cab (1 of 2) for Nissan Frontier SE 2009: 58 Acc sw B132 (right "c" pillar) B19 (left rear of passenger compt) Bat (f/l) Bat (fuse) Bat saver output Body control module (bcm) (left front of center console) Can-h Can-l Cdl lock sw Cdl unlock sw Closed Door lock output (all) Door sw (as) Door sw (dr) Door unlock output (dr) Dr unlk output (other) Exterior lights system Flasher output (left) Flasher output (right) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd Gnd (power) Headlights system Hot at all times Hot in acc or on Hot in on or start Ign sw Inserted Interior lights system Key cylinder lock sw Key cylinder unlock sw Key sw Key switch Left front door switch (in left "b" pillar) Left rear door lower switch Left rear door upper switch M18 M19 M20 M3 4n M4 15p M57 (behind left side of dash) Open Pnk Pwr Pwr sply out Remote keyless entry receiver (top right side of dash) Removed Right front door switch Right rear door lower switch Right rear door upper switch Room lamp output Sensor gnd Signal Door Lock & Keyless Entry Wiring Diagram, King Cab (2 of 2) for Nissan Frontier SE 2009 List of elements for Door Lock & Keyless Entry Wiring Diagram, King Cab (2 of 2) for Nissan Frontier SE 2009: 44 (2.5l) (4.0l) (rear of right front door) right front door lock actuator +ig Actuator Anti theft horn Between full stroke & n Can h Can l Computer data lines system Cpu Data link connector (under left side of dash) E122 E124 E15 e24 (right front of engine compt) E162 E9 (left side of engine compt) Fuse & fusible link box (right rear of engine compt) Fuse 15a Fuse 20a Gnd Gnd (sig) H/lp hi H/lp lo Headlights system Horn (left front of engine compt) Horn relay (right rear of engine compt) Horns system Hot at all times Hot in on or start Ignition relay Ipdm e/r (right rear of engine compt) Key cylinder switch Left front door lock assembly Lock Lock switch full stroke M57 (behind left side of dash) M79 (behind right side of dash) Main power window & door lock/ unlock switch Pnk Right power window & door lock/ unlock switch Unlock Unlock switch full stroke W/ dual note horn W/ single note horn Door Lock Wiring Diagram, Crew Cab (1 of 2) for Nissan Frontier SE 2009 List of elements for Door Lock Wiring Diagram, Crew Cab (1 of 2) for Nissan Frontier SE 2009: 40 Bat (f/l) Bat (fuse) Body control module (bcm) (left front of center console) Can-h Can-l Cdl lock sw Cdl unlock sw Closed Computer data lines system Data link connector (under left side of dash) Door lock output (all) Door sw (as) Door sw (dr) Door sw (rl) Door sw (rr) Door unlock output (dr) Dr unlck output (other) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd (power) Hot at all times Inserted Key cylinder lock sw Key cylinder unlock sw Key sw Key switch Left front door switch (in left "b" pillar) Left rear door switch (in left "c" pillar) M18 M19 M20 M3 4n M57 (behind left side of dash) Open Pnk Removed Right front door switch Right rear door switch (right "c" pillar) Door Lock Wiring Diagram, Crew Cab (2 of 2) for Nissan Frontier SE 2009 List of elements for Door Lock Wiring Diagram, Crew Cab (2 of 2) for Nissan Frontier SE 2009: 17 (rear of left rear door) left rear door lock actuator (rear of right front door) right front door lock actuator (rear of right rear door) right rear door lock actuator Actuator Between full stroke & n Gnd Key cylinder switch Left front door lock assembly Lock Lock switch full stroke M57 (behind left side of dash) M79 (behind right side of dash) Main power window & door lock/ unlock switch Pnk Right power window & door lock/ unlock switch Unlock Unlock switch full stroke Door Lock Wiring Diagram, King Cab (1 of 2) for Nissan Frontier SE 2009 List of elements for Door Lock Wiring Diagram, King Cab (1 of 2) for Nissan Frontier SE 2009: 41 B132 (right "c" pillar) B19 (left rear of passenger compt) Bat (f/l) Bat (fuse) Body control module (bcm) (left front of center console) Can-h Can-l Cdl lock sw Cdl unlock sw Closed Computer