Diagram sections — 28 (63 total)
AIR CONDITIONING ANTI-LOCK BRAKES ANTI-THEFT BODY COMPUTER COMPUTER DATA LINES COOLING FAN CRUISE CONTROL DEFOGGERS ENGINE PERFORMANCE EXTERIOR LIGHTS GROUND DISTRIBUTION HEADLIGHTS HORN INSTRUMENT CLUSTER INTERIOR LIGHTS POWER DISTRIBUTION POWER DOOR LOCKS POWER MIRRORS POWER TOP/SUNROOF POWER WINDOWS RADIO SHIFT INTERLOCKS STARTING/CHARGING SUPPLEMENTAL RESTRAINTS TRANSMISSION TRUNK, TAILGATE, FUEL DOOR WARNING SYSTEMS WIPER/WASHER
AIR CONDITIONING Heater Wiring Diagram for Nissan Sentra SE 2000 List of elements for Heater Wiring Diagram for Nissan Sentra SE 2000: 8 Blower motor (behind right side of dash) Fan control switch Fan resistor (behind right side of dash) Fuse 15a Fuse block (behind left side of dash) G202 (behind left side of dash) Hot in on Off Manual A/C Wiring Diagram for Nissan Sentra SE 2000 List of elements for Manual A/C Wiring Diagram for Nissan Sentra SE 2000: 42 (behind right side of dash) blower motor A/c compressor A/c relay (in relay box) A/c switch Acrly Air con Air control Amp Avcc Cooling fan motor 1 (center front of engine compt) Cooling fan motor 2 (center front of engine compt) Cooling fan relay 1 (lo relay) Cooling fan relay 2 (hi relay) Cooling fan relay 3 (hi relay) Defrost a/c switch Engine control module (ecm) (on right side of firewall) Fan control switch Fan resistor (behind right side of dash) Fuse & fusible link box (at left front of engine compt) Fuse 10a Fuse 15a Fuse block (behind left side of dash) Fusible link h 40a Fusible link i 40a G101 (front of right front fender) G201 (behind right side of dash) G202 (behind left side of dash) Gnd-a Hot at all times Hot in on Hot in on or start Intake door motor (behind center of dash) Load 2 Off Pd pres Recirc switch Red Refrigerant pressure sensor (on a/c liquid tank) Rfrh Rfrl Thermal protector Thermo control amplifier (behind center of dash)
ANTI-LOCK BRAKES Anti-lock Brake Wiring Diagrams for Nissan Sentra SE 2000 List of elements for Anti-lock Brake Wiring Diagrams for Nissan Sentra SE 2000: 49 11l Abs actuator Abs actuator & electric unit (at right rear of engine compt) Abs control unit Abs lamp Combination meter Data link connector (under left side of dash) Diag l Exterior lights system Fl in Fl out Fl ss(+) Fl ss(-) Fr in Fr out Fr ss(+) Fr ss(-) Fuse & fusible link box (at left front of engine compt) Fuse 10a Fuse block (behind left side of dash) Fuse f 40a Fuse g 40a G105 (right rear of engine compt) Gnd Hot at all times Hot in on or start Ign Left front wheel speed sensor Left rear wheel speed sensor Motor Motor relay Mtr rly Pnk Rear in Rear out Red Relay unit Right front wheel speed sensor Right rear wheel speed sensor Rl ss(+) Rl ss(-) Rr ss(+) Rr ss(-) Rxd Sol rly Solenoid valve relay Stop Stoplight switch (on brake pedal bracket) Txd
ANTI-THEFT Anti-theft Wiring Diagram (1 of 2) for Nissan Sentra SE 2000 List of elements for Anti-theft Wiring Diagram (1 of 2) for Nissan Sentra SE 2000: 49 10l 10q 12k 12l Acc sw Anti-theft ind Data link connector (lower left side of dash) Door sw Door sw (dr) Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse block (under left side of dash) G201 (behind right side of dash) G202 (behind left side of dash) G305 (at base of right "b" pillar) G308 (at base of left "b" pillar) Gnd Hood sw Horn/headlamps Hot at all times Hot in acc or on Hot in on or start Ign sw Immobilizer system Key cyl sw (lck) Key cyl sw (unlck) Key sw Key switch Left front door key cylinder switch Left front door lock actuator Lh unlck sens Lock Lock-between full Main power window & door lock/ unlock switch Pnk Red Rh unlck sens Right door lock/ unlock switch Right front door key cylinder switch Right front door lock actuator Security indicator lamp Smart entrance control unit (behind left side of dash) Stroke & normal Stroke & normal unlock-between full Trunk lid key cylinder switch Trunk key cyl sw Trunk room lamp switch Trunk sw Unlock Anti-theft Wiring Diagram (2 of 2) for Nissan Sentra SE 2000 List of elements for Anti-theft Wiring Diagram (2 of 2) for Nissan Sentra SE 2000: 19 Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse 15a G101 (right front of engine compt) G104 (left rear of engine compt) G308 (at base of left "b" pillar) Headlights system Hood switch (left front of engine compt) Horn relay (in relay box) Horns system Hot at all times Left front door switch Left rear door switch Red Right front door switch Right rear door switch Theft warning horn (at right side of engine compt) Theft warning horn relay (in relay box) Theft warning light relay (in relay box) Immobilizer Wiring Diagram (NATS) for Nissan Sentra SE 2000 List of elements for Immobilizer Wiring Diagram (NATS) for Nissan Sentra SE 2000: 15 10l Engine control module (ecm) (right rear of engine compt) Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse block (under left side of dash) G131 (on intake manifold) Gnd-c Hot at all times Hot in on or start Ign on Imline Ind out Nvis (nats) immu (on ignition key cylinder) Pcm/ecm Security indicator lamp
BODY COMPUTER Body Computer Wiring Diagrams, with Remote Control System for Nissan Sentra SE 2000 List of elements for Body Computer Wiring Diagrams, with Remote Control System for Nissan Sentra SE 2000: 60 10q 12k 12l Anti-theft system Batt saver output Battery (c/b) Battery (fuse) Circuit breaker (behind left side of dash) Computer data lines system Condition switch Defogger system Door actuator Door locks system Door switch Dr door actuator Dr door switch Exterior lights system Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse 15a Fuse block (under left side of dash) Fuse d 30a G202 (behind left side of dash) G308 (at base of left "b" pillar) Ground Hazard output Hood switch Horn chirp Horn/headlamps Horns system Hot at all times Hot in accy or on Hot in on or start Ignition Interior lights system Key cyl sw lock Key cyl sw unlck Key switch Left front door switch Left rear door switch Light switch Lock Multi-remote control relay (behind left side of dash) Pnk Pwr (acc) Red Right front door switch Right rear door switch Room lamp output Rr def output Rr defggr switch Seat belt switch Security indicator Smart entrance control unit (behind left side of dash) Trunk key switch Trunk output Trunk switch Trunk, tailgate, fuel doors system Unlock Warning system Body Computer Wiring Diagrams, without Remote Control System & with Power Door Locks for Nissan Sentra SE 2000 List of elements for Body Computer Wiring Diagrams, without Remote Control System & with Power Door Locks for Nissan Sentra SE 2000: 38 10q 12k Air control sw Bat saver out Buckle sw Circuit breaker (behind left side of dash) Defogger relay Defogger system Door lock output Door locks system Door sw Door unlk output Dr door switch Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse block (under left side of dash) Fuse d 30a G202 (behind left side of dash) G308 (at base of left "b" pillar) Ground Hot at all times Hot in on or start Interior lights system Key sw Key switch Left front door switch Left rear door switch Lf unlock sensor Light sw Lock Red Right front door switch Right rear door switch Room lamp out Time control unit (under left side of dash) Unlock V ign Warning systems Body Computer Wiring Diagrams, without Remote Control System & without Power Door Locks for Nissan Sentra SE 2000 List of elements for Body Computer Wiring Diagrams, without Remote Control System & without Power Door Locks for Nissan Sentra SE 2000: 24 10q 12k Air control sw Batt Buckle sw Defogger relay Defogger system Door sw (dr) Fuse 10a Fuse block (under left side of dash) G202 (behind left side of dash) G308 (at base of left "b" pillar) Ground Hot at all times Hot in on or start Ign sw Key sw Key switch Left front door switch Light sw Red Time control unit (under left side of dash) Warning system Warning systems
