Diagram sections — 28 (58 total)
AIR CONDITIONING ANTI-LOCK BRAKES ANTI-THEFT COMPUTER DATA LINES COOLING FAN CRUISE CONTROL DEFOGGERS ENGINE PERFORMANCE EXTERIOR LIGHTS GROUND DISTRIBUTION HEADLIGHTS HORN INSTRUMENT CLUSTER INTERIOR LIGHTS MEMORY SYSTEMS POWER DISTRIBUTION POWER DOOR LOCKS POWER MIRRORS POWER SEATS POWER TOP/SUNROOF POWER WINDOWS RADIO SHIFT INTERLOCKS STARTING/CHARGING SUPPLEMENTAL RESTRAINTS TRANSMISSION TRUNK, TAILGATE, FUEL DOOR WIPER/WASHER
AIR CONDITIONING
1.8L 1.8L Turbo, Manual A/C Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for 1.8L Turbo, Manual A/C Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 41 (beside fuse/relay panel) g202 (not used) (on eightfold auxiliary relay panel) 1995 vftc c A/c clutch A/c cut-off control module (on thirteenfold auxiliary relay panel) A/c diode A/c pressure switch (on right side of a/c condenser, below right headlight) A/c switch Ambient temperature switch Coolant fan Coolant fan control (fc) a/c relay (on thirteenfold auxiliary relay panel) Coolant fan control (fc) series resistance (on left front under side of longitudinal chassis member) Coolant fan control (fc) thermal switch (on lower left side of radiator) Defogger system Eightfold auxiliary relay panel (under left side of dash) First speed coolant fan control relay (on eightfold auxiliary relay panel) Fresh air blower (behind right side of dash, on hvac housing) Fresh air blower series resistance with fuse Fresh air blower switch Fresh/ recirc switch Fresh/recirculating air door servo motor Fuse 30a Fuse 40a Fuse 5a Fuse panel (under left side of dash) G202 (beside fuse/ relay panel) G202 (beside fuse/relay panel) Heater-a/c control panel Hot at all times Hot in acc or run Hot w/ load reduction relay energized Instrument cluster Interior lights system Motronic engine control module (ecm) (in protective box, in left rear corner of engine compartment) Outside air temp sensor (front of a/c con- denser) Second speed coolant fan control relay T121 T32b T6g T8a Automatic A/C Wiring Diagram (1 of 2) for Volkswagen Passat GLS 4Motion 2000 List of elements for Automatic A/C Wiring Diagram (1 of 2) for Volkswagen Passat GLS 4Motion 2000: 26 (inside de- froster grille) sunlight photo sensor (not used) (on hvac housing) Air flow flap motor & position sensor Central flap motor & position sensor Climatronic control module Connector (dlc) (under left side of dash) Data link Defogger system Footwell/defroster flap Fuse 10a Fuse 30a Fuse panel (under left side of dash) G202 (left side of dash) Hot in run and start Hot w/ load reduction relay energized Instrument cluster Interior lights system Motor & position sensor (on hvac housing) Nca T12 T16a T16b T18 T32b Temp regulator flap motor & position sensor Automatic A/C Wiring Diagram (2 of 2) for Volkswagen Passat GLS 4Motion 2000 List of elements for Automatic A/C Wiring Diagram (2 of 2) for Volkswagen Passat GLS 4Motion 2000: 24 (bottom of hvac unit) center outlet temperature sender (in front of a/c condenser) outside air temperature sensor (on hvac unit) floor outlet temperature sender (right side of plenim) fresh air intake duct temperature sensor A/c clutch A/c clutch relay (on thirteenfold auxiliary relay panel) A/c pressure switch (on right side of a/c condenser, below right headlight) After-run coolant pump Coolant fan Coolant fan control (fc) thermal switch (on lower left side of radiator) Coolant fc (fan control) control module Eightfold auxiliary relay panel (under left side of dash) Fresh air blower control module (under right side of dash) Fuse 40a Fuse 5a G202 (beside fuse/ relay panel) G202 (beside fuse/relay panel) G202 (left side of dash) Hot at all times Hot in acc or run Motronic engine control module (ecm) (in protective box, in left rear corner of engine compt) T141 T2p T6p
2.8L 2.8L, Manual A/C Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for 2.8L, Manual A/C Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 39 (beside fuse/relay panel) g202 A/c clutch A/c cut-off control module (on thirteenfold auxiliary relay panel) A/c diode A/c pressure switch (on right side of a/c condenser, below right headlight) A/c switch After-run coolant pump Ambient temperature switch Coolant fan Coolant fan control (fc) a/c relay (on thirteenfold auxiliary relay panel) Coolant fan control (fc) thermal switch (on lower left side of radiator) Coolant fc (fan control) control module Defogger system Eightfold auxiliary relay panel (under left side of dash) Fresh air blower (behind right side of dash, on hvac housing) Fresh air blower series resistance with fuse Fresh air blower switch Fresh/ recirc switch Fresh/recirculating air door servo motor Fuse 30a Fuse 40a Fuse 5a Fuse panel (under left side of dash) G202 (beside fuse/ relay panel) G202 (beside fuse/relay panel) Heater-a/c control panel Hot at all times Hot in acc or run Hot w/ load reduction relay energized Instrument cluster Interior lights system Motronic engine control module (ecm) (in protective box, in left rear corner of engine compartment) Outside air temp sensor (front of a/c con- denser) T121 T2p T32b T6g T6p T8a Automatic A/C Wiring Diagram (1 of 2) for Volkswagen Passat GLS 4Motion 2000 List of elements for Automatic A/C Wiring Diagram (1 of 2) for Volkswagen Passat GLS 4Motion 2000: 26 (inside de- froster grille) sunlight photo sensor (not used) (on hvac housing) Air flow flap motor & position sensor Central flap motor & position sensor Climatronic control module Connector (dlc) (under left side of dash) Data link Defogger system Footwell/defroster flap Fuse 10a Fuse 30a Fuse panel (under left side of dash) G202 (left side of dash) Hot in run and start Hot w/ load reduction relay energized Instrument cluster Interior lights system Motor & position sensor (on hvac housing) Nca T12 T16a T16b T18 T32b Temp regulator flap motor & position sensor Automatic A/C Wiring Diagram (2 of 2) for Volkswagen Passat GLS 4Motion 2000 List of elements for Automatic A/C Wiring Diagram (2 of 2) for Volkswagen Passat GLS 4Motion 2000: 24 (bottom of hvac unit) center outlet temperature sender (in front of a/c condenser) outside air temperature sensor (on hvac unit) floor outlet temperature sender (right side of plenim) fresh air intake duct temperature sensor A/c clutch A/c clutch relay (on thirteenfold auxiliary relay panel) A/c pressure switch (on right side of a/c condenser, below right headlight) After-run coolant pump Coolant fan Coolant fan control (fc) thermal switch (on lower left side of radiator) Coolant fc (fan control) control module Eightfold auxiliary relay panel (under left side of dash) Fresh air blower control module (under right side of dash) Fuse 40a Fuse 5a G202 (beside fuse/ relay panel) G202 (beside fuse/relay panel) G202 (left side of dash) Hot at all times Hot in acc or run Motronic engine control module (ecm) (in protective box, in left rear corner of engine compt) T141 T2p T6p
