Diagram sections — 31 (57 total)
AIR CONDITIONING ANTI-LOCK BRAKES ANTI-THEFT BODY CONTROL MODULES COMPUTER DATA LINES COOLING FAN CRUISE CONTROL DEFOGGERS ENGINE PERFORMANCE EXTERIOR LIGHTS GROUND DISTRIBUTION HEADLIGHTS HORN INSTRUMENT CLUSTER INTERIOR LIGHTS MEMORY SYSTEMS NAVIGATION POWER DISTRIBUTION POWER DOOR LOCKS POWER MIRRORS POWER SEATS POWER TOP/SUNROOF POWER WINDOWS RADIO SHIFT INTERLOCK STARTING/CHARGING SUPPLEMENTAL RESTRAINTS TRANSMISSION TRUNK, TAILGATE, FUEL DOOR WARNING SYSTEMS WIPER/WASHER
AIR CONDITIONING Automatic A/C Wiring Diagram (1 of 2) for Nissan Murano SE 2003 List of elements for Automatic A/C Wiring Diagram (1 of 2) for Nissan Murano SE 2003: 61 (power) gnd 12a A/c and av switch Acc Amb sens Ambient sensor (below lower left side of front grille) Bat Blower motor (behind lower right side of dash) Body control module (behind left side of dash) Bus+ Bus- Can-h Can-l Comp on Comp on sig Computer data lines system Dcu- dsp Display Display control unit Display unit Driver side air mix door motor (behind lower left center of dash) Dsp gnd Dsp shield Dsp- dcu Dsp-dcu Dsu-dsp Fan on Fan on sig Fan pwm out Fuse 10a Fuse 15a Fuse block (j/b) (behind left side of dash) Gnd Hot at all times Hot in acc or start Hot in on Hot in run or start Ign Ign2 In-vehicle sensor (behind left center of dash) Incar sens Intake door motor (behind right side of dash) Intake sens Intake sensor (behind right side of dash, on evaporator assembly) Lan sig M14 (behind left end of dash) M49 M50 M51 M78 (behind right end of dash) Mode door motor (behind left center of dash) Nca Passenger side air mix door motor (behind lower right center of dash) Sens gnd Shield Sun sens Sunload sensor (upper right side of dash, near base of windshield) Unified meter and a/c amplifier (behind lower center of dash) Vactr W/ navigation W/o navigation Automatic A/C Wiring Diagram (2 of 2) for Nissan Murano SE 2003 List of elements for Automatic A/C Wiring Diagram (2 of 2) for Nissan Murano SE 2003: 33 +batt +ign A/c compressor A/c relay Air comp Avcc gnd Can-h Can-l Computer data lines system Cooling fan motor 1 (on right front of engine compartment) Cooling fan motor 2 (on left front of engine compartment) Cooling fan relay-1 Cooling fan relay-2 Cooling fan relay-3 Cpu E13 (at left front corner of engine compt) E28 (at right side of engine compt) Engine control module (behind glove box) of dash, on hvac Fuse & fusible link box (on left front of engine compartment, near battery) Fuse 10a Fusible link k 40a Fusible link l 40a Gnd-a Hot at all times Hot in run or start Intelligent power distribution module engine room (ipdm e/r) (on right front of engine compartment, behind headlight) Joint connector 3 (behind upper right side of dash) Motor fan-1 Motor fan-2 Motor fan-3 Pd- pres Red Refrigerant pressure sensor (right front of engine compt, near radiator filler neck)
ANTI-LOCK BRAKES Anti-lock Brakes Wiring Diagram, with Traction Control for Nissan Murano SE 2003 List of elements for Anti-lock Brakes Wiring Diagram, with Traction Control for Nissan Murano SE 2003: 72 Abs actuator & electric unit (at left side of firewall) Abs ind Bat Brake fluid level switch (on master cylinder fluid reservoir) Brl Can 2 h Can 2 l Can h Can l Clus gnd Clus sp Combination meter Computer data lines system Control unit Data link connector Diag k Diag l Drv 1 gnd Drv 1 sig Drv 1 ss E101 E13 (at left front corner of eng comp) E26 (at lower right side of eng comp) Fl + Fl - Fr + Fr - Fuse & fusible link block (at left front of eng comp) Fuse 12 10a Fuse 14 10a Fuse 19 10a Fuse 20 20a Fuse 21 10a Fuse 88 10a Fuse block (j/b) (behind left kick panel) Fuse h 30a Fuse j 50a Gnd Gnd p Gnd v Grd Hot at all times Hot in on or start Ign Ipdm e/r (intelligent pwr distribution mod engine room) (at right rear corner of engine comp) Left front wheel sensor Left rear wheel sensor Lis M14 (behnd left end of dash) M25 M49 M50 M78 (behind right end of dash) M79 (behnd right end of dash) Mot bat Pressure sensor (at left rear of eng comp) Red Right front wheel sensor Right rear wheel sensor Rl + Rl - Rr + Rr - Sol bat Steering angle sensor (below left side of dash) Stoplight switch (on brake pedal bracket) Unified meter Unified meter & a/c amplifier (behind center of dash) Vdc off Vdc off switch Vdc/tcs/abs control unit Yaw rate/side/ decel g sensor (below center console) Anti-lock Brakes Wiring Diagram, without Traction Control for Nissan Murano SE 2003 List of elements for Anti-lock Brakes Wiring Diagram, without Traction Control for Nissan Murano SE 2003: 65 Abs actuator & electric unit (at left side of firewall) Abs ind Abs/tcs control unit Bat Brl Can h Can l Combination meter Computer data lines system Control unit Data link connector Diag k E101 E26 (at lower right side of engine comp) Fl + Fl - Fl in sol Fl out sol Fr + Fr - Fr in sol Fr out sol Fuse & fusible link block (at left front of eng comp) Fuse 12 10a Fuse 14 10a Fuse 19 10a Fuse 20 20a Fuse 21 10a Fuse 88 10a Fuse block (j/b) (behind left kick panel) Fuse g 30a Fuse h 30a G sensor Gnd p Gnd v Grd Hot at all times Hot in on or start Ign Ipdm e/r (intelligent pwr distribution mod engine room) (at right rear corner of engine comp) Left front wheel sensor Left rear wheel sensor M14 (behnd left end of dash) M25 M49 M50 M79 (behnd right end of dash) Mot + Mot - Mot bat Red Right front wheel sensor Right rear wheel sensor Rl + Rl - Rl in sol Rl out sol Rr + Rr - Rr in sol Rr out sol Sol bat Stoplight switch (on brake pedal bracket) Unified meter Unified meter & a/c amplifier (behind center of dash)
ANTI-THEFT Anti-theft Wiring Diagram for Nissan Murano SE 2003 List of elements for Anti-theft Wiring Diagram for Nissan Murano SE 2003: 67 (at left front corner of eng compt) e13 12a Acc B105 (behind right kick panel) B20 (behind left rear seat) Back door sw Back door switch (at lower center of back door) Bat Between full stroke & n Body control module (behind left end of dash) Can-h Can-l Closed Combi- nation meter Computer data lines system Cpu Data link connector (below left side of dash) Door lock & unlock switch (power window main switch) Door sw (as) Door sw (as) in Door sw (dr) Door sw (dr) in Door sw (rl) in Door sw (rr) in Door switch (left rear door lock assembly) Door switch (right rear door lock assembly) Driver side door key cylinder switch (front door lock assembly) E118 E13 (at left rear corner of eng compt) E28 (at right side of eng compt) Full stroke Fuse & fusible link box (left front of eng compt) Fuse 10a Fuse 15a Fuse block (j/b) left side of dash) Fuse f 50a Gnd Gnd1 Headlamp high relay Headlamp low relay Headlights system Hood switch (at left front of eng compt) Horn (high) Horn (low) Horn relay (in fuse & fusible link box) Horns system Hot at all times Hot in on or start Intelligent power distribution module engine room (on right front of engine compt behind headlight) K-line Lock Lock switch M14 (behind left end of dash) M34 M35 M37 M78 (behind right end of dash) Open Passenger side door lock & unlock switch (front power window switch) Passenger side door switch (front door lock assembly) Pwd serial link Red Security ind out Security indicator lamp Unified meter & a/c amp (behind lower center of dash) Unlock Unlock switch Immobilizer Wiring Diagram for Nissan Murano SE 2003 List of elements for Immobilizer Wiring Diagram for Nissan Murano SE 2003: 28 15a Bat Body control module (behind left end of dash) Can-h Can-l Combi- nation meter Computer data lines system Data link connector (below left side of dash) E118 E13 (at left rear corner of eng compt) Engine control module (ecm) (behind glove box) Fuse & fusible link box (left front of eng compt) Fuse 10a Fuse block (j/b) left side of dash) Fuse f 50a Gnd1 Hot at all times Hot in on or start Ign K-line M35 M37 Nats antenna amp Nats antenna amplifier (behind center of dash) Pnk Red Security ind out Security indicator lamp