COMPUTER DATA LINES
1.8L 1.8L, Computer Data Lines, Except California for Nissan Sentra SE 2000 List of elements for 1.8L, Computer Data Lines, Except California for Nissan Sentra SE 2000: 19 Abs actuator & electric unit (right rear of Adj sw Air bag diagnosis sensor unit (under center console) Check Data link connector (dlc) (under left side of dash) Diag l Engine compt) Engine control module (ecm) (right rear of engine compt) Fuse 10 10a Fuse 12 10a Fuse block (under left side of dash) G131 (on intake manifold) G202 (behind left side of dash) Hot at all times Hot in on or start Kline Scirx Scitx Smart entrance control unit (behind left side of dash)
2.0L 2.0L, Computer Data Lines for Nissan Sentra SE 2000 List of elements for 2.0L, Computer Data Lines for Nissan Sentra SE 2000: 19 (behind right side of dash) Abs actuator & electric unit (right rear of Air bag diagnosis sensor unit (under center console) Consult (rx) Consult (tx) Data link connector (dlc) (under left side of dash) Diag l Engine compt) Engine control module (ecm) (right rear of engine compt) Fuse 10 10a Fuse 12 10a Fuse block (under left side of dash) G131 (on intake manifold) G202 (behind left side of dash) Hot at all times Hot in on or start Kline Smart entrance control unit (behind left side of dash) Transmission (tcm) control module
COOLING FAN Cooling Fan Wiring Diagram for Nissan Sentra SE 2000 List of elements for Cooling Fan Wiring Diagram for Nissan Sentra SE 2000: 17 Cooling fan motor 1 (center front of engine compt) Cooling fan motor 2 (center front of engine compt) Cooling fan relay 1 (in relay box) Cooling fan relay 2 (in relay box) Cooling fan relay 3 (in relay box) Engine control module (ecm) (on right side of firewall) Fuse & fusible link box (at left side of engine compt) Fuse 10a Fuse block (behind left side of dash) Fuse h 40a Fuse i 40a G101 (right front of eng compt) G104 (left rear of eng compt) Hot at all times Hot in on or start Rfrh Rfrl
CRUISE CONTROL Cruise Control Wiring Diagram for Nissan Sentra SE 2000 List of elements for Cruise Control Wiring Diagram for Nissan Sentra SE 2000: 54 11k 4th cut sw Accel/ res switch Ascd brake switch (w/a/t) (on brake pedal bracket) Ascd clutch switch (w/m/t) (on clutch pedal bracket) Ascd control unit (behind left side of dash) Ascd motor actuator (left rear of engine compt) Ascd steering switch Brake nc sw Brake no sw Cancel switch Clutch Combination meter Command sw Cruise Cruise lamp Cruise on/off switch Cruise signal Cruise sw Fuse 10 10a Fuse 2 10a Fuse 20 10a Fuse 30 10a Fuse block (under left side of dash) G104 (left rear of engine compt) G131 (on intake manifold) G201 (behind right sideof dash) G202 (behind left side of dash) Ground Hot at all times Hot in on or start Ign Motor Motor 1 Motor 2 Motor 3 Od cancel Park/neutral position relay (w/a/t) (in relay box) Park/neutral position switch (on left side of transaxle) Powertrain control module (pcm) (right rear of engine compt) Red Set Set lamp out Set/ coast switch Spiral cable Starting/ charging system Stoplight switch (on brake pedal bracket) Transmission control module (tcm) (behind right side of dash) Vehicle speed Vehicle speed sensor (on transaxle) W/ 1.8l W/ 2.0l W/a/t W/m/t
DEFOGGERS Defogger Wiring Diagram for Nissan Sentra SE 2000 List of elements for Defogger Wiring Diagram for Nissan Sentra SE 2000: 37 (on left side of engine compartment) (under left side of dash) (w/ power door locks) (w/o power door locks) 12k Air control Batt Diode (behind right side of dash) Engine control module (right side of firewall) Fuse 10a Fuse 20a Fuse 20a Fuse block Fusible link box G201 (behind right side of dash) G202 (behind left side of dash) G905 (right "c" pillar) Ground Heated mirror relay (lower left kick panel) Hot at all times Hot in on or start Ign Illum Ind Interior lights system Left door mirror defogger Nca Rear window defogger Rear window defogger relay (lower left kick panel) Rear window defogger switch Right door mirror defogger Rr def out Rr def sw Smart entrance control unit (w/ multi-remote control system) (behind left side of dash) Time control unit (w/o multi-remote control system) (under left side of dash) W/ multi-remote control system W/o multi-remote control system
ENGINE PERFORMANCE
1.8L 1.8L, Engine Performance Wiring Diagrams, California (1 of 5) for Nissan Sentra SE 2000 List of elements for 1.8L, Engine Performance Wiring Diagrams, California (1 of 5) for Nissan Sentra SE 2000: 67 (on right front side of cyl head) intake valve timing control solenoid valve (on top rear of engine) egr volume control valve (on top rear of engine, below throttle body) iacv-aac valve (under vehicle, near evap canister) vacuum cut valve by-pass valve 10k A/c system (a/c relay) A/c system (air control, fan control switch) A/c system (thermo control amplifier) A/fshf Acrly Air con Closed Cooling fans system Cvbv Dt1 Dt2 Dt3 Dt4 Dt5 Egr 1 Egr 2 Egr 3 Egr 4 Engine control module (ecm) (on right side of firewall) Evap Evap canister purge volume control solenoid valve (on top rear of engine) Fpr Fuse 10a Fuse block (behind left side of dash) G131 (on intake manifold) Gnd-a Gnd-c Headlights system, defogger system Hot in on or start Hot in start Idle Ign 1 Ign 2 Ign 3 Ign 4 Ignsw Isc 1 Isc 2 Isc 3 Isc 4 Ivc Led r Load 1 Load l Neut O2hm O2hr Pnk Power steering oil pressure switch (on power steering oil pump) Pwst Red Rfrh Rfrl Scv1 Scv2 Scv3 Scv4 Ssoff Stsw Tacho Throttle position switch (on throttle body) Wide open 1.8L, Engine Performance Wiring Diagrams, California (2 of 5) for Nissan Sentra SE 2000 List of elements for 1.8L, Engine Performance Wiring Diagrams, California (2 of 5) for Nissan Sentra SE 2000: 34 (on intake manifold) swirl control valve Combination meter Condenser (at right side of engine compt) Dt1 Dt2 Dt3 Dt4 Dt5 Fuel level Full sw G131 (on intake manifold) G202 (behind left side of dash) Gnd Gnd sens Idle sw Ignition coil 1 (w/ power transistor) Ignition coil 2 (w/ power transistor) Ignition coil 3 (w/ power transistor) Ignition coil 4 (w/ power transistor) Malfunction indicator Nca Obd2 Pwr Red Sp sens Spark plug Tach