ANTI-LOCK BRAKES Anti-lock Brake Wiring Diagrams, with Traction Control for Volkswagen Passat GLS 4Motion 2000 List of elements for Anti-lock Brake Wiring Diagrams, with Traction Control for Volkswagen Passat GLS 4Motion 2000: 47 13a Abs control module (left front inner fender panel) Abs return flow pump Abs return flow pump relay Abs solenoid valve relay Abs warning ind Anti-slip control switch Brakelight switch (below left side of dash) Climatronic control module Control module with indicator unit Data link connector Fuse 10a Fuse 50a Fuse panel (under left side of dash) G102 (on hydraulic unit) G202 (behind left side of dash) Hot at all times Hot in on & start Instrument cluster Interior lights system Left front abs inlet valve Left front abs outlet valve Left front abs wheel speed sensor (on front of left front wheel bearing assembly) Left front traction control outlet valve Left front traction control switch-over valve Left rear abs inlet valve Left rear abs outlet valve Left rear abs wheel speed sensor (on back of left rear wheel bearing assembly) Motronic engine control module (left rear corner of engine compt) Right front abs inlet valve Right front abs outlet valve Right front abs wheel speed sensor (on front of right front wheel bearing assembly) Right front traction control outlet valve Right front traction control switch-over valve Right rear abs inlet valve Right rear abs outlet valve Right rear abs wheel speed sensor (on back of right rear wheel bearing assembly) T16 T18 T32a T32b T80 T88 Thirteen fold auxiliary relay panel (under left side of dash) Traction control ind Transmission control module (passenger's side floor cavity) W/ climatronic air conditioning Anti-lock Brake Wiring Diagrams, without Traction Control for Volkswagen Passat GLS 4Motion 2000 List of elements for Anti-lock Brake Wiring Diagrams, without Traction Control for Volkswagen Passat GLS 4Motion 2000: 39 13a Abs control module (left front inner fender panel) Abs return flow pump Abs return flow pump relay Abs solenoid valve relay Abs warning ind Brakelight switch (below left side of dash) Climatronic control module Control module with indicator unit Data link connector Fuse 10a Fuse 50a Fuse panel (under left side of dash) G102 (on hydraulic unit) Hot at all times Hot in on & start Instrument cluster Left front abs inlet valve Left front abs outlet valve Left front abs wheel speed sensor (on front of left front wheel bearing assembly) Left front traction control outlet valve Left front traction control switch-over valve Left rear abs inlet valve Left rear abs outlet valve Left rear abs wheel speed sensor (on back of left rear wheel bearing assembly) Right front abs inlet valve Right front abs outlet valve Right front abs wheel speed sensor (on front of right front wheel bearing assembly) Right front traction control outlet valve Right front traction control switch-over valve Right rear abs inlet valve Right rear abs outlet valve Right rear abs wheel speed sensor (on back of right rear wheel bearing assembly) T16 T18 T32a T32b Thirteen fold auxiliary relay panel (under left side of dash) W/ climatronic air conditioning
ANTI-THEFT Anti-theft Wiring Diagram (1 of 2) for Volkswagen Passat GLS 4Motion 2000 List of elements for Anti-theft Wiring Diagram (1 of 2) for Volkswagen Passat GLS 4Motion 2000: 45 (lower left "b" pillar) g308 (not used) 14a 38a Alarm horn (left front of luggage compartment) Antenna Central locking warning light (safe) Circuit breaker 30a Comfort system central control module (mounted on floorpan in protective box, under driver's seat & carpet) Computer data lines system Control module Decklid central locking motor (in rear lid lock/ latch mechanism) Defogger system Driver's side central locking lock unit Driver's side door control module (part of master power window switch assembly, on driver's door) Driver's side interior lock switch Eight fold auxiliary relay panel (under left side of dash) Exterior lights system Fuse 10a Fuse 15a Fuse 5a Fuse panel (under left side of dash) G200 (lower left "a" pillar) G203 (lower right "a" pillar) Hood alarm switch (part of hood latch) Hot at all times Hot in on or start Ignition switch Instrument cluster Instrument cluster system Interior lights system Interior lights system (luggage compt light switch) Interior lights system, mirrors system, trunk, tailgate, fuel doors system Key switch Nca Power tops system Radio, interior lights system Rear lid unlocked warning light Red Starting/charging system T15 T23 T29a T32a Trunk, tailgate, fuel doors system Anti-theft Wiring Diagram (2 of 2) for Volkswagen Passat GLS 4Motion 2000 List of elements for Anti-theft Wiring Diagram (2 of 2) for Volkswagen Passat GLS 4Motion 2000: 18 G203 (lower right "a" pillar) G305 (lower right "b" pillar) G308 (lower left "b" pillar) G308 (sedan) (lower left "b" pillar) G909 (wagon) (center rear of roof) Interior lights system Left rear central locking lock unit Left rear door control module (part of power window motor assembly, in left rear door) Mirrors system Passenger's side central locking lock unit Passenger's side door control module (part of power window motor assembly, in passenger's front door) Passenger's side interior lock switch Right rear central locking lock unit Right rear door control module (part of power window motor assembly, in right rear door) T18a T18b T29b Trunk lid central locking switch (in rear lid with lock/ latch mechanism)
COMPUTER DATA LINES Computer Data Lines for Volkswagen Passat GLS 4Motion 2000 List of elements for Computer Data Lines for Volkswagen Passat GLS 4Motion 2000: 23 (behind left side of dash) g202 12a Abs control module (left front inner fender panel) Air bag control module (mounted on floor, in front of center console) Climatronic control module Comfort system central control module (under driver's seat) Data bus on board diagnostic interface Data link connector (under left side of dash) Fuse 10a Fuse panel (under left side of dash) Hot at all times Hot in on or start Instrument cluster Memory seat control module Motronic engine control module (ecm) (left rear corner of engine compt) Nca Radio T12 T23 T31 T32a T32b Transmission control module (on passenger's side floor cavity)
COOLING FAN
