Diagram sections — 29 (47 total)
AIR CONDITIONING ANTI-LOCK BRAKES ANTI-THEFT BODY COMPUTER COMPUTER DATA LINES CRUISE CONTROL DEFOGGERS ELECTRONIC SUSPENSION ENGINE PERFORMANCE EXTERIOR LIGHTS GROUND DISTRIBUTION HEADLIGHTS HORN INSTRUMENT CLUSTER INTERIOR LIGHTS POWER ANTENNA POWER DISTRIBUTION POWER DOOR LOCKS POWER MIRRORS POWER SEATS POWER TOP/SUNROOF POWER WINDOWS RADIO SHIFT INTERLOCKS STARTING/CHARGING SUPPLEMENTAL RESTRAINTS TRANSMISSION WARNING SYSTEMS WIPER/WASHER
AIR CONDITIONING Air Conditioning Wiring Diagrams, Auto A/C for Nissan Pathfinder LE 1996 List of elements for Air Conditioning Wiring Diagrams, Auto A/C for Nissan Pathfinder LE 1996: 62 (left front of engine compt) (left kick panel) +5v 10u 17u 21u A/c auto amp (center of i/p) A/c compressor A/c mode switch A/c relay (rear of left front fender) A/c sig A/c switch A/mix Acc Air mix door motor (center of i/p) Amb sens Ambient air temperature switch (behind center of grille) Ambient sensor (behind center of grille) Auto Blower Diode Dual pressure switch (behind right side of grille) Eccs control module (left rear of engine compt) Fan base Fan control amp (right side of i/p) Fan f/b Fan posi 1 Fan posi 2 Fan posi 3 Fan posi aut Fan switch Fre Fuse 15a Fuse 7.5a Fuse box G100 G200 G200 (left kick panel) G203 (left kick panel) Gnd Hot in on or start Iacv-ficd solenoid valve (left side of engine) Ign In-vehicle sensor (left side of i/p) Inc sens Intake door motor (right side of i/p) Mode switch Motor Nca Off Others Pbr Ptc Ptc (center of i/p) Rec Recirculation switch Sens gnd Sun sens Sunload sensor (center of i/p) Thermal transmitter (front of engine) Vent off Water sens Air Conditioning Wiring Diagrams, Manual A/C for Nissan Pathfinder LE 1996 List of elements for Air Conditioning Wiring Diagrams, Manual A/C for Nissan Pathfinder LE 1996: 29 (left front of engine compt) 10u 17u 1995 vftc c A/c compressor A/c relay (rear of left front fender) A/c switch Ambient air temperature switch (behind center of grille) Blower Diode Dual pressure switch (behind right side of grille) Eccs control module (left rear of engine compt) Fan resistor (right side of i/p) Fan switch Fre Fuse 15a Fuse 7.5a Fuse box G100 G200 (left kick panel) Hot in on or start Iacv-ficd solenoid valve (left side of engine) Intake door motor (right side of i/p) Mode switch Motor Nca Off Rec Recirculation switch
ANTI-LOCK BRAKES Anti-lock Brake Wiring Diagrams for Nissan Pathfinder LE 1996 List of elements for Anti-lock Brake Wiring Diagrams for Nissan Pathfinder LE 1996: 56 (left kick panel) 2wd 4wd Abs control actuator (right rear of engine compt) Abs control unit (below passenger's footrest) Abs relay box (right rear of engine compt) Abs warning lamp Bls Data link connector (left side Diag l Fl in Fl out Fl ss gnd Flss Fr in Fr out Fr ss Fr ss gnd Fuse 20 10a Fuse 28 7.5a Fuse 7 10a Fuse block Fusible link and fuse box Fusible link c 30a Fusible link d 30a G sensor (4wd) (below center console) G200 G200 (left kick panel) Gnd Gnd1 Gnd2 Hot at all times Hot in on or start Instrument cluster Left front wheel speed sensor Left rear wheel speed sensor Motor relay Nca Of i/p) Rear in Rear out Red Right front wheel speed sensor Right rear wheel speed sensor Rl in Rl out Rl ss Rl ss gnd Rr in Rr ss Rr ss gnd Rxd Sila Solenoid valve relay Stop lamp switch Txd
ANTI-THEFT Anti-theft Wiring Diagram (1 of 2) for Nissan Pathfinder LE 1996 List of elements for Anti-theft Wiring Diagram (1 of 2) for Nissan Pathfinder LE 1996: 49 (behind (below (left (left rear (right Acc Anti-theft indic. Back door switch Batt Circuit breaker 1 (left kick panel) Closed Door key lock sw Door key unlock sw Door sw Door unlock sensor Fuse 10a Fuse 7.5a Fuse and fusible link box (right front of engine compt.) Fuse block (left side of i/p) Fuse f 40a G106 left headlamp) G107 right headlamp) G200 kick panel) G203 kick panel) G300 left front seat) G404 side of trunk) G416 frame rail) Glass hatch sw glass hatch key unlock sw hood sw Glass hatch switch Ground Hood switch Horn headlamps Hot at all times Hot in acc or on Hot in on or start Ign Instrument cluster Left front door switch Left rear door switch Locked Open Right front door switch Right rear door switch Security lamp Smart entrance control module (left side of i/p) Starter cutout U28 U52 Unlocked Anti-theft Wiring Diagram (2 of 2) for Nissan Pathfinder LE 1996 List of elements for Anti-theft Wiring Diagram (2 of 2) for Nissan Pathfinder LE 1996: 49 (above right (behind (below (below left (below right (left (left rear (right Back door Back door key cylinder switch Exterior lights system Full stroke lock Full stroke unlock Fuse 10a Fuse 15a Fuse 7.5a Fuse and fusible link box (right front of engine compt.) Fuse block (left side of i/p) G106 left headlamp) G107 right headlamp) G200 kick panel) G202 side of dash) G203 side of dash) G300 left front seat) G301 front seat) G403 rear wheel well) G404 side of trunk) G416 frame rail) Glass hatch Horn system Hot at all times Left front door key cylinder switch Left front door lock actuator Left rear door lock actuator Lock Locked Mid stroke Red Right front door key cylinder switch Right front door lock actuator Right rear door lock actuator Starting/ charging system Theft horn warning relay (in relay box) Theft warning horn Theft warning lamp relay (in relay box) Theft warning relay (in relay box) Unlock Unlocked W16
