| D | Ignition/starter switch |
| E38 | Intermittent wipe regulator |
| F4 | Reversing light switch |
| G213 | Rain sensor |
| J31 | Automatic intermittent wash and wipe relay, on relay plate |
| S5 | Fuse 5 in fuse holder |
| T4 | 4-pin connector, near front interior light |
| T6 | 6-pin connector, near front interior light |
| T6a | 6-pin connector, near front interior light |
| T6e | 6-pin connector |
| T10 | 10-pin connector, orange, in protective housing for connectors on left in plenum chamber |
| T18a | 18-pin connector |
| Y7 | Automatic anti-dazzle interior mirror |
| 81 | Earth connection 1, in dash panel wiring harness |
| 135 | Earth connection 2, in dash panel wiring harness |
| 303 | Earth connection rain sensor/mirror, in interior wiring harness |
| A2 | Positive connection (15), in dash panel wiring harness |
| A20 | Connection (15a), in dash panel wiring harness |
| A87 | Connection (RL), in dash panel wiring harness |
| E22 | Intermittent wiper switch |
| J31 | Automatic intermittent wash and wipe relay, on relay plate |
| J... | Engine control units |
| S224 | Fuse 24 in fuse holder |
| S227 | Fuse 27 in fuse holder |
| T5c | 5-pin connector, on wiper motor |
| T8c | 8-pin connector |
| T10 | 10-pin connector, orange, in protective housing for connectors on left in plenum chamber |
| T18a | 18-pin connector |
| V | Windscreen wiper motor |
| 42 | Earth point, on steering column |
| 81 | Earth connection 1, in dash panel wiring harness |
| 179 | Earth connection, in left headlight wiring harness |
| 199 | Earth connection 3, in dash panel wiring harness |
| 503 | Screw connection (75x), on relay plate |
| A27 | Connection (speed signal), in dash panel wiring harness |
| A96 | Connection (53a), in dash panel wiring harness |
| A97 | Connection (53), in dash panel wiring harness |
| A102 | Connection (windscreen wiper), in dash panel wiring harness |
| *** | From May 1998 |
| -●●- | To April 1998 |
| T5a | 5-pin connector, pink, left C-pillar coupling station |
| T5h | 5-pin connector, near lower part of left A-pillar, wound into wiring harness |
| T5i | 5-pin connector, near lower part of left A-pillar, wound into wiring harness |
| V12 | Rear window wiper motor |
| V59 | Windscreen and rear window washer pump |
| 50 | Earth point, on left in luggage compartment |
| 86 | Earth connection 1, in rear wiring harness |
| 98 | Earth connection, in rear lid wiring harness |
| A97 | Connection (53), in dash panel wiring harness |
| A102 | Connection (windscreen wiper), in dash panel wiring harness |
