Diagram sections — 32 (82 total)
AIR CONDITIONING ANTI-LOCK BRAKES ANTI-THEFT BODY CONTROL MODULES COMPUTER DATA LINES COOLING FAN CRUISE CONTROL DEFOGGERS ELECTRONIC POWER STEERING ENGINE PERFORMANCE EXTERIOR LIGHTS GROUND DISTRIBUTION HEADLIGHTS HORN INSTRUMENT CLUSTER INTERIOR LIGHTS MEMORY SYSTEMS NAVIGATION POWER DISTRIBUTION POWER DOOR LOCKS POWER MIRRORS POWER SEATS POWER TOP/SUNROOF POWER WINDOWS RADIO SHIFT INTERLOCK STARTING/CHARGING SUPPLEMENTAL RESTRAINTS TRANSMISSION TRUNK, TAILGATE, FUEL DOOR WARNING SYSTEMS WIPER/WASHER
AIR CONDITIONING Automatic A/C Wiring Diagram (1 of 2) for Nissan Maxima S 2014 List of elements for Automatic A/C Wiring Diagram (1 of 2) for Nissan Maxima S 2014: 65 23g A/c & av switch assembly (w/o monochrome display) A/c auto amplifier (behind center of dash) A/c display unit (w/ monochrome display) A/c switch assembly (w/ monochrome Acc Amb sns Av control unit (w/o monochrome display) Bat Bcm (body control module) (behind instrument cluster) Blower motor (behind right side of dash) Blwr fan rly Can-h Can-l Computer data lines system Defogger system Display) Driver side air mix door motor (behind left center of dash) E30 Fan pwm Front blower motor relay Fuse 10a Fuse 15a Fuse block (j/b) (lower left side of dash) Fusible link box (battery) (at battery) Fusible link c 100a Gnd Gnd (power) Hot at all times Hot in acc or on Hot in on or start Ign Ill+ Ill- In-vehicle sensor (behind left center of dash) Incar sns Intake door motor (behind center of dash) Intake sensor (behind right side of dash) Intake sns Interior lights system Lan sig M-can h M-can l M125 M152 M156 M160 M163 M19 M33 M57 (behind right side of dash) M61 (behind left side of dash) M79 (left center of dash) Mode door motor (behind left center of dash) Passenger side air mix door motor (behind right side of dash) Pnk Rr def on Sns gnd Sun sns Sunload sensor (on left defroster grille) Vactr W/ monochrome display W/ navigation system W/o monochrome display W/o navigation system Automatic A/C Wiring Diagram (2 of 2) for Nissan Maxima S 2014 List of elements for Automatic A/C Wiring Diagram (2 of 2) for Nissan Maxima S 2014: 59 25g 32g A/c compressor (at left front of engine) A/c relay Ambient sensor (left front of vehicle) Avcc2 Avcc2- pdpres Can-h Can-l Computer data lines system Cooling fan motor 1 (front of engine compt) Cooling fan motor 2 (front of engine compt) Cooling fan relay 1 Cooling fan relay 2 (left side of engine compt) Cooling fan relay 3 (in fuse & fusible link box) Cpu E10 E11 E12 E12 e203 E15 (left side of engine compt) E17 E18 E201 E203 E209 (right front of engine compt) E3 f1 E30 E44 E48 E9 (left rear of engine compt) Ecm (engine control module) (left front of engine compt) Engine coolant temperature sensor (left rear of engine) F10 F13 Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 15a Fusible link k 40a Fusible link m 40a Gnd Gnda-pdres Gnda-tw Hot at all times Hot in on or start Ignition relay 1 Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Joint connector e01 (left side of engine compt) Joint connector e02 (left rear of engine compt) Junction block e44 & e48 Motor fan rly hi Motor fan rly mid P-gnd Pdres Pnk Red Refrigerant pressure sensor (on a/c liquid tank) S-gnd Sig
ANTI-LOCK BRAKES Anti-lock Brakes Wiring Diagram (1 of 2) for Nissan Maxima S 2014 List of elements for Anti-lock Brakes Wiring Diagram (1 of 2) for Nissan Maxima S 2014: 62 (behind left side of dash) m61 75g Abs actuator & electric unit (control unit) (right rear corner of engine compt) Abs/tcs/vdc control unit Actuator B31 c5 Bls Can-h Can-l Can-m2 Can-p2 Computer data lines system Dp fl Dp fr Dp rl Dp rr Ds fl Ds fr Ds rl Ds rr E18 E29 b10 E30 m1 E33 (right rear of engine compt) E44 E46 E47 E49 Fl in Fl out Fr in Fr out Fuse & fusible link box (left front of engine compt) Fuse 10a Fusible link f 50a Fusible link g 30a Gnd Hot at all times Hot in on or start Hsv 1 Hsv 2 Interior lights system Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Junction block e44, e46, e47 & e49 Left front wheel sensor (on left front wheel hub assembly) Left rear wheel sensor (on left rear wheel hub assembly) Motor Motor relay Pnk Red Relay unit Right front wheel sensor (on right front wheel hub assembly) Right rear wheel sensor (on right rear wheel hub assembly) Rl in Rl out Rr in Rr out Solenoid valve relay Usv 1 Usv 2 Vdc off sw Vdc off switch Anti-lock Brakes Wiring Diagram (2 of 2) for Nissan Maxima S 2014 List of elements for Anti-lock Brakes Wiring Diagram (2 of 2) for Nissan Maxima S 2014: 34 (left side of engine comp) (w/ information display) unified meter control unit 12m 24g 31g 67g 70g 77g Abs ind Brake fluid level switch (on master cylinder Brake ind Can-h Can-l Combination meter Computer data lines system E15 E30 m1 Fuse 10a Fuse block (j/b) (lower left side of dash) Gnd Hot at all times Hot in on or start M1 e30 M79 (left center of dash) Park brake switch (on brake pedal bracket) Pnk Pwr Red Reservoir) Slip ind Steering angle sensor (on steering column) Stop light switch (on brake pedal bracket) Vdc off ind Yaw rate/ side/decel g sensor (under rear of center console)
ANTI-THEFT Anti-theft Wiring Diagram (1 of 4) for Nissan Maxima S 2014 List of elements for Anti-theft Wiring Diagram (1 of 4) for Nissan Maxima S 2014: 88 (behind right side of dash) m57 11p 13j 14j 20g 27g 57g 82g Acc led As door ant a As door ant b As door sw 1 As request switch At device out Back door ant a Back door ant b Bat bcm fuse Batt f/l Bcm (body control module) (behind instrument cluster) Brake sw 1 Brake sw 2 Buzzer Can-h Can-l Computer data lines system Cpu Cvt shift selector (park position) switch (intelligent key system) Door lock output all Door lock status dr Door unlock output as Door unlock output dr/fl Door unlock output rr/rl Dr door ant a Dr door ant b Dr door switch Dr request switch E18 E30 Eng start sw Exterior lights system Fl flasher Fob in switch 1 Fob reader data Fob slot illumination Fr flasher Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd rf2 a/l Gnd1 Hazard switch Hot at all times Ign on led Ign relay output Immo led Intelligent key warning buzzer (behind left end of dash) Interior lights system Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) M16 M17 M18 M19 M21 Ob reader clock P/w pwr sply ign P/w pwr sply perm Pnk Pw k-line R/l pwr sply Rear bumper antenna (behind center of rear bumper) Red Remote keyless entry receiver (behind right end of dash) Rf1 tuner signal Rl door switch Room ant 2 a Room ant 2 b Room lamp cont Rr door switch S/l lock led Shift n/p/neutral sw Shift p/ascd cancel sw St relay output Stop lamp switch (on brake pedal bracket) Trunk ant 1 a Trunk ant 1 b Trunk request switch Trunk switch Anti-theft Wiring Diagram (2 of 4) for Nissan Maxima S 2014 List of elements for Anti-theft Wiring Diagram (2 of 4) for Nissan Maxima S 2014: 45 (left side of engine compt) e15 11j 12j 19g 28j 29g Computer data lines system Cpu D102 D106 D115 D15 E16 E17 E18 E30 F10 Front console antenna (behind center of dash) Fuse & fusible link box (left front of engine compt) Fusible link b 80a Fusible link box (battery) (at battery) Fusible link l 40a Headlamp high relay Headlamp low relay Headlights system Horns system Hot at all times Ignition relay 1 Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) J/c e01 (left side of engine compt) Left front outside handle Left rear door switch (left "c" pillar) M12 M15 M61 (behind left side of dash) M79 (left center of dash) Outside key antenna Pnk Rear parcel shelf antenna (under center of rear parcel shelf) Red Request switch Right front outside handle Starter control relay Starter relay Starting/ charging system Anti-theft Wiring Diagram (3 of 4) for Nissan Maxima S 2014 List of elements for Anti-theft Wiring Diagram (3 of 4) for Nissan Maxima S 2014: 26 (right "b" pillar) 10j 26j 27j 33g B104 B19 (left "c" pillar) B24 E30 E46 E50 Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link box (battery) (at battery) Fusible link d 60a Hot at all times Junction block e46 & e50 Left front door switch (left "b" pillar) M10 Red Right front door switch Right rear door switch (right "c" pillar) St rly Tcm (transmission control module) (left front of engine compt) Trunk lid switch & trunk release solenoid (trunk lamp switch) (center rear of luggage compt lid) Trunk opener request switch Anti-theft Wiring Diagram (4 of 4) for Nissan Maxima S 2014 List of elements for Anti-theft Wiring Diagram (4 of 4) for Nissan Maxima S 2014: 47 96j 97j Acc ind Actuator B104 B134 d306 Between full stroke & n Buzzer Combination meter Computer data lines system Cpu D101 D201 Door unlock sensor Fuel lid door lock actuator (left side of luggage compt) Full stroke Interior lights system J/c b05 (in trunk lid) Key cylinder switch Key ind Key slot Left front door lock assembly (rear of driver's door) Left rear door lock actuator (rear of left rear door) Lock Lock ind Lock switch M10 M11 M12 M14 M14 d101 M57 (behind right side of dash) M61 (behind left side of dash) M79 (left center of dash) Main power window & door lock/unlock switch On ind Pnk Push button ignition switch Push switch Red Right front door lock actuator (rear of front passenger's door) Right power window & door lock/unlock switch Right rear door lock actuator (rear of right rear door) Security ind Unified meter control unit (w/ information display) Unlock Unlock switch
BODY CONTROL MODULES
COMPUTER DATA LINES Computer Data Lines Wiring Diagram for Nissan Maxima S 2014 List of elements for Computer Data Lines Wiring Diagram for Nissan Maxima S 2014: 67 (on steering column) steering angle sensor 15g 15j 16j 34g 51g 52g 8g m1 A/c & av switch assembly A/c auto amplifier (behind center of dash) Abs actuator & electric unit (control unit) (right rear corner of engine compt) Air bag diagnosis sensor unit (under rear of center console) Av control unit B10 B125 B203 B208 B32 Bcm (body control module) (behind instrument cluster) Can h1 Can h2 Can l1 Can l2 Can-h Can-l Combination meter Connector (below left side of dash) Data link Driver's seat control unit (under driver's seat) E10 E17 E29 E30 E45 E46 Ecm (engine control module) (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Hot at all times Hot in on or start Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Joint connector b01 (near base of left "b" pillar) Joint connector e03 (left rear of engine compt) Joint connector e04 (left rear of engine compt) Junction block e45 & e46 K-line M can h M can h trm M can l M can l trm M can2 h M can2 l M1 e30 M110 b136 M156 M163 M19 M43 M61 (behind left side of dash) Pnk Red Tcm (transmission control module) (left front of engine compt) W/ color display W/ memory W/ navigation W/o memory W/o navigation