BODY COMPUTER Time Control Unit Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Time Control Unit Wiring Diagram for Nissan Pathfinder LE 1996: 46 52u Acc Ant Antenna Anti-theft system Circuit breaker 1 (left side of dash) Door locks system Door sw Dr lock out Dr ul out Exterior lights system Fuse 10 10a Fuse 14 15a Fuse 24 7.5a Fuse and fusible link box (left front shock tower) Fuse block (left side Fuse f 40a G200 (left kick panel) G203 (right kick panel) G301 (below right front seat) G416 (left rear frame rail) Gnd Hazard out Horn, hlmps Hot at all times Hot in acc or on Interior lights system Key in ign sw Key switch Left front door lock actuator Left rear door lock actuator Left ul sens Multi-remote control relay 1 (front of right fender) Multi-remote control relay 2 (behind left headlight) Nca Of dash) Pnk Rear ul sens Right front door lock actuator Right rear door lock actuator Right ul sens Room lmp out Smj (left side of dash) Time control unit (left side of dash) U40 V bat
COMPUTER DATA LINES Computer Data Lines for Nissan Pathfinder LE 1996 List of elements for Computer Data Lines for Nissan Pathfinder LE 1996: 26 A/t control unit (left end of dash) Abs control unit (under radio/hvac control assembly) Abs diagl Abs rx Abs tx Air bag diagnosis sensor unit (under center console) At clk Atrx Attx Csc Csr Cst Data link connector (for consult) (behind left side of dash) Data link connector (for gst) (behind left side of dash) Ecm (eccs control module) (under steering column) Fuse 21 10a Fuse 24 7.5a Fuse block (left kick panel) G121 (center of fire wall) G200 (left kick panel) Gst Hot at all times Hot in on or start Sssrx Ssstx U13
CRUISE CONTROL Cruise Control Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Cruise Control Wiring Diagram for Nissan Pathfinder LE 1996: 61 (behind right headlamp) 11w 18u 44u 59u A/t control unit (left side of dash) Act power Air valve All a/t Ascd actuator (right rear side of engine compartment) Ascd cancel switch (top of brake pedal support) Ascd clutch switch (top of clutch pedal support) Ascd control unit (left side kick panel) Ascd hold relay (relay box, left front fender) Ascd main switch Ascd steering switch Brake n/c sw Brake n/o sw Cancel Cruise ind Cruise signal Electronic speed- ometer Fuse & fusible link box (right front fender) Fuse 12 7.5a Fuse 20 10a Fuse 54 10a Fuse 8 7.5a G107 G107 (behind right headlamp) G200 (left kick panel) Gnd Horn relay (relay box, left front fender) Horn switch Horns system Hot at all times Hot in on or start Hot in on or start fuse block Inhibitor switch (top of transmission) Instrument cluster Interior lights system Main sw Nca Od cancel sig Od cut signal Off Park neutral position relay (relay box, left front fender) Pathfinder w/ m/t R p Rel valve Release valve Res/acc sw Resume/ accelerate Set/coast Set/coast sw Spiral cable Stop lamp switch (top of brake pedal support) Transmissions system Vac motor Vacuum motor Vehicle speed sensor (right side of transmission) Vss
DEFOGGERS Defogger Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Defogger Wiring Diagram for Nissan Pathfinder LE 1996: 22 28u Door mirror defogger relay (behind left luggage roof trim) Fuse & fusible link box (on right front fender wall) Fuse 12 7.5a Fuse 56 20a Fuse 57 20a Fuse 58 10a Fuse block (j/b) (behind left side of dash) G200 (left kick panel) Hot at all times Hot in on or start Illum Left door mirror defogger Nca On ind Rear window defogger Rear window defogger relay (behind left luggage roof trim) Rear window defogger switch Red Right door mirror defogger Smart entrance control unit (behind left side of dash) To interior lights system
ELECTRONIC SUSPENSION Electronic Suspension Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Electronic Suspension Wiring Diagram for Nissan Pathfinder LE 1996: 19 27u Circuit breaker-1 (on top of fuse block (j/b)) Fuse 12 7.5a Fuse block (j/b) (left side of dash) G106 (behind left headlamp) G107 (behind right headlamp) G200 (left kick panel) G300 (below left front seat) G301 (below right front seat) Hot at all times Hot in on or start Left front shock absorber actuator (at left front shock tower) Left rear shock absorber actuator (at left rear shock tower) Power window relay (on fuse block (j/b)) Right front shock absorber actuator (at right front shock tower) Right rear shock absorber actuator (at right rear shock tower) Shock absorber select switch Sport Touring