data lines system Data link connector (under left side of dash) Door lock output (all) Door sw (as) Door sw (dr) Door unlock output (dr) Dr unlk output (other) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd (power) Hot at all times Inserted Key cylinder lock sw Key cylinder unlock sw Key sw Key switch Left front door switch (in left "b" pillar) Left rear door lower switch Left rear door upper switch M18 M19 M20 M57 (behind left side of dash) Open Pnk Removed Right front door switch Right rear door lower switch Right rear door upper switch Door Lock Wiring Diagram, King Cab (2 of 2) for Nissan Frontier SE 2009 List of elements for Door Lock Wiring Diagram, King Cab (2 of 2) for Nissan Frontier SE 2009: 15 (rear of right front door) right front door lock actuator Actuator Between full stroke & n Gnd Key cylinder switch Left front door lock assembly Lock Lock switch full stroke M57 (behind left side of dash) M79 (behind right side of dash) Main power window & door lock/ unlock switch Pnk Right power window & door lock/ unlock switch Unlock Unlock switch full stroke
POWER MIRRORS Auto Anti-dazzling Mirror Wiring Diagram for Nissan Frontier SE 2009 List of elements for Auto Anti-dazzling Mirror Wiring Diagram for Nissan Frontier SE 2009: 9 Auto anti-dazzling inside mirror Batt Fuse 10a Fuse block (j/b) (under right side of dash) Gnd Hot at all times Hot in on or start Ign M57 (behind left side of dash) Power Mirror Wiring Diagram for Nissan Frontier SE 2009 List of elements for Power Mirror Wiring Diagram for Nissan Frontier SE 2009: 19 12p m4 Changeover switch Defogger system Door mirror remote control switch Fuse 10a Fuse block (j/b) (frontier: under right side of dash) (xterra: right side of dash) (pathfinder: behind right end of dash) Hot in on or acc Interior lights system Left door mirror (pathfinder & xterra: at driver's door mirror) Left/right motor M61 (behind right side of dash) Mirror switch Off Pnk Red Right door mirror (pathfinder & xterra: at front passenger's door mirror) Up/down motor W/ heated mirrors W/o heated mirrors
POWER SEATS Heated Seats Wiring Diagram for Nissan Frontier SE 2009 List of elements for Heated Seats Wiring Diagram for Nissan Frontier SE 2009: 17 B117 (under right front seat) B7 (under driver's seat) E160 Fuse 10a Fuse block (j/b) (under right side of dash) High Hot in on or start Illum Interior lights system Left front heated seat switch Left front seat heater (under driver's seat) Low M61 (behind right side of dash) Off Red Right front heated seat switch Right front seat heater (under right front seat) Power Seat Wiring Diagram for Nissan Frontier SE 2009 List of elements for Power Seat Wiring Diagram for Nissan Frontier SE 2009: 25 B117 (under right front seat) B7 (under driver's seat) Bwd Circuit breaker 2 (behind left end of dash) Down Dwn Front lifting motor (under driver's seat) Front lifting switch Fuse & fusible link box (right rear of engine compt) Fusible link g 50a Fwd Hot at all times Left power Left reclining motor (under rear of driver's seat) Left sliding motor (under driver's seat) Pnk Rear lifting motor (under driver's seat) Rear lifting switch Reclining switch Red Right power seat switch (if equipped) Right reclining motor (under right front seat) Right sliding motor (under right front seat) Seat switch Sliding switch
POWER TOP/SUNROOF Power Top/Sunroof Wiring Diagram for Nissan Frontier SE 2009 List of elements for Power Top/Sunroof Wiring Diagram for Nissan Frontier SE 2009: 41 (behind left side of dash) m57 B7 (under driver's seat) Bat (f/l) Bcm (frontier: left front of center console) (pathfinder: under left side of dash) Can-h Can-l Circuit breaker 2 (w/ power seats) (frontier: behind left end of dash) (pathfinder: behind left side of dash) Combination meter Computer data lines system Cpu Down/open Dr-sw-as Dr-sw-dr Encoder Frontier Fuse & fusible link box (right rear of engine compt) Fuse 1 10a Fuse block (j/b) (frontier: under right side of dash) (pathfinder: behind right end of dash) Fusible link g 50a Gnd Hot at all times Hot in on or start Ign sw Left front door switch (in left "b" pillar) M18 M19 M20 M4 15p M57 (behind left side of dash) Pnk Power (bat) Power (rap) Power windows system Red Right front door switch (pathfinder: at left "b" pillar) Slide limit sw Spd out 2 Sun roof motor assembly (frontier: center front of roof) (pathfinder: at front of sun roof opening) Sunroof switch Tilt limit sw Up/close