COOLING FAN Cooling Fan Wiring Diagram for Nissan Maxima S 2014 List of elements for Cooling Fan Wiring Diagram for Nissan Maxima S 2014: 55 A/c compressor (at left front of engine) A/c relay Avcc2 Avcc2- pdpres Can-h Can-l Computer data lines system Cooling fan motor 1 (front of engine compt) Cooling fan motor 2 (front of engine compt) Cooling fan relay 1 Cooling fan relay 2 (left side of engine compt) Cooling fan relay 3 (in fuse & fusible link box) Cpu E10 E12 E15 (left side of engine compt) E17 E18 E201 E203 E203 e12 E209 (right front of engine compt) E44 E48 E9 (left rear of engine compt) Ecm (engine control module) (left front of engine compt) Engine coolant temperature sensor (left rear of engine) F1 e3 F10 F13 F2 e11 Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 15a Fusible link k 40a Fusible link m 40a Gnd Gnda-pdres Gnda-tw Hot at all times Hot in on or start Ignition relay 1 Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Joint connector e01 (left side of engine compt) Joint connector e02 (left rear of engine compt) Junction block e44 & e48 Motor fan rly hi Motor fan rly mid P-gnd Pdres Pnk Red Refrigerant pressure sensor (on a/c liquid tank) S-gnd Sig
CRUISE CONTROL Cruise Control Wiring Diagram for Nissan Maxima S 2014 List of elements for Cruise Control Wiring Diagram for Nissan Maxima S 2014: 75 (left rear of engine compt) e9 12m 55g 58g Accel/res switch Accelerator pedal position sensor Aps1 Aps2 Ascd brake switch Ascd steering switch Ascdsw Avcc1-aps1 Avcc1-tps-b1 Avcc2-aps2 Bncsw Brake Can-h Can-l Cancel switch Coast/set switch Combination meter Combination switch (spiral cable) (in steering column) Computer data lines system Cruise ind Cvt unit (left rear of engine) E10 E30 m1 E44 E45 E46 E9 (left rear of engine compt) Ecm (engine control module) (left front of engine compt) Electric throttle control actuator (on throttle body) F13 F14 Fuse 10a Fuse 10a f10 Fuse block (j/b) (lower left side of dash) Gnd Gnda-aps1 Gnda-aps2 Gnda-ascdsw Gnda-tps-b1 Hot at all times Hot in on or start Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Junction block e44, e45 & e46 Junction block e45 & e46 M30 M79 (left center of dash) M88 Motor1-b1 Motor2-b1 On/off (main) switch Pnk Pri speed sens Pri speed sensor Primary speed sensor Red Sec spd sens Sec speed sens Secondary speed sensor (top of transaxle) Sens power source Sensor 1 Sensor 2 Sensor gnd Sns pwr source Stoplight switch (on brake pedal bracket) Tcm (left front of engine compt) Throttle control motor Throttle position sensor Tps1-b1 Tps2-b1 Unified meter control unit (w/ information display) Vign
DEFOGGERS Defoggers Wiring Diagram for Nissan Maxima S 2014 List of elements for Defoggers Wiring Diagram for Nissan Maxima S 2014: 52 (behind right side of dash) m57 10m m5 10t b4 11t 1s e7 2n m3 4q m4 A/c auto amplifier (behind center of dash) A/c display unit (w/ monochrome display) A/c switch assembly B53 B54 B58 (right "c" pillar) Batt (f/l) Bcm (body control module) (behind instrument cluster) Can-h Can-l Computer data lines system D102 Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 20a Fuse block (j/b) (lower left side of dash) Fusible link box (battery) (at battery) Fusible link c 100a Fusible link h 40a Gnd Gnd1 Hot at all times Hot in on or start Ign Ign f/b Left door mirror (door mirror defogger) (w/ heated mirrors) (at mirror) M12 M15 M16 M17 M18 M19 M57 (behind right side of dash) M61 (behind left side of dash) M79 (left center of dash) Pnk Rear window defogger Rear window defogger condenser (left "c" pillar) Rear window defogger relay Right door mirror (door mirror defogger) (w/ heated mirrors) (at mirror) Rr def on Rr def rly Rr def sw W/ monochrome display W/o monochrome display
ELECTRONIC POWER STEERING Electronic Power Steering Wiring Diagram for Nissan Maxima S 2014 List of elements for Electronic Power Steering Wiring Diagram for Nissan Maxima S 2014: 28 (behind right side of dash) m57 (cabin) tacho 2p/r out 60g 61g 62g Can-h Can-l Combination meter Computer data lines system E10 E30 E30 m1 Eng tacho Engine control module (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Gnd Hot in on or start Ign Pnk Power steering control unit (right side of dash) Power steering solenoid valve (left rear of engine compt) Sol Sol gnd Steering angle sensor (on steering column) Unified meter control unit (w/ information display) Vehicle spd (2p)
ENGINE PERFORMANCE
3.5L 3.5L, Engine Performance Wiring Diagram (1 of 4) for Nissan Maxima S 2014 List of elements for 3.5L, Engine Performance Wiring Diagram (1 of 4) for Nissan Maxima S 2014: 77 (1, 3 & 5: top of right cylinder bank) (2, 4 & 6: top of left cylinder bank) fuel injectors 12m Af+1 Af+2 Af-1 Af-2 Afh1 Afh2 Avcc1-cursen,int Avcc1-pspres Avcc1-tps-b1 Avcc2 Battery current sensor (left side of engine compt) Cursen E18 E44 E46 E9 (left rear of engine compt) Ecm (engine control module) (left front of engine compt) Electronic controlled engine mount control solenoid valve Emmnv Engine coolant temperature sensor (left rear of engine) Engine oil temperature sensor (lower right front of engine) Evap Evap canister purge volume control solenoid valve (top rear of engine) F13 F14 F2 e11 Fpr Fuse 10a Fuse block (j/b) (lower left side of dash) Gnd Gnda-cursen,int Gnda-o2sr1, o2sr2 Gnda-pdpres Gnda-pspres Gnda-tps-b1 Gnda-tw,to1 Hot in on or start Ign 1 Ign 2 Ign 3 Ign 4 Ign 5 Ign 6 Inj 1 Inj 2 Inj 3 Inj 4 Inj 5 Inj 6 Ipdm e/r (intelligent power distribution e201 Junction block e44 & e46 Module engine room) (left side of engine compt) Mot rly-b1 Motor1-b1 Motor2-b2 O2hr1 O2hr2 O2sr1 O2sr2 Pdpres Pnk Power steering pressure sensor (on power steering high pressure tube) Pspres Qa1-gnda-ta1 Red Refrigerant pressure sensor (on a/c liquid tank) Sig Ssoff Ta1 To1 Tps1-b1 Tps2-b1 Vias 1 Vias 2 Vmot-b1 3.5L, Engine Performance Wiring Diagram (2 of 4) for Nissan Maxima S 2014 List of elements for 3.5L, Engine Performance Wiring Diagram (2 of 4) for Nissan Maxima S 2014: 30 Combination meter Computer data lines system Condenser-2 (left rear of engine) E18 E29 b10 Ecm relay Electric throttle control actuator (on throttle body) F10 F16 (left rear of engine) Fuel pump relay Fuse 15a Hot at all times Hot in on or start Ignition coils (w/ power transistor) (1, 3 & 5: top of right cylinder bank) (2, 4 & 6: top of left cylinder bank) Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Loop wire M24 M79 (left center of dash) Malfunction indicator lamp (mil) Nca Plug spark Pnk Red Sensor 1 Sensor 2 Spark plug Throttle control motor Throttle control motor relay Throttle position sensor Unified meter control unit (w/ information display) 3.5L, Engine Performance Wiring Diagram (3 of 4) for Nissan Maxima S 2014 List of elements for 3.5L, Engine Performance Wiring Diagram (3 of 4) for Nissan Maxima S 2014: 31 (left front of engine compt) tcm (transmission control module) Air/fuel ratio (a/f) sensor 1 (bank 1) (right side of engine) Air/fuel ratio (a/f) sensor 1 (bank 2) (left side of engine) Camshaft position sensor (phase) (bank 1) (rear of right cylinder head) Camshaft position sensor (phase) (bank 2) (rear of left cylinder head) Crankshaft position sensor (pos) (left rear of engine) E11 E18 E44 E44 junction block e44 & e45 e45 E45 E9 (left rear of engine compt) Exhaust valve timing control position sensor (bank 1) Exhaust valve timing control position sensor (bank 2) F10 Fuse 10a Fuse 15a Fuse block (j/b) (lower left side of dash) Heated oxygen sensor 2 (bank 1) (on right exhaust tube assembly) Heated oxygen sensor 2 (bank 2) (on left exhaust manifold) Hot at all times Hot in on or start Intake air temperature sensor Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Junction block e44 & e45 Mass airflow sensor (on intake air duct) Nca Pnk Red St rly Stop light switch (on brake pedal bracket) 3.5L, Engine Performance Wiring Diagram (4 of 4) for Nissan Maxima S 2014 List of elements for 3.5L, Engine Performance Wiring Diagram (4 of 4) for Nissan Maxima S 2014: 82 (front of left cylinder head) intake valve timing control solenoid valve (bank 1) (in fuel tank) fuel level sensor unit & fuel pump (top left side of engine) vias control solenoid valve (bank 1) (top right rear of engine) vias control solenoid valve (bank 2) 30j 63g Accelerator pedal position sensor (on accelerator pedal bracket) Aps1 Aps2 Ascdsw Avcc & e phase 1 Avcc & e phase 2 Avcc1-aps1 Avcc2-aps2 Avcc2-ftpres Avcc2-pdpres Avcc2-pos B10 B7 (under driver's seat) Batt Bncsw Brake Can-h Can-l Cdcv Computer data lines system Cruise control system Cvtc 1 Cvtc 2 E phase 1 E-phase 2 E10 E11 E29 E30 E45 E50 E9 (left rear of engine compt) Ecm (engine control module) (left front of engine compt) Electronic power steering system Evap canister vent control valve (on evap canister) Evap control system pressure sensor (under left Evtc 1 Evtc 2 Exhaust valve timing control magnet retarder (bank 1) (left rear of engine) Exhaust valve timing control magnet retarder (bank 2) (left front of engine) F13 F201 F69 Ftpres Fuel pump Fuel tank temperature sensor Gnd Gnd phase 2 Gnda-aps1 Gnda-aps2 Gnda-ascdsw Gnda-ftpres Gnda-knk1, knk2 Gnda-tf Ignsw Instrument cluster system Intake valve timing control solenoid valve (bank 2) (front of right cylinder head) Junction block Kline Knk1 Knk2 Knock sensor (bank 1) (top of cylinder block) Knock sensor (bank 2) (top of cylinder block) Neut-h Phase 1 Phase 2 Pnk Pos Qa1+ avcc 1 phase1 & e phase1 gnd-pos Rear of vehicle) Red Sensor 1 Sensor 2 Shield Tacho (cabin) Vbr
