Все схемы для электропроводки Mazda 5 Touring 2010

Автомтическая коробка Передач (АКПП) Полная привод (4WD) Блокировка Дифференциала

Электросхема коробки передач АКПП (1 из 2) для Mazda 5 Touring 2010

Электросхема коробки передач АКПП (1 из 2) для Mazda 5 Touring 2010 - Список элементов:

(in transaxle) g15
0517-04
0517-06
0922-101a
0940-01a
0940-01d
1-5
A/t ind
Bcm (behind right side of dash)
Computer data lines system
Fuse block (behind right end of dash)
G14 (rear of engine)
G17 (left front of engine compt)
Hot in on or start
Input/turbine speed sensor (on transaxle)
Instrument cluster
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
Meter fuse 10a
Micro- computer
Oil pressure switch (on left side of transaxle)
Pressure control solenoid b
Primary solenoid valve
Red
Secondary solenoid valve
Selector indicator drive circuit
Solenoid a control pressure
Solenoid a shift
Solenoid b shift
Solenoid c shift
Solenoid d shift
Solenoid e shift
Solenoid f shift
Tcm (left rear corner of engine compt)
Temperature fluid sensor
Transaxle case

Электросхема коробки передач АКПП (2 из 2) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема коробки передач АКПП (2 из 2) для Mazda 5 Touring 2010 - Список элементов:

(on transaxle) transaxle range switch
At main relay
Down sw
Eng b+ fuse 10a
Exterior lights system
G14 (rear of engine)
Hot at all times
Interior lights system
Intermediate sensor
J/c g-04 (behind left end of dash)
M range sw
Main fuse block (left side of engine compt)
Not p position sw
Selector lever component (in center console)
Shift interlock system
Shift lock solenoid
Starting/ charging system
Tcm fuse 20a
Up sw
Vehicle speed sensor (on transaxle)

БАГАЖНИК ЗАДНЯЯ ДВЕРЬ ЛЮЧОК ТОПЛИВНОГО БАКА

схема раздвижной двери питания для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

схема раздвижной двери питания для Mazda 5 Touring 2010 - Список элементов:

G11 (under front passenger's seat)
G12 (at left "d" pillar)
Hot at all times
Left auto closure control module
Left auto closure motor
Left closer fuse 20a
Left latch position switch
Left slide door lock (behind left rear quarterpanel)
Main fuse block (left side of engine compt)
Nca
Right auto closure control module
Right auto closure motor
Right closer fuse 20a
Right latch position switch
Right slide door lock (behind right rear quarterpanel)

БЛОК ПРЕДОХРАНИТЕЛЕЙ И РЕЛЕ

Электросхема блока предохранителей и реле (1 из 2) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема блока предохранителей и реле (1 из 2) для Mazda 5 Touring 2010 - Список элементов:

(left side of engine compt) main fuse block
250a
Abs p fuse 30a
Abs v fuse 20a
Air conditioning system
Anti-lock brakes system
Battery
Btn fuse 60a
Cooling fans system
D lock fuse 20a
Door locks system
Eng +b fuse 10a
Eng ba fuse 20a
Eng bar 2 fuse 15a
Eng bar fuse 15a
Engine controls system
Etc fuse 10a
Exterior lights system
Fan fuse 30a
From hazard a fuse (diagram 1 of 2)
Fuel fuse 20a
Hazard fuse 10a
Head high l 10a
Head high r 10a
Head low l 15a
Head low r 15a
Headlight high relay
Headlight low relay
Headlights system
Horn fuse 15a
Horns system
Illumi fuse 10a
Interior lights system
Left closer fuse 20a
Mag fuse 10a
Main fuse
Main relay
Nca
Power tops system
Right closer fuse 20a
Starting/ charging system
Stop fuse 10a
Sun roof fuse 20a
Tail fuse 10a
Tcm fuse 20a
Tns relay (tail relay)
To defog fuse (diagram 2 of 2)
To tns relay (diagram 1 of 2)
Transmissions system
Trunk, tailgate, fuel doors system

Электросхема блока предохранителей и реле (2 из 2) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема блока предохранителей и реле (2 из 2) для Mazda 5 Touring 2010 - Список элементов:

(behind right end of dash) fuse block
(left side of engine compt) main fuse block
A/c fuse 10a
Abs/dsc fuse 5a
Acc
Air conditioning & body computer systems
Air conditioning system
Air conditioning, door locks, instrument cluster, computer data lines, shift interlock, interior lights, navigation, sound & body computer systems
Blower fuse (w/o rear vent) 40a
Cigar fuse 15a
Defog fuse 25a
Defogger system
Ehpas fuse 5a
Ehpas fuse 80a
Electronic power steering & anti-lock brakes systems
Electronic power steering system
Eng 2 fuse 15a
Eng 3 fuse 20a
Eng fuse 5a
Engine controls & cooling fans systems
Engine controls system
F blower fuse (w/ rear vent) 20a
F wip fuse 25a
Fog fuse 15a
From tcm b fuse (diagram 1 of 2)
Front accessory socket
G12 (at left "d" pillar)
G6 (behind right end of dash)
Headlights system
Ig key 1 fuse 40a
Ig key 2 fuse 40a
Ig1
Ig2
Ignition switch
Instrument cluster, wiper/washer, exterior lights, door locks, anti-theft, body computer & transmissions systems
Joint connector g-06
Meter fuse 10a
Mirror fuse 7.5a
Off
P/outlet fuse 15a
P/w fuse 30a
Pnk
Power windows system
R blower fuse 30a
R wip fuse 15a
Rear accessory socket
Room fuse 15a
Run
S warm fuse 15a
Sas fuse 10a
Seats system
Shift interlock system
Shift/l fuse 5a
Sound, mirrors & navigation systems
Start
Starting/ charging system
Wiper/washer system

БЛОКИ УПРАВЛЕНИЯ КУЗОВОМ

Электросхема блоков управления кузовом для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема блоков управления кузовом для Mazda 5 Touring 2010 - Список элементов:

0940-01a
0940-01b
0940-01c
0940-01d
0940-01e
0940-01f
3aa
3ab
3ac
3ad
A/c fuse 10a
Air conditioning system
Anti-theft system
Body control module (bcm) (behind right side of dash)
Computer data lines system
D lock fuse 20a
Defogger system
Door locks system
Exterior lights & transmission systems
Exterior lights system
F wip fuse 25a
Fuse block (behind right end of dash)
G6 (behind right end of dash)
Hazard fuse 10a
Headlights system
Horns system
Hot at all times
Hot in on
Hot in on or start
Instrument cluster & door locks systems
Instrument cluster & navigation systems
Instrument cluster & warning systems
Instrument cluster system
Interior lights & door locks systems
Interior lights system
J/c c-11 (behind right end of dash)
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
J/c g-06
Main fuse block (left side of engine compt)
Meter fuse 10a
Power tops system
Room fuse 15a
Sas fuse 10a
Shift interlock system
Sound & navigation systems
Sound systems
Wiper/washer system

БЛОКИРОВКИ СЕЛЕКТОРА СТОЯНОЧНЫЙ ТОРМОЗ

Электросхема блокировки селектора для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема блокировки селектора для Mazda 5 Touring 2010 - Список элементов:

0940-01b
0940-01d
Body control module (bcm) (behind right side of dash)
Brake switch (at top of brake pedal assembly)
Down switch
Fuse block (behind right end of dash)
G4 (behind left end of dash)
Hot at all times
Hot in on or acc
J/c c-11 (behind right end of dash)
J/c c-31 (behind left end of dash)
J/c-g04
Key interlock solenoid (in steering column)
M range switch
Main fuse block (left side of engine compt)
Not p position switch
Room fuse 15a
Selector lever component (in center console)
Shift- lock solenoid
Shift/l fuse 5a
Sound systems
Stop fuse 10a
Tcm (left rear corner of engine compt)
Up switch

ВНЕШНЕЕ ОСВЕЩЕНИЕ

Электросхема заднего хода для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема заднего хода для Mazda 5 Touring 2010 - Список элементов:

0920-301a
0940-01a
0940-01d
A/t
Backup light switch (on transaxle)
Bcm (behind right side of dash)
Car navigation unit (if equipped) (behind right side of dash)
Fuse block (behind right end of dash)
G12 (at left "d" pillar)
G13 (at right "d" pillar)
Hot in on or start
J/c c-12 (behind center of dash)
Left backup light
M/t
Meter fuse 10a
Nca
Right backup light
Transaxle range switch (on transaxle)

Электросхема внешнего освещения для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема внешнего освещения для Mazda 5 Touring 2010 - Список элементов:

(behind left end of dash)
0140-101a
0922-101a
0940-01b
0940-01c
0940-01e
1ab
Auto
Bcm (behind right side of dash)
Brake switch (at top of brake pedal assembly)
Computer data lines system
Flash- to- pass
Fuse block (behind right end of dash)
G1 (behind left headlight)
G12 (at left "d" pillar)
G13 (at right "d" pillar)
G14 (rear of engine)
G2 (behind right headlight)
G4 (behind left end of dash)
Hazard fuse 10a
Hazard warning switch
Head light
Headlight switch
High mount brake light
Hot at all times
Hot in on or start
Instrument cluster
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
J/c-g04
Jc-g04
Left brake light
Left front turn/ parking light
Left license plate light
Left rear turn light
Left taillight
Left turn ind
Main fuse block (left side of engine compt)
Meter fuse 10a
Micro computer
Nca
Off
Park
Pcm (rear of engine compartment)
Red
Right brake light
Right front turn/ parking light
Right license plate light
Right rear turn light
Right taillight
Right turn ind
Selector lever component (in center console)
Stop fuse 10a
Tail fuse 10a
Tns
Tns relay
Turn
Turn switch
W/ autolamps

ВНУТРЕННЕЕ ОСВЕЩЕНИЕ

Электросхема подсветки для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема подсветки для Mazda 5 Touring 2010 - Список элементов:

0940-01b
0940-01e
0940-01f
Body control module (behind right side of dash)
Cargo compartment light
Door
G10 (under driver's seat)
G11 (under front passenger's seat)
G12 (at left "d" pillar)
Hot at all times
Interior light
Left
Left front door key cylinder switch/ door lock-link switch/door latch switch (in driver's door)
Liftgate latch switch (on liftgate latch)
Main fuse block (left side of engine compartment)
Map light
Nca
Off
Red
Right
Right front door latch switch (in front passenger's door)
Room fuse 15a

Электросхема подсветки приборов для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема подсветки приборов для Mazda 5 Touring 2010 - Список элементов:

(5 leds & resisters)
(w/ rear vent
0920-201a
0920-301a
0922-202
0922-203
0940-01a
0940-01b
0940-01c
0940-01d
Audio control switch (w/o cruise control)
Audio unit (w/o car navigation) car navigation unit (w/ car navigation) (behind right side of dash)
Auto
Body control module (behind right side of dash)
Climate control unit (lower center of dash)
Clock spring (in steering column)
Cruise control switch illumination (w/ cruise control)
Flash- to- pass
G14 (rear of engine)
G4 (behind left end of dash)
Hazard warning switch & clock switch /dsc off switch illumination
Head light
Headlight switch
Hot at all times
Ignition key illumination
Ill
Illu fuse 10a
Information display
Instrument cluster
Jc c-11 (behind right end of dash)
Jc c-29 (behind left end of dash)
Jc c-31 (behind left end of dash)
Jc c-33 (behind left end of dash)
Jc-g04
Left seat warmer switch (if equipped)
Main fuse block (left side of engine compartment)
Microcomputer
Nca
Off
Rear fan switch
Right seat warmer switch illumination (if equipped)
Room fuse 15a
Selector illumination (a/t)
Tns
Tns ind
Tns relay
W/ auto lamps
W/ car navigation
W/o car navigation

ЗАЗЕМЛЕНИЕ ПОДКЛЮЧЕНИЕ МАССЫ

Электросхема подключение массы заземления для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема подключение массы заземления для Mazda 5 Touring 2010 - Список элементов:

(behind right headlight)
Abs hydraulic unit/control module
Accelerator pedal position sensor
Audio unit
Bcm
Blower relay
Brake fluid level sensor
Brake switch 2
Camshaft position sensor
Car-navigation unit
Climate control unit
Clock spring
Clutch pedal position switch (m/t)
Coil antenna
Condenser
Cooling fan relay (fan relay)
Crankshaft position sensor
Data link connector 2
Door key cylinder switch/ door lock link switch/ left front door latch switch/ left front door lock actuator
Door lock link switch
Dsc hydraulic unit/control module
Dsc off switch
Ehpas control module
Evap system leak detection pump
Fan control module
Fan switch
Filament
Front accessory socket
Front blower relay 1 (w/ rear vent)
Front blower relay 2 (w/ rear vent)
Front fog light switch
Front power mos fet (metal oxide semiconductor field effect transistor)
Fuel pump unit
G1 (behind left headlight)
G10 (under driver's seat)
G11 (under front passenger's seat)
G12 (at left "d" pillar)
G13 (at right "d" pillar)
G14 (rear of engine)
G15 (a/t) (in transaxle)
G16 (right front of engine compt)
G17 (a/t) (left front of engine compt)
G3 (left front of engine compt)
G4 (behind left end of dash)
G5 (left rear of engine)
G6 (behind right end of dash)
G7 (behind left side of dash)
G8 (behind right side of dash)
Hands-free telephone unit (if equipped)
Hazard warning switch
Headlight leveling switch
Headlight switch
High mount brake light
Hood latch switch
Horn switch
Ignition coils 1-4
Information display
Input/ turbine speed sensor shield
Instrument cluster
Interior light
Intermediate sensor
J/c-g04
J/c-g06
Keyless receiver
Left auto closure control module
Left backup light
Left brake light
Left door lock switch
Left front fog light
Left front turn light
Left headlight high
Left headlight leveling actuator
Left headlight low
Left heated outer mirror (if equipped)
Left license plate light
Left parking light
Left rear door lock link switch
Left rear turn light
Left seat warmer switch
Left seat warmer unit
Left sliding door lock
Left taillight
Liftgate latch switch
Map light
Neutral switch (m/t)
Pcm
Power outer mirror switch
Power window main switch
Rain sensor (w/ auto wiper)
Rear accessory socket
Rear blower relay
Rear power mos fet
Rear wiper & washer switch
Rear wiper motor
Refrigerant pressure switch
Right auto closure control module
Right backup light
Right brake light
Right door lock switch
Right front door latch switch/ right front door lock actuator
Right front fog light
Right front turn light
Right headlight high
Right headlight leveling actuator
Right headlight low
Right heated outer mirror (if equipped)
Right license plate light
Right parking light
Right rear door lock link switch
Right rear turn light
Right seat warmer switch
Right seat warmer unit
Right sliding door lock
Right taillight
Sas control module
Seat weight sensor control module
Selector lever component
Sunroof unit
Tcm
Transaxle case
Turn switch
Vehicle speed sensor
W/ rear vent
W/ seat warmer
W/o drl
W/o rear vent
Washer fluid level sensor
Windshield washer motor
Windshield wiper & washer switch
Windshield wiper motor

Звуковой сигнал Гудок

Электросхема звукового сигнал Гудка для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема звукового сигнал Гудка для Mazda 5 Touring 2010 - Список элементов:

0922-202
0922-203
0940-01c
Bcm (behind right side of dash)
Clock spring (in steering column)
G4 (behind left end of dash)
Horn (left front of engine compt)
Horn fuse 15a
Horn relay
Horn switch
Hot at all times
J/c-g04
Main fuse block (left side of engine compt)
Nca
Stop fuse 10a

Магнитола Мультимедия

Электросхема магнитолы, С Навигация (1 из 2) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема магнитолы, С Навигация (1 из 2) для Mazda 5 Touring 2010 - Список элементов:

0920-301a
0920-301b
0920-317
0922-101b
Auxiliary jack
Car navigation unit (behind right side of dash)
Computer data lines system
Fuse block (behind right end of dash)
G8 (behind right side of dash)
Hot in on or acc
Hot in on or start
Instrument cluster
Instrument cluster system
Interior lights system
Joint connector c11 (behind right end of dash)
Left front door speaker
Left rear speaker
Left tweeter
Meter fuse 10a
Mirror fuse 7.5a
Nca
Pnk
Red
Right front door speaker
Right rear speaker
Right tweeter

Электросхема магнитолы, С Навигация (2 из 2) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема магнитолы, С Навигация (2 из 2) для Mazda 5 Touring 2010 - Список элементов:

(behind center of dash) joint connector c12
0922-202 g
0922-203
0940-01a
0940-01d
A/t
Audio control switch
Backup light switch (on transaxle)
Bcm (behind right side of dash)
Clock spring (in steering column)
Computer data lines system
Exterior lights system
G4 (behind left end of dash)
Hands-free telephone unit (if equipped)
Instrument cluster system
J/c g04
Joint connector c11 (behind right end of dash)
M/t
Microphone (behind right center of dash)
Mode
Mute
Nca
Preset +
Preset -
R position
Red
Transaxle range switch (on transaxle)
Transmissions system
Vol +
Vol -
W/ handsfree telephone unit
W/o handsfree telephone unit

Электросхема магнитолы, без Навигация для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема магнитолы, без Навигация для Mazda 5 Touring 2010 - Список элементов:

0920-201a
0920-210b
0922-203
0940-01d
Audio control switch
Audio unit
Auxiliary jack
Bcm (behind right end of dash)
Clock spring (in steering column)
Computer data lines system
E 0922-202
Fuse block (behind right end of dash)
G4 (behind left end of dash)
G8 (behind right side of dash)
Hands-free telephone unit (if equipped)
Hot in on or acc
Interior lights system
J/c-g04
Joint connector 11 (behind right end of dash)
Joint connector c11 (behind right end of dash)
Left front door speaker
Left rear speaker
Left tweeter
Microphone (behind right center of dash) (w/ hands-free telephone unit)
Mirror fuse 7.5a
Mode
Mute
Nca
Pnk
Preset +
Preset -
Red
Right front door speaker
Right rear speaker
Right tweeter
Vol +
Vol -

Навигация GPS Парктроники

Электросхема навигации GPS (1 из 2) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема навигации GPS (1 из 2) для Mazda 5 Touring 2010 - Список элементов:

0920-301a
0920-301b
0920-317
0922-101b
Auxiliary jack
Car navigation unit (behind right side of dash)
Computer data lines system
Fuse block (behind right end of dash)
G8 (behind right side of dash)
Hot in on or acc
Hot in on or start
Instrument cluster
Instrument cluster system
Interior lights system
Joint connector c11 (behind right end of dash)
Left front door speaker
Left rear speaker
Left tweeter
Meter fuse 10a
Mirror fuse 7.5a
Nca
Pnk
Red
Right front door speaker
Right rear speaker
Right tweeter

