| D | Ignition/starter switch |
| J104 | ABS control unit with EDL/TCS/ESP, on left in engine compartment |
| J217 | Automatic gearbox control unit, centre in plenum chamber |
| J492 | All-wheel drive control unit, near rear final drive |
| J... | Engine control units |
| S51 | Fuse, on additional relay carrier above relay plate |
| T8 | 8-pin connector |
| T10d | 10-pin connector, green, in protective housing for connectors on left in plenum chamber |
| T25 | 25-pin connector |
| T47 | 47-pin connector |
| T68 | 68-pin connector |
| V181 | Haldex coupling pump |
| 50 | Earth point, on left in luggage compartment |
| 86 | Earth connection 1, in rear wiring harness |
| A80 | Connection 1 (X), in dash panel wiring harness |
| A121 | Connection (high bus), in dash panel wiring harness |
| A122 | Connection (low bus), in dash panel wiring harness |
| * | Only models with automatic gearbox |
| D | Ignition/starter switch |
| F | Brake light switch |
| F1 | Oil pressure switch |
| G | Fuel gauge sender |
| G6 | Fuel pump |
| G169 | Fuel gauge sender 2 |
| G271 | Hydraulics temperature sender |
| J17 | Fuel pump relay, above central electrics |
| J492 | All-wheel drive control unit, near rear final drive |
| M21 | Left brake and tail light bulb |
| S228 | Fuse 28 in fuse holder |
| T2 | 2-pin connector, on all-wheel drive |
| T8 | 8-pin connector |
| T10a | 10-pin connector, in cable channel on left in engine compartment |
| V184 | Oil pressure control motor |
| 135 | Earth connection 2, in dash panel wiring harness |
| 269 | Earth connection (sender earth) 1, in dash panel wiring harness |
| 501 | Screw connection 2 (30), on relay plate |
| A32 | Positive connection (30), in dash panel wiring harness |
| A98 | Positive connection 4 (30), in dash panel wiring harness |
| A135 | Connection (oil pressure switch), in dash panel wiring harness |
| W1 | Positive connection (54), in interior light wiring harness |
| D | Ignition/starter switch |
| F9 | Handbrake warning switch |
| G1 | Fuel gauge |
| G2 | Coolant temperature sender |
| G3 | Coolant temperature gauge |
| J285 | Control unit with display in dash panel insert |
| K14 | Handbrake warning lamp |
| S11 | Fuse 11 in fuse holder |
| T5h | 5-pin connector, near lower part of left A-pillar, wound into wiring harness |
| T10a | 10-pin connector, in cable channel on left in engine compartment |
| T16 | 16-pin connector, centre in dash panel, self-diagnosis connection |
| T32 | 32-pin connector, blue |
| T32a | 32-pin connector, green |
| 42 | Earth point, on steering column |
| 81 | Earth connection 1, in dash panel wiring harness |
| 135 | Earth connection 2, in dash panel wiring harness |
| A2 | Positive connection (15), in dash panel wiring harness |
| A76 | Connection (K-diagnosis wire), in dash panel wiring harness |
| A115 | Connection (handbrake warning), in dash panel wiring harness |
| B165 | Positive connection 2 (15), in interior wiring harness |