EXTERIOR LIGHTS Backup Lamps Wiring Diagram for Nissan Maxima S 2014 List of elements for Backup Lamps Wiring Diagram for Nissan Maxima S 2014: 23 (left "c" pillar) 12m m5 B19 Backup Backup light relay (on fuse block (j/b)) Cvt unit (left rear of engine) E29 b10 E30 E47 E49 Fuse 4 10a Fuse block (j/b) (lower left side of dash) Hot in on or start J/c b05 (in trunk lid) Junction block e47 & e49 Left rear combination lamp M1 13g R range sw Red Rev lamp rly Right rear combination lamp Transmission control module (tcm) (left front of engine compt) Transmission range switch Exterior Lamps Wiring Diagram (1 of 2) for Nissan Maxima S 2014 List of elements for Exterior Lamps Wiring Diagram (1 of 2) for Nissan Maxima S 2014: 78 (behind right side of dash) m57 (left side of engine compt) As door sw B19 (left "c" pillar) B28 B500 Bat (f/l) Bat bcm fuse Body control module (bcm) (behind instrument cluster) Can-h Can-l Combination switch (lighting & turn signal switch) Computer data lines system Cpu D102 Dr door sw E15 (left side of engine compt) E16 E17 E18 E201 E202 E204 E209 (w/o xenon headlamp) e204 (w/ xenon headlamp) (w/o xenon headlamp: right front of engine compt) (w/ xenon headlamp: left side of engine compt) E224 E225 E235 E30 Fl flasher Fr flasher Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 15a Fusible link box (battery) (at battery) Fusible link d 60a Fusible link h 40a Gnd1 Hazard sw Hazard switch High mounted stop lamp Hot at all times Input 1 Input 2 Input 3 Input 4 Input 5 Interior lights system Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) M15 M16 M17 M18 M19 M21 M6 3j M79 (left center of dash) Nca Output 1 Output 2 Output 3 Output 4 Output 5 Park Pnk Right door mirror (w/ turn signal in mirror) (at mirror) Right front combination lamp Right rear combination lamp Rl door sw Rr door sw Side marker Stop Tail Tail lamp relay Turn signal W/ rear sunshade W/ xenon headlamp W/o rear spoiler W/o xenon headlamp Exterior Lamps Wiring Diagram (2 of 2) for Nissan Maxima S 2014 List of elements for Exterior Lamps Wiring Diagram (2 of 2) for Nissan Maxima S 2014: 44 12m m5 8p e6 B19 (left "c" pillar) B24 Buzzer Combination meter Computer data lines system E202 E204 (w/o xenon headlamp) e209 (w/ xenon headlamp) (w/o xenon headlamp: left side of engine compt) (w/ xenon headlamp: right front of engine compt) E209 (right front of engine compt) E217 E218 E234 E30 Fuse 10a Fuse block (j/b) (lower left side of dash) High mounted stop lamp (w/ rear spoiler) Hot at all times Hot in on or start J/c b05 (in trunk lid) Left door mirror (w/ turn signal in mirror) (at mirror) Left front combination lamp Left license plate lamp Left rear combination lamp Left turn ind Light ind M1 1g M4 6q M6 4j M61 (behind left side of dash) M79 (left center of dash) Park Pnk Red Right license plate lamp Right turn ind Side marker Stop Stop light switch (on brake pedal bracket) Tail Turn signal Unified meter control unit (w/ information display) W/ xenon headlamp W/o xenon headlamp
GROUND DISTRIBUTION Ground Distribution Wiring Diagram for Nissan Maxima S 2014 List of elements for Ground Distribution Wiring Diagram for Nissan Maxima S 2014: 38 Abs actuator & electric unit (control unit) Air bag diagnosis sensor unit shield & left side air bag (satellite) sensor shield Air bag diagnosis sensor unit shield & right side air bag (satellite) sensor shield B114 (base of right "b" pillar) B117 (right "b" pillar) B132 (right "c" pillar) B19 (left "c" pillar) B5 (under driver's seat) B58 (right "c" pillar) B7 (under driver's seat) Bcm (body control module), front passenger air bag off indicator, a/c auto amp, adp steering switch, key slot, av control unit (bose w/ color display), power steering control unit, automatic drive positioner control unit, glove box lamp, trunk lid opener switch, display unit, a/c display unit (w/ monochrome display), a/c switch assembly (w/ monochrome display), aux in jack shield, (bose w/ color display), intake door motor, mode door motor, driver side air mix door motor, passenger side air mix door motor & av control unit shield (bose w/ color display) Data link connector, combination switch, blower motor, climate controlled seat relay (if equipped), trunk lid opener cancel switch, vdc off switch, heated steering wheel switch, door mirror remote control switch, left vanity mirror lamp, auto anti-dazzling inside mirror, sunroof switch, right vanity mirror lamp, sunroof motor assembly, left door mirror, main power window & door lock/unlock switch, left front door lock assembly, right front outside handle, seat memory switch, left front outside handle & left rear personal lamp E15 (left side of engine compt) E204 (left side of engine compt) E206 (left side of engine compt) E209 (right front of engine compt) E229 (right front of engine compt) E33 (right rear of engine compt) E9 (left rear of engine compt) Ecm, cooling fan relay 2, air fuel ratio (a/f) sensor 1 (bank 1) shield, electric throttle control actuator shield & air fuel ratio (a/f) sensor 1 (bank 2) shield F16 (left rear of engine) F24 Fuse block (j/b), combination meter, spiral cable, air bag diagnosis sensor unit, push-button ignition switch (push switch), steering angle sensor, hazard switch, yaw rate/side/decel g sensor, right front outside handle, a/c & av switch assembly (bose w/ color display), cvt shift selector, paddle shifter (shift up), paddle shifter (shift down), front power socket, front console power socket, right front heated seat switch (w/ climate controlled seat), left front heated seat switch, (w/o climate controlled seat), climate controlled seat switch (if equipped), rear sunshade switch, right power window & door lock/unlock switch, right door mirror & accessory relay 2 Generator Ignition coils 1, 2, 3, 4, 5 & 6 (w/ power transistor) & condenser 2 Ipdm e/r (intelligent power distribution module engine room), brake fluid level switch, front wiper motor, shift lock relay, cooling fan relay 3, a/c compressor & tcm (transmission control module) Joint connector m02 (left side of dash) Left front combination lamp (w/ xenon headlamp), cooling fan motor 2, right front combination lamp (w/o xenon headlamp) & right front fog lamp Left front door satellite sensor shield, right front door satellite sensor shield, air bag diagnosis sensor unit & crash zone sensor shield Left reclining motor (w/ memory), left front power seat, left seat belt buckle switch, fuel level sensor unit & fuel pump, left power seat switch, left front seat heater lumbar support switch, climate controlled seat control unit (if equipped), driver seat control unit & left rear power window switch M57 (behind right side of dash) M61 (behind left side of dash) M79 (left center of dash) Nca Rear window defogger Shield Subwoofer amp (w/ base audio), left rear combination lamp, high mounted stop lamp, right rear combination lamp, trunk opener request switch, left license plate lamp, trunk lamp switch & trunk release solenoid, right license plate lamp, high mounted stop lamp shield & rear sun shade unit Washer fluid level switch, left front fog lamp left front combination lamp, daytime light relay (if equipped) & right front combination lamp
HEADLIGHTS Headlights Wiring Diagram (1 of 2) for Nissan Maxima S 2014 List of elements for Headlights Wiring Diagram (1 of 2) for Nissan Maxima S 2014: 55 12m 24g 28j A/l signal As door sw1 B104 Bat (f/l) Bat bcm fuse Body control module (bcm) (behind instrument cluster) Brake ind Can-h Can-l Combination meter Combination switch (lighting & turn signal switch) Computer data lines system Dr door sw E30 Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd Gnd 1 Gnd pwr High beam ind Hot at all times Hot in on or start Input 1 Input 2 Input 3 Input 4 Input 5 Left rear door switch (left "c" pillar) Light ind M10 M16 M17 M18 M19 M21 M57 (behind right side of dash) M79 (left center of dash) Optical sensor (top right side of dash) Output 1 Output 2 Output 3 Output 4 Output 5 Park brake switch (on brake pedal bracket) Pkb Pnk Right rear door switch (right "c" pillar) Rl door sw Rr door sw Unified meter control unit (w/ infor- mation display) Headlights Wiring Diagram (2 of 2) for Nissan Maxima S 2014 List of elements for Headlights Wiring Diagram (2 of 2) for Nissan Maxima S 2014: 51 (left side of engine compt) (w/ halogen) e204 (right front of engine compt) 10j B104 Computer data lines system Cpu Daytime light relay (w/ drl) E15 (left side of engine compt) E16 E17 E18 E200 E201 E202 E204 (left side of engine compt) E209 E209 (w/ xenon) (right front of engine compt) E212 E213 E222 E223 E231 E232 E233 Front fog lamp relay Fuse 10a Fuse 15a Fusible link box (battery) (at battery) Fusible link d 60a Headlamp high Headlamp high relay Headlamp low Headlamp low relay Hid cont Hot at all times Hot in on or start Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Left front combination lamp Left front door switch (left "b" pillar) Left front fog lamp M10 Pnk Right front combination lamp Right front door switch (right "b" pillar) Right front fog lamp W/ drl W/ halogen W/ halogen w/o drl W/ xenon W/ xenon w/o drl W/o drl
HORN Horn Wiring Diagram for Nissan Maxima S 2014 List of elements for Horn Wiring Diagram for Nissan Maxima S 2014: 17 Combination switch (spiral cable) (in steering column) Cpu E17 E202 E30 Fuse & fusible link box (left front of engine compt) Fuse 30 15a Horn (high) (left front of engine compt) Horn (low) (left front of engine compt) Horn relay (in fuse & fusible link box) Horn sw/horn rly Horn switch Hot at all times Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) M1 30g M30 M88