ENGINE PERFORMANCE
3.3L 3.3L, Engine Performance Wiring Diagrams (1 of 2) for Nissan Pathfinder LE 1996 List of elements for 3.3L, Engine Performance Wiring Diagrams (1 of 2) for Nissan Pathfinder LE 1996: 36 (under left side of i/p) (under left side of i/p) data link connector A/c system A/t control unit (left side of i/p) All times Closed Crank- shaft position sensor (below distributor) Data link connector Eccs relay (right side of engine compt, in relay box) Egr temper- ature sensor (left rear of eng, below egr valve) Engine control module (ecm) (behind left center of i/p) Engine coolant temperature sensor (front of eng) For consult For gst Fuse 7.5a Fuse 10a Fuse 7.5a Fuse block (j/b) Fusible link & fuse box G115 (rear of engine) G120 (right side of engine) G200 (left kick panel) Hot at Hot in start Instrument cluster system Intake air temperature sensor (left front of engine compt) J/c (left side of i/p) Knock sensor (rear of engine) Mass air flow sensor (left side of engine compt) Nca Open wide Pnk Power steering oil pressure switch (right rear of engine) Resistor (below distributor) Throttle position sensor (side of throttle body) Throttle position switch (a/t only) (side of throttle body) 3.3L, Engine Performance Wiring Diagrams (2 of 2) for Nissan Pathfinder LE 1996 List of elements for 3.3L, Engine Performance Wiring Diagrams (2 of 2) for Nissan Pathfinder LE 1996: 38 (on transmission) neutral position switch (right side of eng compt, in relay box) inhibitor relay 1o1 A/t Acc Cam- shaft position sensor Condenser (near distributor) Distributor Egr valve & evap canister purge control solenoid valve (left front of eng) Electronic speedo- meter Engine control module (ecm) (behind left center of i/p) Fuel injectors Fuel pump (in fuel tank) Fuel pump relay (left side of i/p) Fuse 10a Fuse 15a Fuse block (j/b) G101 (right front of i/p) G115 (rear of engine) G203 (right kick panel) G404 (left rear corner of vehicle) Hot at all times Hot in on or start Iacv-acc valve (right rear of eng) Ignition coil Ignition switch Instrument cluster Left front heated oxygen sensor (left side of exhaust manifold) Left rear heated oxygen sensor (left side of exhaust pipe) M/t Malfunction indicator lamp Nca Off Power transistor Right front heated oxygen sensor (right side of exhaust manifold) Right rear heated oxygen sensor (right side of exhaust pipe) Start Vehicle speed sensor (right side of trans- mission)
EXTERIOR LIGHTS Back-up Lamps Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Back-up Lamps Wiring Diagram for Nissan Pathfinder LE 1996: 14 (above left rear wheelwell) A/t Back-up lamp sw (on trans) Fuse 7 7.5a Fuse 8 7.5a Fuse block G40 Hot in run or start Inhibitor switch (on trans) Left rear com- bination light M/t Right rear com- bination light U20 U44 Exterior Lamps Wiring Diagram (1 of 2) for Nissan Pathfinder LE 1996 List of elements for Exterior Lamps Wiring Diagram (1 of 2) for Nissan Pathfinder LE 1996: 32 Anti-lock brakes system Combination switch Cruise control system Fuse 20 10a Fuse 61 10a Fuse and fusible link box Fuse block G106 (behind left headlamp) G107 (behind right headlamp) G403 (above right rear wheelwell) G404 (left rear front fender) G404 (left rear side of trunk) G416 (left rear frame rail) Head High mounted stop light Hot at all times J14 Left front clearance light Left license plate light Left rear com- bination light License plate light Off Park Pnk Right front clearance light Right license plate light Right rear com- bination light Smj (left side of dash) Stop lamp switch (top of brake peadl support) U36 W/ spare tire carrier W/o spare tire carrier Exterior Lamps Wiring Diagram (2 of 2) for Nissan Pathfinder LE 1996 List of elements for Exterior Lamps Wiring Diagram (2 of 2) for Nissan Pathfinder LE 1996: 24 Body computer system (w/ multi remote) C10 Combination flasher unit (left side of i/p) Combination meter Combination switch Fuse 11 10a Fuse 14 15a Fuse block G106 (behind left headlamp) G107 (behind right headlamp) G200 (left kick panel) Hazard Hazard switch Hot at all times Hot in run or start Ill. Interior lights system Left front turn light Left turn ind. Right front turn light Right turn ind. Smj (left side of dash) U16 U40