Электросхема навигации GPS (2 из 2) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема навигации GPS (2 из 2) для Mazda 5 Touring 2010 - Список элементов:

(behind center of dash) joint connector c12
0922-202 g
0922-203
0940-01a
0940-01d
A/t
Audio control switch
Backup light switch (on transaxle)
Bcm (behind right side of dash)
Clock spring (in steering column)
Computer data lines system
Exterior lights system
G4 (behind left end of dash)
Hands-free telephone unit (if equipped)
Instrument cluster system
J/c g04
Joint connector c11 (behind right end of dash)
M/t
Microphone (behind right center of dash)
Mode
Mute
Nca
Preset +
Preset -
R position
Red
Transaxle range switch (on transaxle)
Transmissions system
Vol +
Vol -
W/ handsfree telephone unit
W/o handsfree telephone unit

Подогрев стекол и зеркал

Электросхема подогрева стекол и зеркал для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема подогрева стекол и зеркал для Mazda 5 Touring 2010 - Список элементов:

0940-01a
0940-01c
A/c fuse 10a
A/c relay (in main fuse block)
Bcm (behind right side of dash)
Blower relay (w/o rear vent) front blower relay 1 (w/ rear vent) (in main fuse block)
Condenser (defrost) (left rear of luggage compt)
Defog fuse 25a
Filament
Front blower relay 2 (w/ rear vent) (in main fuse block)
Fuse block (behind right end of dash)
G10 (under driver's seat)
G11 (under front passenger's seat)
G12 (at left "d" pillar)
Heating element
Hot at all times
Hot in on
J/c c-12 (behind center of dash)
Left power outer mirror (if equipped) (on left front door)
M def fuse 7.5a
Main fuse block (left side of engine compt)
Nca
Rear blower relay (w/ rear vent) (in main fuse block)
Rear window defroster relay (in main fuse block)
Right power outer mirror (if equipped) (on right front door)
W/ rear vent
W/o rear vent

ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG

Электросхема подушек безопасности SRS AirBag (1 из 2) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема подушек безопасности SRS AirBag (1 из 2) для Mazda 5 Touring 2010 - Список элементов:

(at front of engine compt) crash zone sensor
(behind left side of dash) g7
0810-01a
0810-01b
0810-01c
0810-20a
0810-20b
0810-20c
2aa
Bcm (behind right side of dash)
Computer data lines system
Driver side pretensioner seat belt (base of left "b" pillar)
Fuse block (behind right end of dash)
G11 (under front passenger's seat)
Hot in run or start
Inflator
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
Left buckle switch
Left seat weight sensor (in front
Meter fuse 10a
Nca
Passenger air bag deactivation (pad) indicator
Passenger side pretensioner seat belt (base of right "b" pillar)
Passenger's seat cushion)
Pnk
Red
Right buckle switch
Right seat weight sensor (in front passenger's seat cushion)
Sas control module (below center console)
Sas fuse 10a
Seat track position sensor (under driver's seat)
Seat weight sensor control module (under front passenger's seat)
Short bar

Электросхема подушек безопасности SRS AirBag (2 из 2) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема подушек безопасности SRS AirBag (2 из 2) для Mazda 5 Touring 2010 - Список элементов:

(rear of engine) g14
0922-101a
0922-101b
Air bag ind
Clock spring (in steering column)
Driver side air bag module (center of steering wheel)
Driver side curtain air bag module (in left "d" pillar)
Driver side side air bag module
Driver side side air bag sensor 1 (at base of left "b" pillar)
Driver side side air bag sensor 2 (at base of left "c" pillar)
Inflator
Inflator 1
Inflator 2
Instrument cluster
Microcomputer
Nca
Passenger side air bag module (behind right side of dash)
Passenger side curtain air bag module (in right "d" pillar)
Passenger side side air bag module
Passenger side side air bag sensor 1 (at base of right "b" pillar)
Passenger side side air bag sensor 2 (at base of right "c" pillar)
Red
Seat belts ind
Short bar

ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ

Электросхема предупреждающей системы для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема предупреждающей системы для Mazda 5 Touring 2010 - Список элементов:

0810-01b
0810-01c
0940-01b
0940-01c
0940-01d
0940-01e
3ab
3ad
Bcm (behind right side of dash)
Buzzer
Computer data lines system
Door ind
Fuse block (behind right end of dash)
G10 (under driver's seat)
G14 (rear of engine)
Hot at all times
Hot in on or start
Instrument cluster
J/c c-11 (behind right end of dash)
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
Key reminder switch (integral to ignition switch)
Keyless receiver (behind right side of dash)
Left buckle switch
Left front door key cylinder switch/ door lock-link switch/ door latch switch (in driver's door)
Main fuse block (left side of engine compt)
Meter fuse 10a
Microcomputer
Nca
Red
Room fuse 15a
Sas control module (below center console)
Seat belts ind
Tpms control unit
Tpms ind

ПРИБОРНАЯ ПАНЕЛЬ

Электросхема панели приборов для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема панели приборов для Mazda 5 Touring 2010 - Список элементов:

(behind left end of dash) g4
(behind left headlight) g1
(lower left side of engine) oil pressure switch
(rear of engine) g14
(under driver's seat) g10
0920-301a
0922-101a
0922-101b
0940-01a
0940-01b
0940-01d
0940-01e
1-5
4wd abs ind
Air bag ind
Anti-theft system
At ind
Bcm (behind right side of dash)
Brake fluid level sensor (in brake fluid reservoir)
Brake ind
Brake switch 2 (at top of brake pedal assembly)
Buzzer
Car-navigation unit (w/ navigation) (behind right side of dash)
Charge ind
Check engine ind
Computer data lines system
Cruise (amber) ind
Cruise (green) ind
Door ind
Door locks system
Drive circuit selector indicator
Eps ind
Fuel gauge
Fuel gauge sender unit (on fuel tank)
Fuel low ind
Fuse block (behind right end of dash)
G10 (under driver's seat)
G11 (under front passenger's seat)
Hi beam ind
Hot at all times
Hot in on or start
Illum ind
Instrument cluster
Interior lights system
J/c c-11 (behind right end of dash)
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
J/c g-04
L turn ind
Left front door latch switch (in driver's door)
Left rear slide door switch (at left rear "c" pillar)
Main fuse block (left side of engine compt)
Meter fuse 10a
Microcomputer
Navigation system
Odometer/ tripmeter
Oil ind
Panel light control
Parking brake switch (at base of parking brake lever)
R turn ind
Red
Right front door latch switch (in front passenger's door)
Right rear slide door switch (at right rear "c" pillar)
Room fuse 15a
Seat belts ind
Security ind
Speedometer
Tachometer
Tns ind
Tpms control unit
Tpms ind
Tripmeter switch
Warning systems
Washer ind
Water temperature gauge
Wiper/washer system