INSTRUMENT CLUSTER Instrument Cluster Wiring Diagram (1 of 2) for Nissan Maxima S 2014 List of elements for Instrument Cluster Wiring Diagram (1 of 2) for Nissan Maxima S 2014: 69 (left center of dash) m79 12m 24g 29j 30j 31g Abs ind Air bag ind Auto anti-dazzling inside mirror Av control unit Belt ind Brake fluid level switch (on master cylinder reservoir) Brake ind Buzzer Charge ind Combination meter Computer data lines system Cruise ind Cvt check ind E15 (left side of engine compt) E30 Electronic power steering system Fuel gauge Fuel level sensor unit & fuel pump (fuel level sensor) (in fuel tank) Fuse 3 10a Fuse 4 10a Fuse 6 10a Fuse block (j/b) (lower left side of dash) Gnd High beam ind Hot at all times Hot w/ ignition relay 2 energized Ign Interior lights system Key ind Left turn ind Light ind M119 M156 M163 M23 M24 M61 (behind left side of dash) M79 (left center of dash) Malfunction ind lamp (mil) Master ind Meter illum Oil ind Parking brake switch (on brake pedal bracket) Pkb sig Pnk Red Right turn ind Security ind Slip ind Sound, navigation & power tops systems Speedometer Starting/charging system Tachometer Tire pressure ind Transmissions system Unified meter control unit (w/ information display) Vdc off ind W/ navigation W/o navigation & bose W/o navigation w/ bose Warning systems Water temperature gauge Wiper/washer system Instrument Cluster Wiring Diagram (2 of 2) for Nissan Maxima S 2014 List of elements for Instrument Cluster Wiring Diagram (2 of 2) for Nissan Maxima S 2014: 39 10j 26j 28j As door sw B19 (left "c" pillar) B24 t2 Bcm (body control module) (behind instrument cluster) Can-h Can-l Computer data lines system Cpu Dr door sw E17 F10 Gnd 1 Immo led Interior lights system Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Left front door switch (left "b" pillar) Left rear door switch (left "c" pillar) M10 b104 M17 M18 M19 M21 M57 (behind right side of dash) M6 b1 Meter mode switch Mode a switch Mode b switch Oil pres Oil pressure switch (lower left front of engine) Pnk Right front door switch (right "b" pillar) Right rear door switch (right "c" pillar) Rl door sw Rr door sw Trunk lamp switch & trunk release solenoid (trunk release solenoid: center rear of luggage lid) Trunk sw
INTERIOR LIGHTS Courtesy Lamps Wiring Diagram (1 of 2) for Nissan Maxima S 2014 List of elements for Courtesy Lamps Wiring Diagram (1 of 2) for Nissan Maxima S 2014: 54 10j 26j 28j As door sw 1 B104 B19 (left "c" pillar) B24 Bat (f/l) Bat bcm fuse Body control module (bcm) (behind instrument cluster) Can-h Can-l Computer data lines system Door Dr door sw Fob slot illumination Front room/map lamp assembly Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd 1 Hot at all times Instrument illumination circuit Key slot Left foot lamp Left front door switch (left "b" pillar) Left front room/map lamp Left rear door switch (left "c" pillar) Left rear personal lamp M10 M16 M17 M18 M19 M20 M21 M57 (behind right side of dash) M61 (behind left side of dash) Off Pnk Pw k-line Right foot lamp Right front door switch (right "b" pillar) Right front room/map lamp Right rear door switch (right "c" pillar) Right rear personal lamp Rl door sw Room lamp cont Rr door sw Step lamp cont Trunk lamp cont Trunk lid switch & trunk release solenoid (center rear of luggage compt lid) Trunk sw Courtesy Lamps Wiring Diagram (2 of 2) for Nissan Maxima S 2014 List of elements for Courtesy Lamps Wiring Diagram (2 of 2) for Nissan Maxima S 2014: 37 22j 23j B104 B134 Between full stroke & n Cpu D101 D102 D201 D306 Full stroke Left front door lock assembly (key cylinder switch) (rear of driver's door) Left front kick plate lamp (pre-wiring) (if equipped) Left front step lamp Left rear step lamp Left vanity mirror lamp Lock switch M10 M11 M12 M14 M15 M6 5j M6 6j M61 (behind left side of dash) M79 (left center of dash) Main power window & door lock/unlock switch Off Pnk Red Right front kick plate lamp (pre-wiring) (if equipped) Right front step lamp Right power window & door lock/ unlock switch Right rear step lamp Right vanity mirror lamp Trunk room lamp Unlock switch Instrument Illumination Wiring Diagram (1 of 2) for Nissan Maxima S 2014 List of elements for Instrument Illumination Wiring Diagram (1 of 2) for Nissan Maxima S 2014: 75 Ascd steering switch Bat (f/l) Bat bcm fuse Body control module (behind instrument cluster) Can-h Can-l Climate controlled seat switch Combination meter Combination switch Computer data lines system Courtesy lamps circuit Cvt shift selector (under center console) D101 Diode 3 (left center of dash) Door mirror remote control switch Dr door sw E6 9p Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd 1 Hot at all times Hot w/ ignition relay 2 energized Input 1 Input 2 Input 3 Input 4 Input 5 J/c m01 (left side of dash) Left front door inside handle illumination (if equipped) Left front door switch (left "b" pillar) Left front heated seat switch Low side push led M12 M14 M16 M17 M18 M19 M203 M205 M208 M29 M3 7n M30 M305 M4 6q M4 8q M5 12m M57 (behind right side of dash) M6 10j M79 (left center of dash) M87 M88 Meter ill ind Meter mode switch Nca Output 1 Output 2 Output 3 Output 4 Output 5 Pnk Push- button ignition switch Rear sunshade switch Right front door inside handle illumination (if equipped) Right front heated seat switch Ring led Spiral cable (in steering column) Steering wheel audio control switch Unified meter control unit (w/ information display) W/ climate controlled seats W/ front heated seats W/ power rear sunshade Instrument Illumination Wiring Diagram (2 of 2) for Nissan Maxima S 2014 List of elements for Instrument Illumination Wiring Diagram (2 of 2) for Nissan Maxima S 2014: 44 A/c & a/v switch assembly (w/ color display) A/c display unit (w/ monochrome display) A/c switch assembly (w/ monochrome display) Audio unit (w/ monochrome display) Av control unit (w/ color display) Can-h Can-l Computer data lines system Cpu Display unit (w/ monochrome display) E15 (left side of engine compt) E16 E17 E18 Front room/map lamp assembly Fuse 10a Fuse 15a Fusible link box (battery) (at battery) Fusible link d 60a Glove box lamp Gnd Hazard switch Heated steering wheel switch (if equipped) Hot at all times Ill Ill+ Ill- Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) M132 M133 M152 M160 M163 M57 (behind right side of dash) Mr output P-gnd Pnk S-gnd Tail lamp relay Vdc off switch W/ base W/ bose W/ navigation W/o navigation
MEMORY SYSTEMS Memory Systems Wiring Diagram (1 of 3) for Nissan Maxima S 2014 List of elements for Memory Systems Wiring Diagram (1 of 3) for Nissan Maxima S 2014: 60 10j 82g Adp steering switch Automatic drive positioner control unit (behind right center of dash) Backward Bat Bat (f/l) Bat bcm fuse Bcm (body control module) (behind instrument cluster) Can-h Can-l Change- over switch Circuit breaker (behind left side of dash) Computer data lines system Door mirror remote control switch Down Downward Dr door sw E30 Forward Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd Gnd1 Hot at all times Hot in on or start Ign f/b Interior lights system Left front door switch (left "b" pillar) Leftward Lh mir mtr Lh mir sns Lh select M16 M17 M18 M19 M3 7n M57 (behind right side of dash) M61 (behind right side of dash) M63 M67 Mirror switch Pnk Red Rh mir mtr Rh mir sns Rh select Rightward Sns gnd Sns pwr Strg sns vcc Telescopic switch Tilt motor (on steering column) Tilt switch Uart Up/fwd Upward Memory Systems Wiring Diagram (2 of 3) for Nissan Maxima S 2014 List of elements for Memory Systems Wiring Diagram (2 of 3) for Nissan Maxima S 2014: 18 (at mirror) left door mirror (at mirror) right door mirror Backward D102 m15 D2 m12 Forward Ind 1 Ind 2 M12 M61 (behind left side of dash) Off Pnk Red Seat memory switch Set Sw 1 Sw 2 Telescopic motor (on steering column) Memory Systems Wiring Diagram (3 of 3) for Nissan Maxima S 2014 List of elements for Memory Systems Wiring Diagram (3 of 3) for Nissan Maxima S 2014: 74 20j 49j 50j 51j 52j 53j 54j 56j 57j Address 1 Address 2 B1 m6 B201 b12 B203 B205 B206 B208 B211 B32 B7 (under driver's seat) Backward Bat (ptc) Bwd Can-h Can-l Computer data lines system Driver's seat control unit (under driver's seat) Forward Fr lift sw up Front lift mtr up Front lift sw dwn Front lifting Front lifting motor Frt lift mtr dwn Fwd Gnd Ind 1 Ind 2 Left front power seat (under driver's seat) Left power seat switch Left reclining motor (under driver's seat) Lumbar support motor (in driver's seat back) Lumbar support switch M12 Nca Pnk Pulse front lift Pulse rear lift Pulse recliner Pulse slide Pulse telescopic Pulse tilt Pwr sply encoder Rear lift mtr dwn Rear lift mtr up Rear lift sw dwn Rear lift sw up Rear lifting motor Recliner mtr back Recliner mtr fwd Recliner sw back Recliner sw fwd Reclining switch Red Set sw Slide mtr back Slide mtr fwd Slide sw back Slide sw fwd Sliding motor Sliding switch Switch Switch lifting rear Uart tx/rx
NAVIGATION Navigation Wiring Diagram (1 of 3) for Nissan Maxima S 2014 List of elements for Navigation Wiring Diagram (1 of 3) for Nissan Maxima S 2014: 81 54g 64g 88j Acc Amp on Av control unit B (+) Bat Can h Can l Comp (+) Comp (-) Comp1 shield Comp1 sync Computer data lines system Disp it Display unit E30 Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 15a Fuse block (j/b) (lower left side of dash) Gnd Gvif (+) Gvif (-) Hot at all times Hot in on or acc Hot in on or start Ign Ill Interior lights system It disp Lf pre + Lf pre - Lr pre + Lr pre - M can h M can l M can trm M1 53g M112 M142 M151 M160 M161 M163 M167 M210 M57 (behind right side of dash) M7 r1 Mic gen Mic gnd Mic sig Mic vcc Microphone (center front of roof) Mr out Navi comp1 (+) Navi comp1 (-) Navigation system Pkb sig Pnk Red Reverse sig Rf pre + Rf pre - Rr pre + Rr pre - Shield Shield comp Spd sig Strg sw a Strg sw b Strg sw gnd Sync comp Usb d + Usb d+ Usb d- Usb gnd Usb interface V bus Vbus Navigation Wiring Diagram (2 of 3) for Nissan Maxima S 2014 List of elements for Navigation Wiring Diagram (2 of 3) for Nissan Maxima S 2014: 37 (on brake pedal bracket) park brake switch 24g 80j 81j B103 B134 Back Combination meter Computer data lines system D201 D306 E30 Enter Exterior lights system J/c b05 (in trunk lid) Left front door speaker Left rear door speaker Left rear subwoofer Left tweeter M11 M30 M8 b102 M88 Menu down Menu up Phone Pnk Red Right rear door speaker Right rear subwoofer Right tweeter Source Spiral cable (in steering column) Steering wheel audio control switches Unified meter control unit (w/ information display) Volume down Volume up Navigation Wiring Diagram (3 of 3) for Nissan Maxima S 2014 List of elements for Navigation Wiring Diagram (3 of 3) for Nissan Maxima S 2014: 84 A/c & av switch assembly Acc Amp on Ant b+ Ant main Antenna amplifier Aux gnd Aux in jack Aux shield Aux video + Aux video - Av control unit B103 B109 B110 B132 (right "c" pillar) Batt Bose speaker amplifier (under rear parcel shelf) Camera gnd Camera v+ Can h Can l Cd eject Center speaker Comp out (+) Comp out (-) Computer data lines system D101 Gnd Gps ant Gps antenna Ill (+) Ill cont gnd Interior lights system Lf door out (+) Lf door out (-) Lf in (+) Lf in (-) Lf twdr out (+) Lf twdr out (-) Lh aux audio (+) Lh woofer