POWER WINDOWS Power Windows Wiring Diagram, Crew Cab for Nissan Frontier SE 2009 List of elements for Power Windows Wiring Diagram, Crew Cab for Nissan Frontier SE 2009: 54 (behind left side of dash) (under driver's seat) Acc sw B117 (under right front seat) Bat (f/l) Body control module (bcm) (left front of center console) Can-h Can-l Closed Computer data lines system Cpu Door sw (as) Door sw (dr) Down Down relay Express down Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd Gnd (power) Hot at all times Hot in on or acc Hot in on or start Ign sw Left front Left front door switch (in left "b" pillar) Left front power window motor (center of left front door) Left rear Left rear power window motor (front of left rear door) Left rear power window switch Lock M18 M19 M20 M4 15p M57 M57 (behind left side of dash) Main power window & door lock/ unlock switch Open Pnk Pwr win pwr supp (rap) Rap Red Right front Right front door switch Right front power window motor (center of right front door) Right power window & door lock/ unlock switch Right rear Right rear power window motor (front of right rear door) Right rear power window switch Sunroof motor assembly (center front of roof) Unlock Power Windows Wiring Diagram, King Cab for Nissan Frontier SE 2009 List of elements for Power Windows Wiring Diagram, King Cab for Nissan Frontier SE 2009: 47 (behind left side of dash) Acc sw B117 (under right front seat) B7 (under driver's seat) Bat (f/l) Body control module (bcm) (left front of center console) Can-h Can-l Closed Computer data lines system Cpu Door sw (as) Door sw (dr) Down Down relay Express down Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd Gnd (power) Hot at all times Hot in on or acc Hot in on or start Ign sw Left front Left front door switch (in left "b" pillar) Left front power window motor (center of left front door) Lock M18 M19 M20 M4 15p M57 M57 (behind left side of dash) Main power window & door lock/ unlock switch Open Pnk Pwr win pwr supp (rap) Rap Right front Right front door switch Right front power window motor (center of right front door) Right power window & door lock/ unlock switch Sunroof motor assembly (center front of roof) Unlock
RADIO Base Radio Wiring Diagram for Nissan Frontier SE 2009 List of elements for Base Radio Wiring Diagram for Nissan Frontier SE 2009: 32 Acc Audio unit Bat Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse 20a Fuse block (j/b) (under right side of dash) Hot at all times Hot in on or acc Ill cont Interior lights system Left front door speaker Left front tweeter Left rear door speaker Lh frsp (+) Lh frsp (-) Lh rrsp (+) Lh rrsp (-) Light sw Nca Red Rh frsp (+) Rh frsp (-) Rh rrsp (+) Rh rrsp (-) Right front door speaker Right front tweeter Right rear door speaker Rod antenna W/ crew cab W/ king cab W/o crew cab Premium Sound Radio Wiring Diagram, Crew Cab (1 of 2) for Nissan Frontier SE 2009 List of elements for Premium Sound Radio Wiring Diagram, Crew Cab (1 of 2) for Nissan Frontier SE 2009: 74 16p Acc Amp on/off sig Audio unit Aux gnd Aux in jack Aux l+ Aux r+ Backup Bat (backup) Combination meter Combination switch (spiral cable) Common Data earth Earth (sig) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse 15a Fuse 29 20a Fuse block (j/b) (under right side of dash) Hot at all times Hot in acc or on Ill cont Interior lights system L (+) L (-) Lh frsp (+) Lh frsp (-) Lh rrsp (+) Lh rrsp (-) Light sw M102 M129 M30 M41 M42 M45 M65 M66 Mode Nca Out (8) speed Pnk Power R (+) R (-) Red Remote a swc Remote b swc Remote gnd swc Req Req1 Rh frsp (+) Rh frsp (-) Rh rrsp (+) Rh rrsp (-) Rxd Sat lch (+) Sat lch (-) Sat rch (+) Sat rch (-) Satellite radio antenna (if equipped) Seek down Seek up Shield Speed signal Steering wheel audio control switches Tel sig gnd Tel sig in (+) Tel sig in (-) Tel sig on trig Txd Vol down Vol up Premium Sound Radio Wiring Diagram, Crew Cab (2 of 2) for Nissan Frontier SE 2009 List of elements for Premium Sound Radio Wiring Diagram, Crew Cab (2 of 2) for Nissan Frontier SE 2009: 85 Acc Amp on/off sig Audio amplifier Audio out (+) Audio out (-) B117 (under right front seat) B132 (right "c" pillar) B141 B142 B158 B159 Bat Batt Bcm (body control module) (left front of center console) Bt antenna Bt antenna shld Cont 1 Cont 2 Cont 3 Cont 5 Fr tw (+) Fr tw (-) Frontier Fuse 10a Fuse block (j/b) (under right side of dash) Gnd Gnd 1 Hot in on or start Ign Ladder gnd Ladder in 1 Ladder in 2 Ladder out 1 Ladder out 2 Led ind 1 Led pwr Led/ (amber) Left front door speaker Left front tweeter Left rear door speaker Left rear tweeter Lf rr (+) Lh frsp in (+) Lh frsp in (-) Lh frsp out (+) Lh frsp out (-) Lh rr (-) Lh rrsp in (+) Lh rrsp in (-) Lh rrsp out (+) Lh rrsp out (-) M20 Mic in+ Mic in- Mic out + Mic out - Mic pwr Microphone Mute ctrl Nca Pnk Red Rh frsp in (+) Rh frsp in (-) Rh frsp out (+) Rh frsp out (-) Rh rr (+) Rh rr (-) Rh rrsp in (+) Rh rrsp in (-) Rh rrsp out (+) Rh rrsp out (-) Right front door speaker Right front tweeter Right rear door speaker Right rear tweeter Saver out batt Shield Spd sig Subwoofer Woofer (+)1 Woofer (+)2 Woofer (-)1 Woofer (-)2 Xterra Premium Sound Radio Wiring Diagram, King Cab (1 of 2) for Nissan Frontier SE 2009 List of elements for Premium Sound Radio Wiring Diagram, King Cab (1 of 2) for Nissan Frontier SE 2009: 68 16p Acc Audio unit Aux gnd Aux in jack Aux l+ Aux r+ Backup Bat (backup) Combination meter Common Data earth Earth (sig) Fuse & fusible link box (right rear of engine compt) Fuse 17 15a Fuse 29 20a Fuse 4 10a Fuse block (j/b) (under right side of dash) Hot at all times Hot in on or acc Ill cont Interior L(+) L(-) Left rear door speaker Lh frsp (+) Lh frsp (-) Lh rrsp (+) Lh rrsp (-) Light sw Lights M129 M41 M42 M44 M45 M64 Nca Out 8 speed Pnk R(+) R(-) Red Remote a swc Remote b swc Remote gnd swc Req Req1 Rh frsp (+) Rh frsp (-) Rh rrsp (+) Rh rrsp (-) Right rear door speaker Rxd Sat lch (+) Sat lch (-) Sat rch (+) Sat rch (-) Satellite antenna Satellite radio tuner or pre-wiring for satellite radio tuner (if equipped) Shield Speed signal System Tel sig gnd Tel sig in (+) Tel sig in (-) Tel sig on trig Txd Premium Sound Radio Wiring Diagram, King Cab (2 of 2) for Nissan Frontier SE 2009 List of elements for Premium Sound Radio Wiring Diagram, King Cab (2 of 2) for Nissan Frontier SE 2009: 54 Acc Audio out (+) Audio out (-) Audio out shield B117 (under right front seat) B132 (right "c" pillar) B141 B142 Batt Bcm (left front of center console) Bt antenna Bt antenna shld Combination switch (spiral cable) Cont 1 Cont 2 Cont 3 Fuse 10a Fuse block (j/b) (under right side of dash) Gnd Hot in on or start Ign Ladder gnd Ladder in 1 Ladder in 2 Ladder out 1 Ladder out 2 Led ind 1 Led pwr Led1 camber Left front door speaker Left front tweeter M102 M20 M30 Mic in+ Mic in- Mic out+ Mic out- Mic pwr Mic shield Micro phone Mute ctrl Out saver batt Phone Red Right front door speaker Right front tweeter Seek down Seek up Shield Spd sig Steering wheel audio control switches Vol down Vol up
SHIFT INTERLOCK Shift Interlock Wiring Diagram for Nissan Frontier SE 2009 List of elements for Shift Interlock Wiring Diagram for Nissan Frontier SE 2009: 9 A/t device (in center console) Fuse 12 10a Fuse block (j/b) (under right side of dash) Hot in on or start M61 (behind right side of dash) Park position switch Red Shift lock solenoid Stop light switch (on bracket, above brake pedal)