1.8L 1.8L Turbo, Cooling Fan Wiring Diagram, Manual A/C for Volkswagen Passat GLS 4Motion 2000 List of elements for 1.8L Turbo, Cooling Fan Wiring Diagram, Manual A/C for Volkswagen Passat GLS 4Motion 2000: 15 A/c pressure switch (right side of a/c condenser) A/c system All times Coolant fan Coolant fan control relay (in 13th fold aux relay panel) Coolant fan control series resistor (left front underside of longitudinal chassis member) Coolant fan control thermal switch (lower left side of radiator) Eight fold auxiliary relay panel First speed coolant fan control relay Fuse 40a Fuse 5a G202 (beside fuse/ relay panel) Hot at Hot in on Second speed coolant fan control relay Cooling Fan Wiring Diagram, Auto A/C for Volkswagen Passat GLS 4Motion 2000 List of elements for Cooling Fan Wiring Diagram, Auto A/C for Volkswagen Passat GLS 4Motion 2000: 15 A/c pressure switch (on right side of a/c condenser, below right headlight) After- run coolant pump Climatronic control module Coolant fan Coolant fan control module Coolant fan control thermal switch (on lower left side of radiator) Eightfold auxiliary relay panel (under left side of dash) Fuse 40a Fuse 5a G202 (beside fuse/relay panel) Hot at all times Hot in acc or run T16a T2p T6p
2.8L 2.8L, Cooling Fan Wiring Diagram, Manual A/C for Volkswagen Passat GLS 4Motion 2000 List of elements for 2.8L, Cooling Fan Wiring Diagram, Manual A/C for Volkswagen Passat GLS 4Motion 2000: 16 (beside fuse/ relay panel) g202 A/c pressure switch (on right side of a/c condenser, below right headlight) A/c system After- run coolant pump Coolant fan Coolant fan control module Coolant fan control relay (in 13th fold aux relay panel) Coolant fan control thermal switch (on lower left side of radiator) Eightfold auxiliary relay panel (under left side of dash) Fuse 40a Fuse 5a G202 (beside fuse/relay panel) Hot at all times Hot in acc or run T2p T6p Cooling Fan Wiring Diagram, Auto A/C for Volkswagen Passat GLS 4Motion 2000 List of elements for Cooling Fan Wiring Diagram, Auto A/C for Volkswagen Passat GLS 4Motion 2000: 15 A/c pressure switch (on right side of a/c condenser, below right headlight) After- run coolant pump Climatronic control module Coolant fan Coolant fan control module Coolant fan control thermal switch (on lower left side of radiator) Eightfold auxiliary relay panel (under left side of dash) Fuse 40a Fuse 5a G202 (beside fuse/relay panel) Hot at all times Hot in acc or run T16a T2p T6p
CRUISE CONTROL Cruise Control Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Cruise Control Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 25 13a 31a A/t Brake- light switch (below left side of dash, on pedal cluster) Cluster Clutch vacuum vent valve switch (m/t) (below left side of dash, on pedal cluster) Control module Cruise control module (above glove box) Cruise control switch Cruise control vacuum pump Fuse 10a Fuse 15a Fuse panel (under left side of dash) G202 (behind left side of dash) Hot at all times Hot in on or start Instrument M/t Nca Off Off/ save Res T32a Transmission control module (tcm) (on passenger's side floor cavity) Vacuum vent valve brake switch (a/t) (below left side of dash, on pedal cluster)
DEFOGGERS Defogger Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Defogger Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 28 (mounted on floorpan in protective box, under driver's seat & carpet) comfort system central control module 26a Computer data lines system Defogger heating element Door locks system Driver's side door control module (in door) Driver's side heated outside mirror Fuse 30a Fuse 5a Fuse panel (under left side of dash) G202 (behind left side of dash) G311 (below rear shelf) G406 (in right rear of hatch door) Heated rear window Hot in on or start Hot in on, from load reduction relay Illum- ination lamp Interior lights system Mirror defogger switch Motronic engine control module (left rear corner of engine compt) Off On indicator Passenger's side door control module (in door) Passenger's side heated outside mirror Power mirror switch Rear window defogger switch Sedan Wagon
ENGINE PERFORMANCE
1.8L 1.8L Turbo, Engine Performance Wiring Diagrams (1 of 3) for Volkswagen Passat GLS 4Motion 2000 List of elements for 1.8L Turbo, Engine Performance Wiring Diagrams (1 of 3) for Volkswagen Passat GLS 4Motion 2000: 36 (left rear of engine compt) (not used) (pins 10-20 not used) (pins 22-24 not used) (pins 6-8 not used) A/c system Accelerator pedal position sensors 1 & 2 (in pedal assembly) Air bag control module Bat(30) Cruise control system Data link connector Defogger system Evaporative emission canister purge regulator valve (right side of engine compt, next to air cleaner housing) Fuel pump relay Fuse 15a Fuse bracket (on battery cover) Fuse panel (under left side of dash) G104 Heated oxygen sensor (ho2s) (in catalytic converter inlet, near turbocharger) Hot at all times Ignition switch Leak detection pump (in right rear wheelwell, behind plastic liner) Lock Mass airflow sensor (inside air cleaner housing) Motronic engine control module (in protective box, in left rear corner of engine compartment) Nca Oxygen sensor (o2s) (behind catalytic converter) Red Relay panel Run S2/5 S3/3 S3/4 S3/6 Secondary air pump fuse 40a Start 1.8L Turbo, Engine Performance Wiring Diagrams (2 of 3) for Volkswagen Passat GLS 4Motion 2000 List of elements for 1.8L Turbo, Engine Performance Wiring Diagrams (2 of 3) for Volkswagen Passat GLS 4Motion 2000: 21 Engine speed (rpm) sensor (left rear of cylinder block) Fuel pump Fuse 15a Fuse 20a Fuse panel G104 (left rear of engine compt) Instrument cluster Knock sensor 1 (on left front of engine block) Knock sensor 2 (on left rear of engine block) Nca Oil level indicator light Oil pressure warning light Power accelerator activation fault light Red Secondary air injection pump motor Secondary air injection pump relay (in control module housing, near master cylinder) Secondary air injection solenoid valve (beneath intake manifold, on bracket) T32a/25 T32a/3 T32b/19 T32b/20 1.8L Turbo, Engine Performance Wiring Diagrams (3 of 3) for Volkswagen Passat GLS 4Motion 2000 List of elements for 1.8L Turbo, Engine Performance Wiring Diagrams (3 of 3) for Volkswagen Passat GLS 4Motion 2000: 25 (beneath intake manifold, on bracket) turbocharger recirculating valve (not used) (on front of valve cover) (on intake manifold, near throttle body) intake air temperature (rear side of cyl head) engine coolant temperature sensor (right front corner of engine compt) wastegate bypass regu- lator valve Abs system Brake- light switch (on pedal cluster) Camshaft position sensor (on front of cylinder head, behind timing belt cover) Clutch vacuum vent valve switch (below left side of dash, on pedal cluster) Cruise control system Fuel injectors Fuse 10a Fuse 7.5a Fuse panel (behind left side of dash) G104 (left rear of engine compt) G134 Hot at all times Ignition coils Manifold absolute pressure sensor/ intake air temp sensor Motronic engine control module (in protective box, in left rear corner of engine compt) Nca Red Throttle valve control module (on throttle body) To spark plug