GROUND DISTRIBUTION Ground Distribution Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Ground Distribution Wiring Diagram for Nissan Pathfinder LE 1996: 28 (above right (behind (below (below left (left (left rear (rear (right (right front A/c mode switch, ascd control switch, ascd main switch, clutch interlock switch, combination flasher unit, door mirror remote control switch, fan switch, power antenna, rear wiper switch, rear window defogger switch, recirculation switch, smart entrance control unit, sunroof relay, right door lock and unlock switch, left door mirror defogger (w/o power windows), right door mirror defogger, right front door key cylinder switch, air bag diagnosis sensor unit A/t control unit, condenser, crankshaft position sensor, camshaft position sensor, distributor, eccs control module, left rear heated oxygen sensor, right rear heated oxygen sensor, camshaft position sensor shield, crankshaft position sensor shield, left front heated oxygen sensor shield, right front heated oxygen sensor shield, knock sensor shield, mass air flow sensor shield, left rear heated oxygen sensor shield, right rear heated oxygen sensor shield, throttle position sensor shield Abs control actuator, abs control unit, a/c auto amp., air bag indicator lamp, cruise control indicator lamp, fuel gauge, 4wd indicator lamp, high beam indicator lamp, speedometer, tachometer, turn signal indicator lamp, water temperature gauge, cigarette lighter socket, data link connector for consult, data link connector for gst, fan control amp., fan switch, front wiper amp., front wiper motor, blower motor relay, left heated seat switch, right heated seat switch, illumination control switch, power window relay, left front wheel sensor shield, right front wheel sensor shield, left rear wheel sensor shield, right rear wheel sensor shield, compass and thermometer, integrated homelink transmitter, spot lamp, left vanity mirror, right vanity mirror, left door mirror defogger (w/ power windows), left front door key cylinder switch, left front door lock actuator, right front door lock actuator, power window main switch Ambient switch, ascd hold relay, brake fluid level switch, left clearance lamp, right clearance lamp, daytime light control unit, left front fog lamp, right front fog lamp, front fog lamp switch, left front turn signal lamp, right front turn signal lamp, left front shock absorber, front washer motor, front wiper switch, left headlamp, right headlamp, hood switch, inhibitor relay, park/neutral position switch, power socket relay, theft warning relay, washer level switch Fuel pump, fuel tank gauge unit, left front door switch, left heated seat, right heated seat, left power seat, power socket, left rear combination lamp, right rear combination lamp, left rear shock absorber, rear wiper amp., seat belt buckle switch, speaker amp., back door key cylinder switch, back door switch, glass hatch switch, high mounted stop lamp, left license plate lamp (w/o spare tire carrier), right license plate lamp (w/o spare tire carrier), luggage room lamp, left rear door lock actuator, rear wiper motor G106 left headlamp) G106 right headlamp) G115 of engine) G119 side of engine) G200 kick panel) G202 side of dash) G203 kick panel) G300 left front seat) G301 right front seat) G403 rear wheel well) G404 side of trunk) G416 rear frame rail) Park position switch, overdrive control switch, ashtray illumination, right heated seat, neutral position switch, right rear combination lamp, right rear shock absorber, right power seat, tire carrier switch, right rear door lock actuator Power steering oil pressure switch, alternator
HEADLIGHTS Headlight Wiring Diagram, with DRL for Nissan Pathfinder LE 1996 List of elements for Headlight Wiring Diagram, with DRL for Nissan Pathfinder LE 1996: 33 (left (near right front shock tower) 1st 2nd Alternator Combination meter Daytime running lights control module (front of left fender) Flash Fuse 12 7.5a Fuse 26 7.5a Fuse 59 15a Fuse 60 15a Fuse and fusible Fuse block G106 (behind left headlamp) G107 (behind right headlamp) G200 (left kick panel) Hi beam ind. Hot at all times Hot in on or start Hot in start Instrument cluster system J3l Left headlamp Lighting switch Link box Off Parking brake switch Red Right headlamp Side of dash) Smj (left side of dash) W12 Headlight Wiring Diagram, without DRL for Nissan Pathfinder LE 1996 List of elements for Headlight Wiring Diagram, without DRL for Nissan Pathfinder LE 1996: 20 (near right front shock tower) 1st 2nd Flash Fuse 59 15a Fuse 60 15a Fuse and fusible G106 (behind left headlamp) G107 (behind right headlamp) G200 (left kick panel) Hi beam ind. Hot at all times Instrument cluster Left headlamp Lighting switch Link box Off Red Right headlamp Smj (left side of dash)
HORN Horn Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Horn Wiring Diagram for Nissan Pathfinder LE 1996: 12 Ascd steering switch Fuse & fusible link box (on right front fender well) Fuse 54 10a Horn relay (left front fender well, in relay box 1) Horn switch Hot at all times Left horn Nca Right horn Spiral cable W/ cruise control W/o cruise control