BODY CONTROL MODULES Body Control Modules Wiring Diagram for Nissan Murano SE 2003 List of elements for Body Control Modules Wiring Diagram for Nissan Murano SE 2003: 73 12p 15a Acc Air conditioning system Anti-theft system Auto light sen input Auto light sen pwr Back door sw Bat Batt saver output Body control module (bcm) (behind left side of dash) Can h Can l Combi sw input 1 Combi sw input 2 Combi sw input 3 Combi sw input 4 Combi sw intput 5 Combi sw out 4 Combi sw output 1 Combi sw output 2 Combi sw output 3 Combi sw output 5 Comp on signal Computer data lines system Data link connector Defogger system Door locks system Door sw (as) Dr door sw Dr door unlock Dr lock output (all) E118 E13 (at left front corner of eng comp) Exterior lights system Fan on signal Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (behind left end of dash) Fuse f 50a Gnd Hazard sw Headlights system Hot at all times Hot in accy or on Hot in on or start Ign Instrument cluster system Interior lights system K line Key illum output Key sw Key switch and key lock solenoid Lh flasher output M21 M35 M36 M37 P/w pwr (bat) P/w pwr (rap) Pnk Power windows system Pwr win pwr (bat) Red Rh flasher output Room lamp output Rr def sw Rr wiper auto stop Rr wiper mtr output Security ind output Sensor gnd Step lamp output Wiper/washer system
COMPUTER DATA LINES Computer Data Lines Wiring Diagram for Nissan Murano SE 2003 List of elements for Computer Data Lines Wiring Diagram for Nissan Murano SE 2003: 52 (behind left end of dash) m14 (door lock & unlock switch) A/c & av switch Abs actuator & electric unit (at right rear of eng compt) Air bag diagnosis sensor unit (below center console, between seats) Audio rx Audio tx Audio unit Awd control unit (behind left side of dash) Body control module (behind left side of dash) Bus + Bus - Bus shield Can-h Can-l Combination meter Cpu Data link connector (lower left side of dash) Diag-k Display control unit (w/navigation) (behind center of dash) Display unit Driver seat control unit (under driver seat) Engine control module (behind glove box) F103 Front power window switch (passenger side) Fuse 12 10a Fuse 19 10a Fuse block (j/b) (behind left side of dash) Hot at all times Hot in on or start Intelligent power distribution module engine room (at right rear of eng compt, behind headlight) K-line Low tire pressure warning control unit (behind right side of dash) M25 M37 M43 M49 M80 Navi control unit (under front of center console) Nca Power window main switch Pwr wdo serial link Rx (comb meter) Shield Steering angle sensor (below left side of dash, near steering column) Transmission control module (behind right side of dash) Tx (comb meter) Unified meter & a/c amplifier (behind lower center of dash) Unified meter control unit Vdc/tcs/abs control unit W/ navigation W/o navigation
COOLING FAN Cooling Fan Wiring Diagram for Nissan Murano SE 2003 List of elements for Cooling Fan Wiring Diagram for Nissan Murano SE 2003: 26 +ig Can-h Can-l Cooling fan motor 1 Cooling fan motor 2 Cooling fan relay 1 Cooling fan relay 2 Cooling fan relay 3 Cpu E13 (left front corner of engine compt) E28 (right side of engine compt) Engine control module (ecm) (behind glove box) Fuse 10a Fuse 15a Fusible link & fusible link block (left front of engine compt, near battery) Fusible link k 40a Fusible link l 40a Gnd (power) Gnd (signal) Hot at all times Hot in on or start Intelligent power distribution module (engine room) (on right front of engine compt, behind headlight) Motor fan-1 Motor fan-2 Motor fan-3 Red
CRUISE CONTROL Cruise Control Wiring Diagram for Nissan Murano SE 2003 List of elements for Cruise Control Wiring Diagram for Nissan Murano SE 2003: 50 Ascd brake switch (on brake pedal bracket) Ascd ctrl sw Ascd steering switch Avcc2 Brake sw (close) Brake sw (open) Can-h Can-l Cancel switch Combination meter Computer data lines system Cruise Electric throttle control actuator (on throttle body) Engine control module (ecm) (behind glove box) Fuse 12 10a Fuse 14 10a Fuse 20 10a Fuse 21 10a Fuse 71 10a Fuse block (j/b) (behind left side of dash) Gnd Gnd-a Gnd-a2 Hot at all times Hot in on or start Ipdm e/r (right front of engine compartment) J/c 1 (upper right end of dash) M203 M25 M31 M78 (behind right end of dash) Main switch Motor 1 Motor 2 Nca Pnk Red Resume/ accel switch Secondary speed sensor (right rear of engine compt) Sensor Set Set/ coast switch Spiral cable Stop lamp switch (on brake pedal bracket) Tps1 Tps2 Transmission control module (behind right side of dash) Transmission system Unified meter & a/c amp (behind lower center of dash) box) Unified meter control unit
DEFOGGERS Defoggers Wiring Diagram for Nissan Murano SE 2003 List of elements for Defoggers Wiring Diagram for Nissan Murano SE 2003: 38 +ig 12a 15a A/c and av switch (rear defogger switch) Acc B20 (behind left rear seat) Batt Body control module (behind left side of dash) Can-h Can-l Computer data lines system Driver side door mirror defogger (if equipped) E13 (at left front corner of engine compt) E28 (at right side of engine compt0 Fuse & fusible link block (on left front of engine compt) Fuse 10a Fuse 15a Fuse 20a Fuse block (j/b) (behind left side of dash) Fuse f 50a Gnd Gnd (power) Gnd (signal) Hot at all times Hot in acc or on Hot in on or start Ign Intelligent power distribution module (engine room) (on right front of engine compt, behind headlight) K-line M14 (behind left end of dash) M78 (behind right end of dash) Passenger side door mirror defogger (if equipped) Rear window defogger Rear window defogger relay (behind left kick panel) Red Rr def on Rr def rly Rr def sw
ENGINE PERFORMANCE
3.5L 3.5L, Engine Performance Wiring Diagram (1 of 4) for Nissan Murano SE 2003 List of elements for 3.5L, Engine Performance Wiring Diagram (1 of 4) for Nissan Murano SE 2003: 55 (behind right end of dash) m78 (on front of engine) f23 15a Avcc Avcc2 C-ivc (l) C-ivc (r) Combination meter Condenser (behind upper right side of dash) Crankshaft position sensor (pos) (lower left rear of cylinder block) Engine control module (behind glove box) Enmn1 Evap Evap canister purge volume control solenoid valve (on rear of intake manifold) Front electronic controlled engine mount (lower front center of engine compt) Ftrps Fuel injector Fuse 10a Fuse block (j/b) (behind left side of dash) Gnd Hot in on or start Inj 1 Inj 2 Inj 3 Inj 4 Inj 5 Inj 6 J/c 1 (behind upper right side of dash) Knk1 Knock sensor (lower right side of cyl block) M78 (behind right end of dash) Malfunction indicator lamp Motor1 Motor2 Nca O2hfr O2hrl O2hrr O2sfl O2sfr O2srl Pdpres Phase lh Phase rh Pos Ps pres Qa+ Rear electronic controlled engine mount (w/ awd) (lower rear center of engine compt) Red Refrigerant pressure sensor (right front of eng compt, near radiator filler neck) Tps1 Unified meter control unit V mot Vias Vias control solenoid valve (top front of engine) 3.5L, Engine Performance Wiring Diagram (2 of 4) for Nissan Murano SE 2003 List of elements for 3.5L, Engine Performance Wiring Diagram (2 of 4) for Nissan Murano SE 2003: 32 (on front of engine) f23 Accelerator pedal position (app) sensor 1 Accelerator pedal position (app) sensor 2 Ecm relay Electric throttle control actuator (integral with throttle body, on rear of intake manifold) F33 Fuel pump relay Fuse 10a Fuse 15a Fuse block (j/b) (behind left side of dash) Hot at all times Hot in on or start Ignition coil 1 (w/ power transistor) Ignition coil 2 (w/ power transistor) Ignition coil 3 (w/ power transistor) Ignition coil 4 (w/ power transistor) Ignition coil 5 (w/ power transistor) Ignition coil 6 (w/ power transistor) Intelligent power distribution module engine room (ipdm e/r) (right front of engine compt) J/c 1 (behind upper right side of dash) M67 M78 (behind right end of dash) Nca Nca nca Plug spark Pnk Red Spark plug Throttle control motor Throttle control motor relay Throttle position (tp) sensor 1 Throttle position (tp) sensor 2 3.5L, Engine Performance Wiring Diagram (3 of 4) for Nissan Murano SE 2003 List of elements for 3.5L, Engine Performance