out (+) Lh woofer out (-) Lr door out (+) Lr door out (-) Lr in (+) Lr in (-) M103 M14 M162 M164 M165 M166 M168 M200 M501 M57 (behind right side of dash) M79 (left center of dash) M85 Navigation system Nca Pnk Red Rf door out (+) Rf door out (-) Rf in (+) Rf in (-) Rf twdr out (+) Rf twdr out (-) Rh aux audio (+) Rh woofer out (+) Rh woofer out (-) Right front door speaker Rr door out (+) Rr door out (-) Rr in (+) Rr in (-) Satellite antenna Shield Sw gnd Twdr out (+) Twdr out (-) Video shield Window antenna Rear Camera Wiring Diagram, with Navigation for Nissan Maxima S 2014 List of elements for Rear Camera Wiring Diagram, with Navigation for Nissan Maxima S 2014: 35 (or red) Acc Av control unit Bat Camera gnd Camera on Camera v+ Can h Can l Comp + Comp - Comp+ Comp- Computer data lines system Display unit Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 15a Fuse block (j/b) (lower left side of dash) Gnd Hot at all times Hot in on or acc M can h M can l M110 b136 M142 M160 M163 M164 M57 (behind right side of dash) Pnk Rearview camera Red Shield T100 b139 Rear Camera Wiring Diagram, without Navigation for Nissan Maxima S 2014 List of elements for Rear Camera Wiring Diagram, without Navigation for Nissan Maxima S 2014: 36 Acc Av control unit B139 Batt Cam gnd Camera on Can h Can l Comp+ Comp- Comp2 gnd Comp2 in (+) Computer data lines system Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 15a Fuse block (j/b) (lower left side of dash) Gnd Hot at all times Hot in on or acc M110 b136 M115 M118 M119 M152 M155 M156 M57 (behind right side of dash) Pnk Rear view camera Red Rv cam sig Shield T100 W/ bose W/o bose
POWER DISTRIBUTION Power Distribution Wiring Diagram (1 of 3) for Nissan Maxima S 2014 List of elements for Power Distribution Wiring Diagram (1 of 3) for Nissan Maxima S 2014: 53 (at battery) fusible link box (battery) (left front of engine compt) fuse & fusible link box (left side of engine compt) ipdm e/r (intelligent power distribution module engine room) 82g Anti-lock brakes system Battery Circuit breaker (behind left side of dash) Cpu E16 E18 E201 E30 Ecm relay Engine controls system Exterior lights system Exterior lights, defogger, interior lights, headlights, seats, memory, wiper/washer, trunk, tailgate, fuel doors, power tops, anti-theft, body computer, door locks, warning & power windows systems F10 Front fog lamp relay Fuse 10a Fuse 15a Fuse 30a Fusible link a 250a Fusible link b 80a Fusible link c 100a Fusible link d 60a Fusible link e 100a Fusible link f 50a Fusible link g 30a Fusible link h 40a Fusible link k 40a Fusible link l 40a Fusible link m 40a Headlamp high relay Headlamp low relay Headlights system Headlights, interior lights & exterior lights systems Horns, anti-theft & door locks systems Joint connector e01 (left side of engine compt) Navigation, air conditioning & sound systems Pnk Red Seats & memory systems Seats system Sound & navigation systems Starting/ charging system Tail lamp relay Throttle control motor relay To front wiper relay (diagram 2 of 3) To fuse block (j/b) (diagram 2 of 3) To fuse block (j/b) (diagram 3 of 3) To ignition relay 1 (diagram 2 of 3) W/ bose audio system W/ heated steering wheel Power Distribution Wiring Diagram (2 of 3) for Nissan Maxima S 2014 List of elements for Power Distribution Wiring Diagram (2 of 3) for Nissan Maxima S 2014: 40 (left side of engine compt) ipdm e/r (intelligent power distribution module engine room) (lower left side of dash) fuse block (j/b) 11p 12p A/c relay Accessory relay 1 Accessory relay 2 Air conditioning, body computer, sound, mirrors, defogger & navigation systems Anti-theft, door locks, body computer, power tops, power windows & warning systems Body computer, door locks, anti-lock brakes, transmissions, engine controls, anti-theft & exterior lights systems Cooling fan relay 1 Cpu Door locks & body computer systems E15 (left side of engine compt) E17 E18 From bcm (body control module) (diagram 3 of 3) From fuse 43 (diagram 1 of 3) From fuse 55 (diagram 1 of 3) From fusible link box (battery) (diagram 1 of 3) Front console power socket Front power socket Front wiper high relay Front wiper relay Fuel pump relay Fuse 10a Fuse 15a Fuse 20a Ignition relay 1 Interior lights, door locks, body computer & anti-theft systems M205 M79 (left center of dash) M87 Red Sound systems To fuse 10 (diagram 3 of 3) To fuse 33 (diagram 3 of 3) To push button ignition switch (diagram 3 of 3) Transmissions system Wiper/washer system Power Distribution Wiring Diagram (3 of 3) for Nissan Maxima S 2014 List of elements for Power Distribution Wiring Diagram (3 of 3) for Nissan Maxima S 2014: 61 (left center of dash) m79 (left side of engine compt) ipdm e/r (intelligent power distribution module engine room) 10m 10t 11m 11t 12m 23g 29g Acc ind Acc led Air conditioning system Anti-lock brakes system Bat bcm Bcm (body control module) (behind instrument cluster) Computer data lines, air conditioning, sound, memory, instrument cluster, transmissions, engine controls, body computer, electronic power steering, mirrors, warning, defogger & seats systems Cpu Defogger system E18 E200 E30 Eng Engine controls & cooling fans systems Engine controls system F10 Fan rly From fuse 11 d (diagram 2 of 3) From fuse 32 f (diagram 2 of 3) From g fuse block (j/b) (diagram 2 of 3) From joint connector e01 (diagram 1 of 3) Front blower motor relay Fuse 10a Fuse 15a Fuse 20a Fuse block (j/b) (lower left side of dash) Ign on led Ign rly out 2 Ignition relay 2 Ill Interior lights system Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Lock ind M17 M18 M19 M19 acc cont M21 M79 (left center of dash) On ind Pnk Power windows system Push button ignition switch Push switch Rear def Rear window defogger relay Red S/l lck led Seats system To fuse block (j/b) (diagram 2 of 3) Transmissions system Wiper/washer system
POWER DOOR LOCKS Power Door Locks Wiring Diagram (1 of 4) for Nissan Maxima S 2014 List of elements for Power Door Locks Wiring Diagram (1 of 4) for Nissan Maxima S 2014: 88 (behind right side of dash) m57 11p 13j 14j 20g 27g 57g 82g Acc led As door ant a As door ant b As door sw 1 As request switch At device out Back door ant a Back door ant b Bat bcm fuse Batt f/l Bcm (body control module) (behind instrument cluster) Brake sw 1 Brake sw 2 Buzzer Can-h Can-l Computer data lines system Cpu Cvt shift selector (park position) switch (intelligent key system) Door lock output all Door lock status dr Door unlock output as Door unlock output dr/fl Door unlock output rr/rl Dr door ant a Dr door ant b Dr door switch Dr request switch E18 E30 Eng start sw Exterior lights system Fl flasher Fob in switch 1 Fob reader data Fob slot illumination Fr flasher Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd rf2 a/l Gnd1 Hazard switch Hot at all times Ign on led Ign relay output Immo led Intelligent key warning buzzer (behind left end of dash) Interior lights system Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) M16 M17 M18 M19 M21 Ob reader clock P/w pwr sply ign P/w pwr sply perm Pnk Pw k-line R/l pwr sply Rear bumper antenna (behind center of rear bumper) Red Remote keyless entry receiver (behind right end of dash) Rf1 tuner signal Rl door switch Room ant 2 a Room ant 2 b Room lamp cont Rr door switch S/l lock led Shift n/p/neutral sw Shift p/ascd cancel sw St relay output Stop lamp switch (on brake pedal bracket) Trunk ant 1 a Trunk ant 1 b Trunk request switch Trunk switch Power Door Locks Wiring Diagram (2 of 4) for Nissan Maxima S 2014 List of elements for Power Door Locks Wiring Diagram (2 of 4) for Nissan Maxima S 2014: 45 (left side of engine compt) e15 11j 12j 19g 28j 29g Computer data lines system Cpu D102 D106 D115 D15 E16 E17 E18 E30 F10 Front console antenna (behind center of dash) Fuse & fusible link box (left front of engine compt) Fusible link b 80a Fusible link box (battery) (at battery) Fusible link l 40a Headlamp high relay Headlamp low relay Headlights system Horns system Hot at all times Ignition relay 1 Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) J/c e01 (left side of engine compt) Left front outside handle Left rear door switch (left "c" pillar) M12 M15 M61 (behind left side of dash) M79 (left center of dash) Outside key antenna Pnk Rear parcel shelf antenna (under center of rear parcel shelf) Red Request switch Right front outside handle Starter control relay Starter relay Starting/ charging system Power Door Locks Wiring Diagram (3 of 4) for Nissan Maxima S 2014 List of elements for Power Door Locks Wiring Diagram (3 of 4) for Nissan Maxima S 2014: 26 (right "b" pillar) 10j 26j 27j 33g B104 B19 (left "c" pillar) B24 E30 E46 E50 Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link box (battery) (at battery) Fusible link d 60a Hot at all times Junction block e46 & e50 Left front door switch (left "b" pillar) M10 Red Right front door switch Right rear door switch (right "c" pillar) St rly Tcm (transmission control module) (left front of engine compt) Trunk lid switch & trunk release solenoid (trunk lamp switch) (center rear of luggage compt lid) Trunk opener request switch Power Door Locks Wiring Diagram (4 of 4) for Nissan Maxima S 2014 List of elements for Power Door Locks Wiring Diagram (4 of 4) for Nissan Maxima S 2014: 47 96j 97j Acc ind Actuator B104 B134 d306 Between full stroke & n Buzzer Combination meter Computer data lines system Cpu D101 D201 Door unlock sensor Fuel lid door lock actuator (left side of luggage compt) Full stroke Interior lights system J/c b05 (in trunk lid) Key cylinder switch Key ind Key slot Left front door lock assembly (rear of driver's door) Left rear door lock actuator (rear of left rear door) Lock Lock ind Lock switch M10 M11 M12 M14 M14 d101 M57 (behind right side of dash) M61 (behind left side of dash) M79 (left center of dash) Main power window & door lock/unlock switch On ind Pnk Push button ignition switch Push switch Red Right front door lock actuator (rear of front passenger's door) Right power window & door lock/unlock switch Right rear door lock actuator (rear of right rear door) Security ind Unified meter control unit (w/ information display) Unlock Unlock switch