INSTRUMENT CLUSTER Instrument Cluster Wiring Diagram (1 of 2) for Nissan Pathfinder LE 1996 List of elements for Instrument Cluster Wiring Diagram (1 of 2) for Nissan Pathfinder LE 1996: 62 (1996) (1997) 4wd 4wd a/t model 4wd ind 4wd model 4wd switch (side of transfer case) A/t model A/t oil temp ind Abs ind Airbag ind Anti-lock brakes system Atp ind Atp relay (in relay box 1) Brake ind Canada models w/ spare tire carrier Charge ind Charging system Compass & thermo meter (near power roof) Cruise ind Door ind Exterior lights system Fuel gauge Fuel ind Fuel tank gauge unit (on top of fuel tank) Fuse 27 10a Fuse 7 10a Fuse 8 7.5a 10a Fuse block (behind dash, left of steering column) G106 (behind left headlamp) G107 (behind right headlamp) G200 (left kick panel) G202 (left side of dash) G300 (below left front seat) G416 (left rear frame rail) Headlights system High beam ind Hot in acc or on Hot in on or start Illumination (x4 bulbs) Instrument cluster Interior lights system Left turn ind Malfunction ind Models w/ ascd system Neutral Neutral position switch (side of transfer case) O/d off ind Off Oil ind Others Right turn ind Seat belt buckle switch (in driver's seat belt buckle) Seat belt ind Speed- ometer Tach- ometer Temp. gauge Tire carrier ind U11 U19 U44 Washer fluid level switch (lower right front of engine compartment) Washer ind Instrument Cluster Wiring Diagram (2 of 2) for Nissan Pathfinder LE 1996 List of elements for Instrument Cluster Wiring Diagram (2 of 2) for Nissan Pathfinder LE 1996: 23 4wd a/t model 4wd model A/t control unit (behind dash, left of steering column) A/t fluid temperature switch (on side of transfer case) A/t model Ambient sensor (in front of radiator) Ascd control unit (behind left kick panel) Brake fluid level switch (on brake fluid reservoir) Canada models w/ spare tire carrier Diode (behind left side of glove box) Ecm (eccs control module) (behind center of dash) G301 (below right front seat) G403 (above right rear wheel well) High Inhibitor switch (right side of transmission) Models w/ ascd system Oil pressure switch (on lower left front of engine) Open Parking brake switch (at base of park brake lever) Thermal transmitter (top front of engine) Tire carrier switch Vehicle speed sensor (on transmission) Vss
INTERIOR LIGHTS Courtesy Lamps Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Courtesy Lamps Wiring Diagram for Nissan Pathfinder LE 1996: 26 (left Back door switch Closed Diode (right side of i/p) (w/ anti- theft) Door Fuse 15 7.5a Fuse block (left kick panel) G200 kick panel) G202 side of dash) G300 (below left front seat) G404 (left rear side of trunk) G416 (left rear frame rail) Hot at all times Interior lamp Left front door switch Left rear door switch Left vanity lamp Luggage room lamp Off Open Right front door switch Right rear door switch Right vanity lamp Spot lamp U50 Warning system Instrument Illumination Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Instrument Illumination Wiring Diagram for Nissan Pathfinder LE 1996: 35 (above right (below (left A/c switch A/t ind. illum. A/t only Ascd main switch Ashtray illum. Cigarette lighter illum. Compass and thermometer Cruise only Fuse 61 10a Fuse and fusible link box (left front shock tower) Fuse block (left kick panel) G200 kick panel) G202 side of dash) G301 right front seat) G403 rear wheel well) Hazard switch Head Hot at all times Illumination control rheostat Instrument cluster Lighting switch Off Park Pnk Power window main switch Radio Rear window defogger switch Rear wiper switch U36 U39 U48 U49
POWER ANTENNA Power Antenna Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Power Antenna Wiring Diagram for Nissan Pathfinder LE 1996: 8 Fuse 24 7.5a Fuse block G200 (left kick panel) G203 (right kick panel) Hot at all times Power antenna Radio Red
POWER DISTRIBUTION Power Distribution Wiring Diagram (1 of 3) for Nissan Pathfinder LE 1996 List of elements for Power Distribution Wiring Diagram (1 of 3) for Nissan Pathfinder LE 1996: 56 (diagram 1 of 3) 2nd Acc Anti- lock brakes Anti-theft Battery Charging Circuit breaker-1 Circuit breaker-2 Combination switch (lighting switch) Defogger Engine controls, computer data lines Exterior lights From fuse 56 b From fuse a a Fuse 51 15a Fuse 52 7.5a Fuse 54 10a Fuse 55 15a Fuse 56 20a Fuse 57 20a Fuse 58 10a Fuse 59 15a Fuse 60 15a Fuse 61 10a Fuse 62 7.5a Fuse 63 10a Fuse 65 7.5a Fuse a 100a Fuse and fusible link box Fuse c 40a Fuse d 40a Fuse e 40a Fuse f 40a Fuse g 40a Fuse j 80a Headlights, anti-theft Horns Horns, cruise control, anti- theft Ignition switch Nca Off Pnk Power windows, door locks, body computer, electronic suspension, anti-theft Red Seats Start Starting To accessory relay (diagram 2 of 3) To fuse 14 (diagram 2 of 3) To fuse 26 diagram 3 0f 3) To fuse 54 (diagram 1 of 3) To fuse 6 (diagram 3 0f 3) To fuse block (diagram 3 of 3) To fuse c (diagram 1 of 3) To ignition relay (diagram 2 of 3) Power Distribution Wiring Diagram (2 of 3) for Nissan Pathfinder LE 1996 List of elements for Power Distribution Wiring Diagram (2 of 3) for Nissan Pathfinder LE 1996: 79 11u 11w 12w 16u 16w 17u 18u 19u 20u 27u 28u 29u 40u 42u 44u 50u 52u 54u 56u 59u Accessory relay Air condi- tioning, defogger, anti- theft Anti- lock brakes Cigarette lighter socket Cruise control Defogger, warning systems, anti- theft Engine controls Engine controls, cruise control, starting, exterior