Wiring Diagram (3 of 4) for Nissan Murano SE 2003: 21 (behind upper right side of dash) j/c 3 Camshaft position sensor (phase) (bank 1) (rear of right cyl head) Camshaft position sensor (phase) (bank 2) (rear of left cyl head) Condenser (behind upper right side of dash) Engine coolant temperature sensor (on left rear of engine) Evap control system pressure sensor (below center rear of vehicle, near evap canister) Fuse 15a Fuse block (j/b) (behind left side of dash) Heated oxygen sensor 1 (bank 1) (on right exhaust manifold) Heated oxygen sensor 1 (bank 2) (on left exhaust manifold) Heated oxygen sensor 2 (bank 1) (on outlet of rear twc) Heated oxygen sensor 2 (bank 2) (on outlet of front twc) Hot in on or start Intake valve timing control solenoid valve (bank 1) (on front of right cylinder head) Intake valve timing control solenoid valve (bank 2) (on front of left cylinder head) J/c 1 (behind upper right side of dash) M78 (behind right end of dash) Mass airflow (maf) sensor (on left side of eng, attached to air box) Nca Pnk Red 3.5L, Engine Performance Wiring Diagram (4 of 4) for Nissan Murano SE 2003 List of elements for 3.5L, Engine Performance Wiring Diagram (4 of 4) for Nissan Murano SE 2003: 59 Aps1 Aps2 Ascdsw At-p Avcc Avcc2 B7 (behind left kick panel) Batt Bncsw Brake Can l Can-h Can-l Cdcv Computer data lines system Condenser (behind upper right side of dash) Cruise control system Crusie control system Data link connector (below left side of dash) Ecm Engine control module (behind glove box) Enmn2 Evap canister vent control valve (below center rear of vehicle, near evap canister) Fpr Fuel level sensor unit & fuel pump (in fuel tank) Fuel sen Fuse & fusible link box (left front of engine compt, near battery) Fuse 10a Fuse block (j/b) (behind left side of dash) Gnd Gnd 02 Gnd a Gnd a2 Gnd-m Hot at all times Ign 1 Ign 2 Ign 3 Ign 4 Ign 5 Ign 6 Ign sw J/c 1 (behind upper right side of dash) Kline M78 (behind right end of dash) Moyrly O2srr Pdpres Pnk Power steering oil pressure sensor (on power steering pump) Red Ssoff Starter relay (on ipd module) Stoplight switch (above brake pedal, on bracket) Str rly Tps2 Transmission control module (behind right end of dash) Unified meter & a/c amp (behind lower center of dash) Vmot
EXTERIOR LIGHTS Back-up Lamps Wiring Diagram for Nissan Murano SE 2003 List of elements for Back-up Lamps Wiring Diagram for Nissan Murano SE 2003: 26 B20 (behind left rear seat) Back-up lamp relay (under left side of dash, near fuse block) Can- h rly Can- l rly Computer data lines system Cvt unit (at bottom left of transmission) Fuse 14 10a Fuse block (behind left side of dash) Hot in on or start Inh sw1 Inh sw2 Inh sw3 Inh sw3 mon Inh sw3m Inh sw4 Left back-up lamp Off off off on on Off off on on on Off on off on off Off on on on off P r n d l Park/ neutral position switch Rer- lamp rly Right back-up lamp Shift position Transmission control module (tcm) (behind right side of dash) Exterior Lights Wiring Diagram for Nissan Murano SE 2003 List of elements for Exterior Lights Wiring Diagram for Nissan Murano SE 2003: 87 (at left front corner of eng compt) e13 (at right side of eng compt) e28 (behind left end of dash) (behind left rear seat b20 (behind right end of dash) m78 12a 15a Acc Bat Batt Body control module (bcm) (behind left end of dash) Buzzer Can-h Can-hi Can-l Can-lo Comb sw in 1 Comb sw in 2 Comb sw in 3 Comb sw in 4 Comb sw in 5 Comb sw out 1 Comb sw out 2 Comb sw out 3 Comb sw out 4 Comb sw out 5 Combination meter Combination switch Computer data lines system Cpu Data link connector (below left side of dash) E118 E13 (at left front corner of eng compt) E28 (at right side of eng compt) Fuse & fusible link box (on left front of engine compt, near battery) Fuse 10a Fuse 15a Fuse block Fuse f 50a Gnd Hazard sw Hazard switch High mounted stop lamp Hot at all times Hot in acc or on Hot in on or start Ign Input 1 Input 2 Input 3 Input 4 Input 5 Intelligent power distribution module engine room (on right front of engine compt behind headlight) K-line Left flash out Left front combination lamp Left license plate light Left rear combination lamp Left turn signal M35 M36 M37 Nca Off Output 1 Output 2 Output 3 Output 4 Output 5 Parking Red Right flash out Right front combination lamp Right license plate light Right rear combination lamp Right turn Right turn signal Rx (com meter) Side marker Stop Stop lamp switch (above brake pedal on bracket) Tail Tail lamp relay Turn signal Tx (com meter) Unified meter & a/c amp (behind lower center of dash) Unified meter control unit
GROUND DISTRIBUTION Ground Distribution Wiring Diagram for Nissan Murano SE 2003 List of elements for Ground Distribution Wiring Diagram for Nissan Murano SE 2003: 25 Abs actuator & electric unit, airbag diagnosis sensor unit shield wire Air bag diagnostic sensor unit shield wire Alternator Awd control unit, condenser, fuel level sensor unit, fuel pump, left seat belt buckle switch B105 (behind right kick panel) B113 (base of right "b" pillar) B116 (behind right rear seat) B15 (base of left "b" pillar) B20 (behind left rear seat) B7 (behind left kick panel) Bose speaker amplifier, bose speaker amp, right power seat switch, right rear power window switch, bose speaker amp, right power seat switch, right seat cushion heater, right rear door lock assembly Condenser, ignition coils 1, 2, 3, 4, 5 & 6 (with power transistor) E13 (left front corner of engine compartment) E26 (lower right side of engine compartment) E28 (right side of engine compartment) E29 (right side of engine compartment) F23 (on front of engine) Fuse block, illumination control switch, vdc off switch, headlamp aiming switch, automatic drive positioner control unit data link connector, power socket relay, immobilizer control unit, combination switch, steering angle sensor, integrated display unit, a/c and av switch, unified meter & a/c amp, front power socket, navigation control unit, airbag diagnosis sensor unit, pedal adjusting control unit, cigarette lighter socket, left vanity mirror lamp, map lamp, anti-dazzling inside mirror, sunroof switch, sunroof motor, right vanity mirror lamp, left front door lock assembly, power window main switch, left door mirror (w/defog), seat memory switch, personal lamp (lh & rh), room lamp Instrument cluster, heated seat switch (lh & rh), awd lock switch, door mirror r/c switch, cvt device, coin box lamp, blower motor, condenser, mode door motor, air mix door motor (lh & rh), electric throttle control actuator shield wire, intake door motor, glove box lamp, engine control module (ecm), knock sensor shield wire, crankshaft position sensor, camshaft position sensor, right door mirror (w/defog) right front power window switch, right front door lock assembly Intelligent power distribution module engine room (ipdm e/r), left front fog lamp, right front fog lamp, hood switch, left headlamp, left front combination lamp, brake fluid level switch, front wiper motor, body control module Left rear combination lamp, right rear combination lamp, rear power socket, fuel lid lock actuator relay, driver seat control unit, left power seat switch, pedal adjusting switch, driver seat cushion heater, left rear power window switch, left rear door lock assembly, high mounted stop lamp, back up lamps, back door switch, license plate lamps, rear window defogger M14 (behind left end of dash) M78 (behind right end of dash) Right seat belt buckle switch, heated seat relay, right rear power window switch Washer level sensor, right headlamp, right front combination lamp, cooling fan motor 1, cooling fan motor 2, intelligent power distribution module engine room (ipdm e/r),