POWER MIRRORS Auto Anti-dazzling Inside Mirror Wiring Diagram, with Homelink Universal Transceiver for Nissan Maxima S 2014 List of elements for Auto Anti-dazzling Inside Mirror Wiring Diagram, with Homelink Universal Transceiver for Nissan Maxima S 2014: 17 6q m4 Auto anti-dazzling inside mirror Bat+ Ec+ Ec- Fuse 10a Fuse block (j/b) (lower left side of dash) Gnd Hot at all times Hot in on or start Ign Left door mirror (w/ auto dimming outside mirror) (at mirror) M12 M3 2n M61 (behind left side of dash) Oec+ Oec- Auto Anti-dazzling Inside Mirror Wiring Diagram, without Homelink Universal Transceiver for Nissan Maxima S 2014 List of elements for Auto Anti-dazzling Inside Mirror Wiring Diagram, without Homelink Universal Transceiver for Nissan Maxima S 2014: 7 (behind left side of dash) m61 Auto anti-dazzling inside mirror Fuse 10a Fuse block (j/b) (lower left side of dash) Gnd Hot in on or start Ign Power Mirrors Wiring Diagram for Nissan Maxima S 2014 List of elements for Power Mirrors Wiring Diagram for Nissan Maxima S 2014: 25 Auto anti-dazzling inside mirror circuit Change over switch Defogger Defogger system Door mirror remote control switch Down up Ec+ Ec- Exterior lights system Fuse 17 10a Fuse block (j/b) (lower left side of dash) Hot in acc or on Illumination Interior lights system Left Left door mirror (at mirror) M12 d2 M15 d102 M61 (behind left side of dash) Mirror switch Off Pnk Right Right door mirror (at mirror) Turn signal
POWER SEATS Climate Control Seats Wiring Diagram for Nissan Maxima S 2014 List of elements for Climate Control Seats Wiring Diagram for Nissan Maxima S 2014: 71 20j 58j 59j 60j 61j 81g 98j 99j B12 B12 b201 B201 B201 b12 B208 B212 B216 B217 B32 B32 b208 B7 (under driver's seat) Back sens gnd Back sens sig Back ted 1 Back ted 2 Bat (ptc) Blower gnd Blower power Blwr mtr spd ctrl Circuit breaker (behind left side of dash) Climate control seat blower motor (under driver's seat) Climate control seat control unit (under driver's seat) Climate controlled seat relay (left side of dash) Climate controlled seat switch Cool Cool ind Cool on ind Cool sw input Cushion sens gnd Cushion sens sig Cushion ted1 Cushion ted2 E30 Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 15a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd Heat Heat ind Heat on ind Heat sw input Hot at all times Hot in on or start Ign Illumination Interior lights system M208 m305 M6 b1 M61 (behind left side of dash) M79 (left center of dash) M85 m200 Mid Nca Off Pnk Red Resistor pwr Seat back thermal electric device Seat cushion thermal electric device Sensor Ted Heated Seats Wiring Diagram for Nissan Maxima S 2014 List of elements for Heated Seats Wiring Diagram for Nissan Maxima S 2014: 31 19j 8m m5 B104 B12 B132 (right "c" pillar) B148 B201 B308 B7 (under driver's seat) Fuse 15a Fuse block (j/b) (lower left side of dash) Heater High Hot in on or start Illum Interior lights system Left front heated seat switch (w/o climate controlled seat) Left front seat heater Low M10 M205 M208 M305 M6 18j M79 (left center of dash) M87 Off Pnk Right front heated seat switch Right front seat heater Thermostat Heated Steering Wheel Wiring Diagram for Nissan Maxima S 2014 List of elements for Heated Steering Wheel Wiring Diagram for Nissan Maxima S 2014: 19 Cpu E30 Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Heated steering relay (on fuse block (j/b)) Heated steering wheel Heated steering wheel switch Hot at all times Hot in on or start Illum Interior lights system M1 83g M3 2n M61 (behind left side of dash) M79 (left center of dash) Off On ind Spiral cable (in steering column) Lumbar Wiring Diagram for Nissan Maxima S 2014 List of elements for Lumbar Wiring Diagram for Nissan Maxima S 2014: 19 (behind instrument cluster) bcm (body control module) (behind right side of dash) m57 20j B1 m6 B12 b201 B7 (under driver's seat) Back- ward Backward Batt (f/l) For- ward Forward Fuse & fusible link box (left front of engine compt) Fusible link h 40a Gnd 1 Hot at all times Lumbar support motor (in driver's seat back) Lumbar support switch M17 P/w pwr sply perm m16 Power Seat Wiring Diagram for Nissan Maxima S 2014 List of elements for Power Seat Wiring Diagram for Nissan Maxima S 2014: 40 (behind right side of dash) m57 20j B104 B12 B132 (right "c" pillar) B148 B201 B308 B7 (under driver's seat) Back- ward Batt (f/l) Bcm (body control module) (behind instrument cluster) Bwd Down Dwn For- ward Front lifting motor Front lifting switch Fuse & fusible link box (left front of engine compt) Fusible link h 40a Fwd Gnd1 Hot at all times Left front power seat (under driver's seat) Left power seat switch Left reclining motor (under driver's seat) M10 M16 M17 Nca P/w pwr sply perm Rear lifting motor Rear lifting switch Reclining switch Red Right power seat switch Right reclining motor (under front passenger's seat) Right sliding motor (under front passenger's seat) Sliding motor Sliding switch
POWER TOP/SUNROOF Power Top/Sunroof Wiring Diagram for Nissan Maxima S 2014 List of elements for Power Top/Sunroof Wiring Diagram for Nissan Maxima S 2014: 48 (behind instrument cluster) bcm (body control module) (behind left side of dash) m61 (behind right side of dash) m57 + ign 10j 2p/r out As door sw 1 B104 Batt (fl) Batt bcm fuse Brk sw 1 Close/tilt up sw Combination meter Down/ open Dr door sw Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd Gnd1 Hot at all times Left front door switch (left "b" pillar) M10 M13 M16 M17 M18 M61 (behind left side of dash) Open/tilt dn sw P/w pwr sply ign P/w pwr sply perm Pnk R10 R10 r100 R100 R2 m13 Red Right front door switch (right "b" pillar) Spd sens (2p) Sunroof motor assembly (w/ dual panel sunroof) (center front of roof) Sunroof motor assembly (w/ single panel sunroof) (center front of roof) Sunroof switch Sunshade motor assembly (w/ dual panel sunroof & power sunshade) (center rear of roof) Unified meter control unit (w/ information display) Up/ close W/ dual panel sunroof W/ single panel sunroof
POWER WINDOWS Power Windows Wiring Diagram (1 of 2) for Nissan Maxima S 2014 List of elements for Power Windows Wiring Diagram (1 of 2) for Nissan Maxima S 2014: 66 10j 7n m3 95j As door sw1 As down As up B7 (under driver's seat) Bat Bat bcm fuse Batt (f/l) Between full stroke & n Body control module (bcm) (behind instrument cluster) Com Cpu D101 D201 Dr door sw Encoder Encoder gnd Encoder power Encoder sig1 Encoder sig2 Full stroke Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd Gnd 1 Hot at all times Ign Illumination Key cyl lock sw Key cyl unlock sw Left front door lock assembly (key cylinder switch) (rear of driver's door) Left front door switch (left "b" pillar) Left front power window motor (center of driver's door) Left rear power window motor (center of left rear door) Left rear power window switch Left rear switch Lock Lock switch M10 b104 M11 M12 M14 M16 M17 M18 M57 (behind right side of dash) M6 94j M61 (behind left side of dash) Main power window & door lock/unlock switch Pnk Pw k-line Pwr sply ign Pwr sply perm Red Right front door switch (right "b" pillar) Right rear switch Rl dn Rl up Rr dn Rr up Unlock Unlock switch Power Windows Wiring Diagram (2 of 2) for Nissan Maxima S 2014 List of elements for Power Windows Wiring Diagram (2 of 2) for Nissan Maxima S 2014: 26 93j B1 m6 B104 B132 (right "c" pillar) B134 Bat Com Cpu D101 D306 Down Encoder Encoder power Encoder sig1 Encoder sig2 Gnd Illumination M10 M14 M79 (left center of dash) Pnk Red Right front power window & door lock/unlock switch Right front power window motor (center of front passenger's door) Right rear power window motor (center of right rear door) Right rear power window switch Rear Window Sun Shade Wiring Diagram for Nissan Maxima S 2014 List of elements for Rear Window Sun Shade Wiring Diagram for Nissan Maxima S 2014: 20 89j 90j B19 (left "c" pillar) Down Fuse 10a Fuse block (j/b) (lower left side of dash) Gnd Hot in on or start Illumination Interior lights system M205 M208 M305 M79 (left center of dash) M87 M87 m205 Pnk Rear sunshade switch Rear sunshade unit (under rear parcel shelf) Red
RADIO Radio Wiring Diagram, with Bose with Navigation, Color Display (1 of 3) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, with Bose with Navigation, Color Display (1 of 3) for Nissan Maxima S 2014: 81 54g 64g 88j Acc Amp on Av control unit B (+) Bat Can h Can l Comp (+) Comp (-) Comp1 shield Comp1 sync Computer data lines system Disp it Display unit E30 Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 15a Fuse block (j/b) (lower left side of dash) Gnd Gvif (+) Gvif (-) Hot at all times Hot in on or acc Hot in on or start Ign Ill Interior lights system It disp Lf pre + Lf pre - Lr pre + Lr pre - M can h M can l M can trm M1 53g M112 M142 M151 M160 M161 M163 M167 M210 M57 (behind right side of dash) M7 r1 Mic gen Mic gnd Mic sig Mic vcc Microphone (center front of roof) Mr out Navi comp1 (+) Navi comp1 (-) Navigation system Pkb sig Pnk Red Reverse sig Rf pre + Rf pre - Rr pre + Rr pre - Shield Shield comp Spd sig Strg sw a Strg sw b Strg sw gnd Sync comp Usb d + Usb d+ Usb d- Usb gnd Usb interface V bus Vbus Radio Wiring Diagram, with Bose with Navigation, Color Display (2 of 3) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, with Bose with Navigation, Color Display (2 of 3) for Nissan Maxima S 2014: 37 (on brake pedal bracket) park brake switch 24g 80j 81j B103 B134 Back Combination meter Computer data lines system D201 D306 E30 Enter Exterior lights system J/c b05 (in trunk lid) Left front door speaker Left rear door speaker Left rear subwoofer Left tweeter M11 M30 M8 b102 M88 Menu down Menu up Phone Pnk Red Right rear door speaker Right rear subwoofer Right tweeter Source Spiral cable (in steering column) Steering wheel audio control switches Unified meter control unit (w/ information display) Volume down Volume up Radio Wiring Diagram, with Bose with Navigation, Color Display (3 of 3) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, with Bose with Navigation, Color Display (3 of 3) for Nissan Maxima S 2014: 84 A/c & av switch assembly Acc Amp on Ant b+ Ant main Antenna amplifier Aux gnd Aux in jack Aux shield Aux video + Aux video - Av control unit B103 B109 B110 B132 (right "c" pillar) Batt Bose speaker amplifier (under rear parcel shelf) Camera gnd Camera v+ Can h Can l Cd eject Center speaker Comp out (+) Comp