2.8L 2.8L, Engine Performance Wiring Diagrams (1 of 3) for Volkswagen Passat GLS 4Motion 2000 List of elements for 2.8L, Engine Performance Wiring Diagrams (1 of 3) for Volkswagen Passat GLS 4Motion 2000: 32 (left rear of engine compt) g104 (not used) (pins 14-24 not used) (pins 7-9 not used) A/c system Accelerator pedal position sensors 1 & 2 (in pedal assembly) Air bag control module Bat(30) Cruise control system Evaporative emission (evap) canister purge regulator valve (right side of eng compt) Fuel pump relay Fuse 20a Fuse bracket (on battery cover) Fuse panel Heated oxygen sensor (ho2s) (behind left cyl head, in exhaust manifold) Hot at all times Ignition switch Leak detection pump (ldp) (in left rear wheelhouse) Lock Mass airflow (maf) sensor (attached to air cleaner housing) Motronic engine control module (in protective box, in left rear corner of engine compt) Nca Oxygen sensor (o2s) (behind right of catalytic converter) Red Relay panel Run S2/5 S3/3 S3/4 S3/6 Secondary air pump fuse 40a Start 2.8L, Engine Performance Wiring Diagrams (2 of 3) for Volkswagen Passat GLS 4Motion 2000 List of elements for 2.8L, Engine Performance Wiring Diagrams (2 of 3) for Volkswagen Passat GLS 4Motion 2000: 25 (behind right of catalytic converter) oxygen sensor (o2s) 2 (mil) Camshaft adjustment valve 1 Camshaft adjustment valve 2 Data link connector Engine speed (rpm) sensor (on left side of transmission bellhousing) Fuel pump (in fuel tank) Fuse 15a Fuse 20a Fuse panel G104 (left rear of engine compt) Heated oxygen sensor (ho2s) 2 (behind left cyl head, on exhaust manifold) Instrument cluster Knock sensor (ks) 1 (right side of engine block, beneath intake manifold) Knock sensor (ks) 2 (left side of engine block, beneath intake manifold) Malfunction indicator lamp Nca Red Secondary air injection (air) pump motor (right front corner of engine compt) Secondary air injection (air) pump relay (near master cylinder) Secondary air injection solenoid valve (on rear of intake manifold) T32a/25 T32a/3 T32b/19 T32b/20 2.8L, Engine Performance Wiring Diagrams (3 of 3) for Volkswagen Passat GLS 4Motion 2000 List of elements for 2.8L, Engine Performance Wiring Diagrams (3 of 3) for Volkswagen Passat GLS 4Motion 2000: 22 (not used) (on rear of right cylinder head) engine coolant temperature (ect) sensor (rear of intake manifold) intake manifold change-over valve (rear of intake manifold, in intake duct) intake air temperature (iat) sensor Abs control module Brake- light switch (above brake pedal) Camshaft position (cmp) sensor (bank 2) (rear of left cylinder head) Camshaft position (cmp) sensor (front of right cylinder head) Clutch vacuum vent valve switch (below left side of dash, on pedal cluster) Cruise control system Fuel injectors Fuse 10a Fuse 7.5a Fuse panel G104 (left rear of engine compt) Hot at all times Ignition coil (on left side of cylinder head) Motronic engine control module (in left rear corner of engine compt) Nca Spark plugs Suppressor Throttle valve control module (on throttle body)
EXTERIOR LIGHTS Back-up Lamps Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Back-up Lamps Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 19 (1999-00) (2001) 31a A/t Back- up light Back-up light switch Fuse 15a Fuse panel (under left side of dash) G904 (left rear pillar) G905 (right rear pillar) Hot in on or start Left rear taillight assembly M/t Memory seat control module Multi-function transmission range switch Right rear taillight assembly T28 T6c W/ memory seats Exterior Lamps Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Exterior Lamps Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 47 13a 22a 23a 39a 75x Brake Brake- light switch Comfort system central control module (under driver's seat & carpet) Control module Emergency flasher switch Fuse 10a Fuse 15a Fuse 5a Fuse panel (under left side of dash) G200 (lower left "a" pillar) G202 (behind left side of dash) G203 (lower right "a" pillar) G904 (left rear pillar) G905 (right rear pillar) Head High mount brake- light Hot at all times Hot in on Instrument cluster Interior lights system Left Left front turn signal/ side marker light Left rear taillight assembly Left side turn signal light Left turn ind License plate lights Light switch Load reduction relay Off Park Right Right front turn signal/ side marker light Right rear taillight assembly Right side turn signal light Right turn ind Solid state T15 T32a Tail Thirteen- fold auxiliary relay panel (under left side of dash) Turn Turn signal switch
GROUND DISTRIBUTION Ground Distribution Wiring Diagram (1 of 3) for Volkswagen Passat GLS 4Motion 2000 List of elements for Ground Distribution Wiring Diagram (1 of 3) for Volkswagen Passat GLS 4Motion 2000: 27 (body) (transmission) 1.8l 2.8l Abs control module Amplifier Battery Cd changer unit G100 (left side of engine compartment) G102 (on hydraulic unit) G129 G133 (on valve cover) G302 (under center console, at shifter) G904 (left rear pillar) Ignition coil Ignition coil 1 Ignition coil 2 Ignition coil 3 Ignition coil 4 Kickdown switch Motronic engine control module (ecm) Nca Oil level thermal sensor Radio (w/ amplifier) Secondary air injection (air) pump motor Speedo- meter vehicle speed sensor To g308 (diagram 3 of 3) Ground Distribution Wiring Diagram (2 of 3) for Volkswagen Passat GLS 4Motion 2000 List of elements for Ground Distribution Wiring Diagram (2 of 3) for Volkswagen Passat GLS 4Motion 2000: 51 A/c cut-off control module Air bag spiral spring/ return spring Anti-slip control switch Brake fluid level warning switch Center dash vent illum- ination Cigarette lighter Climatronic control module Clutch pedal position switch Coolant fan control relay Data link connector Daytime running lights change- over relay Driver's backrest heating element Driver's heated seat control module Driver's heated seat temperature sensor Emergency flasher switch Fresh air blower control module Fresh air blower motor Fresh air blower switch Fresh/ recirculating air door servo motor G202 (behind left side of dash) Glove compartment light Instrument cluster Instrument panel light dimmer switch Left dash vent illum- ination Left seat belt switch switch Left washer nozzle heater Light switch Load reduction relay Nca Outside air temperature sensor Parking brake warning light switch Passenger's backrest heating element Passenger's heated seat control module Passenger's heated seat temperature sensor Radio Rear lid motor remote unlock relay Rear window defogger switch Right dash vent illum- ination Right washer nozzle heater Sedan Starting interlock relay T16a T32a T8a Thirteen fold auxiliary relay panel (under left side of dash) Wagon Windshield washer pump Windshield wiper intermittent regulator Windshield wiper motor Windshield wiper/ washer switch Wiper/ washer intermittent relay Ground Distribution Wiring Diagram (3 of 3) for Volkswagen Passat GLS 4Motion 2000 List of elements for Ground Distribution Wiring Diagram (3 of 3) for Volkswagen Passat GLS 4Motion 2000: 68 (sedan) 12v outlet (sedan) 12v socket A/c pressure switch (2.8l) After- run coolant pump (2.8l) Alarm horn Automatic day/night interior mirror Comfort system central control module Coolant fan (1.8l) Coolant fan control module (2.8l) Coolant fan control thermal switch (1.8l) Coolant fan control thermal switch (2.8l) Driver's seat switch (w/o memory seats) Driver's side door control module Dual horns From amplifier (diagram 1 of 3) Front interior light Fuel pump Fuel tank lid unlock motor G200 (lower left "a" pillar) G201 (behind right side of dash) G202 (beside fuse/relay panel) G203 (lower right "a" pillar) G305 (lower right "b" pillar) G308 (lower left "b" pillar) G311 (sedan) (below rear shelf) G406 (wagon) (in right rear of hatch door) G905 (right rear G909 (wagon) (center rear of roof) Heated rear window Heated rear window (wagon) High mount brake light Hood alarm switch Left front turn signal/ side marker light Left headlight assembly Left make-up mirror light switch Left rear door control module Left rear reading light Left rear taillight assembly Left side turn signal light License plate lights Luggage compartment light switch (sedan) Luggage compartment light switch (wagon) Memory seat control module Multi- function transmission range switch Nca Passenger's seat switch (w/o memory seats) Passenger's side door control module Pillar) Power sunroof control module Rain sensor Rear lid remote unlock motor Rear window wiper motor (wagon) Remote fuel tank door switch Right front turn signal/ side marker light Right headlight assembly Right make-up mirror light switch Right rear door control module Right rear reading light Right rear taillight assembly Right side turn signal light Sedan Selector lever warning light (p/n) T23 Transmission control module (tcm) Trunk lid central locking switch Trunk lid central locking switch (wagon) Wagon
HEADLIGHTS Headlight Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Headlight Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 46 18a 19a 20a 21a 36a 75x Bat Control module Daytime running lights change- over relay Dimmer switch Flash to pass Fog Fog- light relay Fuse 10a Fuse 15a Fuse panel (under left side of dash) G200 (lower left "a" pillar) G202 (behind left side of dash) G203 (lower right "a" pillar) Head Headlight dimmer/ flasher switch Headlight switch High High beam ind Hot at all times Ignition switch Instrument cluster Interior lights system Left head- light assembly Light switch Load reduction relay Lock Low Off On fog- light switch Park Parking brake ind Red Right head- light assembly S1/1 S1/5 Start T32a T32b Thirteen- fold auxiliary relay panel (under left side of dash) Thirteenfold auxiliary relay panel (under left side of dash)
HORN Horn Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Horn Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 19 40a Air bag spiral spring/ return spring Dual horn relay Dual horns Fuse 25a Fuse panel (under left side of dash) G202 (behind left side of dash) G203 (lower right "a" pillar) Horn switch Hot at all times Ignition switch Lock Nca S1/4 S1/5 S1/6 S2/2 Start Thirteen fold auxiliary relay panel (under left side of dash)
INSTRUMENT CLUSTER
INTERIOR LIGHTS Courtesy Lamps Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Courtesy Lamps Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 45 (not used) (sedan) (wagon) 14a Comfort system central control module (under driver's seat & carpet) Door Driver's driver's side side central central locking locking unit unit Driver's side door control module (in driver's door) Front interior light Fuse 10a Fuse 5a Fuse panel (under left side of dash) G200 (lower left "a" pillar) G202 (behind left side of dash) G308 (lower left "b" pillar) G909 (center rear of roof) Glove compartment light Hot at all times Hot with lights on Instrument cluster system Interior lights system (instrument illumination) Left center reading light Left front entry light Left left rear rear central central locking locking unit unit Left left rear rear entry entry light light Left make-up mirror light Left make-up mirror light switch Left rear central locking unit Left rear door control module (in left rear door) Left rear reading light Luggage compartment light Luggage compartment light switch Off Passenger's side central locking unit Passenger's side door control module (in passenger's door) Right center reading light Right front entry light Right make-up mirror light Right make-up mirror light switch Right rear door control module (in right rear door) Right rear entry light Right rear reading light Sedan T23 Wagon Instrument Illumination Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Instrument Illumination Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 62 (4 leds) 15a 31a Anti- slip control switch Center Central locking warning light (safe) Cigarette lighter Climatronic control module Comfort system central control module (under driver's seat) Control module Defoggers system (heated mirrors circuit) Digital display light Driver's heated seat control module Driver's side door control module (in driver's door) Driver's side power window switch Emergency flasher switch Fuse 15 10a Fuse 31 15a Fuse 5a Fuse panel (under left side of dash) G201 (behind right side of dash) G202 (behind left side of dash) Generator Head Heater- a/c control panel Hot at all times Hot in on or start Instrument cluster Instrument panel light dimmer switch Instrument panel vent illumination lights Left Left rear door control module (in left rear door) Left rear window switch Light switch Mirror adjustment switch Off Park Passenger's heated seat control module Passenger's side door control module (in passenger's door) Passenger's side interior lock switch Passenger's side window switch Radio Rear lid remote unlock switch Rear window defogger switch Remote/ fuel tank door switch Right Right rear door control module (in right rear door) Right rear window switch Selector lever light diode Selector lever light relay Selector lever position illumination Selector lever warning light (p/n) Shift lock solenoid (in center console, on gear selector mechanism) T12 T23 T32a T8a Thirteen fold auxiliary relay panel (under left side of dash) Transmission control module (on passenger's side floor cavity) W/ a/t W/ driver door mounted rear lid remote unlock/ remote fuel tank switches W/o driver door mounted rear lid remote unlock/ remote fuel tank switches