HEADLIGHTS Headlights Wiring Diagram, with Xenon Lamps for Nissan Murano SE 2003 List of elements for Headlights Wiring Diagram, with Xenon Lamps for Nissan Murano SE 2003: 98 (at left front corner of eng compt) e13 (behind left end of dash) 12a 15a Acc Alternator Auto lt in Auto lt pwr B105 (behind right kick panel) B20 (behind left rear seat) Bat Body control module (bcm) (behind left end of dash) Brake Can-hi Can-lo Charge Comb sw in 1 Comb sw in 2 Comb sw in 3 Comb sw in 4 Comb sw in 5 Comb sw out 1 Comb sw out 2 Comb sw out 3 Comb sw out 4 Comb sw out 5 Combination meter Combination switch Computer data lines system Cpu Data link connector (below left side of dash) Door sw (as) Door sw (as) in Door sw (dr) Door sw (dr) in Door sw (rl) in Door sw( rr) in Driver side door switch (front door lock assembly) E118 E13 (at left front corner of eng compt) E28 (at right side of eng compt) E29 (at right side of eng compt) Front fog lamp relay Fuse & fusible link box (on left front of engine compt, near battery) Fuse 1 10a Fuse 10a Fuse 15a Fuse 6 10a Fuse block Fuse f 50a Gnd Headlamp high relay Headlamp low relay Hid cont High & low High beam High beam solenoid Hot at all times Hot in acc or on Hot in on or start Ign Input 1 Input 2 Input 3 Input 4 Input 5 Intelligent power distribution module engine room (on right front of engine compt behind headlight) K-line Left front combination lamp Left front fog lamp Left headlamp Left rear door switch (rear door lock assembly) M14 (behind left end of dash) M34 M35 M36 M37 M78 (behind right end of dash) Optical sensor (at top left side of dash) Output Output 1 Output 2 Output 3 Output 4 Output 5 Parking brake switch (behind left side of dash) Passenger side door switch (front door lock assembly) Pnk Pwr Red Right front combination lamp Right front fog lamp Right headlamp Right rear door switch (rear door lock assembly) Rx (comb meter) Sensor gnd Tx (comb meter) unified meter & a/c amp (behind lower center of dash) Unified meter control unit Headlights Wiring Diagram, without Xenon Lamps for Nissan Murano SE 2003 List of elements for Headlights Wiring Diagram, without Xenon Lamps for Nissan Murano SE 2003: 97 (at left front corner of eng compt) e13 (behind left end of dash) 12a 15a Acc Alternator Auto lt in Auto lt pwr B105 (behind right kick panel) B20 (behind left rear seat) Bat Body control module (bcm) (behind left end of dash) Brake Can-hi Can-lo Charge Comb sw in 1 Comb sw in 2 Comb sw in 3 Comb sw in 4 Comb sw in 5 Comb sw out 1 Comb sw out 2 Comb sw out 3 Comb sw out 4 Comb sw out 5 Combination meter Combination switch Computer data lines system Cpu Data link connector (below left side of dash) Door sw (as) Door sw (as) in Door sw (dr) Door sw (dr) in Door sw (rl) in Door sw( rr) in Driver side door switch (front door lock assembly) E118 E13 (at left front corner of eng compt) E28 (at right side of eng compt) E29 (at right side of eng compt) Front fog lamp relay Fuse & fusible link box (on left front of engine compt, near battery) Fuse 1 10a Fuse 10a Fuse 15a Fuse 6 10a Fuse block Fuse f 50a Gnd Headlamp high relay Headlamp low relay High High beam Hot at all times Hot in acc or on Hot in on or start Ign Input 1 Input 2 Input 3 Input 4 Input 5 Intelligent power distribution module engine room (on right front of engine compt behind headlight) K-line Left front combination lamp Left front fog lamp Left headlamp Left rear door switch (rear door lock assembly) Low M14 (behind left end of dash) M34 M35 M36 M37 M78 (behind right end of dash) Optical sensor (at top left side of dash) Output Output 1 Output 2 Output 3 Output 4 Output 5 Parking brake switch (behind left side of dash) Passenger side door switch (front door lock assembly) Pnk Pwr Red Right front combination lamp Right front fog lamp Right headlamp Right rear door switch (rear door lock assembly) Rx (comb meter) Sensor gnd Tx (comb meter) unified meter & a/c amp (behind lower center of dash) Unified meter control unit
HORN Horn Wiring Diagram for Nissan Murano SE 2003 List of elements for Horn Wiring Diagram for Nissan Murano SE 2003: 21 +ig Can-h Can-l Combination switch (spiral cable) Computer data lines Cpu E13 (at left front corner of eng compt) E28 (at right side of of eng compt) Fuse & fusible link box) (left front of eng compt) Fuse 10a Fuse 15a Gnd (power) Gnd (signal) High horn (below right headlight) Horn relay (in fuse & fusible link box) Horn rly drive Horn switch Hot at all times Hot in on or start Intelligent power distribution module engine room (ipdm e/r) (on right front of eng compt, behind headlight) Low horn (below left headlight)
INSTRUMENT CLUSTER Display Wiring Diagram for Nissan Murano SE 2003 List of elements for Display Wiring Diagram for Nissan Murano SE 2003: 41 (behind left end of dash) m14 12a 8 p/r A/c & av switch Acc Audio rx Audio tx Audio unit Batt Body control module (behind left side of dash) Bus+ Bus- Can-h Can-l Computer data lines system Cpu Display unit (behind center of dash) Driver seat control unit (under driver seat) Fuse & fusible link block (j/b) (on left front of eng compt, near battery) Fuse 10a Fuse 15a Fuse block (j/b) (behind left kick panel) Gnd Gnd (power) Hot at all times Hot in acc or on Hot in on or start Ign Ill Intelligent power distribution module engine room (ipdm e/r) (right front of eng compt) Low tire pressure warning control unit (behind right side of dash) M14 (behind left end of dash) M37 M49 M50 Nca Shield Speed Tail lamp relay Tail/l rly Unified meter & a/c amplifier (behind center of dash) Gauges & Indicators Wiring Diagram (1 of 2) for Nissan Murano SE 2003 List of elements for Gauges & Indicators Wiring Diagram (1 of 2) for Nissan Murano SE 2003: 66 (with odo/trip meter, cvt ind) (w/ ascd) (w/ awd) (w/ vdc) Abs ind Air bag ind Awd ind Awd lock ind B7 (behind left kick panel) Belt ind Brake Brake fluid level switch (on master cylinder fluid reservoir) Buzzer Charge ind Charging/ starting system Combination meter Cruise ind Cvt ind Door ind E13 (at left front corner of engine compt) E28 (at right side of eng compt) Exterior & interior lights system (hazard switch) Fuel gauge Fuel ind Fuse 10a Fuse block (j/b) (behind left side of dash) Hazard switch High beam ind Hot at all times Hot in on or start Illum Illum control switch (+) Illum control switch (-) Illum ctrl sw (+) Illum ctrl sw (-) Illumination (3) Interior lights system Key switch & key lock solenoid (on right side of steering column) Left turn ind M25 M301 M302 M78 (behind right end of dash) Malfunction ind lamp Nca Odo/ trip meter switch Odo/trip meter & illum ctrl sw Odo/trip meter & illumination control switch Odo/trip meter illum Odo/trip meter sw Oil ind Parking brake switch (behind left side of dash) Red Right turn ind Seat belt buckle switch (in driver seat belt buckle) Security ind Set ind Slip Speed- meter Tachometer Tire pressure ind Unified meter control unit Vdc off Washer ind Washer level sensor (on washer fluid reservoir) Water temp gauge Gauges & Indicators Wiring Diagram (2 of 2) for Nissan Murano SE 2003 List of elements for Gauges & Indicators Wiring Diagram (2 of 2) for Nissan Murano SE 2003: 63 8p/r Abs actuator & electric unit (at right rear of eng compt) At-p range Awd control unit (behind left side of dash) Awd lock Awd lock switch B105 (behind right kick panel) B20 (behind left rear seat) Back door sw Back door switch Batt Body control module (bcm) (behind left side of dash) Can-h Can-h can-l Can-hi Can-l Computer data lines system Cvt device (second position switch) (at bottom left of transmission) Door sw (as) in Door sw (dr) Door sw (dr) in Door sw (rl) in Door sw (rr) in Driver side door switch (front door lock assembly) Engine control module (behind glove box) Fuel level sensor unit & fuel pump (main) Fuel level sensor unit (sub) Fuel sens Fuel sens gnd Fuse 10a Fuse block (j/b) (behind left side of dash) Gnd Gnd (power) Hazard sw Hot at all times Hot in on or start Ign Ign 2 Intelligent power distribution module eng room (on right front of eng compt, behind headlight) Interior lights system Key sw Left rear door switch (rear door lock assembly) Lis Low tire pressure warning control unit (behind right side of dash) M14 (behind left end of dash) M49 M50 M78 (behind right end of dash) Nca Oil press sw Oil pressure switch (on lower right front of cylinder block) Passenger side door switch (front door lock assembly) Red Right rear door switch (rear door lock assembly) Rx (comb meter) Security ind out Starter rly Steering angle sensor (below left side of dash, near steering column) Transmission control module (behind right side of dash) Tx (comb meter) Unified meter & a/c amplifer (behind lower center of dsh) Vdc off Vdc off switch