Tacho Th sens Transmission control module (tcm) (w/a/t) (behind right kick panel) V sens Vehicle speed sensor Vss in Vss out 1.8L, Engine Performance Wiring Diagrams, California (3 of 5) for Nissan Sentra SE 2000 List of elements for 1.8L, Engine Performance Wiring Diagrams, California (3 of 5) for Nissan Sentra SE 2000: 14 13k Fuel level sensor (integral to fuel level sensor unit & fuel pump) Fuel pump (integral to fuel level sensor unit & fuel pump) Fuel pump relay (behind left kick panel) Fuse 10a Fuse 15a Fuse block (behind left side of dash) G131 (on intake manifold) G308 (at base of left "b" pillar) Heated oxygen sensor 2 (rear) (on exhaust system, downstream of three way catalyst) Heated oxygen sensor 3 (on exhaust system, downstream of ads-twc) Hot in on or start Nca Red 1.8L, Engine Performance Wiring Diagrams, California (4 of 5) for Nissan Sentra SE 2000 List of elements for 1.8L, Engine Performance Wiring Diagrams, California (4 of 5) for Nissan Sentra SE 2000: 18 (on exhaust manifold, upstream of twc) air fuel ratio (a/f) sensor 1 (on front end of cyl head) intake valve timing control position sensor (on intake manifold) g131 (on intake manifold) swirl control valve position sensor (on right side of firewall) barometric pressure (baro) sensor (on right side of firewall) manifold absolute pressure (map) sensor (on top rear of engine) egr temperature sensor Engine coolant temperature sensor (on left front side of cyl head) Evap control system pressure sensor (under vehicle, near evap canister) Fuel injectors Fuel tank temperature sensor (integral to fuel level sensor unit & fuel pump) G131 (on intake manifold) G308 (at base of left "b" pillar) Knock sensor (on right side of cyl block) Nca Park/ neutral position switch Pnk Red 1.8L, Engine Performance Wiring Diagrams, California (5 of 5) for Nissan Sentra SE 2000 List of elements for 1.8L, Engine Performance Wiring Diagrams, California (5 of 5) for Nissan Sentra SE 2000: 57 (on air cleaner) mass airflow sensor (right rear of engine compt) j/c 1 02sr A/c system (refrigerant pressure sensor) A/fiaf A/fipf A/funf A/fvmf Atck Avcc Batt Boost Camshaft position sensor Cdcv Crankshaft position sensor Data link connector (dlc) (under left side of dash) Ecm relay (behind right side of dash) Egrts Engine control module (ecm) (on right side of firewall) Evap canister vent control valve (under vehicle, near evap canister) Fgage+ Fgage- Ftemp Ftpres Fuse & fusible link box (at left front of engine compt) Fuse 10a Fuse 15a G131 (on intake manifold) Gnd-e Hot at all times Imline Inj 1 Inj 2 Inj 3 Inj 4 Intake air temperature sensor (on air duct housing) Ivcs J/c 2 (right rear of engine compt) J/c 3 (right rear of engine compt) Kline Knk Nca Nvis (nats) immu (at top of steering column) O2sm Pdpres Phase Pnk Pos Pres Qa+ Qa- Red Scvps Throttle position sensor (on throttle body) Tv00 Tvo Vsp2 1.8L, Engine Performance Wiring Diagrams, Except California (1 of 5) for Nissan Sentra SE 2000 List of elements for 1.8L, Engine Performance Wiring Diagrams, Except California (1 of 5) for Nissan Sentra SE 2000: 75 (behind right side of dash) g201 10k A/c system (a/c relay) A/c system (air control, fan control switch) A/c system (thermo control amplifier) Acrly Air con Ascd 4th Ascd control unit (behind left side of dash) Ascd cr Brake sw Closed Cooling fans system Cr lamp Cvbv Egr 1 Egr 2 Egr 3 Egr 4 Egr volume control valve Evap Evap canister purge volume control solenoid valve Fpr Fuse 10a Fuse block (under left side of dash) G131 (on intake manifold) Gnd-a Gnd-c Headlights system, defogger system Ho2s1hb1 Ho2s1hb2 Ho2s2hb1 Ho2s2hb2 Hot in on or start Hot in start Iacv-aac valve Idle Ign 1 Ign 2 Ign 3 Ign 4 Ignsw Intake valve timing control solenoid valve Isc 1 Isc 2 Isc 3 Isc 4 Ivc Led r Load 2 Load h Lu duty Neut O/d cancel Od-c Overdrive control switch Ovr/c P-lamp Pl duty Pnk Power steering oil pressure switch Powertrain control module (pcm) (right rear of engine compt) Pwst Rfrh Rfrl Scirx Shift a Shift b Ssoff Stsw Swirl control valve control solenoid valve Tacho Throttle position switch Vacuum cut valve by-pass valve Wide open 1.8L, Engine Performance Wiring Diagrams, Except California (2 of 5) for Nissan Sentra SE 2000 List of elements for 1.8L, Engine Performance Wiring Diagrams, Except California (2 of 5) for Nissan Sentra SE 2000: 28 Combination meter Condenser Dropping resistor Fuel level G131 (on intake manifold) G202 (behind left side of dash) Gnd Ignition coil 1 (w/ power transistor) Ignition coil 2 (w/ power transistor) Ignition coil 3 (w/ power transistor) Ignition coil 4 (w/ power transistor) Line pressure solenoid valve Malfunction indicator Nca O/d off Overrun clutch solenoid valve Pwr Red Shift solenoid valve a Shift solenoid valve b Spark plug Tach Torque converter clutch solenoid valve Vehicle speed sensor Vss in Vss out W/ tach W/o tach 1.8L, Engine Performance Wiring Diagrams, Except California (3 of 5) for Nissan Sentra SE 2000 List of elements for 1.8L, Engine Performance Wiring Diagrams, Except California (3 of 5) for Nissan Sentra SE 2000: 20 (on brake pedal bracket) stoplight switch 11l 13k Front heated oxygen sensor 1 (bank 1) Front heated oxygen sensor 1 (bank 2) Fuel level sensor Fuel pump Fuel pump relay (lower left kick panel) Fuse 10a Fuse 15a Fuse block (under left side of dash) G131 (on intake manifold) G308 (at base of left "b" pillar) Hot at all times Hot in on or start Nca Rear heated oxygen sensor 2 (bank 1) Rear heated oxygen sensor 2 (bank 2) W/ nvis W/o nvis 1.8L, Engine Performance Wiring Diagrams, Except California (4 of 5) for Nissan Sentra SE 2000 List of elements for 1.8L, Engine Performance Wiring Diagrams, Except California (4 of 5) for Nissan Sentra SE 2000: 22 (on intake manifold) g131 A/t A/t fluid temperature sensor Egr temperature sensor Engine coolant temperature sensor Evap control system pressure sensor Fuel injectors Fuel tank temperature sensor G131 (on intake manifold) G308 (at base of left "b" pillar) Intake valve timing control position sensor Knock sensor M/t Nca Park/ neutral position switch Park/ neutral position switch (on left side of transaxle) Pnk Red Revolution sensor Swirl control valve control vacuum check switch W/ nvis W/o nvis 1.8L, Engine Performance Wiring Diagrams, Except California (5 of 5) for Nissan Sentra SE 2000 List of elements for 1.8L, Engine Performance Wiring Diagrams, Except California (5 of 5) for Nissan Sentra SE 2000: 68 (or red) (right rear of engine compt) j/c 1 1 sw 2 sw A/c system (refrigerant pressure sensor) Absolute pressure sensor Adjsw Atf Avcc Batt Bstsw Camshaft position sensor Cdcv Crankshaft position sensor D sw Data link connector (dlc) (lower left side of dash) Egrts Evap canister vent control valve Fgage+ Fgage- Ftemp Ftpres Full Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse 15a G131 (on intake manifold) Gnd-e Ho2s1b1 Ho2s1b2 Ho2s2b1 Ho2s2b2 Hot at all times Imline Inj 1 Inj 2 Inj 3 Inj 4 Intake air temperature sensor Ivcs J/c 2 (right rear of engine compt) J/c 3 (right rear of engine compt) Kline Knock Mass airflow sensor Nca Nvis (nats) immu (on ignition key cylinder) Pcm relay (right end of dash) Pdpres Pnk Pos Powertrain control module (pcm) (right rear of engine compt) Pres Qa+ Qa- R pos Red Scitx Swl/v Throttle position sensor Tv00 Tvo Vign Vsp1 Vsp2 W/ nvis W/ nvis red W/o nvis