MEMORY SYSTEMS Memory System Wiring Diagrams (1 of 2) for Volkswagen Passat GLS 4Motion 2000 List of elements for Memory System Wiring Diagrams (1 of 2) for Volkswagen Passat GLS 4Motion 2000: 29 Backrest adjust switch Bwd Circuit breaker 44 30a Computer data lines system Down Driver's power seat circuit breaker Driver's seat backrest adjusting motor Driver's seat fore/ aft adjusting motor Driver's seat front height adjusting motor Driver's seat rear height adjusting motor Driver's seat switch Exterior lights system (back-up lamps) Front height adjust switch Fuse 9 5a Fuse panel (under left side of dash) Fwd G202 (beside fuse/ relay panel) Hot at all times Hot in on Memory seat control module Memory seat lock out switch Memory seat switch Rear height adjust switch Red Seat adjust switch T12 T28 T6c T8b Memory System Wiring Diagrams (2 of 2) for Volkswagen Passat GLS 4Motion 2000 List of elements for Memory System Wiring Diagrams (2 of 2) for Volkswagen Passat GLS 4Motion 2000: 20 Circuit breaker 30a De- fog Door locks system Driver side mirror Driver's side door control module (part of master power window switch assembly, on driver's door) Eight fold auxiliary relay panel (under left side of dash) Fold- in G200 (lower left "a" pillar) G203 (lower right "a" pillar) Heated mirror switch Hot at all times Interior lights system Mirror adjustment switch Mirror folding switch Mirror select switch Mirrors system (heated mirror) Passenger side mirror Passenger's side door control module (part of power window motor assembly, in passenger's front door) Position Power mirror switch
POWER DISTRIBUTION Power Distribution Wiring Diagram (1 of 4) for Volkswagen Passat GLS 4Motion 2000 List of elements for Power Distribution Wiring Diagram (1 of 4) for Volkswagen Passat GLS 4Motion 2000: 56 12 volt socket 12 volt socket (sedan) 75x Abs control module Amp/ dsp fuse 30a Amplifier Amplifier fuse holder Battery Circuit breaker 30a Comfort system central control module Coolant fan control module Driver's power seat circuit breaker Driver's seat switch (w/o memory seats) Driver's side door control module Dual horn relay Eight fold auxiliary relay panel (under left side of dash) First speed coolant fan control relay Fuse 15a Fuse 20a Fuse 30a Fuse 40a Fuse 50a Fuse 5a Fuse adaptor (above relay panel) G202 (behind left side of dash) G203 (lower right "a" pillar) G905 (right rear pillar) Generator Left rear door control module Load reduction relay Memory seat control module (w/ memory seats) Motronic engine control module Passenger's power seat circuit breaker Passenger's seat switch (w/o memory seats) Passenger's side door control module Red Red red Relay panel (under left side of dash) Right rear door control module S1/1 S1/5 Second speed coolant fan control relay Secondary air injection pump relay (2.8l) Starter T15 T2p T6g T8a Thirteen fold auxiliary relay panel (under left side of dash) To fuse panel (diagram 4 of 4) To fuse panel (fuse 1) (diagram 4 of 4) To fuse panel (fuse 2) (diagram 4 of 4) To ignition switch (diagram 3 of 4) To thirteen fold auxiliary relay panel (30) (diagram 2 of 4) W/ 2 speed coolant fan W/o 2 speed coolant fan Power Distribution Wiring Diagram (2 of 4) for Volkswagen Passat GLS 4Motion 2000 List of elements for Power Distribution Wiring Diagram (2 of 4) for Volkswagen Passat GLS 4Motion 2000: 46 (not used) 12a 13a 14a 15a 33a 37a 38a 39a 40a Brake switch Cigarette lighter Comfort system central control module Data link connector Driver's side door control module Dual horn relay Emergency flasher switch From thirteen fold auxiliary relay panel (30) (diagram 1 of 4) Fuel pump relay Fuse 10a Fuse 15a Fuse 20a Fuse 25a Fuse panel (under left side of dash) G202 (under left side of dash) Headlight dimmer switch Instrument cluster Interior lights system Left rear door control module Light switch Motronic engine control module (1.8l) Passenger's side door control module Radio Rear lid remote unlock relay Red Remote fuel tank door switch Remote fuel tank door unlock switch Right rear door control module S1/4 Selector lever relay T10o T121 T32a Thirteen fold auxiliary relay panel (under left side of dash) To ignition switch (diagram 3 of 4) Transmission control module Power Distribution Wiring Diagram (3 of 4) for Volkswagen Passat GLS 4Motion 2000 List of elements for Power Distribution Wiring Diagram (3 of 4) for Volkswagen Passat GLS 4Motion 2000: 50 (if equipped) 1.8l 2.8l 31a 32a 50b A/c pressure switch Abs control module Airbag control module Anti-slip control switch Automatic day/night mirror Back-up light switch Brake light switch Climatronic control module Clutch vacuum vent valve switch (m/t) Comfort system central control module Cruise control switch Data link connector Driver's heated seat control module From thirteen fold auxiliary relay panel (diagram 1 of 4) From thirteen fold auxiliary relay panel (diagram 2 of 4) Fuel injector Fuel pump relay Fuse 10a Fuse 15a Fuse 20a Fuse 5a Fuse panel (under left side of dash) Headlight switch (foglight switch) Ignition switch Instrument cluster Key in ignition switch Lock Motronic engine control module Multi-function transmission range switch Nca Passenger's heated seat control module Power mirror switch Radio Red S3/3 Shift lock solenoid Start Starting interlock relay T121 T32a T75 Thirteen fold auxiliary relay panel (under left side of dash) Tiptronic switch Transmission control module Power Distribution Wiring Diagram (4 of 4) for Volkswagen Passat GLS 4Motion 2000 List of elements for Power Distribution Wiring Diagram (4 of 4) for Volkswagen Passat GLS 4Motion 2000: 36 24a 25a 26a 27a 30a 44a 75x A/c clutch relay (2.8l) A/c cutoff control module Blower switch Climatronic control module (2.8l) Daytime running lights change over relay Driver's heated seat control module Emergency flasher switch Fresh air blower control module From thirteen fold auxiliary relay panel (diagram 1 of 4) Fuse 15a Fuse 20a Fuse 25a Fuse 30a Fuse 5a Fuse panel (under left side of dash) Left washer nozzle heater Memory seat control module Passenger's heated seat control module Power sunroof control module Rear window defogger switch Rear window wiper motor (wagon only) Red Right washer nozzle heater T6c T6g T8a Thirteen fold auxiliary relay panel (under left side of dash) Windshield wiper/washer switch Wiper/washer intermittent relay