INTERIOR LIGHTS Courtesy Lamps Wiring Diagram (1 of 2) for Nissan Murano SE 2003 List of elements for Courtesy Lamps Wiring Diagram (1 of 2) for Nissan Murano SE 2003: 58 (below left side of dash) data link connector 15a B105 (behind right kick panel) B20 (behind left rear seat) Back door sw Bat Battery saver out Between full stroke & n Body control module (behind left end of dash) Can-h Can-l Closed Computer data lines system Cpu Door lock & unlock switch (power window main switch) Door sw (as) Door sw (as) in Door sw (dr) Door sw (dr) in Door sw (rl) in Door sw (rr) in Door switch (left rear door lock assembly) Door switch (right rear door lock assembly) Driver side door key cylinder switch (front door lock assembly) E118 E13 (at left rear corner of eng compt) Full stroke Fuse & fusible link box (left front of eng compt) Fuse 10a Fuse block (j/b) left side of dash) Fuse f 50a Gnd Gnd1 Hot at all times Hot in on or start Ign K-line Key ring illum out Key sw Key switch (key switch & key lock lock solenoid) Lock Lock switch M14 (behind left end of dash) M34 M35 M37 M78 (behind right end of dash) Open Passenger side door lock & unlock switch (front power window switch) Passenger side door switch (front door lock assembly) Pnk Pwd serial link Red Room lamp out Step lamp out Unified meter & a/c amp (behind lower center of dash) Unlock Unlock switch Courtesy Lamps Wiring Diagram (2 of 2) for Nissan Murano SE 2003 List of elements for Courtesy Lamps Wiring Diagram (2 of 2) for Nissan Murano SE 2003: 23 B20 (behind left rear seat) Back door switch (at lower center of back door) Closed Condenser Diode (behind left rear quarter panel, taped to harn) Door Driver side step lamp Driver side vanity mirror lamp Ignition key hole illumination Left luggage room lamp Left personal lamp M14 (behind left end of dash) M78 (behind right end of dash) Map lamp Off Open Passenger side step lamp Passenger side vanity mirror lamp Pnk Red Right luggage room lamp Right personal lamp Room lamp Instrument Illumination Wiring Diagram for Nissan Murano SE 2003 List of elements for Instrument Illumination Wiring Diagram for Nissan Murano SE 2003: 74 (+) (-) (at left front corner of eng compt) e13 (behind left end of dash) (behind left rear seat) b20 (behind right end of dash) m78 (behind right kick panel) b105 12a 15a Acc Awd lock switch Bat Body control module (bcm) (behind left end of dash) Can-hi Can-lo Comb sw in 1 Comb sw in 2 Comb sw in 3 Comb sw in 4 Comb sw in 5 Comb sw out 1 Comb sw out 2 Comb sw out 3 Comb sw out 4 Comb sw out 5 Combination meter Combination switch Computer data lines system Cpu Cvt illumination Data link connector (below left side of dash) Driver side heated seat switch E118 E13 (at left front corner of eng compt) E28 (at right side of eng compt) Fuse & fusible link box (on left front of engine compt, near battery) Fuse 10a Fuse 15a Fuse block Fuse f 50a Gnd Hazard switch Hot at all times Hot in acc or on Hot in on or start Ign Illum Illum (3 bulbs) Illum control sw Input 1 Input 2 Input 3 Input 4 Input 5 Intelligent power distribution module engine room (on right front of engine compt behind headlight) K-line Left rear power window switch M35 M36 M37 Nca Odo/trip meter & illumination control switch Off Output 1 Output 2 Output 3 Output 4 Output 5 Passenger side heated seat switch Red Right rear power window switch Tail lamp relay Unified meter control unit Vdc off switch
MEMORY SYSTEMS Memory Systems Wiring Diagram (1 of 3) for Nissan Murano SE 2003 List of elements for Memory Systems Wiring Diagram (1 of 3) for Nissan Murano SE 2003: 62 (at left front corner of eng compt) e13 (behind left end of dash) m14 (behind left side of dash) body control module (behind lower center of dash) unified meter & a/c amplifier (behind right side of dash) transmission control module (front door lock assembly) driver side door switch 12a 15a Acc Address1 Address2 Automatic driver positioner control unit (under left side of dash, behind fuse block) Bat Can-h Can-l Circuit breaker (behind left side of dash) Cm32 Computer data lines system Cvt device (at bottom left of transmission) Door sw (dr) Fuse & fusible link box (left side of engine compt) Fuse 10a Fuse block (j/b) (behind left side of dash) Fuse f 50a Gnd Gnd (power) Gnd (sens) Gnd (sig) Hot at all times Hot in on or start Ign Ind1 Ind2 Key sw Key switch & key lock solenoid M14 (behind left end of dash) Memory indicator Memory switch-1 Memory switch-2 Mirror motor (rh com) Mirror mtr (lh com) Mirror mtr (lh horiz) Mirror mtr (lh vert) Mirror mtr (rh horiz) Mirror mtr (rh vert) Mirror select sw (lh) Mirror select sw (rh) Mirror sens (lh horiz) Mirror sens (lh vert) Mirror sens (rh horiz) Mirror sens (rh vert) Mirror sw (dn) Mirror sw (left) Mirror sw (right) Mirror sw (up) Pedal motor (fr) Pedal motor (rr) Pedal sensor Red Seat memory switch Set sw Set switch Memory Systems Wiring Diagram (2 of 3) for Nissan Murano SE 2003 List of elements for Memory Systems Wiring Diagram (2 of 3) for Nissan Murano SE 2003: 16 31b 31c Door mirror remote control switch Driver side door mirror Front lifting motor Left M78 (behind right eng of dash) Mirror position switch Mirror select switch Passenger side door mirror Pedal adjusting motor Rear lifting motor Reclining sensor Red Right Sliding sensor Memory Systems Wiring Diagram (3 of 3) for Nissan Murano SE 2003 List of elements for Memory Systems Wiring Diagram (3 of 3) for Nissan Murano SE 2003: 53 31a 32a 48c B20 (behind left rear seat) B303 B304 Bat Can-h Can-l Computer data lines system Driver seat control unit (under driver seat) Driver side power seat switch Driver side reclining motor Driver side sliding motor Fr lifting motor (dn) Fr lifting motor (up) Front lifting sw (dn) Front lifting sw (up) Fuse 10a Fuse block (j/b) (behind left side of dash) Gnd Gnd (sens gnd) Gnd (signal) Hot in on or start Lifting switch (front) Lifting switch (rear) M14 (behind left end of dash) P range sw Pedal adjusting switch Pedal sw (ff) Pedal sw (rr) Pulse sw (front lifting) Pulse sw (reclining) Pulse sw (rr lifting) Pulse sw (sliding) Rear lifting sw (dn) Rear lifting sw (up) Reclining motor (fr) Reclining motor (rr) Reclining sensor Reclining sw (fr) Reclining sw (rr) Reclining switch Red Rr lifting motor (dn) Rr lifting motor (up) Sliding motor (fr) Sliding motor (rr) Sliding sensor Sliding sw (fr) Sliding sw (rr) Sliding switch Start sw
NAVIGATION Navigation Wiring Diagram (1 of 2) for Nissan Murano SE 2003 List of elements for Navigation Wiring Diagram (1 of 2) for Nissan Murano SE 2003: 45 (right end of dash) m78 12a 8 p/r Acc Audio unit Backup lamp relay (at left kick panel) Bat Body computer system Bus+ Bus- Can-h Can-l Computer data Fuse & fusible link block (at left front of engine comp) Fuse 10a Fuse 15a Fuse block (j/b) (behind left side of dash) Gnd Gps ant gnd Gps antenna Gps sig Hot at all times Hot in acc or on Hot in on or start Ign Lines system M351 M62 M63 Navi control unit (under front of center console) Navi gnd Navi input+ Navi input- Nca Rev lamp rly Rgb shield Rgb sync Shield Sound system Speed Sync shield Transmission control module (behind glove box) Unified meter & a/c amp (behind lower center of dash) Voice + Voice - Navigation Wiring Diagram (2 of 2) for Nissan Murano SE 2003 List of elements for Navigation Wiring Diagram (2 of 2) for Nissan Murano SE 2003: 36 A/c & av switch Acc Bus shield Bus+ Bus- Can-h Can-l Computer data lines system Dcu-dsp Display Display control unit (behind center of dash) Dsp gnd Dsp shield Dsp-dcu Exterior lights system Gnd Ign Ill Inv gnd Inv vcc M42 M43 M78 (right end of dash) Nca Pnk Red Rgb gnd Rgb sy Rgb sync Shield Sig gnd Sig vcc Sign gnd Sign vcc Speed Sync gnd
