Wiring Diagram VW BORA 1999 - Motronic control unit - clutch pedal switch - brake light switch - brake pedal switch for CCS
| D | Ignition/starter switch |
| F | Brake light switch |
| F36 | Clutch pedal switch |
| F47 | Cruise control system brake pedal switch |
| J59 | X-contact relief relay |
| J220 | Motronic control unit, centre in plenum chamber |
| S5 | Fuse 5 in fuse holder |
| S13 | Fuse 13 in fuse holder |
| S176 | Fuse 4 (30), on battery fuse holder |
| T10d | 10-pin connector, green, in protective housing for connectors on left in plenum chamber |
| T10e | 10-pin connector, black, in protective housing for connectors on left in plenum chamber |
| T80 | 80-pin connector |
| 500 | Screw connection 1 (30), on relay plate |
| 501 | Screw connection 2 (30), on relay plate |
| A2 | Positive connection (15), in dash panel wiring harness |
| A18 | Connection (54), in dash panel wiring harness |
| A20 | Connection (15a), in dash panel wiring harness |
| * | Only models with manual gearbox |
| --- | Only models with automatic gearbox |
Wiring Diagram VW BORA 1999 - Motronic control unit - cruise control system (CCS) switch - throttle valve module
| E45 | Cruise control system switch |
| E227 | Cruise control system (CCS) SET button |
| F60 | Idling speed switch |
| G40 | Hall sender |
| G69 | Throttle valve potentiometer |
| G88 | Throttle valve module potentiometer |
| J220 | Motronic control unit, centre in plenum chamber |
| J338 | Throttle valve module |
| T8 | 8-pin connector |
| T10e | 10-pin connector, black, in protective housing for connectors on left in plenum chamber |
| T10s | 10-pin connector, next to steering column |
| T80 | 80-pin connector |
| V60 | Throttle valve module |
| 220 | Earth connection (sender earth), in engine wiring harness |
| D101 | Connection 1, in engine wiring harness |