2.0L 2.0L, Engine Performance Wiring Diagrams (1 of 4) for Nissan Sentra SE 2000 List of elements for 2.0L, Engine Performance Wiring Diagrams (1 of 4) for Nissan Sentra SE 2000: 71 (on intake manifold) g131 A/c system (a/c relay) A/c system (air control, fan control switch) A/c system (thermo control amplifier) A/t Acrly Air con Closed Cooling fans system Cvbv Dt1 Dt2 Dt3 Dt4 Dt5 Egr 1 Egr 2 Egr 3 Egr 4 Egr volume control valve Engine control module (ecm) (right rear of engine compt) Evap Evap canister purge volume control solenoid valve Fpr Full sw Fuse 10a Fuse 15a Fuse block (under left side of dash) G131 (on intake manifold) Gnd sens Gnd-a Gnd-c Headlights system, defogger system Hot in on or start Hot in start Iacv-aac valve Idle Idle sw Ign Ignck Ignsw Isc 1 Isc 2 Isc 3 Isc 4 Led r Load 2 Load h M/t Neut O2hfl O2hrl Obd2 Park/ neutral position switch Pnk Power steering oil pressure switch Pwst Red Rfrh Rfrl Sp sens Ssoff Stsw Tacho Th sens Throttle position switch Transmission control module (tcm) (w/a/t) (behind right side of dash) V sens W/ nvis W/o nvis Wide open 2.0L, Engine Performance Wiring Diagrams (2 of 4) for Nissan Sentra SE 2000 List of elements for 2.0L, Engine Performance Wiring Diagrams (2 of 4) for Nissan Sentra SE 2000: 23 (on transaxle) vehicle speed sensor 10k Combination meter Data link connector (dlc) (lower left side of dash) Evap canister vent control valve Fuel level Fuel level sensor Fuel pump Fuel pump relay (lower left kick panel) Fuse 10a Fuse block (under left side of dash) G131 (on intake manifold) G202 (behind left side of dash) G308 (at base of left "b" pillar) Gnd Hot in on or start Malfunction indicator Pwr Red Tach Vacuum cut valve by-pass valve Vss in Vss out 2.0L, Engine Performance Wiring Diagrams (3 of 4) for Nissan Sentra SE 2000 List of elements for 2.0L, Engine Performance Wiring Diagrams (3 of 4) for Nissan Sentra SE 2000: 21 13k Camshaft position sensor Condenser Distributor Evap control system pressure sensor Front heated oxygen sensor 1 Fuel injectors Fuse 10a Fuse 15a Fuse block (under left side of dash) G131 (on intake manifold) Hot in on or start Ignition coil Nca Pnk Power transistor Rear heated oxygen sensor 2 Red Spark plugs W/ nvis W/o nvis 2.0L, Engine Performance Wiring Diagrams (4 of 4) for Nissan Sentra SE 2000 List of elements for 2.0L, Engine Performance Wiring Diagrams (4 of 4) for Nissan Sentra SE 2000: 52 (right rear of engine compt) j/c 3 A/c system (refrigerant pressure sensor) Absolute pressure sensor Atck Avcc Batt Cdcv Crankshaft position sensor Ecm relay Egr temperature sensor Egrts Engine control module (ecm) (right rear of engine compt) Engine coolant temperature sensor Fgage+ Fgage- Ftprs Fuel tank temperature sensor Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse 15a G131 (on intake manifold) G308 (at base of left "b" pillar) Gnd-e Hot at all times Imline Inj 1 Inj 2 Inj 3 Inj 4 Intake air temperature sensor J/c 1 J/c 2 (right rear of engine compt) Kline Knk Knock sensor Mass airflow sensor Nca Nvis (nats) immu (on ignition key cylinder) O2sfl O2srl Pdpres Pnk Pos Pres Qa+ Qa- Red Rgc/s Throttle position sensor Tv00 Tvo Vsp
EXTERIOR LIGHTS Back-up Lamps Wiring Diagram for Nissan Sentra SE 2000 List of elements for Back-up Lamps Wiring Diagram for Nissan Sentra SE 2000: 13 (at base of left "b" pillar) (at base of right "b" pillar) A/t Back-up light switch (on rear of transaxle) Fuse 30 10a Fuse block (under left side of dash) G305 G308 Hot in on or start Left backup light M/t Park/neutral position switch (on left side of transaxle) Right backup light Exterior Lamps Wiring Diagram (1 of 2) for Nissan Sentra SE 2000 List of elements for Exterior Lamps Wiring Diagram (1 of 2) for Nissan Sentra SE 2000: 36 (at base of left "b" pillar) (at base of right "b" pillar) (left rear of engine compartment) (right front of engine compartment) 11l 1st 2nd Combination switch (lighting switch) E103 Fuse & fusible link box (on left side of engine compt) Fuse 2 10a Fuse 38 10a Fuse block (under left side of dash) G101 G104 G305 G308 High mounted stop Hot at all times Lamp Left front combin- ation lamp Left license plate lamp Left rear com- bination lamp Nca Off Parking Parking parking Right front combin- ation lamp Right license plate lamp Right rear com- bination lamp Stop Stoplight switch (on brake pedal bracket) Tail Turn W/ spoiler W/o spoiler Exterior Lamps Wiring Diagram (2 of 2) for Nissan Sentra SE 2000 List of elements for Exterior Lamps Wiring Diagram (2 of 2) for Nissan Sentra SE 2000: 33 (behind left side of dash) (behind right side of dash) (left rear of engine compartment) (right front of engine compartment) (w/ tach) (w/o tach) Body computer system Com- bination switch (turn signal switch) Combination flasher unit (behind center of dash) Combination meter Fuse 26 10a Fuse 5 15a Fuse block (under left side of dash) G101 G104 G201 G202 Ground Hazard Hazard switch Hot at all times Hot in on or start Interior lights system Left front com- bination lamp Left turn ind M29 M30 Multi- remote control relay (behind left side of dash) Out Power Right front com- bination lamp Right turn ind Turn
GROUND DISTRIBUTION Ground Distribution Wiring Diagram for Nissan Sentra SE 2000 List of elements for Ground Distribution Wiring Diagram for Nissan Sentra SE 2000: 31 Blower motor relay, ignition relay, accessory relay, heated mirror relay, data link connector, left door mirror, left front door key cylinder switch, left front door lock actuator, Brake fluid level switch, ascd motor actuator, clutch interlock switch, front wiper switch, front fog lamp switch, daytime light control unit, front wiper motor, hood switch, left front combination lamp, right front combination lamp, right headlamp, right front fog lamp, trunk lid opener relay 2, cooling fan motor 2, cooling fan relay 3, washer fluid level switch, theft warning horn relay Front heated oxygen sensor 1 bank 1 shield, rear heated oxygen sensor 2 bank 1 shield, intake valve timing control position sensor shield, mass airflow sensor shield, evap control system pressure sensor shield, manifold absolute pressure sensor shield, swirl volume control valve sensor shield, front sensor 1 shield, rear sensor 2 shield, sensor 3 shield, crankshaft position sensor (pos) shield Front heated oxygen sensor 1 bank 2 shield, rear heated oxygen sensor 2 bank 2 shield, camshaft position sensor (phase) shield, absolute pressure sensor shield, throttle position sensor shield, crankshaft position sensor (pos) shield, barometric pressure sensor shield G101 (right front of engine compt) G104 (left rear of engine