POWER DISTRIBUTION Power Distribution Wiring Diagram (1 of 2) for Nissan Murano SE 2003 List of elements for Power Distribution Wiring Diagram (1 of 2) for Nissan Murano SE 2003: 58 (behind left side of dash) fuse block (j/b) (left front of engine compt) fuse & fusible link box (right front of engine compt) intelligent power distribuiton module engine room (ipdm e/r) 15a A/c relay Air conditioning system All wheel drive (awd) system Anit-lock brakes system Anti-theft, engine controls, power window, power top, defogger, warning, wiper/washer, navigation, integrated display system Battery Computer data lines system Cooling fans system Cpu Defogger system Defogger, navigation, entertainment, communications, systems Ecm relay Engine control system Engine controls system Exterior lights, interior lights, navigation, integrated display system From fuse 80 (diagram 2 of 2) From ignition relay g (diagram 2 of 2) Front fog lamp relay Front wiper hi relay Front wiper relay Fuse 10a Fuse 15a Fuse 20a Fuse 30a Fusible fusible link c 80a Fusible fusible link e link b 100a 100a Fusible link a 120a Fusible link box (battery) (left front of engine compt, near battery) Fusible link d 60a Fusible link e 80a Fusible link f 50a Fusible link g 30a Fusible link h 30a Fusible link j 50a Fusible link k 40a Fusible link l 40a Fusible link m 40a Headlights system Nca Not used Pnk Red Seats system Starting/ charging system Tail lamp relay Throttle control motor relay To fuse 19 (diagram 2 of 2) To headlight hi relay (diagram 2 of 2) To ignition relay (diagram 2 of 2) To ignition switch (diagram 2 of 2) Transmissions, transfer case, engine controls, warning, instrument cluster, anti-lock brakes, seats, navigation, audio, communications, defogger system Trunk door, door locks, anti-theft, power windows, defogger, headligts, exterior lights, interior lights, power tops, seats, wiper/washer, navigation, warning systems Wiper/ washer system Wiper/ washer, door locks, anti-theft system Power Distribution Wiring Diagram (2 of 2) for Nissan Murano SE 2003 List of elements for Power Distribution Wiring Diagram (2 of 2) for Nissan Murano SE 2003: 58 (behind left side of dash) fuse block (j/b) (right front of engine compt) intelligent power distribuiton module engine room (ipdm e/r) 10a 11a 12a 16a 8a 8a Acc Accessory relay Air conditioning, instrument cluster system Anti-lock brake, transfer case system B20 (behind left rear seat) Blower relay Cigarette lighter Cpu Door locks system Door locks, anti-theft, defogger, mirrors, power windows, headlights, exterior lights, interior lights, power antenna, warning, power tops, navigation, sound systems E117 E13 (left front corner of engine compartment) E26 (lower right side of engine compartment) E28 (right side of engine compartment) Engine controls system From fuse 72 (diagram 1 of 2) From fusible link c (diagram 1 of 2) From fusible link e (diagram 1 of 2) From fusible link m b (diagram 1 of 2) From ignition switch (diagram 2 of 2) Front power socket Fuel pump relay Fuse 10a Fuse 15a Fuse 20a Fuse fuse 10a 10a Headlight high relay Headlight low relay Headlights system Headlights, anti-theft system Ig1 Ignition relay Ignition switch Instrument cluster, engine controls, transmissions, anti-theft, body computer, seats, exterior lights, transfer case, warning system M14 (behind left end of dash) M78 (behind right end of dash) Off Power socket relay (under left side of dash) Rear power socket Red Seats system Start Starting/ charging system To front wiper hi relay (diagram 1 of 2) To front wiper relay (diagram 1 of 2) To fuse 12 (diagram 1 of 2) To ignition relay (diagram 2 of 2) Transmission system Transmissions, anti-lock brakes, engine controls, exterior lights system Transmissions, anti-theft, body computer, instrument cluster, engine controls, power mirror, air conditioning, exterior lights, navigation, integrated display, communication, transfer case, warning system Wiper/washer system
POWER DOOR LOCKS Power Door Locks Wiring Diagram for Nissan Murano SE 2003 List of elements for Power Door Locks Wiring Diagram for Nissan Murano SE 2003: 56 (left front corner of engine compt) e13 B105 (behind right kick panel) B20 (behind left rear seat) Back door door lock actuator Back door sw Back door switch Bat Bat saver output Between full stroke & n Body control module (behind left side of dash) Can-h Can-l Closed Com Computer data lines system Door lock actuator Door lock output Door sw input Door switch Door unlock output Driv door sw Driver side front door lock assembly Driver's door switch Fuel lid lock actuator Fuel lid lock actuator relay (behind left kick panel) Full stroke Fuse & fusible link box (on left front of engine compt, near battery) Fuse 10a Fuse block (j/b) (behind left side of dash) Fusible link f 50a Gnd Hot at all times Interior lights system K-line Key ring ill output Key sw Key switch and key lock solenoid Left rear door lock assembly Lock Lock switch M14 (behind left end of dash) Open Out Pass door sw Passenger side front door lock assembly Passenger side front power window switch (door switch) Pnk Power window main switch (door switch) Power window system Pwr window serial link Red Right rear door lock assembly Room lamp output Unified meter and a/c amp (below lower center of dash) Unlock Unlock switch
POWER MIRRORS Power Mirrors Wiring Diagram for Nissan Murano SE 2003 List of elements for Power Mirrors Wiring Diagram for Nissan Murano SE 2003: 13 12a Change over switch Door mirror remote control switch Fuse 6 10a Fuse block (j/b) (behind left side of dash) Hot in acc or on Left door mirror Left/right motor M57 (behind right side of dash) Mirror switch Off Right door mirror Up/down motor
POWER SEATS Adjustable Pedal Wiring Diagram for Nissan Murano SE 2003 List of elements for Adjustable Pedal Wiring Diagram for Nissan Murano SE 2003: 26 (behind left end of dash) 48c B20 (behind left rear seat) Batt Body control module (bcm) (behind left side of dash) Det sw Detention switch (in center console) E118 E13 (left front corner of engine compt) Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse block (jb) (behind left side of dash) Fusible link f 50a Fwd Gnd Hot at all times Hot in on and start Key switch and key lock solenoid (on steering column) M14 M35 Output Pedal adjusting control unit (behind left side of dash) Pedal adjusting motor (under left side of dash) Pedal adjusting switch (on driver's seat) Red Rwd Heated Seats Wiring Diagram for Nissan Murano SE 2003 List of elements for Heated Seats Wiring Diagram for Nissan Murano SE 2003: 21 B105 (behind right kick panel) B116 (behind right rear seat) B20 (behind left rear seat) Driver's heated seat switch (in center console) Fuse & fusible link box (left front of engine compartment) Fuse 12 10a Fuse 36 15a Fuse block (j/b) (behind left side of dash) Heated seat relay (behind right kick panel) High Hot at all times Hot in on or start Illumination Indicator Interior lights system Left front power seat Low M78 (behind right end of dash) Seat back heater Seat cushion heater Thermostat Power Seat Wiring Diagram for Nissan Murano SE 2003 List of elements for Power Seat Wiring Diagram for Nissan Murano SE 2003: 27 B105 (behind right kick panel) B20 (behind left rear seat) Back fwd Back- ward Body control module (bcm) (behind left side of dash) Down Driver side power seat switch E118 For- ward Front lifting switch Fuse & fusible link box (left front of engine compt) Fuse f 50a Fwd back Hot at all times Left front lifting motor Left rear lifting motor Left reclining motor Left sliding motor M35 Passenger side power seat switch Rear lifting switch Reclin- ing switch Red Right reclining motor Right sliding motor Sliding switch Up dn