STARTING/CHARGING Charging Wiring Diagram for Nissan Frontier SE 2009 List of elements for Charging Wiring Diagram for Nissan Frontier SE 2009: 21 Alt c Battery Can h Can l Charge ind Combination meter Computer data lines system Cpu E203 (xterra: right rear of engine compt) (frontier: front of engine compt) Fuse & fusible link box (right rear of engine compt) Fuse 14 10a Fuse 30 15a Fuse block (j/b) (right side of dash) Fusible link a 140a Fusible link box (battery) (frontier: right side of engine compt) Fusible link f 80a Generator Hot in on or start Ipdm e/r (intelligent power distribution module engine room) (right rear of engine e122 compt) Pnk Unified meter control unit (w/ information display) Starting Wiring Diagram, A/T for Nissan Frontier SE 2009 List of elements for Starting Wiring Diagram, A/T for Nissan Frontier SE 2009: 40 A/t assembly Acc Battery Can h Can l Computer data lines system Cpu E119 E120 E122 E124 E15 (2.5l) (right front of engine compt) E24 (4.0l) (right front of engine compt) F502 F503 F505 Fuse & fusible link box (right rear of engine compt) Fusible link box (battery) (frontier: right side of engine compt) Fusible link j 40a Gnd (pwr) Gnd (sig) Hot at all times Ig1 Ign sw Ignition switch Inh sw 1 Inh sw 2 Inh sw 3 Inh sw 4 Inhibit Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) Off Park/ neutral position switch Pnk Red Start Start relay Starter motor Starter relay Transmission control module (tcm) Starting Wiring Diagram, M/T with Clutch Interlock for Nissan Frontier SE 2009 List of elements for Starting Wiring Diagram, M/T with Clutch Interlock for Nissan Frontier SE 2009: 42 (4.0l) Acc Battery Can h Can l Cancel Clutch interlock cancel relay 1 (xterra: behind dash) (frontier: in fuse & relay box) Clutch interlock cancel relay 2 (in fuse & relay box) Clutch interlock cancel switch (xterra: on bracket, above clutch pedal) Clutch interlock switch (above clutch pedal) Computer data lines system Cpu Diode 3 (xterra: right side of engine compt) (frontier: behind left kick panel) E119 E120 E122 E124 E24 (frontier: right front of engine compt) E24 e15 (2.5l) (right front of (right front of engine compt) Engine compt) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fusible link box (battery) (frontier: right side of engine compt) Fusible link j 40a Gnd (pwr) Gnd (sig) Hot at all times Ig1 Ign sw Ignition switch Illumination Inhibit Interior lights system Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) M61 (behind right side of dash) Motor Off Pnk Red Start Starter Starter relay Starting Wiring Diagram, M/T without Clutch Interlock for Nissan Frontier SE 2009 List of elements for Starting Wiring Diagram, M/T without Clutch Interlock for Nissan Frontier SE 2009: 32 (4.0l) Acc Battery Can h Can l Clutch interlock switch (above clutch pedal) Computer data lines system Cpu E119 E120 E122 E124 E24 e15 (2.5l) (right front of (right front of engine compt) Engine compt) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fusible link box (battery) (frontier: right side of engine compt) Fusible link j 40a Gnd (pwr) Gnd (sig) Hot at all times Ig1 Ign sw Ignition switch Inhibit Ipdm e/r (intelligent power distribution module engine room) (right rear of engine compt) Off Pnk Red Start Starter motor Starter relay
SUPPLEMENTAL RESTRAINTS Supplemental Restraints Wiring Diagram (1 of 2) for Nissan Frontier SE 2009 List of elements for Supplemental Restraints Wiring Diagram (1 of 2) for Nissan Frontier SE 2009: 59 Air bag diagnosis sensor unit (under center console) Air bag ind Air bag w/l As1 (+) As1 (-) As2 (+) As2 (-) B113 C-lh1 (+) C-lh1 (-) C-rh1 (+) C-rh1 (-) Can-h Can-l Combination meter Computer data lines system Cutoff telltale Dr1 (+) Dr2 (+) Dri/dr2 (-) Eczs (+) Eczs (-) Front right seat belt pre-tensioner (king cab: right rear door) (crew cab: base of right "b" pillar) Front right side air bag module (if equipped) (in right front seat) Fuse 10a Fuse block (j/b) (under right side of dash) Gnd Hot in on or start Ign Ind K-line Left