| R | Radio |
| R20 | Treble loudspeaker, front left, in door |
| R21 | Bass loudspeaker, front left, in door |
| R41 | CD changer, rear left in luggage compartment |
| T8a | 8-pin connector |
| T10i | 10-pin connector, black, left A pillar coupling station |
| T12 | 12-pin connector |
| T20 | 20-pin connector |
| 45 | Earth point, behind dash panel - centre |
| 255 | Earth connection -1-, in radio wiring harness |
| V14 | Connection (screening), in CD changer wiring harness |
| *** | Not with radio 'alpha' |
| R | Radio |
| R14 | Treble loudspeaker, rear left, in door |
| R15 | Bass loudspeaker, rear left, in door |
| R16 | Treble loudspeaker, rear right, in door |
| R17 | Bass loudspeaker, rear right, in door |
| R22 | Treble loudspeaker, front right, in door |
| R23 | Bass loudspeaker, front right, in door |
| T8a | 8-pin connector |
| T10k | 10-pin connector, black, right A pillar coupling station |
| T10l | 10-pin connector, black, left B pillar coupling station |
| T10m | 10-pin connector, black, right B pillar coupling station |
| * | Not on radios 'alpha' and 'beta' |
| ** | Not with 2-door vehicle |
| D | Ignition/starter switch |
| E20 | Switches and instruments - lighting control |
| J285 | Control unit with display in dash panel insert |
| R11 | Aerial |
| R24 | Aerial amplifier |
| S12 | Fuse in relay plate fuse box |
| S237 | Fuse in fuse holder |
| S242 | Fuse in fuse holder |
| T1 | Single connector, near roof aerial |
| T6c | 6-pin connector |
| T8 | 8-pin connector |
| T16 | 16-pin connector, in centre of dash panel, self-diagnosis connection |
| T32 | 32-pin connector, blue |
| T32a | 32-pin connector, green |
| 255 | Earth connection -1-, in radio wiring harness |
| 501 | Screw connection -2- (30), on relay plate |
| A4 | Positive (+) connection (58b), in dash panel wiring harness |
| A21 | Connection (86s), in dash panel wiring harness |
| A23 | Connection (30a), in dash panel wiring harness |
| A76 | Connection (diagnosis wire K), in dash panel wiring harness |
| B111 | Positive connection -1- (30a), in interior wiring harness |