lights, warning systems Exterior lights Exterior lights, body computer Exterior lights, cruise control, anti-lock brakes From accessory k relay (diagram 2 of 3) From accessory l relay (diagram 2 of 3) From fuse g (diagram 1 of 3) From fuse j (diagram 1 of 3) From ignition i From ignition switch (diagram 1 of 3) Fuse 10 10a Fuse 11 7.5a Fuse 12 7.5a Fuse 13 15a Fuse 14 15a Fuse 15 7.5a Fuse 18 10a Fuse 19 20a Fuse 20 10a Fuse 24 7.5a Fuse 27 10a Fuse 28 7.5a Fuse 29 15a Fuse 7 10a Fuse 8 7.5a Fuse 9 10a Fuse block (j/b) G200 (left kick panel) G202 (below left side of dash) Headlights Ignition relay Interior lights Interior lights, body computer Mirrors, horns Power antenna, anti- theft, computer data lines Power windows, electronic suspension, power tops Red Seats Shift interlock, cruise control Sound systems Sound systems, anti-theft, power antenna, body computer Sound systems, power antenna, anti- theft Starting, anti- theft Starting, warning systems, body computer, engine controls Switch (diagram 1 of 3) To blower relay (diagram 3 of 3) To fuse 25 (diagram 3 of 3) To ignition relay (diagram 2 of 3) W/ ascd W/o ascd Warning systems Wiper/washer Power Distribution Wiring Diagram (3 of 3) for Nissan Pathfinder LE 1996 List of elements for Power Distribution Wiring Diagram (3 of 3) for Nissan Pathfinder LE 1996: 42 (diagram 1 of 3) (diagram 2 of 3) 10u 13u 14u 21u 26u 31u 32u 33u 36u 37u 39u 48u 49u Air condi- tioning Air condi- tioning, engine controls Air conditioning Blower relay Engine controls Exterior lights From combination switch f From ignition h switch (diagram 1 of 3) From ignition m relay (diagram 2 of 3) From ignition relay (diagram 2 of 3) From ignition relay o From ignition switch (diagram 1 of 3) Fuse 1 15a Fuse 17 15a Fuse 2 15a Fuse 21 10a Fuse 22 10a Fuse 25 10a Fuse 26 7.5a Fuse 6 7.5a Fuse block (j/b) G200 (left kick panel) G202 (below left side of dash) Headlights Interior lights Interior lights, exterior lights Warning systems
POWER DOOR LOCKS Door Lock Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Door Lock Wiring Diagram for Nissan Pathfinder LE 1996: 30 Back door lock actuator Central lock Central unlock Circuit breaker-1 (left kick panel) Door lock status G200 (left kick panel) G202 (below left side of dash) G203 (right kick panel) G300 (below left front seat) G301 (below right front seat) Ground Hot at all times Left front door lock actuator Left rear door lock actuator Left unlock sensor right unlock sensor Lock Lock output Locked Main power window and door lock switch Models w/ multi-remote control system Rear unlock sensor Right door lock/unlock switch Right front door lock actuator Right rear door lock actuator Smart entrance control unit (behind dash, right of steering column) Status door lock Unlock Unlock output Unlocked V bat Keyless Entry Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Keyless Entry Wiring Diagram for Nissan Pathfinder LE 1996: 62 Acc Ant Antenna Back door key cylinder switch Back door lock actuator Back door switch Between full stroke and n Central lock Central unlock Circuit breaker-1 (left kick panel) Door lock status Dr sw (as, rr) Full stroke Fuse 10a Fuse 7.5a Fuse block (j/b) (behind dash, left of steering column) G200 (left kick panel) G202 (below left side of dash) G203 (right kick panel) G300 (below left front seat) G301 (below right front seat) G404 (left rear side of trunk) G416 (left rear frame rail) Ground Hot at all times Hot in acc or on Inserted Key cylinder withdrawn Key in ign sw glass hatch key unlock sw door key lock sw door key unlock sw Key switch Left front door key cylinder switch Left front door lock actuator Left rear door lock actuator Left rear door open Left rear door open switch Left unlock sensor right unlock sensor Lock Lock output Lock sw Locked Main power window and door lock switch Models w/ multi-remote control system Nca Normal Open Rear unlock sensor dr sw (dr) Removed Right door lock/unlock switch Right front door key cylinder switch Right front door lock actuator Right front door open Right rear door lock actuator Right rear door open Smart entrance control unit (behind dash, right of steering column) Status door lock Switch Temper U52 Unlock Unlock output Unlocked V bat
POWER MIRRORS Power Mirror Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Power Mirror Wiring Diagram for Nissan Pathfinder LE 1996: 19 (1996-97) (1998-01) (1996-99) (2000-01) (2000-01) (1996-99) 11u (1996-97) (1998-01) 44u Change over switch Door mirror remote control switch Fuse 10a Fuse block (behind dash, left of steering column) G200 (left kick panel) G201 (right side of dash) G203 (right kick panel) Hot in acc or on Left side door mirror Left/right motor Mirror switch Off Right side door mirror Up/down motor