side air bag (satellite) sensor (if equipped) (left front rocker panel) Left side curtain air bag module (if equipped) (top of left "a" pillar) Lh buckle sw input M35 M57 (behind left side of dash) M61 (behind right side of dash) Ods in P-lh1 (+) P-lh1 (-) P-rh1 (+) P-rh1 (-) Pnk Red Rh buckle sw input Right side air bag (satellite) sensor (if equipped) (right front rocker panel) Right side curtain air bag module (if equipped) (top of right "a" pillar) S-lh1 (+) S-lh1 (-) S-rh1 (+) S-rh1 (-) Satellite-lh (+) Satellite-lh (-) Satellite-rh (+) Satellite-rh (-) Seat belt Seat belt remind Shield Unified meter control unit (w/ information display) Supplemental Restraints Wiring Diagram (2 of 2) for Nissan Frontier SE 2009 List of elements for Supplemental Restraints Wiring Diagram (2 of 2) for Nissan Frontier SE 2009: 32 (behind right side of dash) front passenger air bag module (behind right side of dash) m61 (left side of engine compt) e14 (under driver's seat) b7 (under right front seat) b117 As1 + As1 - As2 + As2 - B117 (under right front seat) Belt tension sensor (crew cab: right "b" pillar) (king cab: right rear door) Combination switch (spiral cable) Crash zone sensor (center front of engine compt) Driver air bag module Fastened Front left seat belt pre-tensioner (crew cab: base of left "b" pillar) (king cab: left rear door) Front left side air bag module (if equipped) (crew cab: in right front seat) (king cab: in driver's seat) Front passenger air bag off indicator Left seat belt buckle switch (in driver's seat belt buckle) M101 M103 M105 M106 Nca Occupant classification system control unit (under right front seat) Occupant classification system sensor (under right front seat) Red Right seat belt buckle switch (king cab: under right front seat) Shield Un- fastened W/ service replacement W/o service replacement
TRANSMISSION 4WD Wiring Diagram, Part Time Mode 4WD (1 of 2) for Nissan Frontier SE 2009 List of elements for 4WD Wiring Diagram, Part Time Mode 4WD (1 of 2) for Nissan Frontier SE 2009: 56 2wd ind 2wd sw 4h sw 4hi ind 4l sw 4lo ind 4lo switch 4lpos sw 4wd fail 4wd ind 4wdposw Acc Actr sw1 Actr sw2 Actr sw3 Actr sw4 Atp ind Atp sw Atp switch Can-h Can-l Combination meter Computer data lines system Data link connector (under left side of dash) E15 (right front of engine compt) E24 (frontier: right front of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Gnd Hot at all times Hot in on or start Ign sw Ignition switch Kline Lock M152 M153 M61 (behind right side of dash) Mem b/u Mtr + Mtr - Mtrmon1 Mtrmon2 Mtrrly1 Mtrrly2 Neut sw Park/neutral position (pnp) switch (on transmission) Pnk Red Run Ssof Start Transfer case control unit (behind left side of dash) Unified meter control unit (w/ information display) Vign Wait detection switch (under vehicle, near transfer case) 4WD Wiring Diagram, Part Time Mode 4WD (2 of 2) for Nissan Frontier SE 2009 List of elements for 4WD Wiring Diagram, Part Time Mode 4WD (2 of 2) for Nissan Frontier SE 2009: 22 (in fuse & relay box) (in fuse & relay box) transfer shift high relay (right rear of engine compt) 2wd 4lo 4wd shift switch Actr sw 1 Actr sw 2 Actr sw 3 Actr sw 4 E24 (frontier: right front of engine compt) Fuse & fusible link box (right rear of engine compt) Fuse & relay box Fuse 10a Fuse link j 40a Hot at all times Interior lights system Red Transfer control device (actuator position switch) Transfer shift low relay (in fuse & relay box) Transfer shut off relay 1 Transfer shut off relay 2 A/T Wiring Diagram (1 of 2) for Nissan Frontier SE 2009 List of elements for A/T Wiring Diagram (1 of 2) for Nissan Frontier SE 2009: 42 A/t assembly A/t fluid temperature sensor 1 A/t fluid temperature sensor 2 Atf sens1+ Atf sens1- Atf sens2+ Atf sens2- C1 (vin) C2 (vout) C3 (gnd) Can-h Can-l Data link connector (under left side of dash) Exterior lights system F10 (2.5l) (on front of engine) (4.0l) (frontier: left front of engine) (xterra: top left side of engine) F502 F503 