POWER DOOR LOCKS Power Door Lock Wiring Diagram (1 of 2) for Volkswagen Passat GLS 4Motion 2000 List of elements for Power Door Lock Wiring Diagram (1 of 2) for Volkswagen Passat GLS 4Motion 2000: 45 (lower left "b" pillar) g308 (not used) 14a 38a Alarm horn (left front of luggage compartment) Antenna Central locking warning light (safe) Circuit breaker 30a Comfort system central control module (mounted on floorpan in protective box, under driver's seat & carpet) Computer data lines system Control module Decklid central locking motor (in rear lid lock/ latch mechanism) Defogger system Driver's side central locking lock unit Driver's side door control module (part of master power window switch assembly, on driver's door) Driver's side interior lock switch Eight fold auxiliary relay panel (under left side of dash) Exterior lights system Fuse 10a Fuse 15a Fuse 5a Fuse panel (under left side of dash) G200 (lower left "a" pillar) G203 (lower right "a" pillar) Hood alarm switch (part of hood latch) Hot at all times Hot in on or start Ignition switch Instrument cluster Instrument cluster system Interior lights system Interior lights system (luggage compt light switch) Key switch Nca Power tops system Power windows system, mirrors system, trunk, tailgate, fuel doors system Radio, interior lights system Rear lid unlocked warning light Red Starting/charging system T15 T23 T29a T32a Trunk, tailgate, fuel doors system Power Door Lock Wiring Diagram (2 of 2) for Volkswagen Passat GLS 4Motion 2000 List of elements for Power Door Lock Wiring Diagram (2 of 2) for Volkswagen Passat GLS 4Motion 2000: 18 G203 (lower right "a" pillar) G305 (lower right "b" pillar) G308 (lower left "b" pillar) G308 (sedan) (lower left "b" pillar) G909 (wagon) (center rear of roof) Interior lights system Left rear central locking lock unit Left rear door control module (part of power window motor assembly, in left rear door) Mirrors system Passenger's side central locking lock unit Passenger's side door control module (part of power window motor assembly, in passenger's front door) Passenger's side interior lock switch Right rear central locking lock unit Right rear door control module (part of power window motor assembly, in right rear door) T18a T18b T29b Trunk lid central locking switch (in rear lid with lock/ latch mechanism)
POWER MIRRORS Automatic Day/Night Mirror Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Automatic Day/Night Mirror Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 11 (lower left "a" pillar) g200 31a A/t Automatic day/night mirror Back-up light switch Exterior lights system Fuse 15a Fuse panel (under left side of dash) Hot in on or start M/t Multi- function transmission range switch Power Mirrors Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Power Mirrors Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 25 Circuit breaker 30a Defogger system Door locks system Down Driver's side door control module Driver's side power mirror Eight fold auxiliary relay panel (under left side of dash) Fold-in mirror motor G200 (on lower left "a" pillar) G203 (lower right "a" pillar) Hot at all times Illumi- nation Interior lights system Left Limit switch Mirror adjustment motors Mirror adjustment switches Mirror fold-away switch Mirror heater Mirror heater switch Mirror selector switch Passenger's side door control module Passenger's side power mirror Power mirror switch Right
POWER SEATS Heated Seats Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Heated Seats Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 18 44a All times Driver's backrest heating element Driver's heated seat control module Driver's seat heating element Driver's seat temper- ature sensor Fuse 44 30a Fuse 5 10a Fuse panel (under left side of dash) G202 (behind left side of dash) Hot at Hot in on or start Interior lights system Nca Passenger's backrest heating element Passenger's heated seat control module Passenger's seat heating element Passenger's seat temper- ature sensor Power Seats Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Power Seats Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 24 Backrest adjust Bwd Circuit breaker 30a Down Driver's backrest adjusting motor Driver's power seat circuit breaker Driver's seat fore/aft adjusting motor Driver's seat front height adjusting motor Driver's seat rear height adjusting motor Driver's seat switch Fore/aft adjust Front height adjust Fwd G202 (beside fuse/ relay panel) Hot at all times Passenger's backrest adjusting motor Passenger's power seat circuit breaker Passenger's seat fore/aft adjusting motor Passenger's seat front height adjusting motor Passenger's seat rear height adjusting motor Passenger's seat switch Rear height adjust T2a T8a
POWER TOP/SUNROOF Sunroof Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Sunroof Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 16 30a Comfort system central control module (mounted on floorpan in protective box, under driver's seat & carpet) Fuse 20a Fuse panel (under left side of dash) G200 (lower left "a" pillar) Hot at all times Lower switch Nca Power sun roof control module Raise switch Red Sun roof control switch Sun roof motor Sun roof regulator T23 T6f
POWER WINDOWS Power Window Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Power Window Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 34 38a Can-h Can-l Circuit breaker 30a Comfort system central control module (under driver's seat & carpet) Door locks system Driver's side door control module Driver's side power window switch Eight fold auxiliary relay panel (under left side of dash) Fuse 15a Fuse panel (under left side of dash) G200 (lower left "a" pillar) G203 (lower right "a" pillar) G305 (lower right "b" pillar) G308 (lower left "b" pillar) Hot at all times Illumination Interior lights system Left front window switch Left rear door control module Left rear window switch Passenger's side door control module Passenger's side window switch Rear window safety switch Right front window switch Right rear door control module Right rear window switch T16b T18a T18b T23 T29a T29b Window motor
RADIO Base Radio, without Monsoon Radio for Volkswagen Passat GLS 4Motion 2000 List of elements for Base Radio, without Monsoon Radio for Volkswagen Passat GLS 4Motion 2000: 28 (not used) 37a Antenna amplifier Anti- theft system Cd changer unit (if equipped) Computer data lines system Fuse 20a Fuse panel G202 (behind left side of dash) G302 (under center console, at shifter) Hot at all times Ignition switch Interior lights system Key-in ignition switch Left front tweeter Left front woofer Left rear tweeter Left rear woofer Nca Pins 1-12 (not used) Radio Red Right front tweeter Right front woofer Right rear tweeter Right rear woofer T20 T8a Radio Wiring Diagrams, with Monsoon Radio for Volkswagen Passat GLS 4Motion 2000 List of elements for Radio Wiring Diagrams, with Monsoon Radio for Volkswagen Passat GLS 4Motion 2000: 34 (not used) 37a Amp/ dsp fuse 30a Amplifier (left side of luggage compartment) Amplifier fuse holder Antenna amplifier Anti-theft system Cd changer unit (if equipped) Computer data lines system Fuse 20a Fuse panel (behind left side of dash) G202 (behind left side of dash) G302 (under center console, at shifter) G904 (left rear pillar) Hot at all times Ignition switch Interior lights system Key-in ignition switch Left front bass speaker Left front treble speaker Left rear treble speaker Nca Pins 1-12 (not used) Radio Red Right front bass speaker Right front treble speaker Right rear bass speaker Right rear treble speaker T20 T23 T24 T8a Thirteen fold auxiliary relay panel (behind left side of dash)