out (-) Computer data lines system D101 Gnd Gps ant Gps antenna Ill (+) Ill cont gnd Interior lights system Lf door out (+) Lf door out (-) Lf in (+) Lf in (-) Lf twdr out (+) Lf twdr out (-) Lh aux audio (+) Lh woofer out (+) Lh woofer out (-) Lr door out (+) Lr door out (-) Lr in (+) Lr in (-) M103 M14 M162 M164 M165 M166 M168 M200 M501 M57 (behind right side of dash) M79 (left center of dash) M85 Navigation system Nca Pnk Red Rf door out (+) Rf door out (-) Rf in (+) Rf in (-) Rf twdr out (+) Rf twdr out (-) Rh aux audio (+) Rh woofer out (+) Rh woofer out (-) Right front door speaker Rr door out (+) Rr door out (-) Rr in (+) Rr in (-) Satellite antenna Shield Sw gnd Twdr out (+) Twdr out (-) Video shield Window antenna Radio Wiring Diagram, with Bose without Navigation, Color Display (1 of 3) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, with Bose without Navigation, Color Display (1 of 3) for Nissan Maxima S 2014: 55 (or pnk) Acc Av control unit Batt Bus gnd Comp Comp out + Comp out - Comp out shield Disp it Disp itm Display unit Fuse 10a Fuse block (j/b) (lower left side of dash) Gnd Hot in on or acc Hot in on or start Ill In (+) In (-) Interior lights system Inv gnd Inv vcc It disp M152 M153 M154 M30 M57 (behind right side of dash) M88 Nbus lh + Nbus lh - Nbus rh + Nbus rh - Phone/ end Phone/ send Red Req 1 Rgb gnd Rgb sync Rgb sync gnd Seek down Seek up Shield Sig gnd Sig vcc Source Spiral cable (in steering column) Steering wheel audio control switches Strg sw a Strg sw b Strg sw gnd Sync gnd Vol down Vol up Radio Wiring Diagram, with Bose without Navigation, Color Display (2 of 3) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, with Bose without Navigation, Color Display (2 of 3) for Nissan Maxima S 2014: 71 (center front of roof) microphone (or pnk) (pins: 12 to 15 not used) (w/ satellite radio tuner) satellite antenna 53g 54g 64g 80j 81j Acc Aud out (+) Aud out (-) B (+) B101 B102 B103 B125 B130 B131 B132 (right "c" pillar) B134 B136 Bat Can h1 Can h2 Can l1 Can l2 Center speaker Computer data lines system D101 D201 D306 E30 Fuse & fusible link box (left front of engine compt) Fuse 15a Gnd Harn earth Hot at all times Ign Left front door speaker Left rear door speaker Left rear subwoofer Left tweeter M11 M110 M14 M9 b103 Mic gen Mic in (+) Mic in (-) Mic power Mic sig Mic vcc Nca Pnk R1 m7 Red Req1 Right front door speaker Right rear door speaker Right rear subwoofer Right tweeter Rxd Sat lch (+) Sat lch (-) Sat rch (+) Sat rch (-) Satellite radio tuner or pre-wiring for satellite radio tuner (if equipped) (under rear parcel shelf) Shield Spd Txd Radio Wiring Diagram, with Bose, Monochrome Display (1 of 3) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, with Bose, Monochrome Display (1 of 3) for Nissan Maxima S 2014: 58 Acc Amp on Antenna amplifier Audio unit Bat Can h Can l Down vol End phone/ Fr sp lh (+) Fr sp lh (-) Fr sp rh (+) Fr sp rh (-) Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 15a Fuse block (j/b) (lower left side of dash) Hot at all times Hot in on or acc Hot in on or start Ill (+) Ill (-) Ill+ Ill- Interior lights system Ladder out 1 Ladder out 2 Ladder shield M103 M132 M135 M30 M501 M88 Nca Phone/ send Pnk Red Rr sp lh (+) Rr sp lh (-) Rr sp rh (+) Rr sp rh (-) Seek down Seek up Shield Source Speed sig Spiral cable (in steering column) Steering wheel audio control switches Strg sw a Strg sw b Strg sw gnd Tel i/f (+) Tel i/f (-) Tel on Tel shield Vol up Window antenna Radio Wiring Diagram, with Bose, Monochrome Display (2 of 3) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, with Bose, Monochrome Display (2 of 3) for Nissan Maxima S 2014: 44 53g 54g Amp on B102 B103 B109 B110 B132 (right "c" pillar) Battery Bose speaker amplifier (under rear parcel shelf) Center speaker D101 E30 Fr door out (+) Fr door out (-) Fr twdr out (+) Fr twdr out (-) Gnd Left tweeter Lh fr in (+) Lh fr in (-) Lh rr in (+) Lh rr in (-) Lh woofer out (+) Lh woofer out (-) M14 Pnk Red Rf door out (+) Rf door out (-) Rh fr in (+) Rh fr in (-) Rh rr in (+) Rh rr in (-) Rh woofer out (+) Rh woofer out (-) Right front door speaker Right rear subwoofer Right tweeter Rr door out (+) Rr door out (-) Shield Twdr out (+) Twdr out (-) Radio Wiring Diagram, with Bose, Monochrome Display (3 of 3) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, with Bose, Monochrome Display (3 of 3) for Nissan Maxima S 2014: 58 8 p/r out 80j 81j Acc Audio out (+) Audio out (-) B (+) B101 B101 m2 B102 B125 B130 B131 B132 (right "c" pillar) B134 Can h1 Can h2 Can l1 Can l2 Can shield 1 Can shield 2 Combination meter Cont 4 D201 D306 Display unit Gnd Ign Ill + Ill - Interior lights system J/c b21 (right kick panel) Ladder gnd Ladder in 1 Ladder in 2 Left front door speaker Left rear door speaker Left rear subwoofer M can h M can l M11 M57 (behind right side of dash) Mic gen Mic in (+) Mic in (-) Mic power Mic sig Mic vcc Microphone (center front of roof) Mute control Pnk Red Right rear door speaker Shield Speed Strg sw out a Strg sw out b Strg sw out gnd Radio Wiring Diagram, without Bose without Navigation, Color Display (1 of 3) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, without Bose without Navigation, Color Display (1 of 3) for Nissan Maxima S 2014: 63 (or pnk) Acc Av control unit Batt Bus gnd Combination switch (spiral cable) (in steering column) Comp Comp out + Comp out - Comp out shield Disp it Disp itm Display unit Fr door lh+ Fr door lh- Fr door rh+ Fr door rh- Fuse 10a Fuse block (j/b) (lower left side of dash) Gnd Hot w/ accessory relay 1 energized Hot w/ ignition relay 2 energized Ill In (+) In (-) Interior lights system Inv gnd Inv vcc It disp M115 M116 M117 M30 M57 (behind right side of dash) M88 Nbus lh + Nbus lh - Nbus rh + Nbus rh - Phone/ end Phone/ send Red Req 1 Rgb gnd Rgb sync Rgb sync gnd Rr door lh+ Rr door lh- Rr door rh+ Rr door rh- Seek down Seek up Shield Sig gnd Sig vcc Source Steering wheel audio control switches Strg sw a Strg sw b Strg sw gnd Sync gnd Vol down Vol up Radio Wiring Diagram, without Bose without Navigation, Color Display (2 of 3) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, without Bose without Navigation, Color Display (2 of 3) for Nissan Maxima S 2014: 70 (center front of roof) microphone (or pnk) (pins: 12 to 15 not used) 64g 80j 81j 82j 83j Acc Aud out (+) Aud out (-) B (+) B101 B102 B125 B130 B131 B132 (right "c" pillar) B136 B19 (left "c" pillar) Bat Can h1 Can h2 Can l1 Can l2 Computer data lines system D201 E30 Fuse & fusible link box (left front of engine compt) Fuse 15a Gnd Harn earth Hot at all times Ign Left front door speaker Left rear door speaker Left tweeter M11 M110 M2 b101 Mic gen Mic in (+) Mic in (-) Mic power Mic sig Mic vcc Nca Pnk R1 m7 Red Req1 Rxd Sat lch (+) Sat lch (-) Sat rch (+) Sat rch (-) Satellite antenna Satellite radio tuner (under rear parcel shelf) Shield Sp lh (+) in Sp lh (-) in Sp rh (+) in Sp rh (-) in Spd Subwoofer amplifier (right "c" pillar) Txd Woofer lh (+) Woofer lh (-) Woofer rh (+) Woofer rh (-) Radio Wiring Diagram, without Bose without Navigation, Color Display (3 of 3) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, without Bose without Navigation, Color Display (3 of 3) for Nissan Maxima S 2014: 89 (on brake pedal bracket) park brake switch (pins: 92 to 94 not used) (pins: 98 to 102 not used) 12m 13g 24g 88j A/c & av switch assembly Ant b (+) Ant main Antenna amplifier Aux gnd Aux in jack Av control unit B10 B104 B134 Backup light relay (on fuse block (j/b)) Cam gnd Can-h Can-l Cn eject Combination meter Comp1 in (+) Comp1 in shield Comp1 in- Comp2 gnd Comp2 in (+) Computer data lines system D101 D306 E29 E30 E47 E49 Fuse 10a Fuse block (j/b) (lower left side of dash) Hot in on or start Ign Interior lights system J/c b05 (in trunk lid) J/c e47 & e49 Left subwoofer Lh aux aud (+) M can h M can l M can2 h M can2 l M10 M103 M112 M118 M119 M120 M121 M14 M2 b101 M200 M210 M501 M57 (behind right side of dash) M79 (left center of dash) M85 M85 m200 Navigation system Nca Pkb sig Pnk Red Reverse sig Rh aux aud (+) Right front door speaker Right rear door speaker Right subwoofer Right tweeter Rv cam sig Shield Speed 8p Sw gnd Tel voice (+) Tel voice (-) Unified meter control unit (w/ information display) Usb d+ Usb d- Usb gnd Usb interface Vbus Voice shield Window antenna Radio Wiring Diagram, without Bose, Monochrome Display (1 of 2) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, without Bose, Monochrome Display (1 of 2) for Nissan Maxima S 2014: 62 80j 81j Acc Antenna amplifier Audio unit Bat Can h Can l Fr sp lh (+) Fr sp lh (-) Fr sp rh (+) Fr sp rh (-) Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 15a Fuse block (j/b) (lower left side of dash) Hot at all times Hot in on or acc Hot in on or start Ill (+) Ill (-) Ill+ Ill- Interior lights system Ladder out 1 Ladder out 2 Ladder shield Left front door speaker Left tweeter M103 M11 M133 M147 M30 M501 M6 b1 M88 Nca Phone/ end Pnk Red Rr sp lh (+) Rr sp lh (-) Rr sp rh (+) Rr sp rh (-) Seek down Seek up Send phone/ Shield Source Spiral cable (in steering column) Steering wheel audio control switches Strg sw a Strg sw b Strg sw gnd Tel i/f (+) Tel i/f (-) Tel on Tel shield Up vol Vol down Window antenna Radio Wiring Diagram, without Bose, Monochrome Display (2 of 2) for Nissan Maxima S 2014 List of elements for Radio Wiring Diagram, without Bose, Monochrome Display (2 of 2) for Nissan Maxima S 2014: 74 8 p/r out 82j 83j Acc Audio out (+) Audio out (-) B (+) B101 B101 m2 B102 B125 B126 B130 B132 (right "c" pillar) B134 B19 (left "c" pillar) Can h1 Can h2 Can l1 Can l2 Can shield 1 Can shield 2 Combination meter Cont 4 D101 D201 D306 Display unit Gnd Ign Ill + Ill - Interior lights system J/c b02 (near base of left "b" pillar) J/c b03 (left "c" pillar) J/c b21 (right kick panel) Ladder gnd Ladder in 1 Ladder in 2 Left rear door speaker Left subwoofer Lh sp in (+) Lh sp in (-) Lh woofer (+) Lh woofer (-) M can h M can l M10 b104 M14 M57 (behind right side of dash) Mic gen Mic in (+) Mic in (-) Mic power Mic sig Mic vcc Microphone (center front of roof) Mute control Pnk Red Rh sp in (+) Rh sp in (-) Rh woofer (+) Rh woofer (-) Right front door speaker Right rear door speaker Right subwoofer Right tweeter Shield Speed Strg sw out a Strg sw out b Strg sw out gnd Subwoofer amplifier (right "c" pillar)