F504 F505 F506 Gnd Gnd-1 Gnd-2 Inh-sw1 Inh-sw2 Inh-sw3 Inh-sw4 K-line Park/neutral position switch Pnk Red Rev rly Rev sen gnd Rev sen vin Rev sen vout Revolution sensor Start rly Starting/ charging system Tcm (transmission control module) V out Vcc Vign A/T Wiring Diagram (2 of 2) for Nissan Frontier SE 2009 List of elements for A/T Wiring Diagram (2 of 2) for Nissan Frontier SE 2009: 21 1st pos switch A/t device (in center console) A/t oil temp ind Can-h Can-l Combination meter Computer data lines system E119 E16 Ecm (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Hot at all times Hot in on or start Ipdm e/r (right rear of engine compt) M57 (frontier: behind left side of dash) (xterra: left a-pillar) M61 (behind right side of dash) O/d off ind Od control switch Pnk Unified meter control unit (w/ information display) Differential Lock Wiring Diagram for Nissan Frontier SE 2009 List of elements for Differential Lock Wiring Diagram for Nissan Frontier SE 2009: 29 13p Can h Can l Combination meter Computer data lines system Diff lock cu Diff lock cu (back up) Diff lock high Diff lock ind Diff lock low Diff lock sw Diff lock sw off Diff lock sw on Differential lock control unit Differential lock mode switch Differential lock position switch (at differential) Differential lock solenoid (at differential) E24 (right front of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Gnd Hot at all times Hot in on or start Interior lights system M24 M4 5p Pnk Red Sss
WARNING SYSTEMS Warning Systems Wiring Diagram for Nissan Frontier SE 2009 List of elements for Warning Systems Wiring Diagram for Nissan Frontier SE 2009: 58 15p Air bag diagnosis sensor unit (under center console) B7 (under driver's seat) Bat (f/l) Bcm (left front of center console) Buckle sw lh Buzzer Can-h Can-l Combination meter Combination switch Computer data lines system Crew cab Door ind Door sw (dr) Fuse & fusible link box (right rear of engine compt) Fuse 10a Fuse block (j/b) (under right side of dash) Fusible link g 50a Gnd Gnd (pwr) Headlights system Hot at all times Hot in on or start Ign sw Input 1 Input 2 Input 3 Input 4 Input 5 Key sw Key switch King cab Left front door switch (in left "b" pillar) Left seat belt buckle switch (in driver's seat belt buckle) M18 M19 M20 M28 M35 M57 (behind left side of dash) Output 1 Output 2 Output 3 Output 4 Output 5 Pnk Pwr Red Remote keyless entry receiver (top right side of dash) Seat belt ind Seat belt remind Signal Tire pressure ind Tire pressure warning check connector (behind left side of dash) Tpms mode sw Tuner sens gnd Unified meter control unit (w/ information display)
WIPER/WASHER Wiper/Washer Wiring Diagram for Nissan Frontier SE 2009 List of elements for Wiper/Washer Wiring Diagram for Nissan Frontier SE 2009: 53 (2.5l) (4.0l) Bcm (body control module) (frontier: left front of center console) (except frontier: under left side of dash) Can-h Can-l Combination meter Combination switch (wiper switch) Computer data lines system Cpu E121 E122 E15 e24 (except xterra: right front of engine compt) E9 (left side of engine compt) Front washer motor (except xterra: right side of engine compt) (xterra: right rear of engine compt) Front wiper high relay Front wiper motor (frontier: left rear of engine compt) (except frontier: on left side of firewall) Front wiper relay Fuse 10a Fuse 30a Fuse block (j/b) (except pathfinder: under right side of dash) (pathfinder: behind right end of dash) Gnd Gnd (power) High Hot at all times Hot in on or start Ign Ign sw Ignition relay Input 1 Input 2 Input 3 Input 4 Input 5 Ipdm e/r (right rear of engine compt) Low M18 M20 M28 M4 15p M57 (except xterra: behind left side of dash) (xterra: left "a"pillar) Move Output 1 Output 2 Output 3 Output 4 Output 5 Pnk Red Stop Unified meter control unit (with information display) Was mtr (+) Was mtr (-) Washer fluid level switch (except pathfinder: right side of engine compt) (pathfinder: in washer fluid reservoir) Washer ind