compt) G105 (right rear of engine compt) G131 (on intake manifold) G134 (top of engine) G201 (behind right side of dash) G202 (behind left side of dash) G305 (at base of right "b" pillar) G308 (at base of left "b" pillar) G902 (left front of roof) G905 (right "c" pillar) Generator Ignition coils 1-4, condenser, distributor, sensor 2, sensor 3, powertrain control module (pcm) or engine control module (ecm) Left front wheel sensor shield, abs actuator & electrical unit Left headlamp, left front fog lamp, cooling fan motor 1, cooling fan relay 2 Left seat belt buckle switch, left front door switch, fuel level sensor unit & fuel pump, subwoofer amplifier, high-mounted stoplamp, left license lamp, right license lamp, left back-up lamp, right back-up lamp, left rear combination lamp, right rear combination lamp, trunk lid key cylinder switch, trunk room lamp switch, powertrain control module (pcm) or engine control module (ecm) Left side airbag sensor shield Main power window & door lock/unlock switch, left vanity lamp, right vanity lamp, map lamp, power socket, power window relay, trunk lid opener relay 1, illumination control, door mirror remote control switch, combination meter, fan control switch, ascd control unit, smart entrance control unit, time control unit Nca Power socket relay, rear window defogger switch, cigarette lighter socket, air bag diagnosis sensor unit, right door mirror, Rear heated oxygen sensor 2 bank 1, rear heated oxygen sensor 2 bank 2, rear heated qxygen sensor 2, camshaft position sensor (phase), crankshaft position sensor (pos), data link connector, intake valve timing control position sensor, powertrain control module (pcm) or engine control module (ecm) Rear window defogger Right door lock/unlock switch, right front door key cylinder switch, right front door lock actuator, time control unit, combination flasher unit, overdrive control switch, shift lock Right side airbag sensor shield Sunroof motor assembly Swirl control valve control vacuum check switch, power steering oil pressure switch, vehicle speed sensor, park/neutral position switch Transmission control module (tcm)
HEADLIGHTS Headlight Wiring Diagram, with DRL for Nissan Sentra SE 2000 List of elements for Headlight Wiring Diagram, with DRL for Nissan Sentra SE 2000: 39 (w/ tach) (w/o tach) 12k 1st 2nd Combination meter Combination switch Daytime light control unit (behind left kick panel) Fog lamp switch Front foglight relay (in relay box) Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse 39 15a Fuse 40 15a Fuse 43 15a Fuse block (under left side of dash) G101 (right front of engine compt) G104 (left rear of engine compt) G201 (behind right side of dash) G202 (behind left side of dash) Generator Hi beam ind Hot at all times Hot in on or start Hot in start Instrument cluster (charge warning lamp) Left front fog lamp Left headlamp Lighting switch Low Low hi Off Parking brake switch Pass Pnk Red Right front fog lamp Right headlamp Theft warning lamp relay (in relay box) Headlight Wiring Diagram, without DRL for Nissan Sentra SE 2000 List of elements for Headlight Wiring Diagram, without DRL for Nissan Sentra SE 2000: 30 (w/ tach) (w/o tach) 1st 2nd Combination meter Combination switch Fog lamp switch Front foglight relay (in relay box) Fuse & fusible link box (on left side of engine compt) Fuse 39 15a Fuse 40 15a Fuse 43 15a G101 (right front of engine compt) G104 (left rear of engine compt) G201 (behind right side of dash) G202 (behind left side of dash) Hi beam ind Hot at all times Left front fog lamp Left head- lamp Lighting switch Low Low hi Off Pass Pnk Red Right front fog lamp Right head- lamp Theft warning light relay (in relay box)
HORN Horn Wiring Diagram for Nissan Sentra SE 2000 List of elements for Horn Wiring Diagram for Nissan Sentra SE 2000: 9 Anti-theft system Fuse & fusible link box (on left side of engine compt) Fuse 33 10a Horn Horn switch Horn relay (in relay box) Hot at all times Red Spiral cable
INSTRUMENT CLUSTER Instrument Cluster Wiring Diagram, with Tachometer for Nissan Sentra SE 2000 List of elements for Instrument Cluster Wiring Diagram, with Tachometer for Nissan Sentra SE 2000: 71 (a/t) (base of left "b" pillar) g308 (behind right side of dash) diode-2 (canada) (left rear of engine compt) g104 (or 28) (or 29) (right front of engine compartment) g101 (w/ multi-remote control) (w/o multi-remote control) 1.4w 1.4w abs ind 10l Abs actuator & electric unit (right rear of engine compt) Air bag Airbag diagnostic sensor unit (under center console) Brake Brake fluid level switch (in brake fluid reservoir) Canada Charge Combination meter Cruise Cruise control system Door Ecm (1.8l calif & 2.0l) pcm (1.8l except calif) (right rear of engine compt) Exterior light system Exterior lights system Fuel gauge Fuel lamp Fuel level sensor unit (in fuel tank) Fuse 10a Fuse block (under left side of dash) G131 (on intake manifold) G202 (behind left side of dash) G308 (base of left "b" pillar) G308 (base of of left "b" pillar) Headlamp system Hi beam ind Hot at all times Hot in on or start Illumination (5 bulbs) Interior lights system Left front door switch Left rear door switch Left turn ind M29 M30 Mil O/d off Oil Oil pressure switch Parking brake switch (at base of parking brake lever) Red Right front door switch Right rear door switch Right turn ind Seat belt buckle switch (in driver seat belt buckle) Seatbelt Set Smart entrance control unit (w/ multi- remote control) (behind left side of dash) Speed- ometer Starting/charging system Tach- ometer Temp. gauge Thermal transmitter Time control unit (w/o multi- remote control) (under left side of dash) Unified meter control unit (w/ odo/trip meter) Usa Vehicle speed sensor (on transaxle) Washer Washer fluid level switch (in washer fluid reservoir) Instrument Cluster Wiring Diagram, without Tachometer for Nissan Sentra SE 2000 List of elements for Instrument Cluster Wiring Diagram, without Tachometer for Nissan Sentra SE 2000: 55 (a/t) (base of left "b" pillar) g308 (behind right side of dash) diode-2 (canada) (left rear of engine compt) g104 (right front of engine compartment) g101 1.4w 10l Air bag Airbag diagnostic sensor unit (under center console) Brake Brake fluid level switch (in brake fluid reservoir) Canada Charge Combination meter Door Exterior lights system Fuel gauge Fuel lamp Fuel level sensor unit (in fuel tank) Fuse 10a Fuse block (under left side of dash) G131 (on intake manifold) G202 (behind left side of dash) G308 (base of left "b" pillar) Headlamp system Hi beam ind Hot at all times Hot in on or start Illumination (5 bulbs) Interior lights system Left front door switch Left rear door switch Left turn ind M29 M30 Mil O/d off Oil Oil pressure switch Parking brake switch (at base of parking brake lever) Powertrain control module (pcm) (behind right of engine compt) Right front door switch Right rear door switch Right turn ind Seat belt buckle switch (in driver seat belt buckle) Seatbelt Speed- ometer Temp. gauge Thermal transmitter Unified meter control unit (w/ odo/trip meter) Usa Vehicle speed sensor (on transaxle) Washer Washer fluid level switch (in washer fluid reservoir)