POWER SEATS Driver Power Seat Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Driver Power Seat Wiring Diagram for Nissan Pathfinder LE 1996: 15 (below left (left rear Circuit breaker 2 (left kick panel) Down Driver's power seat Forward Front lifter motor G300 front seat) G404 side of trunk) G416 frame rail) Hot at all times Rear lifter motor Reclining motor Revervse Slide motor Heated Seats Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Heated Seats Wiring Diagram for Nissan Pathfinder LE 1996: 25 (above right (below (below left (left (left rear Fuse 10a Fuse block (left kick panel) G200 kick panel) G202 side of dash) G300 left front seat) G301 right front seat) G403 rear wheel well) G404 side of trunk) G416 frame rail) High Hot in on or start Indic. lamp Left heated seat Left heated seat switch Low Pnk Right heated seat Right heated seat switch Thermostat switch U54 Passenger Power Seat Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Passenger Power Seat Wiring Diagram for Nissan Pathfinder LE 1996: 11 (above right (below right Circuit breaker 2 (left kick panel) Forward G301 front seat) G403 rear wheel well) Hot at all times Passenger's power seat Reclining motor Revervse Slide motor
POWER TOP/SUNROOF Power Top/Sunroof Wiring Diagrams for Nissan Pathfinder LE 1996 List of elements for Power Top/Sunroof Wiring Diagrams for Nissan Pathfinder LE 1996: 18 27u Circuit breaker 1 (behind left side of) dash) Closed Fuse 12 7.5a Fuse block (behind left side of dash) G200 (left kick panel) G203 (right kick panel) Hot at all times Hot in on or start Ign Nca Power window relay Red Slide Sunroof motor (center front of roof) Sunroof relay (behind center of dash) Sunroof switch Tilt
POWER WINDOWS Power Window Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Power Window Wiring Diagram for Nissan Pathfinder LE 1996: 25 Auto Auto amp Circuit breaker-1 (left side of dash) Front sw Fuse 7.5a Fuse block (behind left side of dash) G200 (left kick panel) G202 (below left side of dash) Hot at all times Hot in on or start Left front power window regulator Left rear power window regulator Left rear power window sub-switch Left rear sw Lock switch Nca Power window main switch Power window relay (on fuse block) Right Right front power window regulator Right front power window sub-switch Right rear power window regulator Right rear power window sub-switch Right rear sw U27
RADIO Base Model, 4 Speaker System for Nissan Pathfinder LE 1996 List of elements for Base Model, 4 Speaker System for Nissan Pathfinder LE 1996: 30 Acc Ant sig Audio Bat (back up) Fr sp lh + Fr sp lh - Fr sp rh + Fr sp rh - Fuse 10a Fuse 7.5a Fuse block (under left side of dash) Hot at all times Hot in acc or on Ill cont Interior lights system Left front door speaker Left rear door speaker Light switch M10 M48 M49 Power antenna system Red Right front door speaker Right rear door speaker Rr sp lh + Rr sp lh - Rr sp rh + Rr sp rh - U52 Base Model, 6 Speaker System for Nissan Pathfinder LE 1996 List of elements for Base Model, 6 Speaker System for Nissan Pathfinder LE 1996: 32 Acc Ant sig Audio Bat (back up) Fr sp lh + Fr sp lh - Fr sp rh + Fr sp rh - Fuse 10a Fuse 7.5a Fuse block (under left side of dash) Hot at all times Hot in acc or on Ill cont Interior lights system Left front door speaker Left rear door speaker Left tweeter Light switch M10 M48 M49 Power antenna system Red Right front door speaker Right rear door speaker Right tweeter Rr sp lh + Rr sp lh - Rr sp rh + Rr sp rh - U52 Stereo Radio Wiring Diagram, with Amplifier for Nissan Pathfinder LE 1996 List of elements for Stereo Radio Wiring Diagram, with Amplifier for Nissan Pathfinder LE 1996: 61 (1996) (1997) (left front door sill) g309 Acc Amp on sig Ant sig Audio B20 B21 Bat (back up) Fr sp lh (+) Fr sp lh (+) in Fr sp lh (+) out Fr sp lh (-) Fr sp lh (-) in Fr sp lh (-) out Fr sp rh (+) Fr sp rh (+) in Fr sp rh (+) out Fr sp rh (-) Fr sp rh (-) in Fr sp rh (-) out Fuse 10a Fuse 15a Fuse 7.5a Fuse block (1996) fuse block j/b (1997) (left side of dash) Gnd Hot at all times Hot in acc or on Ill ctrl Interior lights system Left front door speaker Left rear door speaker Left tweeter Light switch M10 M48 M49 M81 Nca Pnk Power Power antenna system Red Right front door speaker Right rear door speaker Right tweeter Rr sp lh (+) Rr sp lh (+) in Rr sp lh (+) out Rr sp lh (-) Rr sp lh (-) in Rr sp lh (-) out Rr sp rh (+) Rr sp rh (+) in Rr sp rh (+) out Rr sp rh (-) Rr sp rh (-) in Rr sp rh (-) out Speaker amplifier (behind left luggage room trim) U52
SHIFT INTERLOCKS Shift Interlock Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Shift Interlock Wiring Diagram for Nissan Pathfinder LE 1996: 9 Ascd cancel switch (top of brake pedal support) Cruise control system Fuse 12 7.5a Fuse block (left side of dash) G301 (below right front seat) G403 (above right rear wheelwell) Hot at all times Park position switch (near shift lever) Shift lock solenoid (near shift lever)