POWER TOP/SUNROOF Power Top/Sunroof Wiring Diagram for Nissan Murano SE 2003 List of elements for Power Top/Sunroof Wiring Diagram for Nissan Murano SE 2003: 37 15a 2p/r Batt output Battery Body control module (behind left side of dash) Dr door sw Driver side front door lock asembly switch E13 (left front corner of engine compt) Full close Full open Fuse & fusible link block (on left front of engine compt, near battery) Fuse 10a Fuse block (j/b) (behind left side of dash) Fusible link f 50a Gnd Ground Hot at all times Hot in on or start Ignition M14 (behind left end of dash) M78 (behind right end of dash) Pas door sw Passenger side front door lock asembly switch Rap output Red Slide switch Speed sensor (2p) Sun roof motor assembly (front center of roof) Sun roof switch Sw- bit0 Sw- bit1 Sw- bit2 Sw- bit3 Sw- bit4 Tilt switch Timer (+ign) Unified meter & a/c amp (below lower center of dash)
POWER WINDOWS Power Windows Wiring Diagram for Nissan Murano SE 2003 List of elements for Power Windows Wiring Diagram for Nissan Murano SE 2003: 57 15a Bat Body control module (bcm) (behind left side of dash) Can-h Can-l Closed Com Computer data lines system Cpu D51 Door switch Down Drivers door lock assembly E118 E13 (left front corner of engine compartment) Encoder Encoder power Encoder pwr Fuse & fusible link box (left front of engine compartment) Fuse 10a Fuse block (j/b) (behind left side of dash) Fusible link f 50a Gnd Ground Hot at all times Hot in on or start Ign Illum Illumination Interior lights system Left front power window regulator Left rear power window regulator Left rear power window switch Lh door switch Limit sw Limit sw gnd Limit switch Lock Lock switch M14 (behind left end of dash) M34 M37 M78 (behind right end of dash) Open Power window main switch Pulse Red Rh door switch Right front door lock assembly (door switch) Right front power window regulator Right front power window switch Right rear power window regulator Right rear power window switch Serial link Unified meter and a/c amp (behind lower center of dash) Unlk Unlock
RADIO Radio Wiring Diagram, Bose (1 of 3) for Nissan Murano SE 2003 List of elements for Radio Wiring Diagram, Bose (1 of 3) for Nissan Murano SE 2003: 53 A/c & av switch Acc Amp on signal Ant signal Antenna amplifier (behind right center of dash) Audio steering wheel switch Audio unit Back-up Bus+ Bus- Combination switch (spiral cable) Down Earth Fr sp lh amp + Fr sp lh amp - Fr sp rh amp + Fr sp rh amp - Fuse & fusible link box (left side of engine compt) Fuse 38 15a Fuse 6 10a Fuse block j/b (behind left side of dash) Gnd Hot at all times Hot in on or acc Ill Ill cont Instrument cluster system Interior lights system M44 M45 M46 M78 (behind right end of dash) Mode switch Navi gnd Navi input+ Navi input- Navigation system Nca Off Power switch Red Rod antenna Rr sp lh (+) amp Rr sp lh (-) amp Rr sp rh (+) amp Rr sp rh (-) amp Seek switch Shield Speed signal Strg sw a (up) Strg sw b (down) Strg sw c (gnd) Volume switch Radio Wiring Diagram, Bose (2 of 3) for Nissan Murano SE 2003 List of elements for Radio Wiring Diagram, Bose (2 of 3) for Nissan Murano SE 2003: 34 (behind right end of dash) m78 Acc Audio tx Bus shield Bus+ Bus- Can-h Can-l Data lines system Dcudsp Display Display control unit Dsp gnd Dsp shield Dspdcu Fuse 12 10a Fuse block j/b (behind left side of dash) Gnd Hot in on or acc Ign Inv gnd Inv vcc M78 (behind right end of dash) Nca Pnk Red Rgb gnd Rgb sy Rgb sync Shield gnd Sig vcc Sign gnd Sign vcc Sync gnd Radio Wiring Diagram, Bose (3 of 3) for Nissan Murano SE 2003 List of elements for Radio Wiring Diagram, Bose (3 of 3) for Nissan Murano SE 2003: 38 (on left front side of passenger compartment floor) b105 B115 Bose speaker amplifier (under rear parcel shelf) Control swb+ Fr lh spk out+ Fr lh spk out- Fr rh spk out+ Fr rh spk out- Ground Input 1+ Input 1- Input 2+ Input 2- Input ch1 fr lh+ Input ch1 fr lh- Input ch2 fr rh+ Input ch2 fr rh- L woofer - Left front door speaker Left rear door speaker (if equipped) Left tweeter R woofer R woofer - Red Right front door speaker Right rear door speaker (if equipped) Right tweeter Rr lh ch3 input+ Rr lh ch3 input- Rr lh spk out+ Rr lh spk out- Rr rh ch4 input+ Rr rh ch4 input- Rr rh spk out+ Rr rh spk out- Rr sp rh in + Woofer (behind left rear seat) Woofer speaker Radio Wiring Diagram, Except Bose for Nissan Murano SE 2003 List of elements for Radio Wiring Diagram, Except Bose for Nissan Murano SE 2003: 65 b+ rx tx 12a A/c & av switch Acc Acc ign Acc ill ill cont gnd Ant sig Antenna amplifier (behind right center of dash) Audio rx Audio steering wheel switch (if equipped) Audio tx Audio unit Bat (back-up) Bus+ Bus- Can-h Can-l Combination switch Computer data lines system Display unit Down Fuse & fusible link block (left front of engine compt) Fuse 12 10a Fuse 38 15a Fuse 6 10a Fuse block (j/b) (behind left side of dash) Ground Hot at all times Hot in on or acc Hot in on or start Illum Interior lights system Left front door speaker Left rear door speaker Left tweeter Lh fr sp (+) Lh fr sp (-) Lh rr sp (-) lh rr sp (+) rh rr sp (-) rh rr sp (+) Light sw M14 (behind left end of dash) M44 M45 M46 M47 Nca Off Red Rh fr sp (+) Rh fr sp (-) Right front door speaker Right rear door speaker Right tweeter Rod antenna Shield Shield Shield bus- Str sw a up Str sw b dwn Str sw c gnd Switch mode Switch power Switch seek Switch volume
SHIFT INTERLOCK Shift Interlock Wiring Diagram for Nissan Murano SE 2003 List of elements for Shift Interlock Wiring Diagram for Nissan Murano SE 2003: 22 (behind left end of dash) m14 Bat (+) Brake sw Cvt device (at bottom) left of transmission) Detent sw (key) Detent sw (shift) Detent switch (key) Detent switch (shift) Fuse 10a Fuse block (j/b) (behind left side of dash) Gnd Hot at all times Hot in on or start Ign sw Key lock sol output (lock) Key lock sol output (unlock) Key switch & key lock solenoid (on right side of steering column) Shift lock control unit (behind left side of dash) Shift lock sol output Stop lamp switch (above bake pedal, on bracket) Unified meter & a/c amplifier (behind lower center of dash) Vsp signal
STARTING/CHARGING Charging Wiring Diagram for Nissan Murano SE 2003 List of elements for Charging Wiring Diagram for Nissan Murano SE 2003: 13 Alternator Battery Charge Combination meter E29 (at right side of eng compt) Fuse & fusible link box (left front of engine compt) Fuse 10a Fuse 33 10a Fuse block (j/b) (behind left side of dash) Fusible link box (left front of eng compt, near battery) Hot at all times Hot in on or start Nca Starting Wiring Diagram for Nissan Murano SE 2003 List of elements for Starting Wiring Diagram for Nissan Murano SE 2003: 37 Acc Battery Can- h rly Can- l rly Computer data lines system Cpu Cvt unit (at bottom left of transmission) E13 (at left front corner of eng compt) E28 (at right side of eng compt) Fuse & fusible link box (on left front of of engine compt, near battery) Fuse 10a Fuse 15a Fuse m 40a Hot at all times Hot in on or start Ignition switch Inh sw1 Inh sw2 Inh sw3 Inh sw3 mon Inh sw3m Inh sw4 Intelligent power distribution module engine room (right front of eng compt) Nca Off Off off off on on Off off on on on Off on off on off Off on on on off P r n d l Park/ neutral position switch Shift position Start Starter motor Starter relay Starter rly Transmission control module (tcm) (behind right side of dash)