INTERIOR LIGHTS Courtesy Lamps Wiring Diagram, with Power Door Locks for Nissan Sentra SE 2000 List of elements for Courtesy Lamps Wiring Diagram, with Power Door Locks for Nissan Sentra SE 2000: 34 10q 12k Bat sav out Door Door sw Door sw (dr) Fuse 10a Fuse block (under left side of dash) G201 (behind right side of dash) G202 (behind left side of dash) G305 (at base of right "b" pillar) G308 (at base of left "b" pillar) Gnd Hot at all times Hot in on or start Ign sw Interior lamp Key sw Key switch L unlock sens Left front door lock actuator Left front door switch Left rear door switch Left vanity mirror Map lamp Off Red Right front door switch Right rear door switch Right vanity mirror Room lamp out Time control unit (under left side of dash) Trunk room lamp Trunk room lamp switch Courtesy Lamps Wiring Diagram, with Remote Control System for Nissan Sentra SE 2000 List of elements for Courtesy Lamps Wiring Diagram, with Remote Control System for Nissan Sentra SE 2000: 37 10q 12k Bat saver out Diode 4 (left "c" pillar) Door Door sw Door sw (dr) Fuse 10a Fuse & fusible link box (on left side of engine compt) Fuse block (under left side of dash) G201 (behind right side of dash) G202 (behind left side of dash) G305 (at base of right "b" pillar) G308 (at base of left "b" pillar) Gnd Hot at all times Hot in on or start Ign sw Interior lamp Key sw Key switch L unlock sens Left front door lock actuator Left front door switch Left rear door switch Left vanity mirror Map lamp Off Red Right front door switch Right rear door switch Right vanity mirror Room lamp out Smart entrance control unit (behind left side of dash) Trunk room lamp Trunk room lamp switch Trunk sw Courtesy Lamps Wiring Diagram, without Power Door Locks for Nissan Sentra SE 2000 List of elements for Courtesy Lamps Wiring Diagram, without Power Door Locks for Nissan Sentra SE 2000: 13 + closed Closed Door Fuse 10a Fuse block (under left side of dash) Hot at all times Interior lamp Left front door switch Left rear door switch Off Open Right front door switch Right rear door switch Instrument Illumination Wiring Diagram for Nissan Sentra SE 2000 List of elements for Instrument Illumination Wiring Diagram for Nissan Sentra SE 2000: 20 (w/ tach) (w/o tach) 16k 1st 2nd A/t device (illumi- nation) Air control (illumi- nation) Audio unit (illumi- nation) Cd changer (illumi- nation) Combination meter (illumi- nation) Fuse 38 10a Fuse block (under left side of dash) Fusible link & fuse box (on left side of engine compt) G201 (behind right side of dash) G202 (behind left side of dash) Hazard switch (illumi- nation) Hot at all times Illumination control switch Lighting switch (combination switch) Main power window & door lock/ unlock switch (illumi- nation) Off
POWER DISTRIBUTION Power Distribution Wiring Diagram (1 of 2) for Nissan Sentra SE 2000 List of elements for Power Distribution Wiring Diagram (1 of 2) for Nissan Sentra SE 2000: 52 (on left side of engine compt) fuse & fusible link box 10l 10q 11l 16k 1st 2nd Anti-lock brakes Anti-lock brakes, transmissions, cruise control, exterior lights Anti-theft, body computer Anti-theft, headlights, body computer Anti-theft, warning systems, interior lights, door locks, body computer Battery Circuit breaker Cooling fans Defogger, engine controls Door locks, anti-theft, warning systems, defogger, interior lights, body computer Door locks, power windows, body computer, power tops Engine controls Engine controls, transmissions, anti-theft, instrument cluster, interior lights, nats system Engine controls, transmissions, nats system Exterior lights Exterior lights, body computer Fuse 10a Fuse 15a Fuse 20a Fuse block (under left side of dash) Fusible link a 100a Fusible link b 80a Fusible link c 40a Fusible link d 30a Fusible link f 40a Fusible link g 40a Fusible link h 40a Fusible link i 40a Headlights Interior lights Interior lights, engine controls Interior lights, warning systems Lighting switch (combo- nation switch) Nca Off Red Sound systems Starting/ charging Starting/ charging, anti-theft, horns, body computer To accessory relay (diagram 2 of 2) To ignition relay (diagram 2 of 2) To ignition switch (diagram 2 of 2) To power socket relay (diagram 2 of 2) Trunk, tailgate, fuel doors system Warning systems, interior lights Power Distribution Wiring Diagram (2 of 2) for Nissan Sentra SE 2000 List of elements for Power Distribution Wiring Diagram (2 of 2) for Nissan Sentra SE 2000: 42 (behind left side of dash) g202 (behind right side of dash) g201 (diagram 1 of 2) 10k 12k 12l 13k A/c system Acc Accessory relay Anti-lock brakes Blower motor relay Cigarette lighter Engine controls Engine controls, defogger Engine controls, headlights Engine controls, transmissions, anti-theft, cruise control, warning systems, defogger, power windows, headlights, power tops, body computer, interior lights, trunk, tailgate, fuel doors system Exterior lights From fuse 12 d From fuse 3 (diagram 1 of 2) From fusible link c (diagram 1 of 2) From ignition e From ignition f Fuse 10a Fuse 15a Fuse 20a Fuse block (under left side of dash) Ignition relay Ignition switch Mirrors, sound system, anti-theft, body computer Off Pnk Power socket Power socket relay Relay (diagram 2 of 2) Start Starting/ charging Starting/ charging, engine controls, cooling fans, transmissions, cruise control, nats system To fuse 17 (diagram 2 of 2) To fuse 8 (diagram 2 of 2) Transmissions Wiper/ washer
POWER DOOR LOCKS Power Door Lock Wiring Diagram, with Remote Control System for Nissan Sentra SE 2000 List of elements for Power Door Lock Wiring Diagram, with Remote Control System for Nissan Sentra SE 2000: 40 10q Between lock full stroke and n Between unlock full stroke and n Circuit breaker (behind left side of dash) Data link connector (lower left side of dash) Door lock out Door sw Door unlk out Dr door sw Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse block (under left side of dash) G201 (behind right side of dash) G202 (behind left side of dash) G305 (at base of right "b" pillar) G308 (at base of left "b" pillar) Ground Hot at all times Key cyl sw (lk) Key cyl sw (ulk) Key sw Key switch Left door key cylinder switch Left front door lock actuator Left front door switch Left rear door lock actuator Left rear door switch Lh unlck sensor Lock Main power window & door lock/ unlock switch Red Rh unlck sensor Right door key cylinder switch Right door lock/ unlock switch Right front door lock actuator Right front door switch Right rear door lock actuator Right rear door switch Smart entrance control unit (behind left side of dash) Unlock Power Door Lock Wiring Diagram, without Remote Control System for Nissan Sentra SE 2000 List of elements for Power Door Lock Wiring Diagram, without Remote Control System for Nissan Sentra SE 2000: 32 10q Bat Circuit breaker (behind left side of dash) Door sw Dr door sw Fuse 10a Fuse block (under left side of dash) G201 (behind right side of dash) G202 (behind left side of dash) G305 (at base of right "b" pillar) G308 (at base of left "b" pillar) Ground Hot at all times Key sw Key switch Left front door lock actuator Left front door switch Left rear door lock actuator Left rear door switch Lock Lock output Main power window & door lock/ unlock switch Nca Red Right door lock/ unlock switch Right front door lock actuator Right front door switch Right rear door lock actuator Right rear door switch Time control unit (under left side of dash) Unlock Unlock output