схема мультиинформационной системы для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

схема мультиинформационной системы для Mazda 5 Touring 2010 - Список элементов:

(behind right end of dash) j/c c-11
(behind right side of dash) bcm
0940-01b
0940-01d
Clock switch
Computer data lines system
Fuse block (behind right end of dash)
G4 (behind left end of dash)
Hot at all times
Hot in on or acc
Information display
Interior lights system
J/c g-04
Main fuse block (left side of engine compt)
Mirror fuse 7.5a
Room fuse 15a

ПРИВОД ЗЕРКАЛ

Электросхема привода зеркал для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема привода зеркал для Mazda 5 Touring 2010 - Список элементов:

0912-301a
0912-401
Defogger system
Down
Fuse block (behind right end of dash)
G10 (under driver's seat)
Heating element
Hot in acc or run
J/c c-11 (behind right end of dash)
Left
Left power outer mirror (on left front door)
Mirror fuse 7.5a
Nca
Power outer mirror switch
Right
Right power outer mirror (on right front door)

ПРИВОД ЛЮКА И КРЫШИ

Электросхема привода люка или крыши для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема привода люка или крыши для Mazda 5 Touring 2010 - Список элементов:

0940-01c
0940-01e
A/c fuse 10a
Bcm (behind right side of dash)
Close
Down
Fuse block (behind right end of dash)
G10 (under driver's seat)
Hall ic
Hot at all times
Hot in on
J/c c-12 (behind center of dash)
Main fuse block (left side of engine compartment)
Open
Regu- lator
Slide
Sunroof fuse 20a
Sunroof relay 1
Sunroof relay 2
Sunroof switch
Sunroof unit (front of roof)
Tilt

ПРИВОД СТЕКЛОПОДЪЕМНИКОВ

Электросхема стеклоподъемников для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема стеклоподъемников для Mazda 5 Touring 2010 - Список элементов:

Auto
Close
Fuse block (behind right end of dash)
G10 (under driver's seat)
Hot in run or start
Left front power window motor (in left front door)
Left rear power window motor (in left rear door)
Left rear power window sub switch
Open
Open relay
P/w cm
P/w fuse 30a
Power window main switch
Power-cut switch
Red
Right front power window motor (in right front door)
Right front power window sub switch
Right rear power window motor (in right rear door)
Right rear power window sub switch

Противоугонная система Сигнализация

Электросхема открывания авто для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема открывания авто для Mazda 5 Touring 2010 - Список элементов:

(at left "d" pillar)
(at left rear "c" pillar) left rear slide door switch
(at right rear "c" pillar) right rear slide door switch
0922-101b
0940-01a
0940-01c
0940-01e
0940-01f
2j 0940-01b
3ab
Bcm (behind right side of dash)
Computer data lines system
D lock fuse 20a
Door key cylinder switch/ door lock-link switch/ left front door latch switch/ left front door lock actuator (in driver's door)
Door lock relay
Door unlock relay
Double lock relay
Fuse block (behind right end of dash)
G10 (under driver's seat)
G11 (under front passenger's seat)
G12
G12 (at left "d" pillar)
G13 (at right "d" pillar)
G2 (behind right headlight)
G4 (behind left end of dash)
Hood latch switch (on hood latch assembly)
Horns system
Hot at all times
Hot in on or start
Instrument cluster
J/c c-12 (behind center of dash)
J/c-g04
Keyless receiver (behind right side of dash)
Left door lock switch
Left rear door lock-link switch
Left sliding door lock actuator (in left sliding door)
Liftgate latch switch (on liftgate latch)
Liftgate lock actuator (in liftgate)
Lock
Main fuse block (left side of engine compt)
Meter fuse 10a
Nca
Reset
Right door lock switch
Right front door latch switch/ right front door lock actuator (in front passenger's door)
Right rear door lock-link switch
Right sliding door lock actuator (in right sliding door)
Set
Un- lock
Unlock

Электросхема иммобилайзера для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема иммобилайзера для Mazda 5 Touring 2010 - Список элементов:

0922-101a
0922-101b
0940-01b
0940-01d
Bcm (behind right side of dash)
Coil (on ignition key cylinder)
Fuse block (behind right end of dash)
G14 (rear of engine)
Hot at all times
Hot in on or start
Instrument cluster
J/c c-11 (behind right end of dash)
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
Main fuse block (left side of engine compt)
Meter fuse 10a
Microcomputer
Room fuse 15a
Security ind

СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS

Электросхема антиблокировочной тормозной системы АБС (ABS), С Динамическое Управление Стабильностью для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема антиблокировочной тормозной системы АБС (ABS), С Динамическое Управление Стабильностью для Mazda 5 Touring 2010 - Список элементов:

(left front of engine compt) g3
(on left front wheel assembly)
(rear of engine) g14
0614-01c
0922-101a
4wd abs ind
Abs p fuse 30a
Abs v fuse 20a
Abs/ dsc fuse 5a
Combined sensor (base of right "b" pillar)
Computer data lines system
Computer micro-
Dsc hydraulic unit/ control module (dsc hu/cm)
Dsc off switch
Ehpas control module (right front of engine compt)
Fuse block (behind right end of dash)
G1 (behind left headlight)
G4 (behind left end of dash)
Hot at all times
Hot in on or start
Instrument cluster
J/c c12 (behind center of dash)
J/c c31 (behind left end of dash)
J/c g04
Left front abs wheel speed sensor
Left rear abs wheel speed sensor (on left rear wheel assembly)
Main fuse block (left side of engine compt)
Meter fuse 10a
Pnk
Red
Right front abs wheel speed sensor (on right front wheel assembly)
Right rear abs wheel speed sensor (on right rear wheel assembly)
Steering angle sensor (in steering column)