SHIFT INTERLOCK Shift Interlock Wiring Diagram for Nissan Maxima S 2014 List of elements for Shift Interlock Wiring Diagram for Nissan Maxima S 2014: 28 2p e6 3q m4 4p e6 73g 74g At device out shift p/ascd cancel sw m19 Body control module (behind instrument cluster) Can-h Can-l Computer data lines system Cvt shift selector E15 (left side of engine compt) E44 E46 Fuse 10a Fuse block (j/b) (lower left side of dash) Hot at all times Hot in on or start Junction block e44 & e46 M1 e30 M79 (left center of dash) Park position switch (intelligent key system) Park position switch (shift selector) Pnk Red Shift lock relay (left rear of engine compt) Shift lock solenoid Stop light switch (on brake pedal bracket)
STARTING/CHARGING Charging Wiring Diagram for Nissan Maxima S 2014 List of elements for Charging Wiring Diagram for Nissan Maxima S 2014: 35 11g 12m Altc Battery Battery current sensor Can-h Can-l Charge indicator Combination meter Computer data lines system Cur sen E10 E17 E229 (right front of engine compt) E230 E30 E44 E47 Ecm (left front of engine compt) F10 F13 Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link a 250a Fusible link box (battery) (at battery) Fusible link e 100a Generator Hot in on or start Intpres1 Intpress1 Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Junction block e44 & e47 Pnk Starter motor Starting Wiring Diagram for Nissan Maxima S 2014 List of elements for Starting Wiring Diagram for Nissan Maxima S 2014: 49 20g 33g Battery Bcm (body control module) (behind instrument cluster) Can-h Can-l Charging circuit Computer data lines system Cpu Cvt unit (left rear of engine) D range sw E15 (left side of engine compt) E17 E18 E30 E46 E50 Eng st F10 Fuse & fusible link box (left front of engine compt) Fusible link a 250a Fusible link box (battery) (at battery) Fusible link e 100a Fusible link l 40a Gnd Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Junction block e46 & e50 Junction connector e01 (left side of engine compt) L range sw M1 29g M18 M19 M21 M79 (left center of dash) N range sw P range sw Pnk Push button ignition switch Push switch R range sw Red Shift p/n sw St rly St rly out Starter control relay Starter motor Starter relay Tcm (transmission control module) (left front of engine compt) Transmission range switch
SUPPLEMENTAL RESTRAINTS Supplemental Restraints Wiring Diagram (1 of 2) for Nissan Maxima S 2014 List of elements for Supplemental Restraints Wiring Diagram (1 of 2) for Nissan Maxima S 2014: 83 (+) (-) (left center of dash) m79 (right "c" pillar) b132 11m 24j 6q m4 Air bag diagnosis sensor unit (under rear of center console) Air bag ind Air bag w/l As1 (+) As1 (-) As2 (+) As2 (-) B104 B114 B119 B132 (right "c" pillar) B148 B308 B5 (under driver's seat) B56 Can-h Can-l Clh1 (+) Clh1 (-) Combination meter Computer data lines system Crh1 (+) Crh1 (-) Cut off tell tale Dr1 (+) Dr1 (-), dr2 (-) Dr2 (+) Eczs (+) Eczs (-) Fuse 10a Fuse block (j/b) (lower left side of dash) Gnd Hot at all times Hot in on or start Ign Joint connector b04 (left side of luggage compt) Left side air bag (satellite) sensor (base of left "b" pillar) Left side curtain air bag module (left "c" pillar) Lh buckle sw Lh dr sat sens (+) Lh dr sat sens (-) Lhsat (+) Lhsat (-) M10 M24 M43 M5 12m M79 (left center of dash) Occupant classification system control unit (under front passenger's seat) Ods-input P-lh1 (+) Plh1 (-) Pnk Power sply Prh1 (+) Prh1 (-) Red Rh buckle sw in Rh dr sat sens (+) Rh dr sat sens (-) Right front seat belt pre-tensioner (base of right "b" pillar) Right front side air bag module (right side of front passenger's seat back) Right seat belt buckle switch (under front passenger's seat) Right side air bag (satellite) sensor (base of right "b" pillar) Right side curtain air bag module (right "c" pillar) Rsat (+) Rsat (-) Seat belt ind Seat belt reminder Shield Sig Slh (+) Slh (-) Srh (+) Srh (-) Unified meter control unit (w/ information display) Supplemental Restraints Wiring Diagram (2 of 2) for Nissan Maxima S 2014 List of elements for Supplemental Restraints Wiring Diagram (2 of 2) for Nissan Maxima S 2014: 38 (behind right side of dash) front passenger air bag module (late production) left front door satellite sensor (late production) right front door satellite sensor 72g 79g 80g As1(+) As1(-) As2(+) As2(-) B12 B201 B7 (under driver's seat) Combination switch (spiral cable) (in steering column) Crash zone sensor (center front of engine compt) D112 D24 Driver air bag module (in steering wheel) E13 E205 E206 (left side of engine compt) E30 shield Early production Front passenger air bag off indicator Joint connector m03 Late production Left front seat belt pre-tensioner (base of left "b" pillar) Left front side air bag module (left side of driver's seat back) Left seat belt buckle switch (under driver's seat) M105 M106 M29 M48 M49 M57 (behind right side of dash) Nca Red Shield
TRANSMISSION Transmission Wiring Diagram for Nissan Maxima S 2014 List of elements for Transmission Wiring Diagram for Nissan Maxima S 2014: 83 (if equipped) paddle shifter (shift up) 12m 12p Atf temp sens Auto Batt Can-h Can-l Chip select Clock Combination meter Computer data lines system Cvt check ind Cvt fluid temperature sensor Cvt shift selector Cvt unit (left rear of engine) D range sw Data i/o Down E15 (left side of engine compt) Exterior lights system F10 Fuse 10a Fuse block (j/b) (lower left side of dash) Gnd Hot at all times Hot in on or start Interior lights system Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) L range sw L/u & select sol Line press sol Line pressure solenoid valve Lock-up select solenoid valve M203 M23 M24 M78 M79 (left center of dash) Man Mode select switch N range sw P range sw Paddle shifter (shift down) (if equipped) Park position switch (intelligent key system) Park position switch (shift selector) Pnk Position select switch Pri oil press sens Pri spd sens Primary pressure sensor Primary speed sensor R range sw Red Rev lamp rly Rom assembly S/m-a S/m-b S/m-c S/m-d Sec oil press sens Sec press sol Sec spd sens Secondary pressure sensor Secondary pressure solenoid valve Secondary speed sensor (top of transaxle) Sens gnd Sens pwr source Sensor gnd Shift Shift interlock system Shift lock solenoid Spd sens St rly Starting/ charging system Step motor Tcc sol Tcm (transmission control module) (left front of engine compt) Torque converter clutch solenoid valve Trans- mission range switch Unified meter control unit (w/ information display) Up sw shift dn sw Vign
TRUNK, TAILGATE, FUEL DOOR Trunk Release Wiring Diagram for Nissan Maxima S 2014 List of elements for Trunk Release Wiring Diagram for Nissan Maxima S 2014: 28 21j 26j 27j B19 (left "c" pillar) B24 Back trunk Batt pwr f/l Bcm (body control module) (behind instrument cluster) Cancel sw Fuse & fusible link box (left front of engine compt) Fusible link h 40a Gnd 1 Hot at all times M16 M17 M18 M20 M21 M57 (behind right side of dash) M6 b1 M61 (behind left side of dash) Request sw Trunk lamp switch & trunk release solenoid (center rear of luggage lid) Trunk lid opener cancel switch Trunk lid opener switch Trunk opener Trunk opener request switch Trunk sw
WARNING SYSTEMS Chime Wiring Diagram for Nissan Maxima S 2014 List of elements for Chime Wiring Diagram for Nissan Maxima S 2014: 67 (behind right side of dash) m57 (w/ information display) unified meter control unit 10j 11p 12m 24g 24j 57g Air bag diagnosis sensor unit (under rear of center console) B1 m6 B12 B201 B7 (under driver's seat) Bat (f/l) Bat bcm fuse Bcm (body control module) (behind instrument cluster) Brake ind Buzzer Can-h Can-l Card sw1 Combination meter Combination switch (lighting & turn signal switch) Computer data lines system Dr door sw E30 Fob in sw 1 Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd Gnd 1 Hot at all times Hot in on or start Input 1 Input 2 Input 3 Input 4 Input 5 Instrument cluster system Intelligent key warning buzzer (behind left end of dash) Joint connector b04 (left side of luggage compt) K-line seat belt reminder m35 Key slot Left front door switch (left "b" pillar) Left seat belt buckle switch (under driver's seat) Lh buckle sw input b9 M1 e30 M16 M17 M18 M19 M21 M24 M57 (behind right side of dash) M6 b1 M79 (left center of dash) Output 1 Output 2 Output 3 Output 4 Output 5 Parking brake switch (on brake pedal bracket) Pnk Red Seat belt ind Tire Pressure Monitoring Wiring Diagram for Nissan Maxima S 2014 List of elements for Tire Pressure Monitoring Wiring Diagram for Nissan Maxima S 2014: 35 (w/ information display) unified meter control unit 12m A/l pwr sply 5v Bat (f/l) Bcm (body control module) (behind instrument cluster) Buzzer Can-h Can-l Combination meter Computer data lines system Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd Gnd rf2 a/l Gnd1 Hot at all times Hot in on or start Ign (f/b) M16 M17 M18 M19 M24 M57 (behind right side of dash) M79 (left center of dash) Pnk Pwr Rf2 turner sig Sig Tire pressure ind Tire pressure receiver (left center of dash) Tire pressure warning check connector (left side of dash) Tpms mode
WIPER/WASHER Wiper/Washer Wiring Diagram for Nissan Maxima S 2014 List of elements for Wiper/Washer Wiring Diagram for Nissan Maxima S 2014: 60 17g 82g m1 Bat (f/l) Batt Batt bcm fuse Bcm (body control module) (behind instrument cluster) Can-h Can-l Combination meter Combination switch (wiper & washer) switch) Computer data lines system Cpu E15 (left side of engine compt) E17 E18 E200 E202 E204 (left side of engine compt) E30 E30 m1 Front washer motor (in washer reservoir) Front wiper high relay Front wiper motor (left rear of engine compt) Front wiper relay Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 30a Fuse block (j/b) (lower left side of dash) Fusible link h 40a Gnd1 High Hot at all times Ignition relay 1 Input 1 Input 2 Input 3 Input 4 Input 5 Ipdm e/r (intelligent power distribution module engine room) (left side of engine compt) Low Low wash fluid sw M1 4g M16 M17 M18 M19 M28 M57 (behind right side of dash) M61 (behind left side of dash) Move Output 1 Output 2 Output 3 Output 4 Output 5 Pnk Red Stop Unified meter control unit (w/ information display) Washer fluid level switch (in washer reservoir)