POWER MIRRORS Power Mirror Wiring Diagram for Nissan Sentra SE 2000 List of elements for Power Mirror Wiring Diagram for Nissan Sentra SE 2000: 13 12l Change over switch Door mirror remote control switch Fuse 1 10a Fuse block (under left side of dash) G201 (right side of dash) G202 (left side of dash) Hot in acc or on Left side door mirror Left/right motor Mirror switch Right side door mirror Up/down motor
POWER TOP/SUNROOF Power Top/Sunroof Wiring Diagrams for Nissan Sentra SE 2000 List of elements for Power Top/Sunroof Wiring Diagrams for Nissan Sentra SE 2000: 15 (left front of roof) 12k Circuit breaker (on fuse block) Dn/ open Fuse 10a Fuse block (behind left side of dash) G902 Gnd Hot at all times Hot in on or start Sun roof motor assembly (in front of sunroof) Sun roof switch Tilt down/slide open Tilt up/ slide close Up/ close
POWER WINDOWS Power Window Wiring Diagram for Nissan Sentra SE 2000 List of elements for Power Window Wiring Diagram for Nissan Sentra SE 2000: 28 12k Circuit breaker (on fuse block) Express down circuit Front left Front sw Fuse 10a Fuse block (behind left side of dash) G201 (right side of dash) G202 (left side of dash) Hot at all times Hot in on or start Left Left front power window motor Left rear power window motor Left rear power window switch Lock Lock sw Main power window & door lock/ unlock switch Nca Power window relay (on fuse block) Rear sw Red Right Right front power window motor Right front power window switch Right rear power window motor Right rear power window switch Unlock
RADIO Radio Wiring Diagrams for Nissan Sentra SE 2000 List of elements for Radio Wiring Diagrams for Nissan Sentra SE 2000: 39 acc lh fr sp (-) 12l Amp lh rr sp (-) Audio in Audio unit Batt Batt illum control lighting Cd player (if equipped) Fuse & fusible link box (on left side of engine compt) Fuse 1 10a Fuse 32 15a Fuse block (under left side of dash) G308 (at base of left "b" pillar) Ground Hot at all times Hot in on or acc Illum control Interior lights system Left door speaker Left pillar tweeter (w/ premium audio system) Left rear speaker Lh fr sp (+) Lh rr sp (+) Lh rr sp (-) Lighting sw Nca Pnk Red Rh fr sp (-) rh fr sp (+) Rh rr sp (+) Rh rr sp (+) Rh rr sp (-) Right door speaker Right pillar tweeter (w/ premium audio system) Right rear speaker Rod antenna Subwoofer amplifier (w/ premium audio system) Subwoofer speaker
SHIFT INTERLOCKS Shift Interlock Wiring Diagram for Nissan Sentra SE 2000 List of elements for Shift Interlock Wiring Diagram for Nissan Sentra SE 2000: 16 11l 12k Fuse 10 10a Fuse 2 10a Fuse block (under left side of dash) G201 (behind right side of dash) G202 (behind left side of dash) Hot at all times Hot in on or start Nca Park position switch Red Relay Shift lock (a/t device) (at base of selector lever) Shift lock solenoid Stoplight switch (on brake pedal bracket)
STARTING/CHARGING Charging Wiring Diagram for Nissan Sentra SE 2000 List of elements for Charging Wiring Diagram for Nissan Sentra SE 2000: 15 (w/ tachometer) (w/o tachometer) Battery Charge warning lamp Combination meter Fuse & fusible link box (at left front of engine compt) Fuse 10a Fuse 33 10a Fuse a 100a Fuse block (under left side of dash) G134 (top of engine) Generator Hot in on or start Nca Starter motor Starting Wiring Diagram, A/T for Nissan Sentra SE 2000 List of elements for Starting Wiring Diagram, A/T for Nissan Sentra SE 2000: 20 (2000) + s (2001) (w/ ascd) (w/o ascd) Acc Battery Cruise control system (w/ ascd) Fuse & fusible link box (at left front of engine compt) Fuse 20 10a Fuse block (under left side of dash) Fusible link c 40a G131 (on intake manifold) Hot in on or start Ignition switch Nca Off Park/ neutral position switch (on left rear of transaxle) Park/neutral position relay (in relay box) Start Starter motor Starting Wiring Diagram, M/T for Nissan Sentra SE 2000 List of elements for Starting Wiring Diagram, M/T for Nissan Sentra SE 2000: 17 (2001) s + (2000) Acc Battery Clutch interlock relay (in relay box) Clutch interlock switch (on clutch pedal bracket) Fuse & fusible link box (at left front of engine compt) Fuse 20 10a Fuse block (under left side of dash) Fusible link c 40a G104 (left rear of engine compt) Hot in on or start Ignition switch Nca Off Start Starter motor
SUPPLEMENTAL RESTRAINTS Supplemental Restraint Wiring Diagram for Nissan Sentra SE 2000 List of elements for Supplemental Restraint Wiring Diagram for Nissan Sentra SE 2000: 63 (at base of left "b" pillar) g308 (at base of right "b" pillar) g305 (behind left side of dash) g202 A/b w/l Agr + Agr - Air bag diagnosis sensor unit (below center floor console) Air bag warning lamp As a/b inf + As a/b inf - B10 B11 Closed Combination meter Data link connector (dlc) (partial) (under left side of dash) Dgr + Dgr - Door switch Dr a/b inf + Dr a/b inf - Driver air bag module Fasten Front passenger air bag module Fuse 10a Fuse block (behind left side of dash) Ground Hot in on or start Ignition Left front door switch (2000 model) Left front seat belt pretensioner Left front side air bag module Left seat belt buckle switch (2000 model) Left side air bag satellite sensor (if equipped) Lf preten + Lf preten - Ls a/b inf + Ls a/b inf - M29 M30 M34 Nca Nca (at base of left "b" pillar) g308 Open Pnk Red Rf preten + Rf preten - Right front seat belt pretensioner Right front side air bag module Right side air bag satellite sensor (if equipped) Rs a/b inf + Rs a/b inf - Sat lh + Sat lh - Sat rh + Sat rh - Seat belt ind Seat belt indicator (2000 model) Seat belt sw Spiral cable Un- fasten W/ tachometer W/o tachometer
TRANSMISSION