Электросхема антиблокировочной тормозной системы АБС (ABS), без Динамическое Управление Стабильностью для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема антиблокировочной тормозной системы АБС (ABS), без Динамическое Управление Стабильностью для Mazda 5 Touring 2010 - Список элементов:

(behind left headlight) g1
(on left front wheel assembly)
0922-101a
4wd abs ind
Abs hydraulic unit/control module (left rear corner of engine compt)
Abs p fuse 30a
Abs v fuse 20a
Abs/dsc fuse 5a
Computer data lines system
Computer micro-
Fuse block (behind right end of dash)
G14 (rear of engine)
Hot at all times
Hot in on or start
Instrument cluster
J/c c12 (behind center of dash)
J/c c31 (behind left end of dash)
Left front abs wheel speed sensor
Left rear abs wheel speed sensor (on left rear wheel assembly)
Main fuse block (left side of engine compt)
Meter fuse 10a
Red
Right front abs wheel speed sensor (on right front wheel assembly)
Right rear abs wheel speed sensor (on right rear wheel assembly)

СИСТЕМА КОНДИЦИОНЕРА

Электросхема кондиционера для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема кондиционера для Mazda 5 Touring 2010 - Список элементов:

(behind center of dash) passenger compartment temperature sensor
0112-01a
0112-01b
0140-101a
0140-101b
0940-01a
0940-01d
1aw
1ax
2ah
2av
A/c fuse 10a
A/c relay
Air intake actuator (behind right side of dash)
Air mix actuator (behind right center of dash)
Airflow mode actuator (behind left center of dash)
Ambient temperature sensor (behind center of grille)
Bcm (behind right side of dash)
Blower fuse 40a
Blower relay (in main fuse block)
Climate control unit (lower center of dash)
Cold
Computer data lines system
Cooling fan motor
Cooling fan relay
Def
Defogger system
Eng fuse 5a
Engine coolant temperature sensor (top rear of engine)
Evaporator temperature sensor (under center of dash)
Fan control module (left front of engine compt)
Fan fuse 30a
Front blower motor (behind center of dash)
Front power metal oxide semiconductor field effect transistor (power mos fet) (behind center of dash)
Fuse block (behind right end of dash)
G1 (behind left headlight)
G4 (behind left end of dash)
G6 (behind right end of dash)
High & low pressure
Hot
Hot at all times
Hot in run
Hot in run or start
Interior lights system
J/c c-11 (behind right end of dash)
J/c c-12 (behind center of dash)
Jc-g04
Jc-g06
Mag fuse 10a
Magnetic clutch (on a/c compressor)
Main fuse block (left side of engine compt)
Medium pressure
Nca
Pcm (powertrain control module) (rear of engine compt)
Red
Refrigerant pressure switch (right rear of engine compt)
Solar radiation sensor (under top center of dash)
Vent

Электросхема кондиционера Задний контур для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема кондиционера Задний контур для Mazda 5 Touring 2010 - Список элементов:

0140-101a
0940-01a
A/c fuse 10a
A/c relay
Automatic a/c circuit
Bcm (behind right side of dash)
Climate control unit (lower center of dash)
Defogger system
Front blower fuse 20a
Front blower motor (behind center of dash)
Front blower relay 1
Front blower relay 2
Fuse block (behind right end of dash)
G1 (behind left headlight)
G4 (behind left end of dash)
Hot at all times
Hot in run
Interior lights system
J/c c-12 (behind center of dash)
Jc-g04
Mag fuse 10a
Magnetic clutch (on a/c compressor)
Main fuse block (left side of engine compt)
Nca
Off
Pcm (rear of engine compt)
Rear blower fuse 30a
Rear blower motor (center console)
Rear blower relay (in main fuse block)
Rear fan switch
Rear power metal oxide semiconductor field effect transistor (power mos fet)
Rear vent actuator (lower left side of dash)
Red

СИСТЕМА КРУИЗКОНТРОЛЯ

Электросхема системы круизконтроля для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема системы круизконтроля для Mazda 5 Touring 2010 - Список элементов:

(amber) cruise ind
(green) cruise ind
(rear of engine) g14
0140-101a
0140-101b
0922-101a
0922-101b
0922-202
0922-203
1ai
1al
1am
1ao
1ap
1aq
1av
1bc
1bd
2ak
2al
2ao
2ap
2be
2bf
Accelerator pedal position sensor (top of accelerator pedal assembly)
Brake switch 2 (at top of brake pedal assembly)
Cancel switch
Clock spring (in steering column)
Clutch pedal position switch (m/t) (top of clutch pedal assembly)
Computer data lines system
Cruise control main switch
Cruise control switch
Eng bar 2 fuse 15a
Fuse block (behind right end of dash)
G10 (under driver's seat)
G14 (rear of engine)
Hot in run or start
Hot w/ main relay energized
Instrument cluster
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
J/c c-34
Main fuse block (left side of engine compt)
Meter fuse 10a
Microcomputer
Nca
Neutral switch (m/t) (on transaxle)
Pcm (rear of engine compt)
Red
Resume/accel switch
Set/coast switch
Tcm (left rear corner of engine compt)
Throttle body (integral to throttle body)
Vehicle speed sensor (a/t) (on transaxle)

СИСТЕМА ОХЛАЖДЕНИЯ

Электросхема системы охлаждения для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема системы охлаждения для Mazda 5 Touring 2010 - Список элементов:

0112-01a
0112-01b
0140-101a
0140-101b
2ah
2av
Cooling fan motor
Cooling fan relay
Eng fuse 5a
Engine coolant temperature sensor (top rear of engine)
Fan control module (left front of engine compt)
Fan fuse 30a
Fuse block (behind right end of dash)
G1 (behind left headlight)
Hot at all times
Hot in run or start
Main fuse block (left side of engine compt)
Nca
Pcm (rear of engine compt)
Red

СИСТЕМА ПЕРЕДАЧИ ДАННЫХ

Электросхема линии передачи данных CAN для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема линии передачи данных CAN для Mazda 5 Touring 2010 - Список элементов:

(behind left end j/c g-04
(behind right side of dash) (if equipped) car navigation unit
(behind right side of dash) keyless receiver
(left side of dash) j/c c-44
0614-01b
0940-01b
0940-01c
0940-01d
1ai
1am
Abs hydraulic unit/control module (if equipped) (left rear corner of engine compt)
Audio unit (w/o car- navigation system)
Automatic a/c
Bcm (behind right side of dash)
Climate control unit (lower center of dash)
Data link connector 2 (under lower left end of dash)
Dsc hydraulic/ control module (if equipped)
Ehpas control module (right front of engine compt)
G14 (rear of engine)
Hands-free telephone unit (if equipped)
Hot at all times
Ignition key illumination
Information display
Instrument cluster
J/c c-11 (behind right end of dash)
J/c c-12 (behind center of dash)
J/c c-13 (behind upper left side of dash)
J/c c-31 (behind left end of dash)
J/c c-38 (behind left end of dash)
Key interlock solenoid (in steering column)
Key reminder switch (integral to ignition switch)
Main fuse block (left side of engine compt)
Manual a/c
Of dash) g4
Pcm (rear of engine compt)
Pnk
Red
Room fuse 15a
Sas control module (below center console)
Tcm (a/t) (left rear corner of engine compt)

СИСТЕМА УПРАВЛЕНИЯ ДВИГАТЕЛЯ

2.3L

2.3L, Электросхема системы управления двигателем (1 из 4) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

2.3L, Электросхема системы управления двигателем (1 из 4) для Mazda 5 Touring 2010 - Список элементов:

(at top of brake pedal assembly) brake switch 1
0140-101a
1aa
1ab
1ac
1ad
1ae
1af
1ag
1ah
1ai
1aj
1ak
1al
1am
1an
1ao
1ap
1aq
1ar
1as
1at
1au
1av
1aw
1ax
1ay
1az
1ba
1bb
1bc
1bd
1be
1bf
1bg
1bh
Air conditioning system
Clutch pedal position switch (m/t) (top of clutch pedal assembly)
Computer data lines system
Cruise control system
Exterior lights system
G10 (under driver's seat)
G14 (rear of engine)
Hot at all times
Main fuse block (left side of engine compt)
Nca
Neutral switch (m/t) (on transaxle)
Pnk
Powertrain control module (rear of engine compt)
Red
Starting/charging system
Stop fuse 10a

2.3L, Электросхема системы управления двигателем (2 из 4) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

2.3L, Электросхема системы управления двигателем (2 из 4) для Mazda 5 Touring 2010 - Список элементов:

(at right "d" pillar) g13
(rear of engine) g14
0922-101a
0922-101b
Accelerator pedal position sensor (top of accelerator pedal assembly)
Check engine ind
Computer data lines system
Drive-by-wire relay (etc relay)
Eng b + fuse 10a
Eng ba fuse 20a
Eng bar 2 fuse 15a
Eng bar fuse 15a
Etc fuse 10a
Evap system leak detection pump (under rear of vehicle)
Fuel fuse 20a
G14 (rear of engine)
Hot at all times
Instrument cluster
Joint connector c-34
Main fuse block (left side of engine compt)
Main relay (egi main relay)
Mass air flow/ intake air temperature sensor (rear of engine)
Micro- computer
Pnk
Red

2.3L, Электросхема системы управления двигателем (3 из 4) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

2.3L, Электросхема системы управления двигателем (3 из 4) для Mazda 5 Touring 2010 - Список элементов:

(rear of engine) g14
(top right side of engine)
Camshaft position sensor (rear of engine)
Condenser (right rear of engine)
Crankshaft position sensor (above a/c compressor)
Eng 2 fuse 15a
Eng 3 fuse 20a
Eng fuse 5a
Fuel gauge sender unit
Fuel pump
Fuel pump relay
Fuel pump unit (on fuel tank)
Fuse block (behind right end of dash)
G11 (under front passenger's seat)
G5 (left rear of engine)
Hall ic
Hot in on or start
Igniter
Ignition coil 1
Ignition coil 2
Ignition coil 3
Ignition coil 4
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
Main fuse block (left side of engine compt)
Meter fuse 10a

2.3L, Электросхема системы управления двигателем (4 из 4) для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

2.3L, Электросхема системы управления двигателем (4 из 4) для Mazda 5 Touring 2010 - Список элементов:

(behind drive belt auto tensioner) knock sensor
(front of engine) oil control valve
(left side of engine) variable intake air solenoid valve
(left side of engine) variable tumble solenoid valve
(or red)
(rear of engine compt) purge solenoid valve
(top rear of engine) engine coolant temperature sensor
0140-101b
2aa
2ab
2ac
2ad
2ae
2af
2ag
2ah
2ai
2aj
2ak
2al
2am
2an
2ao
2ap
2aq
2ar
2as
2at
2au
2av
2aw
2ax
2ay
2az
2ba
2bb
2bc
2bd
2be
2bf
2bg
2bh
A/f sensor
Egr valve (top rear of engine)
Fuel injectors (top left side of engine)
Ho2s
Manifold absolute pressure sensor (front of engine compt)
Nca
Pnk
Powertrain control module
Red
Starting/ charging system
Throttle body (integral to throttle body)
Variable tumble shutter valve switch (left rear of engine)
W/ pcm 2ae terminal
W/ pcm 2as terminal
W/ pcm 2bg terminal
W/o pcm 2ae terminal
W/o pcm 2as terminal
W/o pcm 2bg terminal

СИСТЕМА УСИЛИТЕЛЯ РУЛЯ

Электросхема усилителя руля для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема усилителя руля для Mazda 5 Touring 2010 - Список элементов:

(right front of engine compt) g16
0415-01
0614-01a
0614-01b
0614-01c
0922-101a
Abs/ dsc fuse 5a
Combined sensor (base of right "b" pillar)
Computer data lines system
Dsc hydraulic unit/control module (dsc hu/cm)
Ehpas control module (right front of engine compt)
Ehpas fuse 5a
Ehpas fuse 80a
Eps ind
Fuse block (behind right end of dash)
G14 (rear of engine)
Hot at all times
Hot in on or start
Instrument cluster
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
Main fuse block (left side of engine compt)
Meter fuse 10a
Micro computer
Pnk
Red
Steering angle sensor (in steering column)
W/ dsc
W/o dsc

Система Фар

Электросхема фар для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема фар для Mazda 5 Touring 2010 - Список элементов:

(rear of engine) g14
0922-101a
0940-01a
0940-01b
0940-01c
0940-01d
0940-01e
Auto
Bcm (behind right side of dash)
Computer data lines system
Computer micro
Discharge type
Flash- to- pass
Fog fuse 15a
Front fog light relay (in main fuse block)
Front fog light switch
Fuse block (behind right end of dash)
G1 (behind left headlight)
G2 (behind right headlight)
G4 (behind left end of dash)
Halogen type
Head
Head high l fuse 10a
Head high r fuse 10a
Head low l fuse 15a
Head low r fuse 15a
Headlight high relay
Headlight low relay
Headlight switch
Hi-beam ind
Hot at all times
Hot in on or start
Instrument cluster
Instrument cluster system
Interior lights system
J/c-12 (behind center of dash)
J/c-31 (behind left end of dash)
Jc-g04
Left discharge headlight control module
Left front fog light
Left high headlight
Left low head- light
Left low headlight
Main fuse block (left side of engine compt)
Meter fuse 10a
Off
Parking brake switch (at base of parking brake lever)
Red
Right discharge headlight control module
Right front fog light
Right high headlight
Right low headlight
Tns
W/ autolamps
W/ drl
W/o drl

СИСТЕМЫ СИДЕНИЙ

Электросхема привода сидений для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема привода сидений для Mazda 5 Touring 2010 - Список элементов:

Fuse block (behind right end of dash)
G10 (under driver's seat)
G11 (under front passenger's seat)
Hot in run
Interior lights system
Left seat warmer switch
Left seat warmer unit
Nca
Right seat warmer switch
Right seat warmer unit
S warm fuse 15a

Стартер Генератор

Электросхема Генератора для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема Генератора для Mazda 5 Touring 2010 - Список элементов:

0140-101a
0140-101b
0922-101a
1ai
1am
250a
2aa
2af
Acc
Battery
Charge
Computer data lines system
Fuse block (behind right end of dash)
G14 (rear of engine)
Generator
Ig key 1 fuse 40a
Ig1
Ignition switch
Indicator
Instrument cluster
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
Main fuse
Main fuse block (left side of engine compartment)
Meter fuse 10a
Microcomputer
Nca
Off
Pcm (rear of engine compartment)
Red
Start
Starting circuit

Электросхема стартера для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема стартера для Mazda 5 Touring 2010 - Список элементов:

0140-101a
1bb
250a
A/t
Acc
Battery
Charging circuit
Ig key 2 fuse 40a
Ignition switch
M/t
Main fuse
Main fuse block (left side of engine compartment)
Nca
Off
Pcm (rear of engine compartment)
Start
Starter
Starter interlock switch (under left side of dash)
Starter relay
Transaxle range switch (on transaxle)

Стеклоочистители и Стеклоомыватели Дворники

Электросхема передних стеклоочистителей дворников и омывателя лобового стекла для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема передних стеклоочистителей дворников и омывателя лобового стекла для Mazda 5 Touring 2010 - Список элементов:

(behind right side of dash) bcm
(w/o auto wiper) int (w/ auto wiper) auto
0940-01c
0940-01d
1g 0922-101a
1m 0922-101a
2i 0940-01b
3a 0940-01c
5t 0940-01e
Autostop switch
Circuit breaker
Computer data lines system
F wip fuse 25a
Fuse block (behind right end of dash)
G1 (behind left headlight)
G3 (left front of engine compt)
G4 (behind left end of dash)
G6 (behind right end of dash)
Hot in on
Hot in on or start
Instrument cluster
J/c c-12 (behind center of dash)
J/c c-31 (behind left end of dash)
J/c-g04
J/c-g06
Meter fuse 10a
Micro- computer
Mist
Nca
Off
Rain sensor (w/ auto wiper) (top center of windshield)
W/ auto wiper
W/o auto wiper
Washer fluid level sensor (right front corner of engine compt, in washer fluid reservoir)
Washer ind
Washer switch
Windshield washer motor (right front corner of engine compt, in washer fluid reservoir)
Windshield wiper & washer switch
Windshield wiper high relay
Windshield wiper motor (center rear of engine compt)
Windshield wiper relay

Электросхема заднего стеклоочистителя дворника и омывателя для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема заднего стеклоочистителя дворника и омывателя для Mazda 5 Touring 2010 - Список элементов:

2h 0940-01b
3aa 0940-01c
6g 0940-01f
Auto- stop switch
Bcm (behind right side of dash)
Fuse block (behind right end of dash)
G12 (at left "d" pillar)
G4 (behind left end of dash)
Hot in on
Int
Jc-g04
Off
R wash
R wip fuse 15a
Rear washer motor (right front of engine compt, in washer reservoir)
Rear wiper & washer switch
Rear wiper motor (in center of liftgate)

ЦЕНТРАЛЬНЫЙ ЗАМОК

Электросхема центрального замка для Mazda 5 Touring 2010

Get access to all wiring diagrams of the car

Электросхема центрального замка для Mazda 5 Touring 2010 - Список элементов:

(at left "d" pillar)
(at left rear "c" pillar) left rear slide door switch
(at right rear "c" pillar) right rear slide door switch
0922-101b
0940-01a
0940-01c
0940-01e
0940-01f
2j 0940-01b
3ab
Bcm (behind right side of dash)
Computer data lines system
D lock fuse 20a
Door key cylinder switch/ door lock-link switch/ left front door latch switch/ left front door lock actuator (in driver's door)
Door lock relay
Door unlock relay
Double lock relay
Fuse block (behind right end of dash)
G10 (under driver's seat)
G11 (under front passenger's seat)
G12
G12 (at left "d" pillar)
G13 (at right "d" pillar)
G2 (behind right headlight)
G4 (behind left end of dash)
Hood latch switch (on hood latch assembly)
Horns system
Hot at all times
Hot in on or start
Instrument cluster
J/c c-12 (behind center of dash)
J/c-g04
Keyless receiver (behind right side of dash)
Left door lock switch
Left rear door lock-link switch
Left sliding door lock actuator (in left sliding door)
Liftgate latch switch (on liftgate latch)
Liftgate lock actuator (in liftgate)
Lock
Main fuse block (left side of engine compt)
Meter fuse 10a
Nca
Reset
Right door lock switch
Right front door latch switch/ right front door lock actuator (in front passenger's door)
Right rear door lock-link switch
Right sliding door lock actuator (in right sliding door)
Set
Un- lock
Unlock