STARTING/CHARGING Charging Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Charging Wiring Diagram for Nissan Pathfinder LE 1996: 13 Alternator Battery Charge indicator Combination meter Fuse 65 7.5a Fuse 7 10a Fuse a 100a Fuse and fusible link box (left front of engine compartment) Fuse block G119 (right front side of engine) Hot in on or start Nca Smj (left side of dash) Starting Wiring Diagram, A/T for Nissan Pathfinder LE 1996 List of elements for Starting Wiring Diagram, A/T for Nissan Pathfinder LE 1996: 21 Acc Battery Engine controls system Fuse 8 7.5a Fuse and fusible link box (left front shock tower) Fuse block Fuse e 30a G107 (behind right headlamp) Hot in on or start Ignition switch Inhibitor relay (left front fender) Inhibitor switch (on Nca Off Start Starter motor Theft warning relay (rear of left front fender) Transmission) U44 W/ anti- theft W/o anti- theft Starting Wiring Diagram, M/T for Nissan Pathfinder LE 1996 List of elements for Starting Wiring Diagram, M/T for Nissan Pathfinder LE 1996: 20 Acc Battery Canada Clutch interlock switch (left side of i/p) Fuse and fusible link box (right front shock tower) Fuse block Fuse e 40a G200 (left kick panel) Hot in on or start Ignition switch Interlock relay (right front shock tower) Nca Off Start Starter motor Theft warning relay (rear of left fender) Usa W/ anti- theft W/o anti- theft W16
SUPPLEMENTAL RESTRAINTS Supplemental Restraint Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Supplemental Restraint Wiring Diagram for Nissan Pathfinder LE 1996: 28 (in left front door jamb) 19u 26u Air bag diagnosis sensor unit (rear of console) Air bag ind. Data link connector (left side of i/p) Door sw Driver side air bag module Fuse 22 10a Fuse 25 10a Fuse block G200 (left kick panel) G309 (left front door sill) Gnd Hot in on or start Ign Instrument cluster Led Left front door switch Nca Passenger side air bag module Spiral cable Sq as1 + Sq as1 - Sq dr + Sq dr - Sss rx Sss tx
TRANSMISSION Transmission Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Transmission Wiring Diagram for Nissan Pathfinder LE 1996: 52 (left side of dash) diode 13u 14u 1995 vftc c 44u A/t control unit (left side of dash) A/t fluid temper- ature sensor A/t fluid temperature switch (on transmission) A/t oil temp ind All times Ascd control unit (behind left side of dash) Atck Automatic transaxle Avcc Data link connector (for consult) (below left side of i/p) Dropping resistor (left front strut tower) Dt1 Dt2 Dt3 Eccs control module (behind center of i/p) Fuse 10a Fuse 7.5a Fuse block G121 (center of safety wall) G200 (left kick panel) G301 (below right front seat) Gnd-a Hot at Hot in on or start Idle Inhibitor switch (on transaxle) Instrument cluster Line pressure solenoid valve Nca O.d. off ind. Over- run clutch solen- oid valve Overdrive control switch Pnk Red Revolution sensor Shift solenoid valve a Shift solenoid valve b Speedometer Tacho Tachometer Throttle position sensor (on throttle body) Throttle position switch (on throttle body) Torque converter clutch solenoid valve Tvo1 Tvoo Vehicle speed sensor (on transaxle) Wot
WARNING SYSTEMS Warning System Wiring Diagrams for Nissan Pathfinder LE 1996 List of elements for Warning System Wiring Diagrams for Nissan Pathfinder LE 1996: 39 (below (left (left rear (right Batt Chime Circuit breaker 1 (left side of i/p) Door sw Fuse 10a Fuse 7.5a Fuse and fusible link box (right front shock tower) Fuse block (left kick panel) Fuse f 40a G200 kick panel) G203 kick panel) G300 left front seat) G404 side of trunk) G416 frame rail) Gnd Head Hot at all times Hot in on and start Ign Instrument cluster Key in ign sw Key switch Left door switch Light sw Lighting switch Off Park Seat belt indicator Seat belt sw Seat belt switch Smart entrance control module (left side of i/p) U19 U28 U37 Warning chime (left side of i/p)
WIPER/WASHER Front Wiper/Washer Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Front Wiper/Washer Wiring Diagram for Nissan Pathfinder LE 1996: 16 56u Front washer motor (on washer fluid reservoir) Front wiper amplifier (right side of safety wall) Front wiper motor (right side of safety wall) Fuse 20a Fuse block (left side of dash) G106 (behind left headlamp) G107 (behind right headlamp) G200 (left kick panel) G202 (below left side of dash) Hot in acc or on Int Inter- mittent Off Wash Wiper switch Rear Wiper/Washer Wiring Diagram for Nissan Pathfinder LE 1996 List of elements for Rear Wiper/Washer Wiring Diagram for Nissan Pathfinder LE 1996: 19 Diode Fuse 10a Fuse block (left side of dash) G200 (left kick panel) G203 (right kick panel) G300 (below left front seat) G404 (left rear side of trunk) G416 (left rear frame rail) Glass hatch switch Hot in acc or on Int Models w/ theft warning system models w/o theft warning system Off Rear washer motor (on washer fluid reservoir) Rear wiper amplifier (behind left luggage room trim) Rear wiper motor (on lower right side of hatch) Rear wiper relay (behind left luggage room trim) Rear wiper switch Wash