1.8L 1.8L, A/T Wiring Diagram, California for Nissan Sentra SE 2000 List of elements for 1.8L, A/T Wiring Diagram, California for Nissan Sentra SE 2000: 84 (behind left side of dash) g202 (left side of engine compart) dropping resistor (on left side of transaxle) park/neutral position switch 1 pos 1.8l 10l 11l 2 pos 2.0l A/t device (o/d switch) A/t fluid temp sensor Ascd Ascd control unit (behind left side of dash) Atck Automatic transaxle Avcc Batt Brk sw Closed throttle Clsd sw Combination meter D pos Data in Data link connector (behind Data out Dt1 Dt2 Dt3 Dt4 Dt5 Duty sol Eccs control module (ecm) (on right of firewall) Engine coolant temperature sensor (left side of engine) Exterior lights system Fl temp Fuse 10a Fuse block (under left side of dash) G131 (on intake manifold) G201 (right side of dash) Gnd Gnd-a Hot at all times Hot in on or start Hot in start Left side of dash) Line press sol valve Lu duty Mem b/u Nca O/d off Obd2 Od ind Od off Over- run clutch sol Ovr/c P/n pos Pwr Pwr sens R pos Red Revolution sensor (right rear of transaxle) Sens gnd Shift sol valve a Shift sol valve b Sp sens Ssa Ssb Stoplamp switch (on brake pedal bracket) Tach Tacho Tcc sol valve Th/sen Throttle position sensor (on throttle body) Transmission control module (tcm) (behind right kick panel) Tvo Vehicle speed sensor Vig Vsp Vsp-2 Vss in Vss out W/tmp Wo sw Wot 1.8L, A/T Wiring Diagram, Except California for Nissan Sentra SE 2000 List of elements for 1.8L, A/T Wiring Diagram, Except California for Nissan Sentra SE 2000: 82 (behind right side of dash) g201 (on intake manifold) (on intake manifold) g131 1 sw 2 sw A/t fluid temp sensor Adjsw Ascd 4th Ascd control unit (behind left side of dash) Ascd cr Atf Automatic transaxle Avcc Batt Closed throttle Combination meter Cr lamp D sw Data link connector (lower left side of dash) Dropping resistor Engine coolant temperature sensor Full Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse block (under left side of dash) G131 G131 (on intake manifold) G202 (behind left side of dash) Gnd Gnd-a Gnd-c Gnd-e Hot at all times Hot in on or start Hot in start Idle Ignsw J/c 2 (right J/c 3 (right Kline Line press sol valve Lu duty Nca Neut O/d cncl O/d off Od-c Overdrive control switch Overrun clutch sol valve Ovr/c P-lamp Park/neutral position switch (on left side of transaxle) Pl duty Powertrain control module (pcm) (right rear of engine compt) Pwr R pos Rear of engine compt) Red Revolution sensor Scirx Scitx Shift a Shift b Shift sol valve a Shift sol valve b Stsw Tach Tacho Tcc sol valve Throttle position sensor (on throttle body) Tvo Vehicle speed sensor Vign Vsp1 Vsp2 Vss in Vss out W/ nvis W/ tach W/o nvis W/o tach Wide open throttle
2.0L 2.0L, A/T Wiring Diagram for Nissan Sentra SE 2000 List of elements for 2.0L, A/T Wiring Diagram for Nissan Sentra SE 2000: 84 (behind left side of dash) g202 (left side of engine compart) dropping resistor (on left side of transaxle) park/neutral position switch 1 pos 1.8l 10l 11l 2 pos 2.0l A/t device (o/d switch) A/t fluid temp sensor Ascd Ascd control unit (behind left side of dash) Atck Automatic transaxle Avcc Batt Brk sw Closed throttle Clsd sw Combination meter D pos Data in Data link connector (behind Data out Dt1 Dt2 Dt3 Dt4 Dt5 Duty sol Eccs control module (ecm) (on right of firewall) Engine coolant temperature sensor (left side of engine) Exterior lights system Fl temp Fuse 10a Fuse block (under left side of dash) G131 (on intake manifold) G201 (right side of dash) Gnd Gnd-a Hot at all times Hot in on or start Hot in start Left side of dash) Line press sol valve Lu duty Mem b/u Nca O/d off Obd2 Od ind Od off Over- run clutch sol Ovr/c P/n pos Pwr Pwr sens R pos Red Revolution sensor (right rear of transaxle) Sens gnd Shift sol valve a Shift sol valve b Sp sens Ssa Ssb Stoplamp switch (on brake pedal bracket) Tach Tacho Tcc sol valve Th/sen Throttle position sensor (on throttle body) Transmission control module (tcm) (behind right kick panel) Tvo Vehicle speed sensor Vig Vsp Vsp-2 Vss in Vss out W/tmp Wo sw Wot
TRUNK, TAILGATE, FUEL DOOR Trunk Release Wiring Diagram, with A/T for Nissan Sentra SE 2000 List of elements for Trunk Release Wiring Diagram, with A/T for Nissan Sentra SE 2000: 13 Door locks system Engine controls system Fuse 6 10a Fuse block (under left side of dash) G131 (on intake manifold) G201 (behind right side of dash) G202 (behind left side of dash) Hot at all times Park/ neutral position switch (on left side of transaxle) Red Trunk lid opener actuator Trunk lid opener relay 1 Trunk lid opener switch Trunk Release Wiring Diagram, with M/T for Nissan Sentra SE 2000 List of elements for Trunk Release Wiring Diagram, with M/T for Nissan Sentra SE 2000: 18 12k Door locks system Engine controls system Fuse 10 10a Fuse 6 10a Fuse block (under left side of dash) G104 (left rear of engine compt) G131 (on intake manifold) G201 (behind right side of dash) G202 (behind left side of dash) Hot at all times Hot in on or start Neutral position switch Red Trunk lid opener actuator Trunk lid opener relay 1 Trunk lid opener relay 2 Trunk lid opener switch
WARNING SYSTEMS Warning System Wiring Diagrams, with Remote Control System for Nissan Sentra SE 2000 List of elements for Warning System Wiring Diagrams, with Remote Control System for Nissan Sentra SE 2000: 32 10q e103 1st 2nd 5u e24 Air bag diagnosis sensor unit (under center console) Batt Buckle switch Combination meter Combination switch (lighting switch) Door sw (dr) E103 Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse block (under left side of dash) G201 (behind right side of dash) G202 (behind left side of dash) G305 (at base of right "b" pillar) G308 (at base of left "b" pillar) Ground Hot at all times Hot in on or start Ignition sw Key switch Left front door switch Light switch M1 12k Off Red Seat belt ind. Seatbelt Seatbelt buckle switch (in driver seatbelt buckle) Smart entrance control unit (behind left side of dash) Warning System Wiring Diagrams, without Remote Control System for Nissan Sentra SE 2000 List of elements for Warning System Wiring Diagrams, without Remote Control System for Nissan Sentra SE 2000: 35 (w/ power door locks & w/o multi- remote control system) (w/o power door locks) 10q e103 1st 2nd 5u e24 8l m2 Air bag diagnosis sensor unit (under center console) Batt Buckle switch Combination meter Combination switch (lighting switch) Door sw (dr) E103 Fuse & fusible link box (on left side of engine compt) Fuse 10a Fuse block (under left side of dash) G201 (behind right side of dash) G202 (behind left side of dash) G305 (at base of right "b" pillar) G308 (at base of left "b" pillar) Ground Hot at all times Hot in on or start Ignition sw Key switch Left front door switch Light switch M1 12k Off Red Seat belt ind. Seatbelt Seatbelt buckle switch (in driver seatbelt buckle) Time control unit (under left side of dash)
WIPER/WASHER 2-Speed Wiper/Washer Wiring Diagram for Nissan Sentra SE 2000 List of elements for 2-Speed Wiper/Washer Wiring Diagram for Nissan Sentra SE 2000: 10 Combination switch (front wiper switch) Front washer motor Front wiper motor Fuse 25 20a Fuse block (under left side of dash) G101 (right front of engine compt) G104 (left rear of engine compt) Hot in on or start Off Wash Intermittent Wiper/Washer Wiring Diagram for Nissan Sentra SE 2000 List of elements for Intermittent Wiper/Washer Wiring Diagram for Nissan Sentra SE 2000: 19 Auto stop Combination switch (front wiper switch) Front washer motor Front wiper motor Fuse 25 20a Fuse block (under left side of dash) G101 (right front of engine compt) G104 (left rear of engine compt) Gnd Hot in on or start Ign Int Int sw Int vr Off Out- put Variable intermittent wiper volume Wash Wash sw