SUPPLEMENTAL RESTRAINTS Supplemental Restraints Wiring Diagram (1 of 2) for Nissan Murano SE 2003 List of elements for Supplemental Restraints Wiring Diagram (1 of 2) for Nissan Murano SE 2003: 58 (at base of left "b" pillar) b15 (at base of right "b" pillar) b113 (behind left end of dash) m14 (behind right end of dash) m78 (partial) (below left side of dash) Air bag Air bag diagnosis sensor unit (under rear of center console) Air bag w/l As1 + As1 - As2 + As2 - Aux1 lh + Aux1 lh - Aux1 rh + Aux1 rh - B109 B11 C lh + C lh - C rh + C rh - Combination meter Data link connector Dr1 + Dr1 - (dr2 -) Dr2 + Eczs + Eczs - Fuse 10a Fuse block (j/b) (behind left side of dash) Gnd Ground Hot in on or start Ignition K-line Left front seat belt pre- tensioner Left front side air bag module Left side air bag (satellite) sensor Left side curtain air bag module M25 M64 Nca Red Right front seat belt pre- tensioner Right front side air bag module Right side air bag (satellite) sensor Right side curtain air bag module S lh + S lh - S rh + S rh - Sat lh + Sat lh - Sat rh + Sat rh - Seat belt Seat belt switch Supplemental Restraints Wiring Diagram (2 of 2) for Nissan Murano SE 2003 List of elements for Supplemental Restraints Wiring Diagram (2 of 2) for Nissan Murano SE 2003: 15 (at lower right side of engine compartment) e26 (behind left rear seat) b20 (behind right rear seat) b116 Combination switch (spiral cable) Crash zone sensor (behind front center of grille, near hood latch) Driver air bag module Driver side front power seat Fastened Front passenger air bag module M201 M202 Nca Passenger side front power seat Seat belt buckle switch Un- fastened
TRANSMISSION A/T Wiring Diagram for Nissan Murano SE 2003 List of elements for A/T Wiring Diagram for Nissan Murano SE 2003: 71 (behind right end of dash) m78 2nd pos Atf temp sens Batt Brake sw Can-h Can-l Chip select Clock Combination meter Computer data lines system Cvt device (second position switch) (below center console) Cvt fluid temp sensor Cvt ind Cvt unit (bottom left of transmission) Data i/o Data link connector (below left side of dash) Engine control module (behind glove box) Exterior lights system Fuse 10a Fuse block (j/b) (behind left side of dash) Gnd Hot at all times Hot in on or start Ign Inh sw1 Inh sw2 Inh sw3 Inh sw3 mon Inh sw4 Intelligent power distribution module (ipdm e/r) (right front of engine compt, behind headlamp) Line press sol valve Lock- up select sol valve Lp sol Lu select sol M14 (behind left end of dash) M78 (behind right end of dash) Park/neutral position switch Pri pres sens Pri spd sens Primary pressure sensor Primary speed sensor Red Rev lamp rly Rom-assy S/m-a S/m-b S/m-c S/m-d Sec pres sens Sec pres sol Sec spd sens Secon- dary press sol valve Secondary pressure sensor Secondary speed sensor (right rear of engine compt) Sel1 Sel2 Sel3 Sens Sens +5v Sens gnd Starter rly Starting system Step motor Stoplamp switch (above brake pedal, on bracket) Tcc sol Tcc sol valve Transmission control module (tcm) (behind right side of dash) Unified meter & a/c amp Unified meter control unit Vign AWD Wiring Diagram for Nissan Murano SE 2003 List of elements for AWD Wiring Diagram for Nissan Murano SE 2003: 31 (behind left end of dash) m14 Awd Awd control unit (behind left side of dash) Awd lock Awd lock switch (center console) Awd solenoid valve (under center rear of vehicle, near differential) Awdsol+ Awdsol- B7 (behind left kick panel) Batt Can-h Can-l Combination meter Computer data lines system Data link connector (below Fuse & fusible link block (left front of engine compt) Fuse 10a Fuse bloick (j/b) (behind left side of dash) Gnd Hot at all times Hot in on or start Ign Intelligent power distribution module (ipdm e/r) (right front of engine compt) Interior lights system K-line Left side of dash) M78 (behind M78 (behind right end of dash) Right end of dash) Unified meter & a/c amp Unified meter control unit
TRUNK, TAILGATE, FUEL DOOR Trunk, Tailgate, Fuel Door Wiring Diagram for Nissan Murano SE 2003 List of elements for Trunk, Tailgate, Fuel Door Wiring Diagram for Nissan Murano SE 2003: 17 (at left front corner of engine compt) e13 B20 (behind left rear seat) Back door lock actuator (at lower center of back door) Back door sw Back door switch Bat Body control module (bcm) (behind left side of dash) Fuel lid lock actuator (behind left rear quarterpanel) Fuel lid lock actuator relay (behind left kick panel) Fuse & fusible link block (on left front of engine compartment, near battery) Fuse 10a Fuse block (j/b) (behind left side of dash) Fuse f 50a Gnd Hot at all times Lock output Unlock output
WARNING SYSTEMS Buzzer Wiring Diagram for Nissan Murano SE 2003 List of elements for Buzzer Wiring Diagram for Nissan Murano SE 2003: 58 15a B7 (behind left kick panel) Bat Batt Belt ind Body control module (bcm) (behind left kick panel) Buzzer Can-h Can-l Comb sw in 1 Comb sw in 2 Comb sw in 3 Comb sw in 4 Comb sw in 5 Comb sw out 1 Comb sw out 2 Comb sw out 3 Comb sw out 4 Comb sw out 5 Combination meter Combination switch Computer data lines system Door sw (dr) Driver door sw in Driver side front door switch E13 (at left front corner of eng compt) Front power seat (driver side) Fuse & fusible link block (on left front of eng compt, near battery) Fuse 10a Fuse block (j/b) (behind left side of dash) Fuse f 50a Gnd Gnd (power) Hot at all times Hot in acc or on Hot in on or start Ign Input 1 Input 2 Input 3 Input 4 Input 5 K-line Key sw Key switch & key lock solenoid M14 (behind left end of dash) M78 (behind right end of dash) Output 1 Output 2 Output 3 Output 4 Output 5 Red Rx (comb meter) Seat belt buckle switch Tx (comb meter) Unified meter & a/c amplifier (behind lower center of dash) Unified meter control unit Tire Pressure Monitoring Wiring Diagram for Nissan Murano SE 2003 List of elements for Tire Pressure Monitoring Wiring Diagram for Nissan Murano SE 2003: 58 (left side of dash) tire pressure warning check connector 12a A/c & av switch Acc Ant input Antenna Bat Batt Body control module (behind left side of dash) Bus + Bus - Bus shield Can-h Can-l Combination meter Computer data lines system Data link connector (below left side of dash) Dcu-dsp Diag-id input Display Display control unit (w/navigation) (behind center of dash) Display unit Dsp gnd Dsp-dcu E118 E13 (at left front corner of eng compt) Exterior lights system Flsher out left Flsher out right Fuse & fusible link block (on left side of eng compt, near battery) Fuse 10a Fuse block (j/b) (behind left side of dash) Fuse f 50a Gnd Gnd (power) Hazard Hot at all times Hot in acc or on Hot in on or start Ign Low tire pressure warning control unit (behind right side of dash) M14 (behind left end of dash) M205 M25 M35 M37 M43 M78 (behind right end of dash) M81 Nca Rx (comb meter) Shield Tire pressure Tire pressure sensor Tx (comb meter) Unified meter & a/c amplifier (behind lower center of dash) W/ navigation W/o navigation
WIPER/WASHER Front Wiper/Washer Wiring Diagram for Nissan Murano SE 2003 List of elements for Front Wiper/Washer Wiring Diagram for Nissan Murano SE 2003: 43 15a red Bat Body control module (bcm) (behind left kick panel) Combination switch (lighting switch) Cpu E118 E13 (at left front corner of engine compartment) E28 (at right side side of engine compartment) Fr+ Fr- Front washer motor (on washer fluid reservoir) Front wiper hi relay Front wiper motor (on left side of firewall) Front wiper relay Fuse & fusible link box (at right rear of engine compartment) Fuse 10a Fuse 15a Fuse 20a Fuse block (j/b) (behind left kick panel) Fuse f 50a Gnd High Hot at all times Hot in on or start Ign Input 1 Input 2 Input 3 Input 4 Input 5 Intelligent power distribution module (engine room) (at right rear corner of engine compt) Low M14 (behind left end of dash) M29 M35 Move Output 1 Output 2 Output 3 Output 4 Output 5 Red Stop Rear Wiper/Washer Wiring Diagram for Nissan Murano SE 2003 List of elements for Rear Wiper/Washer Wiring Diagram for Nissan Murano SE 2003: 40 15a red Auto stop B20 (behind left rear seat) Bat Body control module (bcm) (behind left kick panel) Combination switch (lighting switch) E118 E13 (at left front corner of engine compartment) Fuse & fusible link box (at right rear of engine compartment) Fuse 10a Fuse block (j/b) (behind left kick panel) Fuse f 50a Gnd Hot at all times Hot in on or start Ign Input 1 Input 2 Input 3 Input 4 Input 5 Intelligent power distribution module (engine room) (at right front of engine compartment) M14 (behind left end of dash) M29 M34 M35 M36 Move Output Output 1 Output 2 Output 3 Output 4 Output 5 Rear washer motor (on washer fluid reservoir) Rear wiper motor (below right side of rear window) Red Rr+ Rr- Stop