SHIFT INTERLOCKS Shift Interlock Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Shift Interlock Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 14 (not used) 13a 31a Brakelight switch (behind left side of dash, on pedal cluster) Fuse 13 10a Fuse 31 15a Fuse panel (under left side of dash) Hot at all times Hot in on or start Multi-function transmission range switch P/n warning indicator Selector lever warning light Shift lock solenoid (on gear selector mechanism) Transmission control module (on passenger's side floor cavity)
STARTING/CHARGING Charging Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Charging Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 13 (body) Battery Contr0l module w/ indicator unit Generator Generator warning light Ignition switch Instrument cluster Lock Red Start Starter T32a Thirteen fold auxiliary relay panel (under left side of dash) Starting Wiring Diagram, A/T for Volkswagen Passat GLS 4Motion 2000 List of elements for Starting Wiring Diagram, A/T for Volkswagen Passat GLS 4Motion 2000: 18 (behind right side of dash) g201 (body) (not used) 50b Alarm system starting interlock relay (thirteen fold auxiliary relay panel) Battery Comfort system central control module (under driver's seat & carpet) G202 (behind left side of dash) Generator Ignition switch Lock Multi-function transmission range switch Red Start Starter Starting interlock relay (thirteen fold auxiliary relay panel) T15 Thirteen fold auxiliary relay panel (under left side of dash) Starting Wiring Diagram, M/T for Volkswagen Passat GLS 4Motion 2000 List of elements for Starting Wiring Diagram, M/T for Volkswagen Passat GLS 4Motion 2000: 16 (body) 50b Alarm system starting interlock relay (thirteenfold auxiliary relay panel) Battery Clutch pedal position switch (below left side of dash) Clutch position starting interlock relay (thirteenfold auxiliary relay panel) Comfort system central control module (under driver's seat & carpet) G202 (behind left side of dash) Generator Ignition switch Lock Red Start Starter T15 Thirteenfold auxiliary relay panel
SUPPLEMENTAL RESTRAINTS Supplemental Restraint Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Supplemental Restraint Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 27 (no connection) Acc Air bag control module (mounted on floor in front of center console, near ventilation ducts) Air bag malfunction indicator lamp (mil) Air bag spiral spring/ return spring (w/slip ring) Comfort system central control module (mounted on floorpan in protective box, under driver's seat & carpet) Data link connector (dlc) Driver side rear head air bag igniter Driver's side air bag igniter Driver's side side air bag crash sensor (under driver's seat & carpet, mounted on floorpan crossmember) Driver's side side air bag igniter Hot at all times Ignition/ starter switch Instrument cluster Lock Motronic engine control module (ecm) (in protective box, in left rear corner of engine compartment) Nca Passenger side air bag igniter 1 Passenger side rear head air bag igniter Passenger side side air bag igniter Passenger's side side air bag crash sensor (under passenger's seat & carpet, mounted on floorpan crossmember) Run Solid state Start T32a T32b W/ head air bag
TRANSMISSION A/T Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for A/T Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 40 (behind right side of dash) (left side of eng compt) (not used) (pin 56-84 not used) 13a 15a 1995 vftc c 31a Acc Brakelight switch (below left side of dash, on pedal cluster) Data link connector (under left side of dash) Exterior lights system (backup light) Fuse 10a Fuse 15a Fuse panel (under left side of dash) G100 G201 G201 (behind right side of dash) Hot at all times Hot in on or start Ignition switch Illum Interior lights system Kick- down switch Lock Motronic engine control module (in left rear corner of eng compt) Multi-function transmission range switch (on shift selector assembly) Nca Red Shift lock solenoid (on gear selector) Solenoid valves Solid state Start Starting/ charging system Tiptronic switch/ selector level position illumination Transmission Transmission control module (on passenger's side floor cavity) Transmission fluid temperature sensor Transmission vehicle speed sensor Vehicle speed sensor (on transmission housing)
TRUNK, TAILGATE, FUEL DOOR Trunk & Fuel Door Release Wiring Diagram, Sedan for Volkswagen Passat GLS 4Motion 2000 List of elements for Trunk & Fuel Door Release Wiring Diagram, Sedan for Volkswagen Passat GLS 4Motion 2000: 14 14a Comfort system central control module (mounted on floorpan in protective box, under driver's seat & carpet) Decklid central locking motor (in rear lid lock/latch mechanism) Driver's side door control module (part of master power window switch assembly, on drivers door) Fuel tank lid unlock motor (on right side of luggage compartment) Fuse 10a Fuse panel (under left side of dash) G305 (lower right "b" pillar) Hot at all times Interior lights system Rear lid remote lock key switch Rear lid remote unlock switch Remote fuel tank door switch T23 Trunk & Fuel Door Release Wiring Diagram, Wagon for Volkswagen Passat GLS 4Motion 2000 List of elements for Trunk & Fuel Door Release Wiring Diagram, Wagon for Volkswagen Passat GLS 4Motion 2000: 17 38a Comfort system central control module (mounted on floorpan in protective box, under driver's seat & carpet) Fuel tank lid unlock motor (on right side of luggage compartment) Fuse 15a Fuse panel (under left side of dash) G202 (behind left side of dash) G305 (lower right "b" pillar) G308 (lower left "b" pillar) G909 (center rear of roof) Hot at all times Interior lights system Rear lid remote unlock motor (on rear lid w/ lock/latch mechanism) Rear lid remote unlock motor relay Remote fuel tank door switch T23 Thirteen fold auxiliary relay panel (under left side of dash) Trunk lid central locking switch
WIPER/WASHER Wiper/Washer Wiring Diagram for Volkswagen Passat GLS 4Motion 2000 List of elements for Wiper/Washer Wiring Diagram for Volkswagen Passat GLS 4Motion 2000: 35 (not used) (wagon) 24a 27a 75x Fuse 15a Fuse 25a Fuse panel G200 (lower left "a" pillar) G202 (behind left side of dash) G406 (right rear of hatch door) Hot at all times Hot in on Instrument cluster Left washer nozzle heater Load reduction relay Multi-function indicator mode select switch Nca Rain sensor (if equipped) (integral to automatic day/night interior mirror) Rear window wiper motor (wagon) Right washer nozzle heater Sedan Speed signal T o T10c T32a Thirteen fold auxiliary relay panel Vehicle Wagon Washer switch Windshield & rear window washer pump Windshield wiper intermittent regulator Windshield wiper motor Windshield wiper/ washer switch Wiper/washer intermittent relay
